Used External Grinding Machine for sale (67,460)

Condition: used, Year of construction: 1984, Technical details: grinding diameter min/max: 8 / 40 mm number of spindle speeds: 3000 U/min total power requirement: ca. 1,2 kW weight of the machine ca.: 0,24 t dimension machine xH: 0,7 x 0,9 x 1,3 m The grinding spindle is equipped with two hand levers: Working range left = manual grinding device for small shank drills. working range right = swiveling device of conical shank drills cutting angle max 180 Drill swivel arm small: clearance angle 5° - 9°; drill Ø 8 - 15mm manually adjustable; grinding wheel cup wheel Ø 200 x 40mm with holder Ø 32mm Drill swivel arm large: clearance angle 5° - 9°; drill Ø max 400mm; pitch 6x with index grid manual; grinding wheel currently clamped Ø 180 x 31mm with receptacle Ø 32mm Grinding modes: Normal grinding, DK grinding, center grinding, spiral countersink, multiple step drill. Fjdpfju Ng Irjx Afnjfu *

Condition: used, Year of construction: 1982, Technical details: dimensions of grinding wheel: Ø 150 x 20 mm grinding spindle speed: 3600 U/min height over floor: 900 mm current type: 220 V machine weight approx.: 27 kg dimensions L x W x H: 0,37 x 0,35 x 1,4 m Ffodpfou Ngxdox Afnou Double sanding bench sitting on foot stand (foot Ø 353mm) Left side with drill grinding device (angle 90° - 180°), longitudinal adjustment 25mm incl. accessories *

Condition: used, Technical details: grinding length: 300 mm Fedpovc Aw Sjfx Afnefu centre height: 175 mm swing diameter: 315 mm table clamping surface LxW: 1.800 x 200 mm control: Heidenhain Longitudinal adjustment of grinding unit on table max.: 1100 mm work piece spindle speed: 3steps/1500-2200 U/min feed continuous: 0,001-1 mm Max. travel x-axis: 300 weight of the machine ca.: 3,1 t dimension machine xH: 2,9 x 1,6 x 1,4 mm Swivel for right and left machining Automatic table reversal Tailstock: MK3 holder Operation: Manual control unit/foot switch Coolant: System with feed Heidenhain measuring device *

Condition: used, Cup Surface Grinding Machine / Cylinder Head Grinding Machine Max. grinding area approx. 550 x 250 mm Electromagnetic clamping plate 500 x 200 mm Machine dimensions (L x W x H): 2070 x 900 x 1600 mm Ffsdpfx Afewlbz Tsnou Machine weight: 1000 kg Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: like new (used), Year of construction: 2019, Horizontal surface grinder in almost new condition with few operating hours! Operating hours: see image PC control Okamoto Travel X-axis: 600 mm Travel Y-axis: 22.5 - 497 mm Travel Z-axis: 400 mm Speed range rpm: 1-2800 (stepless) Rapid traverse mm/min: 4000 Main drive kW: 7.5 Maximum table load in kg: 1000 Accessories: - Electro-permanent magnetic clamping plate: 400 x 600 P13 mm, height 80 mm (make Wagner) - 2 grinding wheel flanges Ffodpfx Afoyhdqusneu - Table dresser - Automatic straight dresser, spindle box mounted - Automatic compensation of the wheel dressing amount - Automatic central lubrication - Ball screw in the Y and Z axes with AC servo motor and measuring system - Coolant system with belt filter system grinding length 600 mm grinding width 400 mm workpiece height 400 mm weight of the machine approx. 4,5 t dimensions of the machine approx. 3400 x 2647 x 2203 mm

Condition: used, Year of construction: 2021, width of the strips 150 mm Ffedsyfwznspfx Afnsu band length 2000 mm band speed 45 m/s total power requirement 4 kW weight of the machine ca. 275 kg dimensions of the machine ca. 1450 x 1260 x 900 mm The AL150HS is a 2-in-1 machine: Belt sander and pipe grinder at the same time. Technical data: - Adjustable sanding angle: 20° - 90° - Grinding diameter: 20.0 / 114.3 mm

Condition: used, Cylindrical Grinder. VEB SA 200x800, Használt gép Manufacturer: VEB, WMW Werkzeugmaschinen GmbH Model: SA 200x800 Overall Dimensions: 3070 x 1480 x 650 mm Year: 1960 Weight: 4.1 t Ffedpfx Aexx Sixefnsu Grinding Wheel Diameter: 400 x 15 mm Center Distance: 800 mm Table Size: 1000 x 200 mm Electrical Data: 380 V; 15 A; 6 kW

