Used other metal processing machinery for sale (532)

Year of construction: 2009, condition: excellent (used), functionality: fully functional, QUINTAX (USA) Q5H 5-AXIS HEAVY DUTY PRECISION CNC ROUTER WITH (2) 6' X 10' TABLES CNC FAGOR 8070 2 Tables Dim : 1830 mm x 3040 mm each 72" x 120" Travels X = 4400 mm (longt) 173.2" Y = 3800 mm (cross) 149.6" Z = 1500 mm (vertical) ( Limitation under the cross rail ) 59.1" C = +/- 360" Fedpfx Afsyf Nugjnefu B = +/- 120" Spindle speeds maxi 21.000 t/min Tool attachment : HSK63F Toolchanger : 20 station Coolant installation Double 72" (1.83 M) X 120" (3.04 M) Tables with 37 mm Steel Top Plates. 1.5 M Z-Axis Height. ..59.1" 30 kw. 40HP HSK 63F Tool Change Style Spindle, Liquid Cooled, Air Clamping including Chiller Package. Central Lube System with Low-Level Switch. AC Variable Speed Inverter Drive for Spindle. Hand-held Teach Pendant. Fagor 8070 5-Axis CNC Control includes 512 MB RAM, 40 GB Hard Drive, 11" Color Monitor, Ethernet Port; Telediagnostics; CD Drive/USB Port. Fagor AC Digital Servo Package with Absolute Encoding. 20-Station Automatic Rotary Carousel Tool Changer. 63 x 40 mm Ball Screws and Ball Nuts. 45 mm Rails and Linear Bearings. 12" x 16" Tube Construction Plus Polymer Composite Filled Bridge Tube Supports and Base. Dust Collection Nozzle, Hoses for 5-Axis. Catia 5 Postprocessor. Renishaw Toolsetting Probe. Fagor Linear Scales on X, Y, U, V, Axis and Rotary Feedback on B and C Axis. Continuous C- Axis. Renishaw MP-10 Optical Probe and Software. 15 KW 20 HP Rated 170 M/3 Minute at 254 mm Water Gauge. Includes Hoses and Controls Perimeter Light Curtain System. additional spare new spindle included

Year of construction: 2008, operating hours: 1 h, condition: used, functionality: fully functional, machine/vehicle number: STCOS M5, Burr Oak Single Tube Cut-Off System Model: STCOS M5 Year:2007 Specifications Machine Code: LHM, SWS, 36HF, SCO, SPA, 12ROHG, ECTG Cut-Off - Tcd Standard Hitch Feed - Tcd Standard Straightener – Tcd Fedjv Nak Ajpfx Afnjfu Standard W/ Sizing Pull-Apart – Tcd Standard Coil Stand – Tcd 3 Position Over Head Uncoiler Runout Table - Tcd 12’ Runout Table W/ Hinge Gate Supply: 480 Volts, 3 Phase, 60 Hertz Control: 110/24 Volts Extra Options The Hinge Gate Run Out Table Needs To Be Able To Switch From One Side To The Other Tooling – Tcd .500” O.D. Complete Set With 14 Straightening Rolls, 4 Sizing Rolls 6 Pair Clamp Jaws (Total), 1 Exit Guide Tube, (3) Tube Entry Bullets And Connectors .375” O.D. Complete Set With 14 Straightening Rolls, 4 Sizing Rolls 6 Pair Clamp Jaws (Total), 1 Exit Guide Tube, (3) Tube Entry Bullets And Connectors

Year of construction: 1983, condition: used, machine/vehicle number: 3604.1, Clamping surface for workpiece device: 230 x 500 mm Ffjdocxb Nmjpfx Afnju Installation height between table and punch holder adjustable: 160 - 400 mm Projection to the center of the punch: 130 mm Stamp working stroke: 40 - 250 mm Punch pressing force max .: 40 kN Stamp speed: 7.5 m / min max.working stroke: 2300 / h electr. Connection: 380 V, 1 kW Weight approx .: 620 kg Required space: 1030 x 850 x 2060 mm

