Used Ferromatik 250 for sale (10,161)

Condition: good (used), Here we offer you an Indramat main spindle unit. Indramat RAC 2.2-250-380-A01-W1 main spindle unit Type: 2.2-250-380-A01-W1 Scope of delivery: (See image) 2-week commissioning guarantee The unit comes from a warehouse clearance. We also offer express shipping (DHL, UPS, TNT). We will gladly answer any further questions you may have by phone. Ljdpfezdqvbjx Al Tehh Written orders can be placed by email or fax.

Condition: good (used), Year of construction: 2013, chuck outer diameter: 250 mm, through hole: 100 mm, Metal cutting Tooling CBT - 250 MACH-ID 2996 Make: CBT Type: 250 Year: 2013 Diameter: 250mm 3 Chuck: x Spindle bore:100mm Lhjdpfx Alezdiiho Toh Connector: 70 Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 1999, chuck outer diameter: 250 mm, through hole: 75 mm, Metal cutting Tooling ROHM - 250 MACH-ID 2997 Make: ROHM Type: 250 Year: 1999 Diameter: 250mm 4 chuck: x Spindle bore:75mm Lhsdpfxjzdih Do Al Toh Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), !!!DEMO MACHINE!!! For sale is a Felder FD-250 slot drilling machine with a maximum drilling depth of 160 mm. The machine is in very good condition and has been refurbished and inspected by our qualified technicians. (Fully functional) Technical specifications: - Drilling height adjustment with handwheel: 130 mm - Table size: 550 x 300 mm (expandable with table extensions) - Drilling length: 250 mm Lodpozgr Drofx Al Tjhh - Drilling depth: 160 mm - Clamping device and 90° stop - 3 HP (2.2 kW) motor, 400 volts The machine is located in A-8561 Söding and can be inspected and collected at any time during our opening hours. Subject to prior sale! Related terms: Bench drill, drilling machine, drill, slot, drilling Reference: R-D1618

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2014. It features a powerful main spindle drive with 18kW and a speed range of 0-4500 rpm. Equipped with a Siemens SINUMERIK 840Dsl control system and a robust 12-position EMAG flange turret, it ensures precise and efficient operations. Ideal for handling workpieces up to 6kg with its specialized hydraulic chuck. For more information about this vertical turning machine, please reach out to us. Additional equipment, not included • Coolant tank capacity: 360 liters Machine Benefits Technical Machine Benefits Lhodpjytfppofx Al Tsh • High working accuracy, rapid traverse speeds, high maximum speed of driven tools • Machine from single shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78db(a) Extra Information Machine still under power Technical Specification Through-spindle Coolant Yes Dimensions Machine Depth 3900 mm

Condition: used, Year of construction: 2004, turning diameter 250 mm swing diameter 250 mm turning height 250 mm Control Siemens Sinumerik 840 D total power requirement 60 kW Lhedpfx Alszdvgfs Tjh weight of the machine ca. 9 t

Condition: used, Year of construction: 2011, controller manufacturer: Fanuc, controller model: 30i, _____ Description: Year of manuf. : 2011 Control : Fanuc 30i In General: Year of manufacture:2011 Control system:Fanuc 30i Maximum table load:100 kg Travel range X/Y/Z:300/300/370 mm Installation weight:approx. 33,000 kg Machining station I (X/Y/Z/B): Technology:1 x vertical spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station II (X/Y/Z/B): Technology:1 x vertical spindle + 1 x horizontal spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station III (X/Y/Z/B): Technology:1 x vertical spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station IV (X/Y/Z/B): Technology:1 x vertical spindle + 1 x horizontal spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Loading station: Numbers:2 pieces (front and rear) Equipment: Position measurement systems:Direct on all axes Chip removal:Chip conveyor Coolant supply:IKZ system, 30 bar Tool breakage monitoring:Artis, type CTM V5 Zero-point clamping system:Erowa Emulsion mist separator:Reven Lodpjzfu Rfsfx Al Tohh

Condition: new, Material number 16 Cr Mn 5 Lhodpfx Asb Rmx Hjl Toh Width of centering groove: 32 mm Length: 90 mm Width: 60 mm Height: 54 mm

Condition: excellent (used), Faceplate chuck Ljdpjf Dx Skofx Al Tshh Diameter 250 mm Clamping range: 120 - 200 mm Max. speed 3500 rpm Weight 30 kg

