Used Leit Spindle Lathe for sale (14,389)

Condition: used, Year of construction: 2018, functionality: fully functional, turning diameter: 1,000 mm, turning diameter over bed slide: 710 mm, turning length: 8,000 mm, Used heavy-duty lathe with extensive steady rest equipment – ideal for pipe machining and long rolls! This robust conventional lathe with an impressive turning length of 8,000 mm was specifically designed for pipe machining applications. The sophisticated machine design allows the cutting edge to easily pass the open steady rests – ideal for precise machining of long, hollow workpieces. Technical Highlights: • Turning diameter over bed: 1,000 mm • Turning diameter over support: 710 mm Csdpsv Tnttsfx Ah Ioha • Center height: 900 mm • Turning length: 8,000 mm • Spindle bore: 155 mm • Machine weight: approx. 18.2 tons • Main drive: 30 kW with frequency converter, continuously variable Design advantages: • Machine bed cast in one piece and artificially aged – for maximum stability and stress-free operation • 5 hardened and ground guideways for maximum precision • Continuous feed control of the longitudinal axis via ball screw – no Norton or lock-box gearing • Electric-driven tailstock with hydraulic clamping • Manually adjustable cross support with trapezoidal thread spindle • 4-station tool carrier, manually pivoting • Triple-guided turning support – for extremely smooth running Steady rests & tube processing: • Various steady rests (stationary and follow-on) optional Available • Motorized steady rest carriers with hydraulic clamping • Spindle adjustment conveniently possible from the operator's side • Traveling steady rests can be mounted either on the left or right Application: Thanks to its sophisticated design, the machine is ideally suited for light to medium-duty machining – especially for the precise machining of tubes. The continuously variable speed and feed control ensures high flexibility and ease of use.

Condition: new, Year of construction: 2025, functionality: fully functional, spindle bore: 105 mm, turning diameter: 560 mm, turning diameter over bed slide: 360 mm, turning length: 2,000 mm, spindle speed (max.): 1,600 rpm, DLZ 560 – Conventional Precision Lathe The DLZ 560 is a robust and versatile lathe designed for demanding use in mechanical engineering and metalworking. Max. turning diameter over bed: Ø 560 mm Max. turning diameter over cross slide: Ø 360 mm Spindle bore: Ø 105 mm Chedpjxdnd Asfx Ah Isa Spindle speed range: 36 – 1600 rpm (12 steps) Centre distance: 2000 mm Motor power: 7.5 kW Machine weight: approx. 2,900 kg Thanks to its heavily ribbed Meehanite cast bed, the machine offers high stability and excellent vibration damping. Wide, hardened and ground guideways ensure long-lasting precision, even when machining heavy workpieces up to 500 kg. The comprehensive standard equipment includes, among others, Multifix toolpost, 325 mm three-jaw chuck, 400 mm faceplate, fixed and travelling steady rests, 2-axis digital readout, as well as coolant and lubrication systems, and much more. Also available with infinitely variable spindle speed! The DLZ 560 impresses with its high accuracy, user-friendly operation, and versatility – ideal for single-part and small-batch production in toolmaking and mechanical engineering. Available from the end of December. Photo similar.

Condition: good (used), Year of construction: 2004, ELBERON Multipurpose Lathe Type: GRC300X750 Chuck 130 mm In good condition. Csdpfx Aewah Rqjh Ieha See data sheets for details.

Condition: good (used), Year of construction: 1974, LZ-Lathe Fabr.Boley Type: 6 LZ Year 1974 Center height : 140 mm center distance : 500 mm spindle speed : 28-3550 rpm spindle bore : 32 mm collet chuck device, 3-jaw chuck, quick-change tool holder Parat. Chodpeqw U Uwjfx Ah Ioa Machine documentation available, machine can be demonstrated under power.

Condition: good (used), Year of construction: 1967, LZ-Lathe Fabr.WEIPERT TYPE:UD 500 e year 1967 with digital readout ,top support feed tool holder MULTIFIX size C ,Forkardt chuck 315 mm. Chsdpfx Aju Rd H Ish Isa Center height : 250 mm Center width : 1500 mm spindle bore : 65 mm Spindle speed : 14 -1400 rpm Machine is in good condition .