Year of construction: 2009, condition: ready for operation (used), overall weight: 3,000 kg, spindle speed (max.): 32,000 rpm, This MIKRON Multistar CX-24/500R was manufactured in 2009. It features a high production capacity with up to 280 pcs/min in multiple cycles and a main motor power of 2.2 kW. The machine accommodates a maximum workpiece diameter of 24 mm with swivel clamp and operates efficiently with a spindle rotation speed up to 32,000 rpm. Ideal for high-volume production environments. Contact us for more information about this machine. Additional equipment • Environmental conditions: +10 °C to +40 °C, max. humidity 50% at 40 °C, 90% at 20 °C, max. altitude 1000 m a.s.l. • Machine lifetime: 20 years Ffsdpfx Asx D Rqlofnsu Machine Benefits Technical Machine Benefits • Max. Production: 70 pcs/min • Max. Production in multiple cycle: 280 pcs/min Extra Information Control Unit Input voltage: 400V – 3-phase – 50/60 Hz – 200 A Power consumption: ~15–30 kWA Movement Max. stroke of units: 53 mm Max. speed: 0.2 m/sec Acceleration: 1.3 m/sec² + 3 m/sec² Electrical cabinet weight: ~800–1500 kg Spindle Rotating collet rotation speed: 6000 rpm Tools Max. stroke (X): 30 mm Max. stroke (Y): 35 mm Max. stroke (Z): 40 mm Media Compressed air: 5–6 bar (max. 6 g/m humidity) Compressed air consumption: ~10–20 m³/h Oil tank capacity: ~850 litres Oil vapour emissions: below permitted limits (with electrostatic filter)

Year of construction: 1964, condition: used, Dust suction hood , mm Motor output 4,1 kW Ffjdpfx Aswizlyofnju Air consumption für ÖL m³/h Weight 250 kg Pump - Rotation speed 3000 U/p. Min. Oil - sucking off - car. Special price - without guarantee. Machine dealer with own stock of 1600 m².

Year of construction: 1991, condition: used, machine/vehicle number: 5385, comprising: Magazine loader SIEMENS, year of manufacture: 1991, serial no.: 5385, ERSA ERS 503 reflow oven, serial no. 8596-003, rated power 38 kW, PCB conveyor ALL SMT C-100LD-2-L, year of manufacture: 2016, width: approx. 100 cm, weight: 90 kg, pick-and-place machine ASM Siplace D1i, serial no.: C3052-12040561, year of manufacture: 2013, net weight: approx. 2,000 kg, with 28 feeder slots, pick-and-place machine ASM Siplace D1i, serial no.: C3052-12040560, year of manufacture: 2013, net weight: approx. 2,000 kg, with 28 feeder slots, including magazine trolley, PCB conveyor NUTEK NTM410L-350-1, year of manufacture: 2014, width adjustable, stencil printer (solder paste printer) DEK Horizon 03, serial no.: 282950, year of manufacture: 2004, de-magaziner SIEMENS, serial no.: 5385, year of manufacture: 1991, incl. accessories such as feeders and PCB magazines. Fsdjyidkuepfx Afnjfu

Condition: used, 4-axis industrial robot, handling robot, SCARA robot, handling robot, loading robot, placer STÄUBLI type TS80 + CS8C bmn Year of manufacture 10/2011 Serial no. F11/5JN5A1/A Year 2011 Number of axes 4 Handling weight (rated load) 2 kg Handling weight (maximum load) 8 kg Arm reach 800 mm Repeat accuracy (X+Y) 0.01 mm Repeat accuracy (Z) 0.004 mm Repeat accuracy (R) 0.002° Working range axis 1 +-280° Working range axis 2 +-310° Stroke axis 3 (Z-axis) 200 mm Rotation axis 4 (R-axis) +-500° Nominal speed / maximum speed: Axis 1 350 / 490 °/s Axis 2 500 / 620 °/s Axis 3 1600 / 2220 mm/s Axis 4 1200 / 1929 °/s Axes 1 + 2 8.11 / 10.84 m/s Robot configuration floor mounting Controller STÄUBLI CS8C bmn Ffjdpfx Afevmhphsneu Serial no. F11/5JN5A1/C Rated voltage 1 x 230 VAC Rated frequency 50 - 60 Hz Connected load 1700 VA Dimensions of controller (W x H x D) 450 x 310 x 450 mm - Controller adjacent with removable "Teach in" operation - Material gripper, workpiece gripper HELLA / MADER Total weight 190 kg Transport footprint L x W x H 900 x 700 x 1500 mm Very good condition