Condition: good (used), Year of construction: 2002, Make: PLEIGER Type: HF 75 / 115 S 30 Control: Siemens Simatic panel Year: 2002 Ljdpfx Aokvnc Sjl Tohh Stroke speed slide step 1 : 4 - 20 M/Min Stroke speed slide step 2 :0,3 - 3 M/Min Rotation chuck step 1 : 300 Rpm and 320 Nm Rotation chuck step 2: 100 Rpm and 1290 Nm Horizontal deep hole honing machine Horizontal tube honing machine Horizontal cylinder honing machine Horizontal pipe honing machine Fine finishing of cylindrical bores Specifications Metric US Standard Drilling depth 11500 mm Power on spindle 55 kW Speeds / ranges 300 Rpm Dimensions (Estimate) Length 25000 mm Width 2000 mm Height 2000 mm Weight 30000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 2011, operating hours: 38,546 h, travel distance X-axis: 745 mm, travel distance Z-axis: 300 mm, spindle motor power: 18,000 W, spindle speed (max.): 4,500 rpm, total height: 3,200 mm, total width: 1,500 mm, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840Dsl with integrated PLC S7-300, positioning accuracy: 1 mm, product length (max.): 3,900 mm, number of slots in tool magazine: 12, number of axes: 2, This EMAG VSC 250 vertical turning machine was manufactured in 2011. It features a Siemens SINUMERIK 840Dsl control system, a robust hydraulic 6-jaw chuck, and a flange turret with 12 tool positions. With a spindle speed up to 4500 rpm and a main spindle drive power of 18kW, it's ideal for precise, efficient operations. For more information about this vertical turning machine, please reach out to us. Additional equipment, optional • Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication • 15-inch TFT monitor • V24 interface Machine Benefits Ledpfx Aey Ehckjl Tjhh Qualitative Machine Benefits • Machine from single-shift operation • Maximum room temperature: up to 30°c • Maximum humidity: 50% • Sound pressure level: 78 db(a) • 2nd unit with yom 2014 available Technical Machine Benefits • Spindle torque: 300 nm • Vdi shaft diameter: 40 mm • Maximum speed of driven tools: 6000 rpm • Maximum torque of driven tools: 40 nm / 8. 5 kw • Coolant system standard delivery pressure: 7 bar maximum delivery pressure: 7 bar internal coolant supply pressure range: 7 bar (non-adjustable) coolant tank capacity: 360 liters • Chuck model: 6agf 260 k6 k14 • Chuck diameter: 260 mm • Chuck weight: 57 kg • Maximum clamping force for internal clamping (50 bar): 12. 8 kn • Maximum clamping force for external clamping (50 bar): 4. 2 kn Extra Information Machine still under power Dimensions Machine Depth 3900 mm Technical Specification Driven Tools Yes

Condition: used, functionality: fully functional, total height: 6,300 mm, total width: 1,580 mm, total length: 2,680 mm, load capacity per storage section: 250 kg, input voltage: 415 V, warranty duration: 12 months, Equipment: documentation/manual, safety light barrier, KARDEX SHUTTLE 250 - 1250X825-NT GREY IN COLOUR 45 TRAYS TRAY DIMENSIONS 1250MM X 825MM AUTOMATIC HEIGHT ADJUSTMENT FOR TRAYS WHEN ENTERING MACHINE 12 MONTHS WARRANTY Lhodpfowtqz Eox Al Tjh SERVICE & MAINTENANCE CONTRACTS AVAILABLE THESE MACHINES ARE MODULA AND CAN THEREFORE BE REDUCED IN HEIGHT TO FIT INTO ANY HEIGHT RESTRICTIONS

Condition: used, functionality: fully functional, machine/vehicle number: 250-1850X825, total height: 6,300 mm, total width: 2,030 mm, total length: 2,680 mm, load capacity per storage section: 250 kg, input voltage: 415 V, warranty duration: 12 months, Equipment: safety light barrier, KARDEX SHUTTLE 250-1850X825-NT 1 AVAILABLE GREY IN COLOUR Lodpswtqxdsfx Al Tshh TRAY WEIGHT 250KG NUMBER OF TRAYS 45 TRAY DIMENSIONS - 1850mm x 825mm AUTO ADJUST TRAY HEIGHT PER TRAY 12 MONTHS WARRANTY SERVICE & MAINTENANCE CONTRACTS AVAILABLE THESE MACHINES ARE MODULA AND CAN THEREFORE BE REDUCED IN HEIGHT TO FIT ANY HEIGHT RESTRICTIONS