Condition: good (used), Year of construction: 2010, LZ-Lathe Fabr.JET Type :GHB-1330 Bj.2010 Chjdsqwgzqspfx Ah Iea with 3 ash digital indicator, 3 jaws lathe chuck DM 160 mm tool holder Multifix size A, 2 steady rests coolant device. Turning diameter overbed: 330 mm Turning diameter over face: 197 mm Center width: 750 mm Spindle speeds: 70-2000 rpm spindle bore : 38 mm Machine in good condition from the training workshop Machine documentation available .

Condition: good (used), Year of construction: 1962, Centre lathe manufacturer VDF HEIDENREICH&HARBECK type: 24 RO, year of manufacture 1962, overhauled in 1992. Equipped with 3-axis digital readout Heidenhain, 250 mm Forkardt chuck, Multifix B toolholder. Centre height: 255 mm Csdpsxziuwefx Ah Isha Swing over bed: 510 mm Swing over cross slide: 270 mm Distance between centres: 1000 mm Spindle bore: 55 mm Spindle speeds: 20 - 900 rpm, Motor power: 6.5 kW The machine is in good condition, electrical diagrams available. Required floor space: Length 3 m, Depth 1.2 m, Height 1.3 m, Weight approx. 1800 kg.

Condition: ready for operation (used), Year of construction: 1996, LZ lathe, make SASTA STANKO, type: SA562M, year of manufacture 1996 Swing diameter above bed: 500 mm Swing diameter above plan support: 290 mm Tent length: 1500 mm Spindle speeds: 16 2000 rpm Spindle bore: 55 mm Codpevkuauefx Ah Ijha Chuck diameter 250 mm Forkardt tool holder Multifix size C. Machine with rapid traverse X and Z axis Good general condition. For further information see data sheets.

Condition: good (used), Year of construction: 1979, Schütte SF51 6-spindle automatic bar lathe Suitable for complex turning operations in metalworking Chjdsyhpvpjpfx Ah Iea The Schütte SF 51 is a proven, cam-controlled 6-spindle automatic bar lathe with a 51 mm spindle bore, ideal for the efficient serial production of turned parts. These robust machines feature an electronic cam control system that offers high process stability and flexibility for turning, drilling, and threading operations. The machine is valued for its stability and flexibility in manufacturing demanding workpieces. Technical status: The machine has been regularly modernized and is up to current technical standards. Maintenance & Servicing: Professional maintenance performed strictly according to schedule by specialists. Manufacturer: Schütte Type: SF 51 Cam-controlled multi-spindle automatic bar lathe Number of spindles: 6 main spindles Control system: Conventional Spindle bore: 51 mm Max. feed: 125 mm Max. turning length: 102 mm Max. drilling depth: 102 mm Threading unit Chip conveyor 6-position bar loader Voltage: 400 V The orange transport rack for long stock is included in the offer. The scissor lift table is not part of this auction but can be purchased from us separately. Gruse ELS 2-13-9 hydraulic scissor lift table "Everything from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de You can find more items—new and used—in our shop! International shipping costs on request!

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: LZ280/3, turning diameter over cross slide: 190 mm, spindle bore: 43 mm, turning diameter: 330 mm, turning diameter over bed slide: 330 mm, center height: 165 mm, turning length: 670 mm, quill stroke: 90 mm, quill diameter: 45 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 30 rpm, GDW precision lathe LZ 330 V EconomyLine The LZ 330 V EconomyLine is a powerful lead and feed spindle lathe with stepless speed control from 30–4000 rpm. The standard paint finish includes RAL 7035 (light gray) for the housing and RAL 7016 (anthracite gray) for the substructure, splash guard hood and chuck guard. Equipment & accessories: Csdpjv Dan Defx Ah Ioha ✅ 3-axis position indicator with 6" color display ✅ Quick-change tool holder Multifix A including 1 turning tool holder ✅ Coolant system & central lubrication ✅ Chip tray, splash guard & spindle brake ✅ LED machine light & collet board K32 ✅ Electromechanical limit switch device for thread/feed ✅ Tool cabinet with telescopic extension including operating tools Additional equipment package (optional): ➕ Three-jaw chuck Ø 160 mm (up to 4,600 rpm) ➕ Keyless drill chuck (3-16 mm, B16/MK3) ➕ Live center MK3 & drill bit holder ➕ 4 additional turning tool holders & 1 drill bit holder 📦 Delivery: ✔️ Disposable packaging & safe transport including insurance Perfect for precise and demanding turning operations in industry and trade! 🚀

