Used Cnc Saw for sale (14,031)

Condition: used, CNC Press Brake COLLY 502/A Numerical Command: CYBELEC type DNC 32 P-CM Capacity: Maxi length 2000 mm x 50 T Throat depth: 200 mm Distance between uprights: 1600 mm Back Gear Gauge 1 axe Defective cylinder Dodpo Aihyvefx Aa Hokw Right cylinder joint to change Machine functional (only right cylinder joint to change) Voltage: 380 V Length: 2500 mm Depth: 2100 mm Total height: 2400 mm Weight: approx 4 T

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground ball screws of the highest precision class. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. Such characteristics are important for ensuring balanced movement even in more complex tasks. The movement of the various axes is controlled by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters that can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different P Dsdpfevvi Nzox Aa Hskw

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Dkjdpsw Dcccjfx Aa How

Condition: used, Material clamping via handwheel. Cutting length 3000 mm. Max. cutting height 60 mm. Dsdpfsvvkblex Aa Hekw Storage location: Nattheim

Condition: used, Year of construction: 1985, Cutting length: 3100 mm Cutting height: Adjustable from 0-45 mm Saw unit: Powerful three-phase motor 220/380 volts, 1.8 kW power Clamping bar at the top with a handwheel Storage location: Nattheim Djdpjvvkazjfx Aa Hokw

Condition: used, Year of construction: 2001, Cutting width: 3300 mm Cutting length: 3350 mm Weight: approx. 4000 kg Saw blade projection: 100-(115) mm Saw carriage: Feed speed: 100-(130) m/min. Return speed: 100-(130) m/min. Main saw blade: 400-(430) mm Motor: 7.5-(11-13.2) kW Scoring unit: 215 mm Motor: 2.2 kW Pusher: Rapid feed: 160 m/min. Return speed: 60 m/min. Extraction: Air speed: 30-35 m/sec. Extraction nozzle: 200 mm / 115 mm Compressed air: Pressure: 5-6 bar Consumption: 20-30 l/min. Storage location: Nattheim Djdovvkqgopfx Aa Hekw

Condition: used, Year of construction: 2009, Automatic central lubrication Milling unit 7833 2-stage, 11 kW power 1000 - 24000 rpm 1 double drilling spindle in X-direction 1 integrated sawing unit for sawing / grooving in X-direction, traveling Tool changer 7892, 16-way Linear Pick-up changer, permanently installed on the right-hand side of the machine Laser pointer consisting of 2 laser pointers for positioning the vacuum suction cups or tracing the workpiece contour Automatic console - suction cup positioning 6 consoles including 3 suction cup holders per console including 1 vacuum suction cup 80x80 mm per suction cup holder including 4 feeding aids Additional processing fields at the front for 6 consoles Basic unit pneumatics for frame clamping system 7974 (6 consoles) 2D barcode scanner Video camera in the processing head Vacuum pump 140 m³/h Vario tool Change changing unit package consisting of Consists of: Vector axis 7899 (C-axis), fully interpolating, 0-360° continuously rotatable, including pneumatic tool changer 7890, single-slot magazine pick-up system, permanently installed in front of the machine frame on the left. Tool changer 7894, 6-slot pick-up magazine specifically for Vario Tool Change tool holders, permanently installed in the machine frame on the left, can be equipped with a Vario Grip KSJ F 40 collet chuck, 3 Vario Grip KSJ F 40 tool holders (for 2-20 mm ER32 collets), 1 saw blade holder, 3 collets according to customer selection, 1 carbide circular saw blade, max. 220 mm diameter. Dkedpfx Ajvvi Spoa How Storage location: Nattheim

Condition: good (used), functionality: fully functional, saw blade diameter: 350 mm, Saw motor: 1.5 / 1.8 kW Dodo Aiityspfx Aa Hskw Saw blade size: 350 mm 2 saw blade speeds: 1400 / 2800 rpm Miter angle stepless: ±45°

Condition: used, CITIZEN CINCOM R 04 VI is a CNC automatic lathe / Swiss-type lathe designed for high precision, accuracy and reliability. It features 6 axes and 2 spindles, max. turning diameter 4 mm, max. turning length 40 mm, internal spindle diameter 9 mm, max. threading diameter 3 M. Main specs: up to 20000 t/min, spindle power 0.5/0.75 kW; tool-holder count 3 with 15 stations; turning tools 5, drilling tools 4, transverse tools 2; tool shank 8 mm; counter-operation 4 tools. Voltage 50 Hz 3x400 V; machine weight ≈850 kg; dimensions L1485×W560×H1410 mm. Accessories: LNS TRYTON 107 Hybrid bar feeder, parts catcher, coolant system, lamp. Ensures tight tolerances; suited to watchmaking, medical, automotive, aerospace and precision components. Dsdpfxjzv I D Ho Aa Hjkw

