Used Deckel Lkd for sale (700)

Year of construction: 1981, condition: good (used), machine/vehicle number: 2608-0129, Travel for the x-axis - 400 mm Travel for the y-axis 250 mm Travel for the z -axis 340 mm Kljdpfxod Dz Rhs Ab Tsp Table Surface area - 600 x 300 mm Turning speed range 40 - 3150 rpm Planetary grinding heads included. With full technical documentation There is no possible drilling and milling - no tooling Transport dimensions: 1.5 x 1.7 x 1.8 m, Weight ; 1300 kg.

Condition: used, Motor output 3 kW Kedsv Nq Skopfx Ab Tslp total power requirement 3 kw Weight 1.400 kg

Condition: used, Year of construction: 2008, x-travel 1000 mm y-travel 1000 mm z-travel 1000 mm Control Siemens 840D powerline spindle tunring speed 8.000 U/min drive capacity - main spindle 100/40% ED 32/44 kW tool taper HSK-A 100 number of tool places 354 Pos. rapid traverse ( x / y / z ) 60 m/min Kledpfoxcp R Uox Ab Tjp size of pallet 800 x 800 mm In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features: - NC rotary table with pallet carrier - Rotary pallet changer - 40 bar internal coolant supply - Rotating viewing window - Wall-mounted magazine with 300 magazine positions - Rotating wall tool lock, 30 positions (inactive) and 54 positions (active) - Infrared measuring probe - SK 50 mechanical tool breakage detector - Tool identification - 4-color signal lamp Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: good (used), Year of construction: 2011, functionality: fully functional, Technical details x-travel 400 mm y-travel 580 mm z-travel 460 mm Control Heidenhain iTNC 530 Additional information HSC Precision Machining Center HSC 55 linear NEW DMG Design Heidenhain iTNC530 3D Control SmarT.NC User Interface DMG ERGOLine® Control, 19" Screen HSC 55 linear 5-Axis Version Rotary Swivel Table Clamping Surface 400 x 400 mm Swivel Range A-Axis +10/-110°; C-Axis 360° Maximum Load Capacity 200 kg, Absolute Measuring Systems Including Drive Cooling for A and C Axes X = 450 mm, Y = 580 mm, Z = 460 mm 80 m/min Rapid Traverse Spindle Speed ??20 – 42,000 rpm For HSK-E50 Tool Holder according to DIN 69893 AC Main Drive with 13/10 kW (40%/100% ED) Tool magazine with 60 positions Chain magazine with double gripper Active cooling unit for main spindle and linear drives Kedoyv Ap Hspfx Ab Telp Active cooling unit for control cabinet Direct absolute measuring systems including purge air Coolant/air cooling switch Renishaw laser tool measurement for measuring tool length and diameter incl. calibration mandrel with tool holder 3D quickSET Toolkit for checking and correcting the kinematic accuracy of 5-axis machine configurations (only in conjunction with optional probe) PP 60 optical infrared probe Electronic handwheel Application Tuning Cycle (ATC) software Selection of the optimal machining mode for the current operation 20-position pallet tower storage and transfer station Pallet size: UPC 320x320mm Loading door and air supply at the worktable Pallet management via machine control Including UPC-P chuck Four-color indicator light Air blower through the spindle center, selectable via M-function and softkey Maintained air with low oil content Dust extraction for graphite Rotating viewing window Operating mode 4 Process monitoring in production Laminated safety glass window

Condition: good (used), Year of construction: 1989, functionality: fully functional, Technical details x-travel 400 mm y-travel 390 mm z-travel 350 mm Control DIALOG4/CONTOUR 3 Kljdsyv Abvepfx Ab Top tool taper SK 40 spindle turning speed range 31 - 3150 U/min feed range 10 - 2000 mm/min weight of the machine ca. 1,7 t dimensions of the machine ca. 1.600 x 2.500 x 2.000 mm Additional information CNC control DIALOG4/CONTOUR 3 Table: 700 x 480 mm rigid angle table Swivel-type vertical milling head Coolant tank