Condition: used, Technical details: Chedpfx Aju Idw Ieh Isa number of spindles: 11 Stück number of stations: 11 Stück taper: SK 40 air pressure - required: 6 - 7 bar total power requirement: 13 kW weight of the machine ca.: 10,2 t space requirements of the machine approx.: 4,0 x 4,0 x 3,4 m dimensions of machine: 3,4 x 3,45 x 2,9 m dimensions electric cabinet: 2,1 x 0,4 x 1,9 mm Transfermachine (drilling & cutting) Accesssories optional please enquire to this additional position! - workpiece holding turret Ø 1000mm with tool holder for 8 tool clamping stations, self centering clamping chuck jaws between the jaws, max. 20mm chuck jaw stroke ( oil pneumatic circulation) - 11 working stations with Sk40 intake (right 4x Drill-& Mill spindle and 1x mitU-axis , left 4x Drill-& Mill spindle ) - drill unit 8x spindle stroke 125mm, feed 0 - 2 m/min, 164 - 1005 rpm with 12 gears stages - thread cutting unit working stroke 125mm, rotation direction clockwise and counter clockwise, 31,5 - 194 rpm with 12 gears stages - opposite located drill units 8 pieces with SK 40 holder - coolant device with supply - control via switch panel - with swarf basin L: 1200 x W: 740 x H: 220mm i.D. *

Condition: used, Technical details: number of spindles: 15 Stück number of stations: 8 Stück control: PS 2000 weight of the machine ca.: 17,0 t total power requirement: 83,0 kW dimensions of machine: LxBxH: 2400x2800x2800 mm dimensions electric cabinet: Nr.1:LxBxH: 1000x850x2350 mm dimensions electric cabinet: Nr.2: LxBxH: 1250x650x2230 mm dimensions electric cabinet: Nr.3: LxBxH: 650x600x1700 mm dimensions electric cabinet: Nr.4: LxB.H: 1000x500x1350 mm space requirements approx. LxWxH: 5,0 x 6,2 x 3,8 m TRANSFER MACHINE with 3 work station and 15 drill & mill spindles for example the production of a high quantity of armatures Other technical information about the machine: - workpiece carrier: workpiece holding barrel Ø 800mm for 8 work piece - clamping station, cycle time of 10 sec. Chjdpfx Aheu Idxfs Iea - drilling and milling unit: SK 40 intake; spindle stroke 125 mm; standard feed rate 1m/min; rapid traverse feed rate 4m/min; RPM max. 2240 rpm - right 3x drill-& mill spindle, 1x thread cutting spindle, 1x U-axis such as radial 2x drill-& mill spindle slideable, 1x thread cutting spindle slideable and 2x U-axis slideable - left 3x drill-& mill spindle, 1x thread cutting spindle, 1x U-axis such as radial 2x drill-& mill spindle slideable, 1x thread cutting spindle slideable and 2x U-axis slideable - 1.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 125mm; RPM 35.5 - 900 rpm; right/left - 2.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 80mm; RPM 45 - 560 rpm; right/left Equipment: - 2 hydraulic aggregate - chip conveyor - belt filter produced by Filtertechnik Gera (fleece band 430mm) - control panel - manual switch i.D. *