Condition: ready for operation (used), De uitrusting bestaat uit: 1 - afwikkeltoren met 4 afwikkelaars (AG 3000 a) Capaciteit per afroller: 3 ton armlengte: 1350 mm maximale snelheid: 25 m/min, frequentiegestuurd 2 - bobine-selector (MT-4 1250) min: 150 mm Ffjdpfoxqh Sajx Afneu maximale snelheid: 25 m/min, frequentiegestuurd 3 - richtunit (RM-4 1250) min: 150 mm maximale snelheid: 25 m/min, frequentiegestuurd 4 - snij-eenheid (TS 1250 + KST-2) min: 150 mm maximale snelheid: 25 m/min, frequentiegestuurd 5 - Schechtl-schaar voor het op lengte snijden met Siemens Touch CNC-besturing 1250 x 2 mm

Year of construction: 2019, condition: ready for operation (used), number of axes: 4, Machine tool manufactured in 2019... This Elumatec's Aluminum Profile Processing Line – SBZ 131 + DG 104 offers a complete processing line for aluminum and steel profiles. It features an integrated solution for cutting, mitre cutting, and complex profile machining, optimized for serial production. Consider the opportunity to buy this Elumatec's Aluminum Profile Processing Line – SBZ 131 + DG 104. Contact us for further details. • Complete processing line for aluminum and steel profiles • Ready-to-run configuration for immediate production • Industrial environment; very good overall condition • Integrated solution covering cutting, mitre cutting, and complex profile machining • Working length: 7.2 m Fsdpfx Afsyic Tbjnefu • Capabilities: • Complete profile machining in a single setup • Turret tool system with fast tool change • High industrial precision • Optimized for serial/mass productionDouble Mitre Saw • Cutting length: 6.0 m • Features: • Pneumatic tilting and rotation • Large-diameter saw blades • High precision and repeatability • Minimal material wasteApplications / Ideal for • Aluminum windows and doors manufacturers • Industrial profile processors • Façade systems and structural profile manufacturers • Plants expanding capacity or upgrading technology

Condition: used, functionality: fully functional, Machine Type: TORNOS MS7 – Single-Spindle Swiss-Type Automatic Lathe Application Area: Automatic machining of bar stock with Barboy magazine loader (feed system) Typical Workpiece Parameters: • Max. permissible bar diameter: approx. 10 mm • Max. turning length (without attachments): approx. 60 mm (with flat cams) Machine Dimensions (approx.): • Length: approx. 1440–1500 mm • Width: approx. 900 mm • Height: approx. 1500 mm Weight: • Machine only: approx. 700–880 kg • With Barboy equipment: approx. 1800 kg Spindle / Performance: • Spindle speed range: up to approx. 12,000 rpm • Spindle bore: approx. 11 mm • Motor output: typically several 4 kW motors Tooling / Axes: • Number of toolholders: approx. 5 Voltage / Connection: • 380 V / 50 Hz, three-phase Ffjdpfjyir I Dox Afnsu Barboy magazine loader including conveyor, splitter, and accessories Overall dimensions of machine + Barboy: approx. 4500 × 600 × 1400 mm Weight incl. Barboy: approx. 1800 kg