Condition: used, Year of construction: 1997, functionality: fully functional, turning diameter over cross slide: 450 mm, turning length: 420 mm, turning diameter: 350 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 180 mm, travel distance Z-axis: 420 mm, overall weight: 3,500 kg, KEGAI TUR-15 Manufacturer: Ikegai Model: TUR-15 Machine Type: CNC Turning Center Year: 1997 CNC Control: Fanuc Series 18-T Drives: Fanuc Alpha Series Number of Axes: 2 Swing Over Bed: Approx. 450 mm Maximum Turning Diameter: Approx. 350 mm Maximum Turning Length: Approx. 410–420 mm X-Axis Travel: Approx. 170–200 mm Z-Axis Travel: Approx. 420 mm Chuck: 8" Hydraulic Chuck Spindle Nose: A2-6 Spindle Bore: Approx. 57–61 mm Bar Capacity: Approx. 45–51 mm Spindle Speed: Up to 4,000 rpm Spindle Motor Power: Approx. 11 kW / 15 HP Turret Capacity: 12 Stations Djdpfx Ajzvmytoa Hokw Tailstock: Included Chip Conveyor: Included Machine Dimensions: Approx. 2,440 × 1,470 × 1,575 mm Machine Weight: Approx. 3,300–3,700 kg

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, cutting length (max.): 10,000 mm, feed length X-axis: 5,020 mm, saw blade diameter: 500 mm, total length: 6,100 mm, type of input current: three-phase, saw blade speed: 2,800 rpm, input voltage: 380 V, air pressure: 6 bar, overall weight: 1,600 kg, The machine is currently undergoing refurbishment; further photos will follow. Classic Magic 500 TU5 -Double miter saw with program/positioning control -Electrically adjustable saw head, speed V = 20 m/min -Saw blade diameter 500 mm -Saw blade bore 32 mm -Max. cutting length 5,200 mm; automatic extension up to 10,000 mm possible for oversized parts -Min. cutting length at 90° = 225 mm -Horizontal pivoting of the saw heads -Miter angle range from 90° to 22.5° (outward) -Saw heads with automatically controlled full protective guards -Profile support roller track (right) -Pneumatic material/workpiece clamping Dksdpfx Aaj Afbtws Hjw The machine comes with the following accessories: -Cleverbridge for data transfer via USB or RJ45 -Long roller track -Additional tensioner on the roller track -Horizontal + Vertical tensioners -Macro function (ideal for mosquito screen manufacturers) -Oversized part cutting -Shortcut function -Cross-cutting -Automatic cutting -Automatically extending profile support

Condition: used, HAUSER S 50 CNC 311 is a CNC jig grinder delivering precision, high accuracy and reliable performance for demanding grinding tasks. 2‑column execution, table 1020×860 mm, X travel 900 mm, Y 600 mm, vertical slide travel 635 mm, spindle‑to‑table clearance 750 mm, passage between columns 950 mm; max grinding diameter 230 mm (360 mm with intermediate plate); taper grinding up to 16°. Key specs: Z stroke 0–170 mm stepless, stroke speed 1–12000 mm/min, stroke frequency 6 Hz, U‑axis fine feed 6 mm, planetary C motion 5–300 t/min, grinding spindle 4500–80000 rpm (air turbine up to 160000 rpm); supply 3×400 V 50 Hz, total power 9 kVA; weight ≈6300 kg; size 3000×2500×2870 mm. Fitted with retrofitted control, set of grinding arbors, grinding motors 45 S/45 ST and C‑axis; refurbished 2016. Achieves tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors. Djdpo Afc Tlofx Aa Hekw

Condition: good (used), Year of construction: 1998, - Heidenhain CNC Pilot control system - Accessories included - Powered tooling - Counter spindle Work area Max. turning diameter 160 mm Swinging diameter over bed 440 mm Swinging diameter over compound slide 210 mm Turning length 350 mm Main spindle Spindle bore 56 mm Max. spindle speed 5,000 rpm Drive power 7.5 kW Number of spindles: Main spindle C-axis Travel distances X-axis 160 mm Z-axis 350 mm Tailstock travel 350 mm Tailstock Arbor diameter 80 mm Tailstock travel 350 mm Tailstock mounting MK 3 Feeds Rapid traverse X 20 m/min Dksdpj Afhifefx Aa How Rapid traverse Z 30 m/min Space requirement approx. 2,800 x 1,800 x 1,800 mm Machine weight approx. 3,400 kg