Condition: used, Technical details: spindle taper: 40 number of spindles: 9 Stück weight of the machine ca.: 10,0 t total power requirement: 13 (17,5 PS) kW dimensions of machine: LxBxH: 4100x3400x3200 mm dimensions electric cabinet: LxBxH: 2100x350x1900 mm TRANSFER MACHINE DRILL AND THREADCUTTING MACHINE - ROTARY TRANSFER MACHINE with 9x Drill-& Mill Spindles - right 2x Drill-&Mill Spindle from that 1x with U-axis flexible and 1x thread cutting unit with 9 stages flexible - left 2x Drill-&Mill Spindle from that 1x with U-axis flexible and 1x thread cutting unit with 9 stages flexible, such as radial 2x Drill-&Mill spindle and 1x thread cutting unit 9 stages, flexible - workpiece carrier with 8 clamping stations: workpiece holding barrel Ø 1000 mm (oil-pneumatic cycle), clamping station self-centering clamping jaws - Drilling: SK 40 intake; spindle stroke 125 mm; standard feed rate 0 - 2 m/min; RPM at 12 stages with 164-1005 rpm - Drill- and facing unit; SK 40 intake; spindle stroke 90 mm; standard feed rate 0 - 2 m/min; rapid traverse feed rate 7.5 m/min; RPM at 12 stages with 166 - 1020 rpm Cedpfx Asu Idwbeh Ieha - 3 piece thread-cutting units: SK 40 Intake; Working stroke 125 mm; RPM at 12 stages with 31.5 - 194 rpm; clockwise and counterclockwise - 6 piece opposing drill units: SK 40 intake Equipment: - coolant system with feed - operation through control panel - chip box - counting mechanism - elevated platform with stairs i.D. *

Condition: used, Technical details: spindle taper: SK40 spindle stroke: 175 mm number of spindles: 8 Stück number of stations: 5 Stück cycle time: 15-20 sec revolutions per minute: bohren/drill/taladrar 225...1037 U/min. revolutions per minute: gewinde/threading/roscar 50...316 U/min. feed: 0,2 m/min total power requirement: 30 (40PS) kW weight of the machine ca.: 9,0 t space requirements of the machine approx.: 3,9x2,4x2,5 m dimensions of machine: L:3,9xB:2,2xH:2,7 m dimensions L x W x H: +Anlage/plant/planta 2,7x2,52x2,25 m The machine will be on a General overhaul (pictures from original condition at the former Company) Chjdpfsu Idycex Ah Ioa The machine has been constructed for the metal cutting process of workpieces in one clamping session. Especially blanks made of brass with a diameter 90mm x approx 100mm length would be machined with this machine. description: - workpiece support with switch plate with clamping station type round table with horizontal axis with 5 workpiece stations processing units: - drill spindle and thread cutting units - drill capacity up to 2 3/4" and 81,53mm in brass - thread cutting up to 2 1/2" und metric thread Machine is equipped with a feeding-and unloading unit for workpieces. ( feed capacity 3 -4 pieces/min and cycle time 15 - 20 sec.) furthermore incl. coolant device i.D. *

Condition: used, Technical details: number of spindles: 9 Stück total power requirement: 83,0 kW weight of the machine ca.: 17,0 t Chedpsu Idvkefx Ah Ija TRANSFERAUTOMAT with 9x drill-and mill spindles - right 3x drill-& mill spindle, 9 stages, driven, fixed and left 3x drill-& mill spindle 9 stages, driven, fixed such as radial 3x drill-& mill spindle with 9 stages, driven, fixed i.D. *

Condition: used, Technical details: Chedpfx Aheu Idwns Iea number of spindles: 9 Stück weight of the machine ca.: 10,2 t Transfer machine with 9 Drill-& Mill spindles - right 2x drill -& mill spindle and 1x thread cutting spindle with 9 stages - left 2x drill -& mill spindle and 1x thread cutting spindle with 9 stages such as radial 2x drill-& mill spinlde flexible and 1x thread cutting spindle 9 stages, flexible i.D. *

Condition: used, Technical details: number of spindles: 15 Stück number of stations: 8 Stück control: PS 2000 total power requirement: 83,0 kW weight of the machine ca.: 17,0 t space requirement of the machine approx.: LxBxH: 5,0 x 6,2 x 3,8 m Cedpfx Ahsu Idxrs Isha dimensions of machine: LxBxH: 2400x2800x2800 mm dimensions electric cabinet: Nr.1: LxBxH: 1000x850x2350 mm dimensions electric cabinet: Nr.2: LxBxH: 1250x650x2230 mm dimensions electric cabinet: Nr.3: LxB.H: 650x600x2300 mm dimensions electric cabinet: Nr.4: LxBxH: 1300x650x2350 mm TRANSFER MACHINE with 3 work station and 15 drill & mill spindles - for example the production of a high quantity of armatures Other technical information about the machine: - workpiece carrier: workpiece holding barrel Ø 800mm for 8 work piece - clamping station, clock cycle of 10 sec. - drilling and milling unit: SK 40 intake; spindle stroke 125 mm; standard feed rate 1m/min; rapid traverse feed rate 4m/min; RPM max. 2240 rpm - right 4x drill-& mill spindle with 18 stages and 1x thread cutting spindle hydr. 14 up to 224 U/min, left 4x drill and mill spindle with 18 stages and 1x thread cutting spindle hydr. from 14 up to 224 U/min such as radial 3x drill -and mill spindle from that 1x U-Axis and 1x thread cutting spindle 1.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 125mm; RPM 35.5 - 900 rpm; right/left 2.Thread-cutting unit: SK 40 Intake; Quill Ø 125 mm; quill-stroke 80mm; RPM 45 - 560 rpm; right/left Equipment: - 2 hydraulic aggregate - chip conveyor - belt filter produced by Filtertechnik Gera (fleece band 430mm) - control panel - manual switch i.D. *

