Used Spinner U 620 for sale (85)

Condition: repair required (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 465 mm, workpiece weight (max.): 500 kg, table load: 500 kg, rotary table diameter: 650 mm, spindle speed (max.): 20,000 rpm, CNC Heidenain 620 WORK AREA: Longitudinal X: 630 mm Transversal Y: 530 mm Vertical Z: 465 mm SPINDLE: Tool attachment cone: HSK 63 Speed: 20.000 rpm Power: 28 kW Torque: Nm 100 TOOL CHANGER: Tool magazine: 32 places Maximum tool diameter/with free adjacent positions: 76 / 130 mm Maximum tool weight: 7 kg Maximum tool length: 300 mm CN ROTARY TABLE WITH CN SWIVEL AXIS: Table diameter: 650 mm Permitted load: 500 kg B axis: -5° (-90°) /+110° DIMENSIONS AND WEIGHTS: Weight: 8.000 kg Dimensions: mm2.735x2.420x2.820h 5 PALLET PALLET CHANGE SYSTEM: - Base frame as electro-welded rigid - Security carter with all the security elements on the island - 5 pallet racks - Movement system for loading and unloading pallets - Pneumatics, electrical and control system of the island Storage of 5 pallets measuring 400 x 400, fixing the pallets on the pallet racks, total weight between pallet and piece 100 kg. Machine complete with: • Optical lines in X/Y/Z • Chip conveyor • 70bar TW high pressure refrigerant, external tank with paper filter Nwedpfozblf Hox Aireh • TNC software option "continuous 5-axis interpolation and 3D machining" • Piece feeler for machining centres, Blum TC 52 system • WIRELESS infrared probe for the mechanical probing of tools • Instruction manuals and CE declaration

Condition: like new (used), Year of construction: 2011, functionality: fully functional, operating hours: 1,013 h, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, controller manufacturer: Siemens, table length: 1,100 mm, table width: 560 mm, controller model: 840d SL ShopMill Operate, rotational speed (max.): 12,000 rpm, operating hours of spindle: 203 h, For sale is a machining center of the brand Spinner and the type P3-620 The machine has an internal 2 compartment pallet changer, which makes it possible to set up during the work process. Particularly noteworthy are the 203 spindle hours and the very good condition of the machine Technical data: Year of construction: 2011 Control: Siemens 840d-SL ShopMill Operate Spindle speed: 12,000 1/min Spindle holder: SK 40 Table dimensions: 1,100*560 mm Travel X 620 mm Travel Y: 520 mm Z travel: 460 mm Tool changer: 32 pockets (chain) Tool changer head: double arm Pallet changer: 2-fold (180 °) Machine lighting, Chip conveyor in the milling area, Chip conveyor scraper belt with coolant device Belt filter system with IKZ 40 bar Hydraulic oil cooling system, Rotary feed-through in the table Nwodpfx Aijt Sftwsreh On request, loading and transport (Europe-wide) can be organized for an additional charge. Prices plus VAT Viewing possible by appointment. Please contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: ready for operation (used), Year of construction: 2012, operating hours: 14,228 h, functionality: fully functional, controller model: Heidenhain 620, number of slots in tool magazine: 54, Equipment: chip conveyor, Submitting a bid obligates you to collect the machine on time by the end of 2025! TECHNICAL DETAILS Control: Heidenhain 620 Number of tool magazine positions: 54 MACHINE DETAILS Operating hours Operating hours: 31,063 h Program run: 14,228 h EQUIPMENT Infinitely variable spindle speed Chip conveyor Internal cooling Air cooling 3D probe Nsdpfxox A D Uuj Airewh