Condition: used, Surface grinder, TOS Hostivař BPH 300, Used machine Manufacturer: TOS Hostivař Type: BPH 300 Overall dimensions: Ffjdpsxxk Dusfx Afneu Width: 3030 mm Depth: 1670 mm Height: 2160 mm Electrical data: 3×380V; 50Hz Table size: 1000 × 300 mm Maximum grinding width: 300 mm Maximum workpiece height: 350 mm Max. table load: 2745 N – approx. 275 kg Grinding wheel (diameter × width × bore): 250 × 25 × 76 mm Minimum grinding wheel diameter: 120 mm Longitudinal table stroke: 1060 mm Cross table stroke: 350 mm Vertical travel of the grinding head: 420 mm Machine weight: approx. 3000 kg Accessories: Coolant system Table-mounted magnetic chuck (1000 × 300 mm)

Condition: used, The HFS 4080B C is a robust Conventional Surface Grinder designed for precision in toolmaking, repair shops, and training environments, making it a reliable choice in the Grinding Machines category. With its heavy cast-iron machine frame, this grinder offers a torsion-proof structure that enhances stability during operation. The dual V-guides for transverse motion, combined with box ways for linear motion, ensure high precision during machining processes. The large 400x800 mm table and a travel X-axis of 850 mm accommodate heavy workpieces effortlessly. Features such as the dynamically balanced grinding spindle with preloaded precision bearings guarantee excellent performance and longevity. Additionally, the user-friendly 2-axis position indicator allows for precise grinding wheel placement and boosts productivity through automatic spark-out strokes. This gentle yet efficient operation ensures minimal heat build-up and consistent results, making the HFS 4080B C a reliable choice for any workshop. You can order now to enhance your machining capabilities with this high-performance grinding solution from KNUTH. Ffodpfx Aeuxpumefnsu

Condition: used, Year of construction: 1989, Used machine Year of manufacture: 1989 Equipment and technical data: - The conveyor belt integrated into the table is driven by a geared motor. - The built-in dial gauge on the handwheel and at the front of the table allows for precise monitoring of material removal. - The machine is designed on the principle of thickness reduction (thickness planing), which means uniform material removal and grinding accuracy to within 0.1 mm. - Optimal grinding pattern thanks to the oscillating sanding belt. - No belt misalignment due to pneumatically controlled oscillation. Fsdpsygbpxofx Afnjfu - Sanding belt length: 1600 mm - Sanding belt width: 200 mm - Table length: 1000 mm - Working height: 120 mm - Drive motor: 5.5 kW Availability: short-term Storage location: Flörsheim

Condition: used, Year of construction: 1979, Technical details: grinding diameter min/max: Aufnahme: Ø 200 x 32 mm number of spindle speeds: 3000 U/min total power requirement: ca. 1,2 kW weight of the machine ca.: 0,24 t dimension machine xH: 0,7 x 0,9 x 1,6 m The grinding spindle is equipped with two hand levers: Working range left = hand grinding device for small shank drills, grinding wheel currently Ø 120 x 30mm; admission=Ø 32mm; speed 3000 rpm.; with grinding support Working range right = swiveling device for conical shank drill; cup grinding wheel currently Ø 160 x 30mm; admission=Ø 32mm; speed 3000 rpm. Cutting angle max 180° for double-edged and 120° for triple-edged Ffedpfxju Ng Nco Afnju Clearance angle 5° - 9°; drill-Ø 8 - 40mm, possible grinding modes e.g.: normal grinding, DK-grinding, center grinding, spiral grinding, step drill grinding Machine illumination available *

Condition: ready for operation (used), functionality: fully functional, External cylindrical grinding machine Manufacturer: SCHAUDT Ffodpfxjyfm S No Afnju Max. grinding length: approx. 1000 mm, max. grinding wheel diameter: approx. 600 mm Swiveling grinding spindle unit Equipped with coolant system, machine lamp, and fleece filter unit

Condition: excellent (used), Year of construction: 2008, X/Y/Z travel: 900 x 400 x 200 mm Table size: 800 x 400 mm Fedpov Irwrsfx Afnjfu

Condition: excellent (used), Year of construction: 1973, Grinding length 500 mm Grinding width 230 mm Table size 760 x 200 mm Ffedpfx Ajwn Tdxjfnju Automatic feed Magnetic chuck Filtration system

Condition: excellent (used), Year of construction: 2013, Siemens Sinumerik 840D control Max. workpiece diameter: 250 mm Max. workpiece length: 1500 mm Max. workpiece weight: 150 kg Internal grinding device Paper band filter Centre tip Fjdpowwtq Djfx Afnsfu Diamond dressing plate Grinding wheel change assist