Condition: good (used), Year of construction: 1977, spindle bore: 360 mm, turning length: 2,000 mm, Oil Country Lathe Ø 970 x 2000 mm Double Hydraulic chuck Double chuck front and rear with 360 bore Cedpfx Ahexf E Rce Ioha API Threading Cutter attachment Safety cover dfor front and rear chuck Conical turning carriage Multi fix tool system DBC Turning Length: 2000mm Swing over bed Ø: 970mm Swing over cross slide Ø:500mm Spindle bore: 360mm Spindle power: 22kW Stroke pinole: 360mm Spindle taper: 6Mk Speeds / ranges: 28-500Rpm Feed rate X-Axis: 4000mm/min. Feed rate Z-Axis: 2000mm/min. Length: 5500mm Width: 1900mm Height: 1900mm Weight: 10600kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), spindle bore: 360 mm, travel distance X-axis: 798 mm, travel distance Z-axis: 358 mm, spindle motor power: 45,000 W, rotational speed (max.): 500 rpm, total height: 2,100 mm, total length: 8,100 mm, total width: 2,750 mm, overall weight: 13,000 kg, Chip conveyor  SMW Front and Rear chuck 700 mm  Double revolver 6+8 positions Big Bore 360 mm Tailstock with power quill Tooling package included with inserts and jaws Max. turning Ø:665mm X-Axis: 798mm Z-Axis: 358mm Spindle bore: 360mm Speedrange: 500Rpm Spindle power: 45kW Pinole taper: 6Mk Stroke pinole: 230mm Quill Ø: 150mm Cjdpfx Ahswxb Erj Ieha Length: 8100mm Width: 275mm Height: 2100mm Weight: 13000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: not inspected (used), MURATEC MT 12 horizontal axis cnc lathe with gantry FANUC 18 i numerical control Turning diameter (mm) 160 Rot. diameter on bench (mm) 250/210 Max. turning length (mm) 220 Spindle taper type ASA 5 Min spindle speed (rpm) 10 Spindle speed max (rpm) 4500 Spindle speed ranges 2 ELECTRONIC Rapid feed rate (mm/min) 24,000 Longitudinal travel (mm) 200 Z1 axis Transverse travel (mm) 200 X1 and X2 axis Turret type 2 x 15 Spindle motor power 7.5 kw Voltage (volts) 400 Year of construction 2005 Serial no. 04KX23750001 Weight (Kg) 5500 Height (mm) 2200 Width (mm) 2700 Depth (mm) 1850 gantry workpiece size diameter 120 mm x 100 mm; max. allowable workpiece weight 3 kg for No. 2 workpieces; rapid speed 120 m/min. Spindle bore (mm) 62 Accessories no. 2 axial motorized modules, no. 2 radial motorized modules, chip conveyor, Z-axis counter spindle 2 stroke 650 mm; counter spindle speed 4500 rpm; C-axis continuous, motorized tool speed 4000/min; motorized tool motor power 3 kw. YOM 2013 Codpfx Ahozfw A Ro Ioha