Condition: used, Year of construction: 2012, x-travel 635 mm y-travel 510 mm z-travel 460 mm control SLIMline Siemens turning speed range - main spindle 20 - 12.000 min/-1 power capacity - main spindel 13 / 9 kW Torque 83 / 57 Nm tool taper SK 40 table surface area 790 x 560 mm number of T-slots 4 + 1 T-slot - width 4 x 14H12 / 1 x 14H7 mm T-slot - distance 100 mm max. table load 600 kg table height over floor 720 mm number of toolpositions 20 pos. max. tool diameter 80 mm Kljdpfsx S Rxnjx Ab Top max. tool-dia with free toolbox 130 mm max. tool length 300 mm max. tool weight 6 kg Total weight, approx. max. 60 kg feed speeds max. 20.000 mm/min rapid traverse 30 m/min total power requirement 17 kVA weight of the machine ca. 4,0 t dimensions of the machine ca. 4,5 x 4,0 x 2,8 m CNC-Machining Center Vertikal DECKEL MAHO - DMC 635 V Ecoline - only 9.290 Spindle-Hours

Condition: used, Year of construction: 2004, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, total height: 4,375 mm, total length: 12,300 mm, total width: 11,200 mm, table length: 1,600 mm, table width: 1,400 mm, table load: 3,500 kg, Equipment: documentation/manual, 5-axis CNC Universal Machining centre, simultaneous Control: Heidenhain iTNC 530 Table size: 1600x1400 mm Table load: 3500 kg Number of pallets: 2 x Maximum workpiece diameterxheight: 1950x1100 mm Movement X-axis: 1800 mm Movement Y-axis: 2000 mm Klodpjyu Twkjfx Ab Tjp Movement Z-axis: 1100 mm C-Axis table rotation: 360 ° B-Axis travel: -7 / 187 ° Spindle Speed: 18000 1/min Spindle taper: HSK-A63 Spindle motor: 28/19 kW Magazin capacity: 120 Required floor space: 11200x12300 mm Height: 4375 mm Weight: 58000 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: excellent (used), Year of construction: 2011, operating hours: 11,000 h, CNC controller: HEIDENHAIN iTNC530 Kledpfx Ajyv H I Heb Top X-axis travel mm: 450 Y-axis travel mm: 580 Z-axis travel mm: 400 C-axis degrees: 360° (0,001°) A-axis degrees: +10° -110° Worktable Table dimensions mm: 400x400 Max. workpiece weight kg: 200 Spindle speed rpm: 42.000 Tool holder: HSK-E50 Tool magazine slots: 60 Electronic Handwheel Infrared probe blowing air through spindle center selectable via M-function Signal lamp NC swivel rotary table 3D quickSET 20-position pallet tower storage and transfer station

Condition: good (used), Clamping surface of the fixed angle table: 195 x 605 mm Table travel longitudinal/vertical automatic and manual: 290/300 / 330/340 mm Spindle head transverse travel manual: 150 mm Spindle taper: ISA 40 Kljdpoyvgf Refx Ab Tjp 16 spindle speeds: 40 - 2000 rpm 16 feeds: 10 - 500 mm/min Spindle drive motor: 380 V, 1/1.4 kW Weight approx.: 660 kg Space requirement: 1200 x 900 x 1570 mm

Condition: ready for operation (used), Year of construction: 2009, operating hours: 35,295 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, total height: 3,200 mm, total width: 5,400 mm, table width: 900 mm, table length: 700 mm, table load: 1,400 kg, overall weight: 13,000 kg, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 48, product length (max.): 3,400 mm, swivel angle B-axis (min.): -29 °, swivel angle B-axis (max.): 180 °, swivel angle C-axis (max.): 360 °, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 80P duoBLOCK was manufactured in 2009. It features impressive axis travels with X-axis at 800 mm, Y-axis at 1050 mm, and Z-axis at 850 mm. The machine includes a robust table size of Ø 900 × 700 mm and a maximum workpiece weight capacity of 1800 kg. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 80P duoBLOCK vertical machining centre we have for sale. Contact us for further details. Kjdpfx Aboyvhfme Tjlp • Rotary axes: B-axis (tilting head) -30° to +180°; C-axis (rotary table) 360° continuous • Table size: approx. Ø 900 × 700 mm • Max. workpiece weight: approx. 1400–1800 kg • Spindle type: Vertical milling spindle • Coolant through spindle (CTS): yes • CE compliant • Condition: Very good working condition; full service history available Technical Specification Taper Size SK 40 Through-spindle Coolant Yes