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm Dkodpfx Aj Ad Izrja Hew spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 2005, CNC Machining Center Manufacturer: IMA Type: BIMA 300 Year of manufacture: 2005 Technical data Work area - Machining area X-axis: 4,300 mm - Machining area Y-axis with main spindle and 20 mm tool: 1,400 mm - Machining area Y-axis with drilling unit (all vertical drilling spindles): 1,100 mm - Max. clamping height above the vacuum suction surface: 125 mm - Max. workpiece thickness: depends on equipment and application - Working height: approx. 950 mm - Two-zone work area without pendulum machining: 2 x 2,050 mm - Average clearance without pendulum machining: 200 mm - Two-zone work area with pendulum machining: 2 x 1,750 mm - Average clearance with pendulum machining: 800 mm Main spindle - Spindle power: 7.5 kW - Tool holder: HSK-F63 - Taper diameter: 38 mm - Automatic tool clamping - Clamping force: 11,000 N - Release force: 20,400 N - Max. tool weight: 6 kg - Spindle speed: continuously variable, 1,500 - 18,000 rpm - Direction of rotation: programmable, clockwise and counterclockwise - Drive: Three-phase motor with frequency converter - Spindle lubrication: permanently lubricated at the factory - Spindle cooling: air-cooled - Integrated CNC rotary axis for tool positioning over 360°, with torque support and pneumatic connection Axis speeds - Max. rapid traverse X-/Y-axes: 60 m/min - Max. rapid traverse Z-axis: 30 m/min Vacuum, extraction, and compressed air - Required compressed air pressure: 7 bar - Extraction port diameter: 250 mm - Required extraction air velocity: 28 m/s - Required extraction volume flow: 4,950 m³/h - Vacuum pump capacity: 90 m³/h Dimensions and weight - Machine length: approx. 5,750 mm - Machine width: approx. 3,830 mm - Machine weight: approx. 6,000 kg Accessories - 90-degree angle drilling unit - 3 x HSK tool holders Note: Dksdpfj Adyhwjx Aa Hew The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, BOEHRINGER / VDF NV 250 T is a CNC vertical turning machine designed for precision machining, high accuracy and reliability. Total axes 4; spindle hole 65 mm; travels Z 260 mm, X 760 mm, Y ±50 mm; rapid traverse X 120 m/min, Z 40 m/min; turret 12 positions VDI 40/DIN 69880. Spindle head A6; stepless up to 4500 t/min; spindle power 31 kW; voltage 50 Hz 3x 400 V; machine weight approx. 8500 kg. Equipment: 3-jaw chuck Ø250 mm with automatic centering, lamp, coolant system, oil mist extractor, automatic loading/unloading unit. Achieves tight tolerances; typical for automotive, aerospace, medical and machine tool sectors Dodpfx Aj Adzhloa Hekw

Condition: not inspected (used), Year of construction: 2003, turning diameter: 175 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 125 mm, travel distance Z-axis: 120 mm, CNC Lathe Manufacturer: MURATEC Model: MZ 60 Dkjdpfezz S Rzox Aa Hjw Year of manufacture: 2003 Control system: Fanuc Technical details Turning diameter: 175 mm Spindle speed: 6,000 rpm Number of tool stations: 12 positions X-axis travel: 125 mm Z-axis travel: 120 mm Used; sold without warranty Machine transport dimensions (LxWxH) approx.: 1900 x 3100 x 2500 mm Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to technical changes, errors, and prior sale.

Condition: good (used), Year of construction: 2012, CNC Turning / Millingcenter Machine type: DMG CTX beta 500 V6 Control: Siemens 840 D Shopturn Year: 2012 Working hours: 42.067 h Spindle running time: 20.209 h SPECIFICATIONS Dedpfez D Ug Isx Aa Hokw Max. turning length: 500 mm Turningdiameter: 410 mm Max. swing over bed: 700 mm Spindle bore: 87 mm Bar capacity: 77 mm C-Axis: 0,01° Main Spindle: ISM 76 Max. revolution: 5.000 rpm Spindle power: 25 / 34 kW Torque: 280 Nm Collet chuck: Hainbuch Spantop Nova 65 Subspindle: ISM 52 Max. revolution: 5.000 rpm 3-jaw chuck: Berg KHL 200 mm Travel Y-Axis: mm Amount of turrets: 1 Tool: VDI 40 Driven Tools: 12 revolution driven tools: 4.000 drive power driven tools : 11,3 kW Equipment Chip conveyor Short Bar Loader: LNS QLS 80 S2 Direct linear scales: X,Y High pressure pumps Toggle filter Tool setter