Condition: used, Struers Type: Struers Accutom-5 Struers Accutom-5 Precision Cutting Machine Laboratory saw including accessories & cutting discs Description: For sale is a Struers Accutom-5 precision cutting machine. This is a high-quality laboratory and precision saw designed for accurate sectioning of metals, ceramics, minerals, electronic components, sample materials, and workpieces with minimal deformation and excellent cut quality. Ideal for material testing, metallography, precision engineering, research, workshops, or laboratory use. The machine operates with adjustable speed, feed control, and integrated cooling, enabling precise, clean, and reproducible cuts. Extensive accessories and several original Struers cutting discs are included (see photos). Features: - Precise sectioning of materials and sample specimens - Adjustable cutting speed and feed rate - Minimal material loss due to precision cutting - Automatic or manual cutting operation - Recirculating coolant system to protect the sample and cutting disc - Adjustable cutting force (low / medium / high) - Programmable cutting modes - Very smooth operation and accurate positioning Technical Data: Device: Struers Accutom-5 Precision Cutting Machine Speed: 300 – 3000 rpm Feed: 0.005 – 3.0 mm/s Positioning speed: X/Y each 13 mm/s Cutting force: approx. 20 N / 40 N / 60 N Cutting discs: Diameter: 75 – 152 mm Max thickness: 2 mm Mounting hole: 12.7 mm Max sample size: Clamping length: up to 225 mm Cutting length: up to 30 mm (with Ø 20 mm sample) Coolant tank: approx. 4 liters Noise level: approx. 65 dB(A) Power / Electrical: Mains voltage: 220 – 240 V Ffsdsyhpqgjpfx Afnsu Frequency: 50 – 60 Hz Power input: approx. 370 W Current consumption: approx. 2.7 – 3 A Fuse: 6.3 A slow-blow Dimensions & Weight: Width: approx. 510 mm, Depth: approx. 700 mm, Height: approx. 270 mm Weight: approx. 45 kg Important note: "The table shown in the photos is not included in the sale." Condition: used Scope of delivery (see photos): - Struers Accutom-5 cutting machine - Several original Struers cutting discs (Diamond / SiC / Al2O3 depending on set) - Sample holder / clamping accessories (see photos) - Documentation / manual / spare parts documents - Integrated coolant tank (Subject to changes and errors in the technical data. All information provided without liability!) We are happy to answer further questions for you by phone.

Condition: excellent (used), Minimum quantity lubrication Make Steidle (28308) Fodpfxjirmilj Afnefu Type Deltamat D 40

Year of construction: 2015, condition: ready for operation (used), This PROFILATOR VF-320-L was manufactured in 2015. A Modular Gear Machining Center, it features a flexible system for dry machining with multiple process modules tailored to specific needs. Key features include programmable synchronization, modular design, and suitability for dry machining. Ideal for automotive gearbox components and high-precision gear components. If you are looking to get high-quality gear machining capabilities, consider the PROFILATOR VF-320-L machine we have for sale. Contact us for more information. • Machine Type: Modular Gear Machining Center / Multi-Process Gear Production System • Machine Concept: Flexible modular system for dry machining of gears and transmission components. Configurable with multiple process modules according to customer requirements. • Polygon and face slot machining • Gear and spline cutting (rotative cutting, hobbing, front-face gear cutting) • SCUDDING® internal and external gear generation • Gear tooth pointing (rotative and indexing modes) • Chamfering and deburring (ZEM series) • Shifter stop machining for synchronizer sleeves • Free programmable tool/workpiece synchronization • Modular design with different machine sizes • Single or multispindle configurations • Short cycle times • Parallel processes possible • Reduced setup and operating costs Fsdpfjx Imuqex Afnefu • Ergonomic and maintenance-friendly access • Suitable for dry machining • Gear quality DIN 5–7 (with SCUDDING®) • Surface roughness Rz 2–3 • High cutting stability and precision • Automotive gearbox components • Synchronizer gears • Shafts and gear wheels • Internal and external splines • Belt pulley profiles • High-precision gear components