Condition: used, Year of construction: 2008, screw size 18 mm closing pressure 250 kN opening stroke max. 350 mm mould space 200 mm control Selogica Number of working hours 52.492 h weight 2030 kg ARBURG ALLROUNDER 270 S 250-70 – Injection Molding Machine – Year ofManufacture: 2008 – Excellent Condition Interface for robot systems in accordance with EUROMAP 67 available A reliable and proven ARBURG ALLROUNDER 270 S 250-70 injection molding machine, manufactured in 2008, is for sale. The machine is ideal for producing precise plastic parts in small to medium-volume production runs and impresses with its robust construction and the renowned ARBURG quality “Made in Germany.” Technical Highlights: - Clamping force: 250 kN - Injection unit: Size 70 Ljdpfsywzv Iex Al Tehh - Screw diameter: approx. 18–25 mm - Injection pressure: up to approx. 2,500 bar - Column spacing: approx. 270 x 270 mm - Platen size: approx. 380 x 380 mm - Connected load: 53 kW Electrical specifications: - Operating voltage: 400 V / 50 Hz - Control voltage: 230 V / 24 V - Total current consumption: 89 A Additional information: - Year of manufacture: 2008 - Manufacturer: ARBURG (Germany) - Machine is robust, durable, and easy to maintain - Ideal for technical plastic parts and precision applications Advantages: - Proven SELOGICA control system (standard for this series) - Compact design - High process reliability - Long-term availability of spare parts guaranteed Viewing available by appointment. Additional information, photos, or videos available upon request. - Operating hours: 52,492 hours, 7,085,048 cycles - Centring ring mounts: ø125 mm - Blowing unit fitted

Condition: used, Year of construction: 2006, Nominal volume flow: 4900 m³/h. Minimum volume flow: 3532 m³/h. Intake nozzle: 250 mm. Static pressure at Vmin: 2740 Pa. Air pressure connection: 8.5 bar. Motor: 6.5 kW. Storage location: Nattheim. Lsdpfx Aljzd An Nj Tjhh

Condition: used, operating hours: 16,911 h, Vehicle No.: 407-25 HITACHI ZX 250 LCN-3 Year of manufacture: 2008 * 132 kW * Hammer circuit Ljdpfx Ajzc Airjl Tshh * Quick coupler * Cabin protective grille * Undercarriage approx. 70% Inspection possible at any time during our business hours, test drive by appointment! For export sales, a deposit will be retained and refunded upon receipt of the confirmation of arrival. Company logos or advertising markings on the vehicles may have been digitally edited in the photos. No guarantee is given for the functionality of the extras. All information is provided without guarantee - subject to errors, changes, typographical mistakes and prior sale. Vehicle descriptions explicitly do not constitute guaranteed characteristics. We refer to our General Terms and Conditions, which must be acknowledged.

Condition: used, The machine is suitable for the agglomeration of thermoplastic films and fibres. The throughput can be estimated to be 500 kg - 1000 kg/h, depending on the material, its condition and humidity. The system consists of: • conveyor belt • load-dependent control for the belt conveyor. • metal detector • HERBOLD granulator type SMS 45/100-H5-3 • pneumatic material transport to the storage silo • plastcompactor unit HV-70 (consisting of a storage silo feeding screw, plastcompactor, central blower, cooling circuit) • HERBOLD secondary granulator type SML 45/100-S4-2 • intensive cooling • SZS II 630/200 conveying fan Lhjdpfxezdd Avs Al Teh • screening machine, undersize grain will be returned into the compactor silo. • material conveyor type MFT with big bag station and automatic switchover to the on-site silo • automatic exhaust air filter • electrical control unit • compressor.