Condition: good (used), Year of construction: 1974, Digital display Ffjdpfxjwpya Ns Afnsu Grinding diameter 250 mm Grinding length 650 mm Accessories

Condition: ready for operation (used), Year of construction: 1977, functionality: fully functional, grinding length: 700 mm, grinding width: 550 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 475 mm, TECHNICAL DETAILS X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 475 mm Manual grinding area Length: 700 mm Width: 550 mm Height: 400 mm Automatic grinding area Length: 700 mm Width: 470 mm Height: 400 mm Table size: 1,100 x 500 mm Fodpfx Afjyf Ahmjnofu Maximum workpiece height: 400 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,000 x 1,960 x 2,550 mm Machine weight: 3,300 kg EQUIPMENT Operating manual

Condition: used, Year of construction: 1992, Technical details: Fedpfor R Ek Sex Afnsfu grinding diameter: 50 mm grinding length: 100 mm centre height: 100 mm centre distance: 200 mm

Condition: used, Year of construction: 2005, Technical details: Fodpfx Afjvap Ryonsfu grinding length: 400 mm workpiece weight: 250 kg weight of the machine ca.: 4,1 t swing diameter: 250 mm grinding spindle speed: 2387, 2938 U/min

Condition: used, Year of construction: 1989, Technical details: Ffedpfxer R Elpj Afnsu grinding diameter: 300 mm grinding length: 540 mm centre height: 175 mm total power requirement: 20 kVA centre distance: 1000 mm

Condition: used, Year of construction: 2014, Technical details: grinding diameter max.: 3-220 mm regulating wheel width: 500 mm max. width of grinding wheel: 500 mm weight of the machine ca.: 16 t. dimensions of the machine ca.: 12 x 10 x 8 m. grinding wheel diam. min/max.: 420-610 grinding wheel diameter - width-internal grin: 304,8 x 500 mm Regulatin wheel diameter min/max.: 300-350 mm The machine is currently designed for plunge grinding JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls. Fjdpfx Aet Uw Avjfnsfu *

Condition: excellent (used), functionality: fully functional, KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE MODEL: 1000 U YEAR OF MANUFACTURE: 2000 PARTIAL OVERHAUL: 2026 Centre height: 175 mm Fodpfoyf E Suex Afnefu Grinding length: 1000 mm Equipment: - Standard accessories - Standard workpiece headstock MK5 with adapter flange DIN 55027, size 5 - Splash guard hood for the above - Tailstock with fine adjustment, MK4 - Internal grinding attachment with protective cover for grinding spindle D:80 mm for belt-driven spindles - FISCHER internal grinding spindle type HJN 842, incl. grinding mandrels (4 pieces, choice) - HJNZ 42 collet chuck - Oil mist lubricator for HJN spindles - STREULI magnetic paper band filter system, type: SPB 2 - Coolant supply through the workpiece spindle - HEIDENHAIN digital length measuring system on X and Z axes - Sine bar on the workpiece headstock incl. alignment arbor MK5 - Permanent magnetic chuck, D:200 mm - Three-jaw chuck, D:160 mm - Four-jaw chuck, D:160 mm - Collet attachment for Schaublin collets B32 - Set of B32 collets, D: 1.0–30.0 mm, increment 0.5 mm (59 pieces) - Dial indicator stop for table swivel with indicator 0.01 mm - Table fixed stop - Dressing stop for internal grinding - LED machine lamp - Various grinding wheel flanges, left (2 pieces) - Pneumatic table load relief - Swiveling dressing device for external, face, or internal grinding operations - Set of vibration damping pads - New three-color paint finish (light grey RAL 7035 / blue RAL 5012 / dark grey RAL 7016) - New acceptance protocol according to KELLENBERGER standard - Documentation - CE conformity The machine is currently being overhauled, sample photos shown!

Condition: used, Year of construction: 2015, control Grind-X weight of the machine ca. 2900 kg Ffjdpfxjyiu Sxe Afnou

Condition: good (used), Year of construction: 1990, Thread cutting machines with accessories Ffjdpovk D Rpsfx Afneu Manufacturer SONE Type: 2000 . 230V .

Condition: good (used), Year of construction: 2000, CNC surface and profile grinding machine Fabr.Ziersch & Baltrusch Type:PROFITLINE ZB 62 NC Year of manufacture.2000 grinding range : 600X270mm Electromagnet with continuous transverse pole pitch 600X200mm. P = 4 mm Ffsdpfxjfrbcks Afnou Wet grinding device, with automatic paper belt filter, machine trough. Complete machine documentation available.