Condition: good (used), Please read the technical specifications carefully. If the machine is of interest to you as an investment, we kindly ask that you provide full identification, including a correct phone number and email address, when requesting an offer. DECKEL Milling Machine Toolroom Milling Machine DMU 35 M 3 x 2 axes CNC Milling Machine With SIEMENS 810 D – ShopMill software Year of manufacture: 2001 and 2003 (2 units available) Travel distances (X/Y/Z): 350 x 240 x 340 mm Klodpjxz Rdaefx Ab Tep Spindle speed, stepless: 20 – 6,300 rpm Spindle taper: SK 40 DIN 69871 Clamping bolt: DIN 69872 Drive power: 6.3 / 10 kW (100/40% duty cycle) Torque: 55 / 80 Nm max. Universal swivel/rotary table: 400 x 290 mm Table load: 100 kg Distance spindle nose/table: min./max. 145 / 485 mm Feed rates: 3,000 mm/min Rapid traverse: 5,000 mm/min Input resolution: 0.01 mm Rotary axis range: 360 degrees Swivel range: degrees Total power consumption: kVA Weight: approx. 1,750 kg Technical data subject to change! Accessories/Equipment: - Direct measuring system for 3 axes - Spindle drive via servomotor with toothed belt - 2 gearbox stages - Fully enclosed guard cabin with sliding door - Swiveling control panel - Coolant nozzles at the vertical head - Coolant system - Chip tray with coolant tank - Electronic handwheel - Machine feet - Machine light - Serial RS232C interface, LAN (RJ45) The machine is perfectly suited for prototyping, toolmaking, training, mechanical workshops, gunsmiths, etc. Its outstanding universal capability is thanks to the additional manually operated rotary/swivel table, which allows 5-sided machining. Condition: Good to very good, from a vocational training center, see photos. Can be inspected under power.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 79,500 h, functionality: fully functional, machine/vehicle number: 11710000713, travel distance X-axis: 700 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 700 mm, controller model: HEIDENHAIN iTNC 530, workpiece weight (max.): 600 kg, The machine spindle was replaced according to DMG in 2022. A measurement protocol for the machine is included! TECHNICAL DETAILS Travel X-axis: 700 mm Travel Y-axis: 700 mm Travel Z-axis: 700 mm Spindle speed: 18,000 rpm Spindle torque: 110 / 84 Nm Spindle power: 34 / 28 kW Tool holder: SK 40 Tool changer: 180 positions Pallet size: 500 x 500 mm Max. workpiece weight: 600 kg Rapid traverse: 60 m/min MACHINE DETAILS Control: HEIDENHAIN iTNC 530 Total connected load: 68 kVA Dimensions & Weight Space requirements: 9.5 x 7.5 x 3.4 m Machine weight: 10.5 t Operating Hours Kledpfoyvp Dkjx Ab Tjp Spindle hours: 79,500 h Power-on hours: 112,000 h EQUIPMENT NC rotary table RS 10 pallet rotary storage, total of 12 pallet stations iTNC operator panel for the loading station ICS 40 bar (production package) Through-spindle air blast BA 4 2/4 hydraulic clamping for worktable and set-up station BLUM laser (prepared) Oil mist separator TS 649 probe Mechanical tool breakage detection SDS (Spindle Diagnostic System) Rinse gun Electronic handwheel Chip conveyor

Condition: used, Year of construction: 1981, weight of the machine ca. 1.700 kg Klsdpfxsyv Nite Ab Top dimensions 2000 x 1000 x 1950 mm

Condition: used, x-travel 390 mm y-travel 190 mm z-travel 390 mm table surface area 740 x 255 mm spindle turning speed range 40 - 2000 U/min spindle taper ISO 40 feeds 8 - 400 mm/min rapid traverse 1200 mm/min Kedjyv Ngfepfx Ab Tslp total power requirement 2,2 kW

Year of construction: 2001, condition: used, Technical details: x-travel: 400 mm Ksdpeikbtnefx Ab Tjlp y-travel: 300 mm z-travel: 500 mm table clamping surface:: 400 x 300 mm table load: 50 kg semi-automatic operated: LASERSOFT 3D laser capacity: 100 W total power requirement: 27 kVA weight of the machine ca.: 2,5 t dimensions of the machine ca.: 3 x 3,5 x 2,8 m CNC engraving/texturing/labeling/contouring-laser maschine, approx. 9.000h "machine on", approx. 5.500h "laser on" *