Condition: excellent (used), Vötsch Vötsch Industrial Tempering Oven VTL 200/250/225 250°C 11.25 m³ 58 kW – Heating Cabinet Description: For sale is an industrial tempering oven / heating cabinet manufactured by Vötsch Industrietechnik GmbH. This unit is ideally suited for industrial tempering, drying, and heat treatment processes. The large usable chamber allows for processing of large or multiple components simultaneously. The oven is controlled via a JUMO IMAGO 500 system, enabling precise temperature control as well as automated programs. Typical applications: - Industrial manufacturing - Plastics and metals processing - Component drying - Heat treatment - Testing technology / materials testing - Laboratory and research applications The system is built with heavy-duty industrial quality and designed for continuous operation. Technical Data: Manufacturer: Vötsch Industrietechnik GmbH Model: VTL 200/250/225 Maximum temperature: 250 °C Temperature safety classes: TB Class 1 TWB Class 2 Chamber: Usable volume: 11.25 m³ Internal dimensions: Width 2000 mm x Height 2500 mm x Depth 2250 mm External dimensions: Width 2900 mm x Height 3530 mm x Depth 2700 mm Lhodpfx Aoytrzfsl Tjh Load capacity: Interior load capacity: 400 kg Floor surface load: 1000 kg Weight: Net weight: 1850 kg Electrical data: Connection: 3/N/PE AC 400 V ±10 % / 50 Hz Rated current: 90 A Nominal power: 54 kW Connected load: 58 kW Additional data: Minimum exhaust air volume flow: 600 m³/h Reduced exhaust air volume flow: 150 m³/h Purge time: 465 s Total steam volume: 14.9 m³ Sound pressure level: < 70 dB(A) Safety temperature limiter cutoff temperature: 280 °C Adjustable temperature limiter: 270 °C Weight: 1850 kg Condition: Used Scope of delivery: (See photo) (Specifications subject to change and errors excepted!) If you have any further questions, we are happy to assist you by phone.

Condition: good (used), Conventional lathe, Pinacho model ML 18-250, year 2019. Distance between centers: 1,500 mm, main spindle bore: 58 mm, chuck diameter: 250 mm, swing over bed: 502 mm, bed width: 300 mm, Fagor Innova digital readout. Lodpfx Ajzcxnwel Tehh

Condition: new, Year of construction: 2026, cutting height (max.): 150 mm, cutting range round steel at 45°: 108 mm, cutting range round steel at 90°: 108 mm, BERG+SCHMID GBS 250 Super AutoCut double mitre bandsaw Speed: 18-110 - Mitre left 60° + right 45° - Sliding quick clamping vice - Solid vice + machine casting - Ball bearing rotary table - Hydraulic brake cylinder - Solid, large material support - Automatic cooling system - Worm gear running in oil bath - Closed saw frame - Adjustable ball roller bearings Lhodpfx Ajr Ik Sqel Teh - Tool compartment - door in the base - Cut monitoring by ammeter - Cutting pressure feed regulator - Support roller (infeed side) - Machine base (supplied disassembled) GBS 250 Super AutoCut 3-stage system: I. Automatic lowering of the saw frame via the hydraulic cylinder, infinitely adjustable feed, with limit switch at the end of the cut II. high-speed lowering of the saw frame to the workpiece, then switch to normal saw feed. (e.g. for scribing) III. Hydraulic cylinder works as brake cylinder: a) Manual operation (e.g. for notching) or b) Lowering in idle state Saw blade dimensions: 2765x27x0.9mm Further accessories such as saw bands, roller conveyors, measuring stops, minimum quantity lubrication etc. available on request! Delivery time: ex stock Waiblingen Beinstein

Condition: used, Year of construction: 1980, Spindle swivels: No Height adjustment: Handwheel Milling vice adjustment: Manual Height indicator: Scale Milling stop indicator: Scale Milling spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 9000, speed indicator defective Motor power: 5 / 6 kW Motor brake: Yes Dust extraction port: 120 mm Lhodpfx Aszdzb Isl Teh Machine length: 2500 mm Machine depth: 900 mm Weight: 800 kg