Condition: used, functionality: fully functional, YEAR 1990 Power rating 15 kW Shaft diameter ø 120 mm Roller diameter ø 400 mm Resistive moment Cm 333 Cm3 IPN capacity 240 x 106 mm Capacity HEB 120 x 114 mm Capacity Pipe wall thickness x Ø 139 x 5 mm Ffodpsummkaofx Afnju Capacity flat 125 x 25 mm Hydraulic / Mechanical Hydraulic

Condition: excellent (used), thread dia. 36 mm Fodpfx Asyhq S Eofnsfu

Condition: used, Rolling Machine Brand: JAMMES PROMECAM Type: HC 1310 Maximum thickness: 10 mm Maximum length: 3040 mm Rolling capacity: 1500 mm Upper roller diameter: 300 mm Side roller diameter: 220 mm Working speed: 0 to 7 m/mm Hydraulic control 1 hp motor Hydraulic unit motor: 5.5 kW Weight: 7000 kg Ffsdswf Ndiepfx Afnju Dimensions: 5100 x 1000 x 1000 mm Type: 4-roller rolling machine

Year of construction: 2020, condition: used, Vixen Wash Type TSC with Siemens Simatic HMI Control with (2) x Filter Mists, Basket Size 490mm x 490mm. S/No. 3029 (2020). Country of Origin: United Kingdom Fedpfx Afeyidrlenefu Location: These lots are located in Leamington Spa, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Year of construction: 2019, operating hours: 1,022 h, condition: ready for operation (used), controller manufacturer: SIEMENS, controller model: SIMATIC HMI, overall weight: 2,100 kg, total height: 2,300 mm, This MHG SMG 160 was manufactured in 2019. It features a complete system size of 2300x7600x1500mm and weighs 2100kg. Equipped with a SIEMENS Simatic S7 PLC for control, it includes a recovery system and filter cabinet for efficient operation. The blasting cabinet is enhanced with wear protection and LED lighting. Consider the opportunity to buy this MHG SMG 160. Contact us for more information. • Power: Hard-wired via terminal block, 230/400V/PE/N, 50 Hz • Conveyor belt speeds: 9.6 / 24 / 38 mm/sec • Max. workpiece dimensions: 300 x 50 mm • Max. surface load: 50 kg • Adjustable lateral guidance of components on conveyor belts • Blasting nozzles: 4 x 8 mm boron carbide, individually adjustable • Blasting modes: Continuous or intermittent • Travel path: Horizontal stroke, 400 mm stroke length Ffsdpfex D Rf Njx Afnju • System control: Siemens Simatic S7 PLC • Cabinet: 2 service/adjustment doors; front door with pneumatic baffle plate • Lighting: 2x LED inside blasting cabinet • Wear protection package in cabinet • Media history: Operated exclusively with glass beads (low-wear) • Operating hours: 1,022 h (as of Dec 13, 2023; system no longer in use) • Color: RAL 7024 graphite gray • Production date: March 2019 • Condition: Good to very goodConveyor belt: 7800mm x 300mmBelt length before the cabin: 2,500 er the cabin: 2,500 in length: approx. 2,800 mm. Additional equipment • Recovery system 255 with 120 L abrasive storage container; recovery of intact abrasive and separation of dust/dirt particles • Filter cabinet 1703 with 17 m² filter area and 4.0 kW fan motor Dimensions Machine Depth 1500 mm

Year of construction: 1981, condition: ready for operation (used), - USED - DOUBLE COLUMN MECHANICAL PRESS TONNAGE: 400 ton WORKTABLE: 2750 x 1520 mm INNER SLIDE TRAVEL: 600 mm Ffodpfxjyigv Hs Afneu PLATE HOLDER TRAVEL: 200 mm PLATE HOLDER CAPACITY: 75 ton USEFUL HEIGHT: 980 mm MOTOR POWER: 50 kW

Condition: ready for operation (used), - USED - DOUBLE COLUMN MECHANICAL PRESS TONNAGE: 900 ton WORKTABLE: 4572 x 2438 mm INNER SLIDE TRAVEL: 940 mm USEFUL HEIGHT: 1408 mm Ffodpeyigvyefx Afnou DISTANCE BETWEEN UPRIGHTS: 4672 x 1900 mm WORKING SPEED: 8 - 18 mm/sec