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 Nwedpfx Asyzkdcoireh • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Condition: ready for operation (used), Year of construction: 2020, operating hours: 5,900 h, travel distance X-axis: 1,530 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 465 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 110, number of axes: 5, This 5-axis SPINNER U1530 was manufactured in 2020. It features an impressive X-axis travel of 1,530 mm, Y-axis travel of 530 mm, and Z-axis travel of 465 mm. The machine is equipped with a Heidenhain iTNC 530 control unit and has a tool capacity of 110 stations. If you are looking to get high-quality machining capabilities, consider the SPINNER U1530 vertical machining centre we have for sale. Contact us for further details. - Tool Capacity: 110 tool stations (large capacity chain magazine)- Coolant System: IKZ (Internal Coolant Supply / Through-Spindle Coolant)- Additional Equipment: Swivel rotary table (5-axis configuration), standard fixed table extension with vise clamping system, chip conveyor, Elbaron mist/smoke extraction unit, hydraulic/coolant pump station with pressure gauge and CEMO 100-liter auxiliary tank Nodpfx Aiezf Aghsrswh Technical Specification Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2021, operating hours: 6,000 h, travel distance X-axis: 1,530 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 465 mm, controller manufacturer: SIEMENS, controller model: 840D-SPIOS V1, overall weight: 10,500 kg, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 54, number of axes: 5, This 5-axis SPINNER U5-1530 was manufactured in 2021. It features an impressive X-axis travel of 1530 mm, Y-axis travel of 530 mm, and Z-axis travel of 465 mm. The machine includes a fixed rigid table combined with a 2-axis rotary/tilt table, enhancing its versatility. If you are looking to get high-quality machining capabilities, consider the SPINNER U5-1530 vertical machining centre we have for sale. Contact us for further details. - Number of Axes: 5-axis simultaneous- Table Configuration: Fixed rigid table section (Starrtisch U-1530) combined with a 2-axis rotary/tilt table (SPRT650 / Version T)- Spindle Speed: up to 12,000 rpm (Advanced spindle option)- Spindle Taper: SK40- Tool Magazine Capacity: 54 positions- Short circuit power of the grid (SK-Netz): >= 1.6 MVA (100xPnE/R-Modul in kW)- Connected load: 26 kVA- Nominal voltage: 3~ 400 V + N + PE- Nominal current of protective device (In): 50 A- Operational rated current (Ib): 42 A- Grid frequency: 50 / 60 Hz- Grid type, connection type: TN-Netz (5-wire) with grounded and loadable star point- Residual Current Circuit Breaker (RCCB): Without FI-Schalter (recommended)- Control System: SIEMENS 840D-SPIOS V1 (SINUMERIK 840D sl sl SPIOS V2 platform)- Measuring System: X/Y/Z linear scales (U-1530 Advanced) paired with a BLUM 3D workpiece touch probe and B/C axis measuring system- Coolant Through Spindle (IKZ): Yes, featuring a high-pressure CTS unit preparation and high-pressure tank (BAZ 70 bar)- Rotary Axis Braking: Hydraulic brakes on B + C axes with 2-way rotary union feedthrough (70/7 bar)- Ambient Temperature Range: 15°C < T < 35°C- Relative Humidity: Nedezc R D Dopfx Airswh

Condition: good (used), Year of construction: 2005, operating hours: 9,999 h, functionality: fully functional, SPINNER Werkzeugmaschinenfabrik GmbH Used CNC Lathe Model: SPINNER UP65 Year of manufacture: 2005 Control: Siemens Sinumerik 840 Main spindle + counter spindle Sauter turret with driven tools Operating hours: 80,412 h Accessories: 3 driven tools, 10 standard tools with holders, 8 empty holders CE certified Buffer battery last changed in March No chip conveyor Typical technical specifications of the SPINNER UP65: • Max. turning diameter: approx. 300–400 mm • Max. turning length: approx. 600–1,000 mm • Swing over bed: approx. 500–600 mm • Spindle bore: 65 mm main spindle • Main spindle speed: approx. 4,000–5,000 rpm • Counter spindle speed: up to approx. 6,000–7,000 rpm Njdpfxoy Sr Iqe Airewh • Main spindle drive power: approx. 15–22 kW • Turret: Sauter tool turret with driven tools • Tool holder: typically VDI30 • Travel paths: X approx. 200–250 mm, Z approx. 600–1,000 mm • Rapid traverse: X approx. 20 m/min, Z approx. 24 m/min • Control: Siemens Sinumerik 840 • Machine weight: approx. 4,500–6,500 kg Chucks: • Main spindle: Ø160 with Ø81, through bore Ø60 • Counter spindle: Ø160 with Ø43