Condition: used, Year of construction: 2024, load capacity: 25,000 kg, lifting height: 3,100 mm, total length: 8,880 mm, · Lastschwerpunktabstand: 1200 mm · Lastabstand, Mitte Antriebsachse zu Gabel: 1070 mm · Achsabstand: 4250 mm · Achslast, Last vorn: 15500 kg · Achslast, Last hinten 53800 kg · Achslast, vorn ohne Last 17400 kg · Achslast, hinten ohne Last 4100 kg · Spurweite, vorn / hinten 2200/2140 mm · Reifendruck 1,0 MPa · Mastneigung, α = vorwärts / β = rückwärts: 5/10° · Sitzhöhe 2150 mm · Höhe beim Neigen der EGO-Kabine / OHG 3800 mm · Breite beim Neigen der EGO-Kabine / OHG 3700 mm · Breite über Gabelarme, min. / max. 2700/800 mm · Seitenverschiebung ± bei Breite über Gabeln 557/1585 mm · Min. Arbeitsgangbreite für 90° Stapelung 9550 mm · Wenderadius 5875 mm · Wendekreis innen 550 mm · Betriebsdruck für Hydraulik 22,0 MPa Lhodpfx Aszdldmel Teh · Hydrauliköltank, Volumen 330l · Kraftstofftank, Füllmenge 375l · AdBlue-Tank, Füllmenge 35l · Kraftstoffsorte des Motors Diesel, 4-Takt · Leistung ISO 3046 / bei Drehzahl 185/220 kW / rpm · Drehmoment ISO 3046 / bei Drehzahl 1160/1200 Nm / rpm · Anzahl Zylinder / Zylinderhubraum 6 / 7700 cm³ · Kraftstoffverbrauch, normale Fahrweise 8-11 l/h · AdBlue-Verbrauch, normale Fahrweise 3-5 % of diesel · Getriebe Typenbezeichnung des Herstellers: Dana TE17000 · Kupplung, Typ Drehmomentwandler · Getriebe, Typ Hydrodynamisches Lastschaltgetriebe · Anzahl der Gänge, vorwärts / rückwärts 3/3 · Generator, Typ / Leistung AC/3080 W · Startbatterie, Spannung / Kapazität 2x12 / 145 V/Ah · Antriebsachse, Hersteller / Typ Kessler D91 / Differential und Nabenvorgelege · Hubgeschwindigkeit Ohne Last (m/s) 0,3 · Hubgeschwindigkeit Bei Nennlast (m/s) 0,32 · Senkgeschwindigkeit Ohne Last (m/s) 0,38 · Senkgeschwindigkeit Bei Nennlast (m/s) 0,38 · Fahrgeschwindigkeit, V/R Ohne Last (km/h) 24/24 · Fahrgeschwindigkeit Bei Nennlast (km/h) 23/23 · Steigfähigkeit, max. Ohne Last (%) 60 · Steigfähigkeit, Mit Nennlast (%) 29 · Steigfähigkeit bei 2 km/h Ohne Last (%) 41 · Steigfähigkeit bei 2 km/h Mit Nennlast (%) 22 · Zugkraft Max. (kN) 173 · Geräuschpegel, innen LpAZ*, EGO-Kabine (dB(A)) 72 · Geräuschpegel, außen LWA (dB(A)) 109

Condition: used, Year of construction: 1983, workpiece diameter 250 mm centre distance 0 mm honing length max. mm max. module 5 Gear Ø, min./max. 10 / 250 mm Module range 1 - 5 Length of teeth / max. table stroke 500 mm Height of centres of tailstocks 220 mm Max. weight of workpiece 50 / 100 kg Honing head swivelling +/- 35 ° Speeds of honing tool 20 - 500 rpm Size of honing tool, Ø x width 300 x 40 mm Workpiece speeds 500 - 3,000 rpm Total adjustment of cross slide 270 mm Rapid traverse of cross slide 50 mm Infeed travel of cross slide, mechanical 1 - 8 mm/Ø Roughing / finishing infeed 1 - 29 / 0.2 - 2.8 mm/sec Table speeds, hydraulic 0 - 6 m/min Total electrical load 5.5 kW - 380 V - 50 Hz Weight 3,200 kg Lhsdpst Hwzpjfx Al Teh Accessories / Special Features * Working parameters can be preset using counters and control units. Automatic working process with workpiece counter. * All roughing and finishing infeeds can be adjusted by a decade switch; as well as by table reverse times and fast infeeds with preset times (1sec = Ø 0.04 mm), set on a potentiometer. Ampere display, etc. * Convex honing and conical honing are possible via templates. Asymmetric honing is also possible if the workpiece is prepared appropriately (i.e. pre-shaped). * Separate honing oil unit with magnetic separator and fine filter. * Mechanical tailstocks for manual loading. * Oil mist separator. * Sliding doors with foot switch. * Separate hydraulic unit. Condition : Good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. We have a large selection of gear machines available. Please let us know your requirements.