Condition: used, Year of construction: 2006, spindle speed (max.): 5,000 rpm, total width: 45,000 mm, total length: 19,900 mm, total height: 23,000 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, bar length: 600 mm, CNC Lathe (with 2nd spindle, 3 turrets and Y-axis) Spindle bore diameter 65 mm Spindle speed 5.000 R/min Spindle motor 25/20 kW Spindle speed counter spindle 5.000 R/min Chedpfx Ahsy Nyrxo Iea X-axis movement 165 / 165 / 165 Y-axis movement 80 mm Z-axis movement 220 / 150 / 650 mm W-axis movement (subspindle to mainspindle) 690 mm C-axis indexing 0,0001° Number of turret 3 Number of tools on turret 12 (3x 12) Tool taper VDI 30 Bar feeder LNS Quick Load Servo 65 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2006, spindle speed (max.): 5,000 rpm, total width: 45,000 mm, total length: 19,900 mm, total height: 23,000 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, bar length: 600 mm, CNC Lathe (with 2nd spindle, 3 turrets and Y-axis) Spindle bore diameter 65 mm Spindle speed 5.000 R/min Spindle motor 25/20 kW Spindle speed counter spindle 5.000 R/min X-axis movement 165 / 165 / 165 Y-axis movement 80 mm Z-axis movement 220 / 150 / 650 mm W-axis movement (subspindle to mainspindle) 690 mm C-axis indexing 0,0001° Number of turret 3 Number of tools on turret 12 (3x 12) Tool taper VDI 30 Codpfjy Nyg Aex Ah Isha Bar feeder LNS Quick Load Servo 65 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: repair required (used), Year of construction: 2001, CNC-controlled wood lathe – processes 3 parts simultaneously. Csdpsf Ezgqofx Ah Ieha No controller included. Control cabinet without a computer; the attractive price without control should be taken into consideration. Technical specifications: Maximum working length: 1200 mm Maximum square section: 100 x 100 mm 3 parts processed simultaneously Programmable template Fagor control Designed for high productivity.

Condition: good (used), Centre height: 290 mm Centre distance: 3000 mm Swing diameter over bed: 580 mm Swing diameter over cross slide: approx. 400 mm Spindle bore: 63 mm Spindle mount DIN 55027: Size 8 Speed range: 25 – 1120 rpm Bed width: 365 mm Longitudinal feed: 0.03 – 1.3 mm/rev Cross feed: 0.008 – 0.33 mm/rev 80 metric threads: 0.25 – 76 mm 96 Whitworth threads: ½” – 152 tpi 52 module threads: 0.25 – 22 module 88 diametral pitch threads: 1 – 176 DP Tailstock taper: MK 4 Drive power: 5.5 kW Dimensions (L x W x H): 4450 x 1300 x 1350 mm Weight: 2800 kg Accessories / Special Features: • Quick-change tool post, brand "Multifix", size B • Hardened bedways • Bed stop Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel Csdpfx Aextu Eroh Ijha

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: rotational speed infinitely variable, Manufacturer: 600 Lathes Model: Harrison V350 Centre Height: 170 mm Swing over Bed: 350 mm Swing over Cross Slide: 196 mm Swing in Gap: 535 mm Width in front of Face Plate: 165 mm Distance between Centres: 650 mm Spindle Speeds (stepless via potentiometer across 3 ranges, with digital readout): 15 - 340 rpm 45 - 1010 rpm Chsdpfexcuulsx Ah Iea 150 - 3250 rpm Spindle Mount (Camlock): D1-4 Spindle Bore: 54 mm Spindle Motor: 7.5 kW Carriage Guideway Width: 318 mm Cross Slide Travel: 250 mm Top Slide Travel: 140 mm Tailstock Quill Travel: 140 mm Tailstock Quill Taper: MT4 Quill Diameter: 63 mm Metric Version Machine Threads: Metric: 0.2 - 14 mm (51) Imperial TPI: 2 - 56 (56) Module: 0.2 - 3.5 (20) Diametral Pitch: 8 - 56 (20) Drive Power: 7.5 kW Equipment: 3-Axis Digital Readout 3-jaw Chuck Röhm D:200 mm 4-jaw Chuck D:160 mm Collet Chuck System Steady Rest 4-position Quick Change Toolpost Live Centre Chuck Guard Additional Chip Shield on Carriage Coolant System Rear Splash Guard Machine Documentation incl. Schematics Dimensions: Floor to Spindle Centre: 1050 mm Overall Length: 1900 mm Overall Width: 1100 mm Overall Height: 1300 mm Weight: 1350 kg The machine can be demonstrated under power on site by arrangement. All details without guarantee. Errors and prior sale reserved.