Condition: used, Year of construction: 2004, Slider length: 3400 mm Cutting width at the rip fence: 1300 mm Cutting width at the crosscut fence: 3200 mm Cutting depth: 154 mm Dkedpezqyxxsfx Aa How Scoring saw: yes Saw blade height adjustment: electric / position control Saw blade swivel adjustment: electric / position control Rip fence adjustment: electric / position control Crosscut fence adjustment: manual Saw blade angle display: digital display Cutting height display: digital display Rip fence display: digital display Crosscut scale display: scale Crosscut scale with miter function: yes Saw blade diameter: 450 mm Speeds: 4 Motor power: 7.5 kW Dust extraction connection: 80 and 120 mm Machine length: 3600 mm Machine width: 2000 mm Weight: 1200 kg

Condition: used, KELLENBERGER KEL‑VISTA UR 175/1000 is a CNC cylindrical grinder, engineered for precision, high accuracy and reliability. Capacities: centre height 175 mm, distance between centres 1000 mm, max workpiece 100 kg; grinding wheel Ø400×63 mm, bore 127 mm; tailstock travel 50 mm, max table tilt 9°. Specs: wheel peripheral speed 35 m/s, spindle speeds 8–800 t/min (stepless), grinding spindle motor 5 kW, rapid feed 12 m/min, spindle taper ASA5/MK5, overall L3200×W1700×H2000 mm. Accessories: coolant system, paper filtration, set of grinding wheels. Delivers tight tolerances; ideal for automotive, aerospace, machine tools and medical sectors. Dkodpfoz Dvzajx Aa Hjw

Condition: used, TORNOS DECO 2000/13 is a CNC automatic lathe engineered for precision machining, high accuracy and dependable reliability. Key capacities: 10 axes; max workpiece length 180 mm; internal spindle diameter 13 mm; spindle speeds 100-12000 t/min; back spindle 100-8000 t/min. Main specs: 50 Hz 3x400 V supply; spindle motor 2.2 kW; total power 11 kVA; weight approx. 2550 kg; footprint L2000×W1260×H1950 mm. Equipment: bar feeder IEMCA GENIUS 226/32, chip conveyor, coolant system, oil mist extractor. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical. Dkodpfx Aoz Dvztoa Hsw

Condition: used, Year of construction: 2015, axis stroke (X,Y,Z) 6175x1550x300 mm Number of spindle head vertical 20 St. Number of spindles head horizontal 10 St. Number of milling agregates 1 St. Speed 24.000 U/min. Capacity 300 kg/h Sawing unit ja_yes 0 Control Homag PC85 CNC powerTouch HOMAG BMG 511 /60/12/F/K Profi ----- Machine already professionally dismantled and stored at our warehouse in Oberkochen: - 5-axis CNC processing center - Moving gantry machine (dual-drive gantry system) - 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm - 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° - 1 Chain tool changer, 30-position - Includes SL laser projector - Includes vacuum suction cups (as available) - Spare parts and accessories as shown in photos - Last HOMAG 5-axis service: 2024 - Last HOMAG service: 2025 - Price includes professional dismantling and loading onto customer's truck - Costs for loading frames/transport securing devices NOT included; see note at the end of the description Technical Data ----- Max. workpiece lengths: All aggregates: Single 6,000 mm; Pendulum min. 1,550 mm, max. 3,200 mm Tool dia. 25 mm: Single 6,175 mm; Pendulum min. 1,550 mm, max. 3,200 mm Max. workpiece width: All aggregates, front stop 1,100 mm Milling operation tool dia. 25 mm: Front stop 1,325 mm, rear stop 1,550 mm Workpiece thickness: Max. 300 mm including clamping devices Routing spindle and drilling head ----- 2 independent Z-axes 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm Liquid-cooled routing spindle, DRIVE5C+ aggregate interface with 3-point torque support 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° for drilling and sawing operations at any angle 1 motor 2.3 kW, frequency-controlled, max. speed 7,500 rpm selectable via program for rapid processing even with small Djdpszqggvsfx Aa Hskw diameters 20 vertical HIGH-SPEED spindles 10 horizontal spindles 1 grooving and parting saw Includes Z-axis module Includes extraction hood Tool changer: ----- 1 Pick-up station for 350 mm saw blade for DRIVE5(C)+ 1 Chain tool changer, 30-position, D=80 For tools and aggregates with HSK-F63 Chain changer with 30 tool/aggregate positions for use with machines featuring 1 main spindle 1 upstream double gripper for rapid tool changing Console table with ----- 12 consoles, Y=1,500 mm for K-table 6 lifting rails (HPL), lift 100 mm Additional accessories: ----- SPEED PACK: Increase in... Max. traverse speed of X-axis: 80 m/min; vector speed = 110 m/min Contour laser positioning aid 1 vacuum pump (300 m³/h) Chip conveyor belt with extension Vacuum clamping system SL-Laser Energy-efficient 5-axis extraction hood Safety equipment: ----- Laser, bumper SAFESCAN for Speed ??Pack CE mark HOMAG Speed ??Pack HOMAG Quality Package Enclosed energy chain Control system ----- PowerControl PC85 HOMAG powerTouch Handheld terminal HOMAG IPC Powerpack Software ----- HOMAG woodWOP 7.1 WoodScout diagnostic system MMR B...

