Used Rotary Lathe for sale (9,127)

Condition: used, centre height / mm O. 600 mm Hfodpfozcghfex Af Ajk Weight: 340 kg

Condition: used, Year of construction: 1969, turning diameter over bed 500-600 mm turning length 2800 mm Hodovdx I Ajpfx Af Aofk bore diameter 130 mm weight of the machine ca. 5,25 t required space / m

Year of construction: 1961, condition: used, centre height 235 mm turning diameter 470 mm turning speeds 2700 U/min turning length 1500 mm Hfodpfx Afel Ab Hte Aek inkl. Zubehör (siehe Bilder)

Condition: used, table diameter 630 mm weight of the machine ca. ca, 0,35 t table height 220 mm Hfsdpsymf U Ejfx Af Ask

Year of construction: 1980, condition: used, turning diameter over bed 655 mm turning diameter over slide rest 390 mm Hsdolc Uk Iopfx Af Aefk turning length 1250 mm spindle bore 82 mm spindle turning speed range 9-1120 U/min feeds 0,049-3 mm/U total power requirement 12 kW weight of the machine ca. 5,2 t required space 3,5 x 1,9 x 1,7 m m

Condition: used, Year of construction: 1972, turning diameter over bed 1650 mm turning diameter over slide rest 1350 mm turning length 10000 mm turning speeds 1,4 - 280 U/min greates pass round over bed 1580 mm center height over square guideway 825 mm bed length 13.350 mm bed width 1.120 mm spindle diameter in front bearing 260 mm spindle bore 82 mm upper head travel 500mm tailstock quill diameter 200 mm max. workpiece weight between centres 10.000 kg weight of the machine ca. 25,5 t Power 45 KW The machine is a first-hand purchase, is free from defects and is in very good condition. In 2023, the headstock was overhauled; this included replacing the main spindle bearings, chrome plating and Hfodpfx Afsy S Duvs Aek reworking the main spindle and bottom wheel (bearing seat). The guideways are also in very good condition, considering their age. Accessories - Feed guard Equipment - 3-axis digital display - 1 x faceplate - 1 x roller stand - Chip conveyor (Kabel Schlepp 300/100)

Condition: used, centre height / mm Hsdpfxoy Sup Re Af Aefk weight 110 kg diameter 360 mm

Condition: used, centre height / mm weight 110 kg diameter 400 mm Hsdpfx Afsy Suqze Asfk

Condition: used, table diameter 500 mm Hodpsylz D Hofx Af Asfk weight of the machine ca. ca. 0,2 t table height / mm

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, total height: 2,300 mm, total length: 4,000 mm, total width: 2,400 mm, overall weight: 8,200 kg, Sales from Bremen location. Inspection possible by appointment. Model: PUMA 350 A Hsdpfx Ajzufknof Aofk Year of manufacture: 2000 Control: Fanuc 18-TC Spindle speeds: 30 – 3000 rpm Bar capacity: 160 mm Chuck diameter: 305 mm Swinging diameter over bed: 700 mm Swinging diameter over slide: 480 mm Turning diameter: 550 mm Turning length: 1050 mm Spindle bore: 102 mm Spindle nose: A2-8 Rapid traverse X-axis: 16,000 m/min Rapid traverse Z-axis: 20,000 m/min Travel X-axis: 362 mm Travel Z-axis: 1105 mm Max. bar diameter: 91 mm Number of tool positions: 12 Dimensions (L x W x H): 4000mm x 2400mm x 2300mm Weight: 8200 kg

Condition: used, Year of construction: 2006, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Hfedpfx Aozumzzef Aok Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, turning diameter over bed: 540 mm turning length: 1.500 mm turning diameter in the recess: 580 mm Working travel of the lower slide max. approx.: 415 mm Hfedpfx Aszumxtjf Aok adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 1/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 68 mm bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, Control system: SIEMENS 840D Turning diameter: 2,800 mm Turning height: 1,000 mm Hfedpfx Afezumwvs Ajk Load capacity: 16,000 kg Max. swing diameter, approx.: 2,800 mm Turning diameter - external, max.: 2,800 mm Spindle speed: 63 rpm Travel of the cross slide: 620 mm Ram stroke - max.: 690 mm INCLUDED Chip conveyor 4-position tool turret Hydraulic chuck: 2800 mm EQUIPMENT Tool holder CAPTO 6 Electric handwheel Retrofit in 2009 DESCRIPTION The machine is in very good condition and was used for hard turning of roller bearings. In 2009, the machine was mechanically overhauled by Maschinenbau HELLWIG. As part of this general overhaul, the control system was also upgraded to a SIEMENS 840 Powerline.

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, Control system: SIEMENS 840D Turning diameter: 4,000 mm Turning height: 1,400 mm Travel range of the rotary table: 850 mm Max. swing diameter, approx.: 4,200 mm Turning diameter - external, max.: 4,000 mm Travel range of the cross slide: 850 mm Ram stroke - max.: 950 mm Hjdszumwiepfx Af Asfk EQUIPMENT - Hydraulic chuck - Tool holder CAPTO 6 - Electric handwheel - Retrofit in 2007 INCLUDES Chip conveyor 4-position tool turret DESCRIPTION The machine is in very good condition and was used for hard turning of 4m cylindrical roller bearings. In 2007, the machine underwent mechanical refurbishment by Maschinenbau HELLWIG. As part of this general overhaul, the control system was also upgraded to a SIEMENS 840 Powerline.