Condition: reconditioned (used), Year of construction: 2011, CNC Vertical Machining Center DECKEL MAHO DMF 260 linear, NEW DMG Design With Siemens 840 D path control with Shop Mill Year of manufacture: 2011 Travel distances: X 2600 mm Y 700 mm Z 700 mm Spindle speed range: 20 – 14,000 rpm, stepless (SK 40) Including the following accessories: Kledpjyvvlnofx Ab Tep - Rigid angle table, 2920 mm x 750 mm clamping area - Controlled swivel milling head (B axis) - NC rotary table by Hofmann with tailstock, center height: 200 mm - Vertical tool changer with 40 magazine slots (SK 40) - Electronic handwheel - Full enclosure with sliding doors and interior lighting - Coolant high pressure system, 40 bar - Chip conveyor - Operating modes 3 + 4 - 2 x Rotoclear (rotating viewing window) - Partition wall - Coolant system - RITTAL control cabinet cooler - 4 height-adjustable machine feet - Operating manual

Condition: used, Universal Tool Milling Machine with Digital Readout DECKEL Type FP 1 Universal Milling Machine Machine No.: 2102 - 3322 Year of manufacture: 1986 Travel range X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Kedpfx Abjr D T Uye Tslp Spindle mount: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed rate: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.6 and 2 kW, pole-changeable Power supply: 380 Volt, 50 Hz - 3-axis active digital readout HEIDENHAIN Type TNC 113 - Infinitely variable feed on X, Y, and Z axes - Spindle speed selectable via 2 motor speeds and 8 gearbox steps - Quill movement on vertical milling head: 60 mm - Vertical milling head swivels and is extendable by 100 mm horizontally - Fixed angle table 600 x 210 mm - Coolant system integrated in machine base - Separate electrical cabinet - Original chip tray for mounting on the machine base - Operating manual, electrical diagram, spare parts list included Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 830 kg Good condition

Condition: used, Year of construction: 2004, Technical details: Kedpfxewzx Nmj Ab Tolp x-travel: 750 mm y-travel: 600 mm z-travel: 520 mm table surface area: D 700 x 500 mm turning speeds: 42.000 1/min tool taper: HSK E50 control: HEIDENHAIN iTNC 530 tool change unit: 60 pos. rapid traverse: 50 m/min table load capacity - central/maximum: 350 kg total power requirement: 50 kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 3,2 x 2,65 x 2,8 m 5-axis simultaneously HSC-machining center, NC-round-swivelling table B-axis 180°, C-axis 360°, chip conveyor, el. handwheel, laser, prepared for 3D touchprobe HEIDENHAIN TS 641 (without touchprobe), mode 4, oilmist suction, spindle chiller, no internal coolant supply, approx. 141.300 hours "machine on", approx. 64.500 hours "spindle on" in total machine in good condition (test report available) *

Condition: excellent (used), Year of construction: 2008, operating hours: 40,255 h, functionality: fully functional, For sale is a DMG DECKEL MAHO DMF 220 linear, a 5-axis universal travelling-column machining center. The machine was built in 2008 and was modernized / totally retrofitted in 2022 with Siemens Sinumerik 840D Solution Line control. Equipped with 5-axis simultaneous machining license, Siemens Sinamics drive technology, Siemens OP15 Black Operator Panel, MCP control panel and electronic handwheel. Technical data: Manufacturer: DMG DECKEL MAHO Type: DMF 220 linear Machine type: 5-axis universal machining center / travelling-column machining center Year of manufacture: 2008 Control: Siemens Sinumerik 840D Solution Line Modernization / Total Retrofit: Siemens CNC / drive modernization in 2022 5-axis simultaneous operation: License available Serial number: 15115223244 Machine number: 2499093 Travel X: 2,200 mm Travel Y: 560 mm Travel Z: 720 mm Tool taper: SK 40 Table load: 2,500 kg Main spindle speed range: 20 - 14,000 rpm Connected load: 80 kVA Max. rated current: 115 A Fuse protection: 125 A Supply voltage: 400 V Frequency: 50 Hz Kedpfeyuzg Hex Ab Tjlp AC control voltage: 230 V DC control voltage: 24 V Power-on hours: approx. 40,255 h Spindle / working hours: approx. 13,082 h CNC / drive technology: X-axis: Siemens Sinamics 160 A, 2 x SMC20 encoder module Y-axis: Siemens Sinamics 50 A, 2 x SMC20 encoder module Z-axis: Siemens Sinamics 80 A, 2 x SMC20 encoder module B-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module A-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module Spindle axis: Siemens Sinamics 26 kW, 2 x SMC20 encoder module Operator panel: Siemens OP15 Black Operator Panel MCP control panel: Siemens Electronic handwheel: Siemens Magazine technology: Magazine A: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine B: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine C: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Software / licenses: 5-axis simultaneous machining license Axis licenses Operator software license Equipment: Integrated swivelling table / trunnion-type table setup Paper band filter unit Coolant / filter unit Electrical cabinet Full enclosure Working area lighting Siemens control panel Condition: Machine in well-maintained condition Modernized Siemens control and drive technology 5-axis simultaneous machining available