Condition: used, Year of construction: 1996, core drilling diameter max. 25 mm bore depth 1000 mm swing diameter mm total power requirement 25 kW weight of the machine ca. 12,5 t dimensions of the machine ca. m T B T (Germany) CNC-Controlled Horizontal Deep Hole Drilling " Centre " Model BWP 250 Year 1996, but reconditioned mechanically and electrically in 2006 _____ Working range: X Axis, machine column cross 2,000 mm Z Axis, drilling slide horizontal 1,200 mm Drilling depth 1.000 mm Y Axis, drilling slide vertical 1,100 mm Table clamping area 1,200 x 2,000 mm Drilling capacity in solid material, approx. 4 - 25 mm Lhodot Hw Ayopfx Al Tsh Tool holder taper HSK 50 Spindle speeds 1.260 - 15,000 rpm Feed rates / quickfeed, XYZ, infinitely variable 100 - 10,000/15.000 mm/min. Force rate of feed motors 27 Nm / 1.000 daN Spindle drive steplessly adjustable 7 kW Total electrical load, approx. 30 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: " Ideal machine for the complete processing of large workpieces like tool a. dies (cooling holes) mould- and dieplates, hydraulicparts etc. by means of deep hole drilling up to 25 x 1.000 mm, face milling up to Ø 60 mm, spiral twist drilling, counterboring and threading up to M 24 x 3 mm. " SIEMENS Continuous Path Control in 4 axes Model 840 D, with process monitoring for coolant pressure, operation data control function, toollife, feed force,Error diagnostics and easy dialogueprogramming directly on the panel, etc. " High Frequency Spindle Make GAMFIOR with stepless speeds " Hydraulically movable drill bush carrier, swivels 90° for holding gun drills (ELB) or picking up regular tools from the tool changer like twist drills, milling tools, taps, etc. " With automatic tool changer made by MIKSCH, Model CTM 40, using a 12-position tool changer, which is mounted on the r.h.side of machine housing, in fixed position, only moving forward and backward for tool changing operation. " Built-on indexing table as B-Axis made by FIBRO Model RTN 400 = 420 x 420 mm, " Extra Rotary Table made by FIBRO with Ø 1.000mm, for indexing 3-144 positions " Built-in coolant device with chip conveyor and various filters. " 2 steady rests. " Completely covered working area with access at the front and at the side. Condition : Very good condition. This is a rare and valuable machine. Under Power Delivery : immediately ex our Stock Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2004, turning diameter 250 mm turning length 100 mm control SIEMENS 840 D total power requirement 35 kW weight of the machine ca. 7500 kg dimensions of the machine ca. m E M A G (Germany) Vertical CNC Controlled Hard Turning and Grinding machine with tool turret and workpiece handling System Model VSC 250 DS Year 2004 # M7 28.69324 _____ Turning Ø, max. 250 mm Turning length internal / external 100 mm Workpiece length min./max. 29 – 100 mm 6-positon tool turret Ø / swing-Ø 480/790 mm Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm Feed rate / Quick feed X/Z 45/30 m/min. Feed force X/Z 5,5/11 kN Spindle speed 4.300 / 6.000 rpm Spindle drive 28 kW Total electrical load, approx. 35 kW - 400 V - 50 Hz Weight, approx. 7,500 kg Accessories / Special Features: * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor, graphics, menu-supervised dialogue programming, and all the usual options, cycles and subprograms, etc. * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without motorized tools posts, two positions T 3 u. T 6 equipped with grinding spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp. Lhedpjt Hxa Tefx Al Teh regular grinding tools * Workpiece handling device with WP transportation frames and circulation system and pick-up and unloading of finished parts directly through the motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW Autobloc with membrane clamping and clamping control system. * MARPOSS MIDA Measuring Probe for measuring blank parts a. the finished parts * NORGREN air measuring system, hydraulic weight compensation of spindle, * Main elements of machine are temperature stabilized by a coolant system made by HYFRA * Recooler for the grinding coolant sitting on a large Coolant device consisting of SEITZ Paper Band filter and a mobile Chipconveyor, Magnetic separator, Centrallubrication, etc. Vertical CNC lathes offer a thermo-resistant construction (chips do not fall onto the machine bed),fast workpiece change times (pick-up system through the main spindle) and a ridged tool arrangement,which also allows unrelated machining work, like hard turning or grinding process on the same machine. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.