Condition: used, Year of construction: 2011, operating hours: 69,103 h, functionality: fully functional, machine/vehicle number: NT430111102, travel distance X-axis: 750 mm, travel distance Z-axis: 1,635 mm, overall weight: 26,500 kg, For sale is a CNC turning and milling center from the renowned manufacturer Mori Seiki, type NT4300DCG/15000S, manufactured in 2011. The machine features a dual spindle, a milling spindle, and extensive technical equipment, making it suitable for demanding turning and milling operations. Technical specifications: Manufacturer: Mori Seiki Type: NT4300DCG/15000S Year of manufacture: 2011 Serial number: NT430111102 Machine number: 1216 Travel distances X/Z: 750 / 1,635 mm Max. turning diameter: 750 mm Electrical connection power: 69 kVA Machine weight: approx. 26,500 kg Control system: Type F31IA5 Equipment and accessories: Dual spindle Milling spindle 10-position tool turret, partially with driven tools Three- and four-jaw chucks Internal tool measuring system Renishaw HPRA Chip conveyor, manufacturer Enomoto Dkedpfx Aao Afx Als Hjw Coolant filtration system with band filter, manufacturer Knoll, type FKA500, year of manufacture 2012 Separate cooling unit, type CLPB, serial number 159145 Siemens control system, type Simatic Two workbenches with 10 and 12 drawers respectively Partition and lighting system Extensive accessories with digital and analog measuring instruments, hand tools, and machine accessories Sales offer: A powerful CNC machining solution with extensive equipment for industrial production. The machine is offered including the described accessories. Attractive offer – flexible & hassle-free We offer you not only a high-quality product but also customized financing options that adapt to your needs. Whether it's a down payment, installment payment, or individual financing models – together we will find the right solution. If desired, we will also take over the complete transport organization. From planning to reliable delivery, we ensure a smooth and timely process so that you don't have to worry about anything. 📞 Feel free to contact us for more information or a non-binding offer. We will advise you personally and competently. Subject to prior sale, changes, and errors!

Condition: good (used), Year of construction: 2006, functionality: fully functional, Overhauled: 2014 Control system: Heidenhain iTNC 530 Dkedpfx Ae Adn Rgsa Hsw Table: 10,000 x 3,000 mm X-axis travel: 10,000 mm Y-axis travel: 4,200 mm Z-axis travel: 1,100 mm Distance between columns: 3,500 mm Distance between table and spindle (without head): 2,000 mm Distance between table and 45° head: 1,298 mm Table load capacity: max. 30,000 kg Rapid traverse rate: 10 m/min Feed rates: 6 m/min Spindle speed: 3,000 RPM Spindle power: 40 kW 3 heads: 1. Vertical, integrated, 2. Universal orthogonal head 1°, 3. Universal twist head

Condition: good (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 175 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 435 mm, Fanuc 18i-TB control Collet chuck device main spindle Dkjdpfx Aae Af Ipkj Hsw Collet chuck device sub spindle C-axis Y-axis 12-fold turret with driven tools chip conveyor bar loading device coolant device Technische Daten: / technical details max. Stangendurchlass / max. bar diameter 51 mm max. Drehdurchmesser / max. turning diameter 175 mm Verfahrweg X / travel X 175 mm Verfahrweg Z / travel Z 435 mm Verfahrweg Y / travel Y +-40 mm max. Drehzahl / max. spindle speed 5000 UpM/rpm Anzahl der Revolverplätze / number of tool places 12 Eilgang X,Z,Y / rapid feed X,Z,Y 18,20,12 m/min Gewicht/weight 4550 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.