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,520 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, rapid traverse X-axis: 32 m/min, rapid traverse Y-axis: 32 m/min, rapid traverse Z-axis: 32 m/min, controller manufacturer: SIEMENS, controller model: 840D, rotational speed (max.): 12,000 rpm, overall weight: 10,000 kg, spindle speed (max.): 12,000 rpm, spindle nose: ISO 40, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Year: 2018, CE compliant CNC: SIEMENS 840D with SHOP MILL 4+1 axes ONLY 18,300 power-on hours Worktable dimensions: 2-piece table - fixed 920x540 mm / rotary-tilting 650x500 mm (with extension ring) Longitudinal X-axis travel: 1520 mm Nsdpfxsy Azcle Airswh Transversal Y-axis travel: 520 mm Vertical Z-axis travel: 420 mm Spindle taper type: ISO 40 Spindle speed: 12,000 rpm Automatic tool changer: 32 positions Spindle motor power: 15 kW Approximate net weight: 10,000 kg Accessories: Internal coolant Chip conveyor Full upper enclosure Pneumatic door opening BLUM tool presetting and workpiece probe capability

Condition: ready for operation (used), Year of construction: 2016, travel distance X-axis: 2,660 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 10,000 rpm, number of axes: 5, This 5-axis SPINNER U5-2520 was manufactured in 2016. It features an impressive X-axis travel of 2660 mm, Y-axis travel of 520 mm, and Z-axis travel of 460 mm. The machine is equipped with a spindle speed of 10,000 rpm and an automatic tool changer with 2x52 positions. If you are looking to get high-quality machining capabilities, consider the SPINNER U5-2520 vertical machining centre we have for sale. Contact us for further details. • B-axis: +110° / -90° • ATC: 2 x 52 tools Nedpfx Asy Efxieirewh Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2005, Capacity Max turning diameter: ≈ 300 to 400 mm Max turning length: ≈ 600 to 1000 mm Swing over bed: ≈ 500 mm Spindle Nsdpfey Ewkqjx Airjwh Spindle bore: ≈ 65 mm ← this matches the UP65 naming Chuck size: 200 to 250 mm Spindle speed: ≈ 3500 to 4500 rpm Spindle power: ≈ 15 to 22 kW Axes X travel: ≈ 200 to 250 mm Z travel: ≈ 600 to 1000 mm Rapid traverse: X: ~20 m/min Z: ~24 m/min Tailstock Hydraulic tailstock Quill diameter: ~80 mm Quill stroke: ~100 to 150 mm Machine weight Around 4,500 to 6,500 kg

Condition: ready for operation (used), Year of construction: 2015, operating hours: 5,381 h, functionality: fully functional, machine/vehicle number: AS0211, spindle speed (max.): 5,000 rpm, travel distance X-axis: 180 mm, travel distance Y-axis: 90 mm, travel distance Z-axis: 704 mm, controller model: FANUC SERIES 31 i-MODEL A, No minimum price – guaranteed sale to the highest bidder! Placing a bid obligates you to collect the machine within the specified periods: either between 11.05.2026 and 13.05.2026 or between 18.05.2026 and 21.05.2026. TECHNICAL DETAILS TRAVEL DISTANCES X1-axis: 180 mm X2-axis: 180 mm Y1-axis: ±45 mm Z1-axis: 704 mm Z2-axis: 620 mm E2-axis: 720 mm Rapid traverse X/Y/Z-axis: 30 m/min SPINDLE 1 Max. speed: 5,000 rpm Spindle nose: A6k Spindle bore: 65 mm Draw tube bore: 65 mm Chuck diameter: 210 mm Drive power: 24 kW SPINDLE 2 Max. speed: 7,000 rpm Spindle nose: Ø 110 mm Nwsdpfx Asym Ai Hjirsh Spindle bore: 42 mm Draw tube bore: 42 mm Chuck diameter: 140 mm Max. chuck jaw weight: 1.25 kg Output power: 16.5 kW Max. speed for driven tools: 8,000 rpm Number of tool turret stations 1: 12 Number of tool turret stations 2: 10 All tool positions are driven MACHINE DETAILS Control: FANUC SERIES 31 i-MODEL A Operating voltage: 400 V Frequency: 50–60 Hz Rated current: 80 A Dimensions & Weight Installation dimensions (L x W x H): 4,500 x 2,400 x 2,400 mm Machine weight: 9,000 kg Read operating hours: 5,381 h EQUIPMENT Chip conveyor by KNOLL Tool holders (as shown in the photos are included) External reference: Dürr