Condition: used, Year of construction: 1985, x-travel 710 mm y-travel 600 mm z-travel 500 mm NC-rotary table 630 mm spindle taper SK 40 spindle turning speed range 18 - 6300 U/min control DIALOG 4 feed 2 - 3600 mm/min rapid traverse 6 m/min table load max. 485 kg quill stroke 80 mm spindle drive 9,5 kW total power requirement 20 kVA weight of the machine ca. 4,6 t Kodpfx Ajtqqtbeb Tjlp dimensions 3,8 x 2,24 x 2,35 m Accessories: vertical head with hydr. tool clamping and quill retraction, electron. handwheel, coolant

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm Kodpfx Aotqqlleb Tjlp z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Condition: used, Year of manufacture: 1980s Technical data: Travel X/Y/Z: 400 / 400 / 400 mm Tool holder: SK 40 Speed range: 40 - 4000 rpm Feed, stepless adjustable: 2 - 360 mm/min Rapid traverse: 4000 mm/min Swivel table: 700 x 460 mm, max. load 350 kg Tool changer: Number of tools: 20 Max. tool diameter: 80 mm Max. tool length: 300 mm Max. tool weight: 6 kg Equipment: - Control: CNC path control Deckel Dialog 11 Kledpfoyfrf Iox Ab Tjp - Hydromechanical clamping system SK 40 with drawbar according to DIN 69872 - Vertical and horizontal working spindle - Milling head manually swivels +/- 90° - Geometrically stepped direct drive for maximum torque - Milling performance at the working spindle

Condition: used, Year of construction: 1982, x-travel 300 mm y-travel 160 mm z-travel 340 mm feeds -stepless- 5-500 mm/min rapid traverse 1200 mm/min spindle turning speed range 40 - 2000 U/min tool taper Normkegel 40 table length 600 mm table width 120 mm Kljdjvvnfuepfx Ab Tep voltage 380 V frequency 50 Hz rated current 13 A weight of the machine ca. 0,750 t dimensions of the machine ca. 1,8 x 1,5 x 1,8 m DESCRIPTION Machine incl: active three-axis digital readout HEIDENHAIN documentation various tool holders Machine vice etc.

Condition: ready for operation (used), functionality: fully functional, Specifications Kedpfxsytfbxe Ab Tjlp Manufacturer: Deckel Model: SOE Condition: Used Stock number: 00662

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, feed length X-axis: 300 mm, feed length Y-axis: 160 mm, feed length Z-axis: 340 mm, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 340 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, Deckel FP1 milling machine with Heidenhain TNC113 digital readout in very good condition. Technical specifications: Year of manufacture: 1989 Machine no.: 2102-5533 * Speed: 40 - 2000 rpm * Infinitely variable feed on 3 axes * Rapid traverse on 3 axes * Spindle brake Ksdeytcarepfx Ab Telp * Table movement X/Y/Z: 300/160/340 mm * Vertical milling head can be adjusted 100 mm on the spindle block * Vertical quill * Drawbar system SK40/M16 * Weight approx. 800 kg Accessories and equipment: 3-axis digital readout Heidenhain TNC113 Coolant system Central lubrication Operating manual, spare parts diagram