Condition: good (used), Sheet metal round roller Round roller 1000 x 1.5 mm width 1040 mm roll diameter 55 mm asymmetrical roller arrangement width 1500 mm depth 930 mm height 1280 mm Ffedpfxsud Spnj Afnou Weight 200 kg without pallet

Condition: excellent (used), Temperature 80 / 130° Carrying force 100 kg Content 750l Fjdpfemmfg Nex Afnefu MARCELS MASCHINEN AG

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, total length: 800 mm, total width: 900 mm, total height: 1,600 mm, filling weight (max.): 100,000 g, TECHNICAL DETAILS Workpieces: Press-in studs M6 x 15 Fjdpfx Ajyf A U Hefnsfu Feeding capacity: 15/min (single track) Max. fill weight: 100 kg Max. fill volume: 25 dm³ MACHINE DETAILS Voltage: 230 V Max. power consumption: 100 VA Dimensions (L x W x H): 800 x 900 x 900 mm EQUIPMENT Linear feeder rail Transport hose Air blow nozzle Note: The workpieces, max. 100 kg or 25 dm³, are stored in the parts feeder and correctly oriented. At the end of the sorting process, the workpieces are buffered on a linear feeder rail and supplied to the singulation unit. Behind the singulation unit, a suitable transport hose and an air blow nozzle are installed. Each workpiece is transported individually through the transport hose. Possible electric interfaces include HAN connectors, bus modules and valve manifolds.

Year of construction: 2000, condition: ready for operation (used), functionality: fully functional, overall weight: 130 kg, total length: 1,200 mm, total width: 780 mm, total height: 1,280 mm, Equipment: foot remote control, TECHNICAL DETAILS Grommet size: 4 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,200 x 780 x 1,280 mm Net weight: 130 kg Ffjdsyf A S Ejpfx Afnsu EQUIPMENT on castors with foot switch Note: The machine is sold without a riveting head.

Year of construction: 2009, condition: ready for operation (used), travel distance X-axis: 2,500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 410 mm, controller manufacturer: SIEMENS, controller model: 840D SL Sinumerik, overall weight: 20,000 kg, total height: 2,600 mm, spindle motor power: 45,000 W, product length (max.): 5,200 mm, spindle speed (max.): 4,000 rpm, table load: 4,000 kg, number of axes: 5, This 5-axis HABRAMA PPSM 2200 was manufactured in 2009. It features a robust workbench of 390 x 3750 mm, supporting a maximum table load of 4000 kg. The grinding head offers a drive power of 45 kW and a spindle speed of up to 4000 rpm. With a total power consumption of 100 kVA and a weight of 20,000 kg, this machine ensures precision and efficiency for complex grinding tasks. Contact us for more information about this machine. • Axes and travels • C-axis: +30° / -30° • B-axis: +20° / -20° • U-axis: 105 mm • W-axis: 125 mm • B2-axis: +20° / -20° • Worktable • Workbench size: 390 x 3750 mm • Feed speeds • X-axis: 21 m/min • Y-axis: 10 m/min • Z-axis: 6 m/min • C-axis: 2 m/min • B-axis: 6 m/min • U-axis: 4 m/min • W-axis: 4 m/min • B2-axis: 6 m/min • Grinding head • Grinding wheel mount: 100 mm H5 • Programmable constant cutting speed: 10–80 m/s • Grinding wheel type: ceramic or resin bonded • Max. grinding wheel width: 101 mm • Grinding wheel diameter: 210–400 mm • Grinding wheel bore: 152.4 mm (6") • Grinding range: up to module 22; custom profiles freely programmable • Total machine power consumption: 100 kVA Additional equipment Fodpfx Aeyf Hcusfnofu • Hybrid clamping device/plates (workholding) • Coolant system approx. 4000 liters with integrated deep-bed filter