Condition: used, Year of construction: 2012, x-travel 760 mm y-travel 460 mm z-travel 460 mm control TNC 620 Heidenhain turning speed range - main spindle max. 12.000 min/-1 power capacity - main spindel 14 / 10 kW Torque 89 / 63,7 Nm tool taper SK 40 table surface area 900 x 410 mm max. table load 350 kg T-slots 4x number of toolpositions 24 pos. max. tool diameter 130 mm Nwedpfezgibujx Airjh max. tool length 200 mm max. tool weight 8,0 kg rapid traverse ( X / Y / Z ) 36 m/min total power requirement 20 kVA weight of the machine ca. 3,3 t dimensions of the machine ca. 3,0 x 2,5 x 2,9 m CNC Machiningcenter Vertical SPINNER - VC 750

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 450 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, LOW operating hours! Spindle hours: 1,300 h Power-on hours: 10,700 h Control: SIEMENS 840D SL OPERATE Travel: X = 450, Y = 400, Z = 400 mm Table size: 770 x 410 mm Max. workpiece weight: 200 kg Tool changer magazine with 24 stations Tool holder: SK 40 Max. spindle speed: 15,000 rpm Nwsdpfx Asy Ifmxjiroh

Condition: ready for operation (used), Year of construction: 2015, operating hours: 12,244 h, spindle speed (max.): 4,500 rpm, travel distance X-axis: 275 mm, travel distance Z-axis: 700 mm, spindle motor power: 11,000 W, total height: 1,620 mm, overall weight: 4,200 kg, controller manufacturer: SIEMENS, controller model: 840D-SolutionLine, number of slots in tool magazine: 16, number of axes: 2, This 2-axis SPINNER TC 600-65MC horizontal turning machine was manufactured in 2017, featuring a Siemens 840D control system and a 16-position indexing turret. It includes a main spindle with a speed of up to 4,000 rpm and a power of 24 kW. The machine offers a swing diameter over bed of 425 mm and a maximum turning diameter of 310 mm. Consider the opportunity to buy this SPINNER TC 600-65MC horizontal turning machine. Contact us for more information about this machine. Additional equipment • Full splash guard cladding + coolant unit • Work area light + pneumatic equipment • Panoramic window for optimum visibility into the work area Machine Benefits Technical Machine Benefits • Center distance: approx. 600 mm • Max turning diameter: 310 mm • Torque: main spindle (fanuc, s6 40%) 178 nm, main spindle (siemens, s6 40%) 301 nm • Quill stroke: 120 mm • Adjustment travel: 475 mm • Speed of rotating tools: 6000 1/min • Driven tool power: (fanuc, 30 min) 3. 7 kw, (siemens, 40%) 6. 0 kw Nwjdpfx Aex D E Hnjirsh Extra Information Media Pneumatics max. operating pressure: 10 bar Normal pressure: 6 bar Hydraulics max. operating pressure: 30 bar Control Unit Control system: Standard Siemens 840D, Option Fanuc 21i Operating voltage: 400 V Mains frequency: 50/60 Hz Control voltage: 24 V DC Interfaces: USB, Ethernet, SPINNER-UNIMAG bar feed (electric) Technical Specification Through-spindle Coolant No Counter Spindle No Driven Tools Yes Taper Size VDI 30

Condition: excellent (used), Year of construction: 2013, Spinner TC600-65MC cnc lathe with C-axis and driven tools Year: 2013 Technical details: Control SIEMENS 840D-SolutionLine Spindle speed range: 4500 rpm Spindle motor power: 11 kW/ 16.5 kW Torque: main spindle (siemens, s6 40%) 301 Nm X-Axis Movement: 230 mm X-Axis Rapid Traverse: 15 m/min Z-Axis Movement: 740 mm Z-Axis Rapid Traverse: 24 m/min Center distance: approx. 600 mm Max turning diameter: 310 mm Workpiece diameter over bed: 425 mm Number of turrets: 1 Tool taper: DIN 69880/ VDI30 Number of turret stations: 16 Driven tool holder positions: 16 C-axis Speed of rotating tools: 6000 1/min Driven tool power: 6 kW Tailstock: Quill stroke: 120 mm Adjustment travel: 475 mm Machine dimensions: 2730x1500x1620mm Nwedpfx Aisy Sv Egerjh Machine weight: 4500 kg Accessories/options: - hydraulic chuck with jaws - collet type chuck with collets - static tool holders - driven tool holders - Renishaw tool measuring arm - Swarf conveyor - High pressure coolant system - Bar feeder - Documentations

