Planing machines Offers
max. planing length: 700 mm
min. planing length: 150 mm
Gpargcg
max. working width: 700 mm
clamping area: 710 x 450 mm
main drive: 7,5 kW
motor for rapid traverses: 1,1 kW
length of machine: 2850 mm
width of machine: 1590 mm
height of machine: 1840 mm
weight of machine: 3400 kg
hydraulic drive
12
Shaping length -850mm
Shaping width -780mm
Jwpvxm
Working height -510mm
Toolholder manual vertical adjustment -200mm
Table size 820x450mm
MARCELS MASCHINEN CH
5
The 7212 gantry planer was built in the USSR in 1984. The machine can process workpieces weighing up to 8,000 kg, 4,000 mm long and 1,250 mm wide.
Technical data :
- maximum dimensions of the processed detail (width x height): 1250 x 1120 mm
- table dimensions (width x length): 1120 x 4000 mm
- maximum workpiece weight: 8000 kg
- maximum workpiece weight per 1000 mm of the table: 4000 kg
Bzc3nc3xis
- distance between stands: 1350 mm
- greatest distance between the table and the upper beam: 1200...
5
Maximum disc diameter: 500 mm (currently 400 mm mounted) Very stable design
Bonbyn33is
5
Planing Machine - Double Column / Brand: WALDRICH-COBURG / Type: 4 D 2020 / Year of construction: 1959, Renewal electrical system: 2014
2014: Renewal of the electrical system with replacement of
the control cabinet.
The machine can be inspected by appointment under working condtion.
Condition: Very well maintained, functional.
1,5 Shift operation
TECHNICAL DESCRIPTION:
- Planing length: 8.000 mm
- Planing width: 1.000 mm
- Planing height: 980 mm
- Portal passage: 1.030 x 960 mm
- Clam...
6
Hydr. single column planing machine make WALDRICH COBURG type 2E 1515
Com.# 2110108 Year of construction 1966
combined gantry planing and milling machine with removable milling attachment
Technical data:
plane length 2000 mm
Planing width 900 mm
Plane height 750 mm
table surface 2000 x 650 mm
table surface in very good condition
admissible workpiece weight 1550 kg
Milling head
11 Spindle speeds 112 - 1120 rpm
Power 1,5 kW
Speed 960 rpm.
Psyq83
Tool holder MK 3
max. cutter diameter 63 mm
Axial ad...
6
weight of the machine ca. 10 t
Buuknct7jb
12
Shaping length -750mm
Shaping width -780mm
Working height -460mm
Vbvvugdp
Toolholder manual vertical adjustment -200mm
Table size 710x420mm
MARCELS MASCHINEN CH
Overall size: 2700 × 4800
Working area: 2100 × 3700
Italian spindle HSD, with ceramic bearings and power 9 kW, 24,000 rpm
Axis movement by servo motors
X os - 2 pieces 2kw servo motor
Y os - 1 piece 2kw servo motor
Z os - 1 piece 1kw servo motor with brake
30 mm linear guide rails
FALCON industrial computer control
Axial sensor stops to prevent errors and possible damage to the machine
automatic changeover, for 14 tools, with aluminum holders, located under the portal, for faster work
Automatic...
6
Klopp type 375 fast planer / short planer
planer length: 375mm
Drptepgz
planing width: 500mm
table size: 350x315
stroke speed: 19-190mm stroke
max. distance table to ram: 390mm
weight 920kg
Condition see pictures.
EXW ( ex stock ) on Plaette Leonberg
6
Planing Machine - Double Column / Brand: WMW-HECKERT /
Type: HZ 1250x1000x6000/3 / Year of construction: 1972,
Modernisation mid-2004.
2004: Modernisation and commissioning by the machine manufacturer: Renewal of the control system and the electrical system with replacement of the control cabinet.
Bysn8ejiob
The machine can be inspected by appointment under working condtion.
Condition: Very well maintained, functional.
1,5 Shift operation
TECHNICAL DESCRIPTION:
- NC-control WMW, Typ: MDF 60...
3
Maximum planing length 6000 mm Maximum thickness of planed sheets 80 mm Maximum angle of inclination of knives 35 ° Number of hydraulic clamping cylinders 6 Number of manual clamps 5 Compression force of hydraulic clamp 35000N Maximum tensile force of support 60000N Cutting speed number of degrees 4 range 14-18-22,4- 28m min-1 Stroke of knife carriage horizontal 100mm vertical 120mm Electric motor for drive support power 21kW speed 1340min-1 Floor area of machine length 9380mm width 2270mm Machi...
10
KLOPP horizontal shaper, fast planer.
working length = 550 or 750mm.
Year of manufacture unknown.
Including vice, second tool holder, chip tray to slide into T-slots (see photos).
Condition is functional with wear due to age.
Fpzz2up9c
15
KÖLLMANN Plano Milling Machine
Type:E900
Year:1972
Working table area:3700x900mm
Max. table load:12500kg
Table travel:4300mm
Horizontal spindle travel:800mm
Horizontal spindle speed:1200rpm
Vertical spindle travel:1250mm
Vertical spindle speed:1200rpm
Pialp
Vertical spindle tilt:45°
Machine weight:30t
Please Note: The above information has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be gua...
The Double station CNC Panel Working Machinery specialized for machining aluminium composite panels.
Also called in the market as ACP panels or ACM panels.
The machine first grooves and then cuts the aluminium composite panels by using cutter bits using 2 high speed spindle motors, clamps the panels by vacuuming with a vacuum table and vacuuming pump, extracts the swarf coming out from the panel by a dust extraction system.
Thanks to the double station working system, it is possible to load 2 di...
7
Planer with table 1320 x 5000mm. Available to see in Storebro
Bxln3bgxkh
2
Motor 0,6 / 0,8 kW;2-stage
baffle: approx. 40 -110 Habe/min.; steplessly adjustable
plane length: approx. 200 mm
Svb9l0
planing width: approx. 190 mm
Height adjustment: approx. 150 mm
Accessories: machine vice on swivel plate; chip catcher, swivelling; emergency stop; 1 pc. planing chisel; technical copies
4
Vertical shaping machine for the production of grooves and gears.
The machine can also be used to produce conical grooves.
Suobyw
2
X-travel: 500-4000mm, y-travel: 800mm, z-travel: 400mm, planing width: 1250mm, connected load: 108.1kW, length: 10,500mm, width: 5000mm, height: 2500mm, weight: 33.2t.
Btlc7xzift
8
Used planing machine in good condition
Bfres3bg9z
6
PLANER.
Bumc83xxjc
Make : MARIO CARNAGHI.
Model : FP52/2250.
Table size : 1550x10000 mm.
Distance between columns : 2250 mm.
Vertical travel : 1600 mm.
Total length of the pallet : 22500 mm.
External distance V-guides : 970 mm.
Planning heads : 3
Tool holders on the post : 1.
Tool holders on the crosspiece : 2.
Table drive with by Ward Leonard group.
Machine approx. weight : 55 ton.
THE MACHINE CAN BE PROVIDED WITH VERTICAL MILLING HEAD.
8
Plano Milling machine tool STANKO typ 7212G,
table 1250x4000mm,
dbc 1350mm
table travel 4200 mm
Bwnyprqpit
2 milling and 3 planing heads