Condition: refurbished (used), Year of construction: 2001, functionality: fully functional, Processing diameter: 4,200 mm Hjdpfjzumubjx Af Aefk Table speed: 12.3 min-1 Max. workpiece weight: 9,000 kg X-axis: 1,110 mm Processing height: 850 mm Workpiece height: min. 50 / max. 850 mm Control system: SIMATIC S7-300 Tool holder: Grinding segments Integrated dressing unit on the grinding head In 2010, the machine underwent a comprehensive mechanical and electrical overhaul. As part of this modernization, the entire automation and drive technology was converted to Siemens technology. The machine is equipped with a MARPOSS P7 in-process measuring system. The measuring system is fully integrated into the Siemens SIMATIC S7-300 PLC control system via PROFIBUS.

Condition: used, Year of construction: 1961, turning diameter Max. 4200 mm faceplate diameter 3700 mm turning height Max. 2600 mm workpiece weight Max. 35 t Power 80 PS Hedpouddnvofx Af Ajfk DIGITAL CONTROL DISPLAY Largest diameter with the crossbeam supports: 4200mm Largest turning diameter with side support: 3900mm Largest turning height above faceplate: 2500 Side support 1 vertical grinding ram: 1200mm stroke (out of operation) 1 turning ram: 1400mm stroke

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Hjdpfx Afjygx D He Aofk Machine table drive Main drive power: 80kW Number of gearboxes: 2 Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN

Condition: used, Year of construction: 1977, faceplate diameter 2500 mm swing diameter 2700 mm turning height 2000 mm cross rail - adjustment 1500 mm workpiece weight max. 20.000 kg total power requirement 71 kW Control Siemens Sinumerik 840 Single-column vertical lathe 2000 x 2000mm Retrofit: 1997 Gr. turning diameter: 2700mm Gr. distance f. face plate to bottom of toolholder: 2150mm chisel holder: 2150mm Support swivelling up to 30° Chisel cross-section: 240x240mm small plunging diameter: 300mm Special equipment: Hodpfx Ajuddpgsf Ajfk Re-moulding, taper turning, thread cutting, constant cutting speed

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter Hedpezubyrjfx Af Asfk delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1999, total length: 3,350 mm, total width: 1,550 mm, total height: 1,800 mm, Colour: White Empty weight: 3.300 kg In very good condition. In 2017 Refurbished for €32.000 - Year: 1999 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Drive system: Teach-in - Control system brand: Monforts - Control system type: Monforts Control System MTC K - Power [kW]: 15.0 - Centre height [mm]: 250 - Swing over bed [mm]: 500 - Carriage turning diameter [mm]: 290 - Distance between centres [mm]: 1500 Hedpfxjztxl Ns Af Aefk - Spindle bore [mm]: 70 - Min. spindle speed [rpm]: 2 - Max. spindle speed [rpm]: 2800 - Options: Fixed steady, Three-jaw chuck - Transport dimensions: 3350mm x 1550mm x 1800mm (l x w x h) - Transport weight [kg]: 3300kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2001, center height over bed 500 mm centre distance 6.000 mm bed width 670 mm turning diameter over bed 1.030 mm turning dia. over face-slide 640 mm Max. workpiece weight between centers 5.000 kg Max. workpiece weight between centers (collet) 6.000 kg feed speeds x- and z-axis 6.500 mm/min spindle head ASA 15" spindle turning speed range 4 - 830 U/min Torque 6.224 Nm total power requirement 70 kW weight of the machine ca. 11,3 t Headstock: - Front bearing, inside diameter: 235 mm - Rear bearing, inside diameter: 216 mm - Diameter of hole through spindle: 170 mm - Morse taper in spindle sleeve: 6 MK Hfsdpfxjzt Szks Af Ask Tailstock: - Quill diameter: 150 mm - Quill travel: 400 mm - Quill morse taper: 6 MK Saddle and cross slide: - Torque AC axes drive motors (X and Z): 17/22 Nm - Max. feed force, X and Z (continuously rated): 2500 daN - Recirculating ballscrew diameter X-axis: 40 x 5 mm - Max. travel, X-axis: 650 mm

Year of construction: 2016, condition: ready for operation (used), CMZ brand CNC lathe, model TA 20 Y, manufactured in 2016. Hsdpfozrwf Eex Af Aofk

Condition: good (used), Year of construction: 2007, Pinacho CNC lathe, Rayo 180 model, built in 2007, with Fanuc control. Distance between centers: 750 mm, turning diameter: 360 mm, chuck diameter: 200 mm, bed width: 250 mm, main spindle bore: 42 mm, speed range: 100 to 4,000 rpm, motor power: 5.5 kW, automatic 8-tool turret. Hfedev T Tvyspfx Af Aok

Condition: good (used), Year of construction: 2000, CNC lathe, manufactured by CMZ, model TBI450, year 2000. Hjdpfx Aszmvzbsf Aofk

Year of construction: 2012, condition: good (used), Separator sluice / cell wheel sluice Nestro, year of manufacture 2012, for the separation / differentiation of paper chips or paper edge sections. Technical data: Manufacturer: Nestro Lufttechnik GmbH Year of manufacture: approx. 2012 Motor: 4 kW Volume flow rate max. 28000 m³/h Inlet diameter max.: 450 mm Speed: 22 rpm Rotor width: 1500 mm Rotor diameter: 1200 mm Dimensions: 2200 x 2200 x 2500 mm (L x W x H) Weight: approx. 3000 kg Hedpozt Ipkofx Af Asfk Note: The machine is in good condition. It was inspected and tested by us in 28816 Stuhr. The video can be found at the top of our website or on our YouTube channel. Inspections, including under power, are possible at any time by arrangement. Please note: All technical data refer to the manufacturer's specifications. We assume no liability for the information provided or for any errors. The offers are non-binding, subject to prior sale, and can be revoked at any time. Inspections are possible by arrangement. The sale is made against advance payment, ex works, without any warranty.