Condition: excellent (used), Spinner MVC 1100 + 4th/5th axis indexing head Njdpfxszd Ad De Airswh Year of manufacture: 2005 Control system: - Fanuc control Travel ranges: - X - 1100, Y - 610, Z - 610 mm Spindle: - Tool holder: SK40 - Speed range: max. 8000 rpm Table design: - Clamping surface: 1200 x 600 mm - Max. table load: 1000 kg Tool magazine: - Tool changer: 24 magazine positions Additional options: - Chip conveyor - Coolant through spindle (CTS) - Documentation Delivery time: - Immediately available Info: - New spindle in X-Y-Z - New main spindle bearings in 2025 - 4th axis indexing head

Condition: good (used), Year of construction: 2005, Ref. -No.: 10475 Manufacturer: SPINNER Type: TC52-MC Year of construction: 2005 Type of control: CNC-Steuerung Control: Siemes 810 D ShopTurn Storage location: Halberstadt Country of origin: Germany Machine-No.: AN0XXXX Turning Speeds: 280/400 RPM Tool holder type: Stahlhalter 9 pcs. Turning Diameter: 280/400 mm Turning Length: 550 mm Tool Taper: VDI 30 Spindle Speed Max.: 5.000 RPM Turret places: 12 Pcs Further information: Three-jaw chuck: Schunk brand Nodjzc Dzvjpfx Airjwh Driven tool stations Oil mist extraction Coolant system Cabin, extraction Donaldson Tirit DCE Machine can be inspected under power by arrangement.

Condition: ready for operation (used), Year of construction: 2023, spindle speed (max.): 5,000 rpm, travel distance X-axis: 360 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 1,580 mm, spindle motor power: 29,500 W, total height: 2,115 mm, total width: 1,980 mm, overall weight: 8,500 kg, product length (max.): 5,750 mm, number of axes: 3, This 3-axis SPINNER TC800L 110 was manufactured in 2023. The machine is fully functional and includes a steady rest, tailstock, chip conveyor, and oil mist extraction system. It operates on a 3-phase power supply at 400 V. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800L 110 horizontal turning machine we have for sale. Contact us for further details. • Status/condition • Machine powered on and still in operation • Fully functional; steady rest requires sensor bang-up replacement • Configuration and capacities • Turret without AgW (adjustable power supply) • Turret type: axial/radial • Number of tool stations: 12x VDI50 (option: 16x VDI40 or 12x BMT65) • Tool holder type: VDI50 (option: VDI40/BMT65) • Number of driven tools: 12 (option) • Driven tool speed: 4000 rpm • Driven tool power (S1/S3): 2.2 / 5.5 kW • Driven tool torque (S1/S3): 17.5 / 43 Nm (axial), 14 / 35 Nm (radial) • Maximum turning diameter: 500 mm • Maximum swing diameter: 800 mm • Turning length: 800 mm / 1580 mm (L version) • Distance between centers: 800 mm / 1580 mm • Maximum workpiece weight: 800 kg • Axes • Rapid traverse X/Z: 15 / 24 m/min • Spindles • Number of spindles: 2 • Main spindle • Nose: A11 • Bar capacity: 110 mm • Torque (100% / 40%): 175 / 235 Nm • Torque gear stage 2: 700 / 939 Nm Nwedpjyyzucefx Airsh • Sub spindle (option) • Nose: A6 • Bar capacity: 52 mm • Chuck size: 210 mm • Power (S1/S6): 15 / 19 kW • Torque (S1/S6): 95 / 121 Nm • Tailstock (if equipped) • Pinole diameter: 110 mm • Taper: MK4 • Stroke: 100 mm • Thrust force: 850 daN • Fluids and tanks • Coolant tank capacity: approx. 235 l (up to 270 l in L-version) • Hydraulic tank: approx. 31 l • Central lubrication tank: approx. 2–3 l • Electrical data • Electrical connection: 3-phase 400 V + N + PE • Frequency: 50/60 Hz (also stated as 50 Hz) • Rated current: 44 A • Fuse protection current: 50 A • Rated current protection: 63 A • Connected load: approx. 40 kVA (up to 50 kVA with 2 spindles) • Protection class: BA 3 (Chap. 3.4.5) • Network type: TN network with grounded neutral point • Recommended protection: without FI switch (recommended) Additional equipment • Steady rest (note: sensor bang-up replacement needed) • Tailstock • Chip conveyor • Oil mist extraction system • Possibly chuck and tool holder (to be confirmed) Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 1996, spindle speed (max.): 8,000 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 285 mm, number of axes: 2, Horizontal turning machine manufactured in 1996. This SPINNER SB-CNC features an X-axis travel of 250 mm and a Z-axis travel of 285 mm. The main spindle operates at a speed of 8,000 U/min. If you are looking to get high-quality turning capabilities, consider the SPINNER SB-CNC machine we have for sale. Contact us for further details. Defects: X-axis standstill monitoring triggeredControl cabinet cooling system defective Njdezb Icujpfx Airjwh • Voltage: 3/PE ~ 400 V • Frequency: 50 / 60 Hz • Operating Current (IB): 20 A • Rated Current (IN): 25 A Technical Specification Counter Spindle No Driven Tools No

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 200 mm, travel distance Z-axis: 500 mm, controller manufacturer: SIEMENS, controller model: Sinumerik, number of axes: 2, Horizontal turning machine manufactured in 2000. This SPINNER PD CNC features a Siemens Sinumerik control system, ensuring reliable operation. If you are looking to get high-quality turning capabilities, consider the SPINNER PD CNC machine we have for sale. Contact us for further details. Defect: Njdpfjzb H Uiex Airjwh Revolver gear mechanism defective • Horizontal Turning Machine • Control: Siemens Sinumerik • Technician required Technical Specification Counter Spindle No Driven Tools No

Condition: like new (used), Year of construction: 2021, operating hours: 900 h, functionality: fully functional, Control: FANUC Series 32i Model B Swing over bed: 600 mm Max. turning diameter: 400 mm Max. turning length: 650 mm Spindle bore: D65 mm X-axis travel: 275 mm Z-axis travel: 700 mm C-axis: 0.001 degree Rapid traverses (X / Z): 15 / 24 m/min Spindle speed: 5,000 rpm Drive power: 34 kW Torque: 325 Nm Tool stations: 12 (all stations driven) Tool holder: VDI40 Speed of driven tools: 6000 rpm Weight: approx. 5800 kg Dimensions (L x W x H): 2800 x 1750 x 2090 mm Nwedpezd Evcofx Airsh Equipments, accessories: - Programmable C-axis - Driven tool turret - Chip conveyor - Coolant system - Static tool holders - Driven tool holders - Tool setter / Tool measuring arm - D200 mm hydraulic 3 jaws chuck - Tailstock - Manuals The machine is barely used and is in mint condition. Immediately available.

Condition: excellent (used), SPINNER TC600-65 SMCY | Year of manufacture 2012 | Y-axis | BMT45 | driven tools | Siemens 840D | 15 bar HPC For sale is a high-quality CNC turning center, the SPINNER TC600-65 SMCY, manufactured in 2012. Technical data: Manufacturer: SPINNER Werkzeugmaschinenfabrik GmbH Type: TC600-65 SMCY Year of manufacture: 2012 Machine number: AT0560 Working area: • Max. turning diameter: 400 mm • Max. turning length: 650 mm • Max. swing diameter: 600 mm • Travel in X-axis: 275 mm • Travel in Y-axis: mm • Travel in Z-axis: 700 mm • Spindle bore: 65 mm Tool system: • 16-position turret BMT45 • 16 driven tool stations • Spindle orientation • Tool measurement in the working area Control system: • Siemens 840D Equipment: • Y-axis for complex milling and drilling operations • 16-position BMT45 turret with driven tools • Direct measuring system in the X-axis • Tailstock • High-pressure coolant system 15 bar • Automatic sliding door • Robot interface for automation solutions • Hardened and ground slideways • Heavy-duty, FEM-optimized machine bed made of cast iron • High vibration damping for precise machining results Electrical data: • Mains connection: 400 V • Frequency: 50 / 60 Hz • Operating current: 53 A • Rated current: 63 A ✔ Y-axis and driven tools for complete machining ✔ Automation-ready via robot interface ✔ Powerful Siemens Sinumerik ONE control system Bar loader: CUCCHI GIOVANNI CNC-DB70 Nedpfxozgvgke Airjwh Stand loader 3300mm, 12-70mm diameter Year of manufacture 2012 is included in the price. The machine is in technically perfect and well-maintained condition and can be inspected under power by appointment. Further technical documentation, accessory lists, videos, as well as information on price and availability are available upon request.

Condition: excellent (used), Year of construction: 2008, MACHINE DATA Nwodpfxottu A Hj Airjh Type Machining center - Vertical Make SPINNER Type MVC 1100 Year of construction 2008 CNC control Siemens Country of origin Germany Delivery time immediately Freight basis ex location TECHNICAL DETAILS x-path 1100 mm y-path 510 mm z-path 510 mm rapid traverse 18/18/15 m/min Siemens control Type 840 D SL Shop Mill Table surface 1200x600 mm Workpiece weight 1000 kg Spindle speed - infinitely variable 8000 rpm Spindle holder: ISO 40 Tool changer 24 Cooling through the spindle 20 bar Machine weight approx. 8 tons Space requirement approx. 3000x2350 m Store mill Preparation for 4 axis

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, For sale is a high-quality CNC turning and milling center, a Spinner TC77-SMCY with Siemens Sinumerik control. The machine is equipped with: Y-axis C-axis Counter spindle Powered tools Chip conveyor Extensive tool package Technical data: Njdpoy Uwmwefx Airjwh Bar diameter 77 mm 12-position VDI50 turret Main spindle ASA 8 Counter spindle ASA 6 Speed up to 4000 rpm Turning diameter approx. 500–690 mm Turning length approx. 800–900 mm Y-axis ±60 mm Main and counter spindle Weight approx. 6000–7000 kg

Condition: ready for operation (used), Year of construction: 2009, operating hours: 1,000 h, travel distance X-axis: 360 mm, travel distance Z-axis: 980 mm, controller manufacturer: SIEMENS, controller model: 840D Solution Line, number of axes: 4, This 4-axis SPINNER TC800 was manufactured in 2009. It features a radial turret and is equipped with Siemens control, ensuring reliable operation. With approximately 1,000 operating hours, this machine has been barely used. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800 horizontal turning machine we have for sale. Contact us for further details. • Control: Siemens 840D Solution Line • X-axis travel: approx. 360 mm • Z-axis travel: approx. 980 mm • Rapid traverse X-axis: approx. 18 m/min • Rapid traverse Z-axis: approx. 24 m/min • Main spindle speed: up to approx. 4000 rpm • Main spindle power: approx. 24 kW (100%) • Main spindle power: approx. 33 kW (40%) • Spindle nose: A8 • Bar capacity: approx. 77 mm • Counter spindle: Yes • Counter spindle speed: up to approx. 5000 rpm • Counter spindle power: approx. 15 kW • Counter spindle spindle nose: A6 • Counter spindle bar capacity: approx. 52 mm • Tool turret type: VDI 50 • Number of tool stations: 12 • Driven tools: Yes • Number of driven tools: up to 12 • Driven tool speed: up to approx. 4000 rpm • Maximum turning diameter: approx. 500 mm • Maximum swing over bed: approx. 800 mm Njdpfx Ajyv Epvjirewh • Maximum turning length: approx. 800 mm • Tailstock: Yes • Tailstock taper: MK4 • Tailstock stroke: approx. 100 mm • Tailstock force: approx. 8500 N • Voltage: 400 V • Frequency: 50/60 Hz • Control voltage: 24 V DC • Compressed air pressure: approx. 6–10 bar • Hydraulic pressure: approx. 70 bar • Chip conveyor: Yes • Coolant system: Yes • Hydraulic unit: Yes • Electrical cabinet: Yes • Radial turret • No quill • Barely used, approximately 1,000 operating hours Technical Specification Counter Spindle Yes Driven Tools Yes
