Gear Hobbing Machine - Horizontal

PFAUTER P 160 H

Condition: used, Year of construction: 1992, max. wheel diameter 175 mm gear width 710 mm max. module 4,5 min. module 0,5 weight 4,5 t Nwjdpfevzhfrox Af Iob total power requirement 10,5 kW Equipment/accessories: - Milling arbors - Clamping devices - Documentation

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, turning length: 810 mm, turning diameter over cross slide: 800 mm, turning diameter: 320 mm, spindle motor power: 25,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 810 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 6,000 rpm, CNC FANUC MSX-701 / MAPPS IV Nedpowlvlgefx Af Ijwb CAPACITY Swing diameter over bed: mm 800 Swing diameter over cross slide: mm 800 Maximum turning diameter: mm 320 Standard turning diameter: mm 200 Maximum distance between the center: mm 1.130 Maximum turning length: mm 810 Maximum workpiece size: mm 300 TRAVELS X axis turret 1 and 2: mm 210 Y axis turret 1 and 2: mm +65 / -45 Z axis turret 1 and 2: mm 810 B axis headstock 2: mm 920 MAIN SPINDLE Maximum speed: rpm 5.000 Drive power (30 min / continuous operation): kW 25/22 Maximum bar diameter: mm 65 Spindle bore: mm 73 Spindle diameter in front bearing: mm 120 Spindle mount: JIS A2-6 C-axis resolution: degrees 0,001 SUB SPINDLE Maximum speed: rpm 5.000 Drive power (30 min / continuous operation): kW 25/22 Maximum bar diameter: mm 65 Spindle bore: mm 73 Spindle diameter in front bearing: mm 120 Spindle mount: JIS A2-6 C-axis resolution: degrees 0,001 FEED DRIVES Rapid traverse turret 1 X/Y/Z: m/min 30/20/50 Rapid traverse turret 2 X/Y/Z: m/min 30/20/50 TOOL TURRET Number of turrets: 2 Number of tool stations per turret: 16 Shaft cross – section for turning tools: mm 20 x 20 Maximum shaft diameter for boring bars: mm 32 Turret switching time (1 station): s 0,18 Maximum speed of the driven tools: rpm 6.000 Drive power for driven tools (5 min/continuous operation): kW 7,5/5,5 DIMENSIONS Installation area with chip conveyor: mm 5.120 x 2.720 Net weight: kg 8.300 Macchina equipped with: • High pressure cooling system • Bar loader interface • Gantry-type piece unloading arm • Cutting effort management system and load monitor • No. 1 double radial motorized tool holder • No. 3 axial motorized tool holders • No. 2 external tool holders • No. 2 double boring bar holders • No. 2 single radial motorized tool holders • No. 2 internal boring bar holders • No. 2 Kitagawa BD 208 self-centering chucks diam. Mm 210 • No. 1 set of jaws for each self-centering chuck • Instruction manuals and CE declaration Year of manufacturing: 2010

Condition: used, Year of construction: 1969, max. wheel diameter 160,175 mm gear width 355 mm max. module 4,5 spindle bore 75 mm centre distance 410 mm min. number of teeth 2, 3 cutter diameter max. 115 mm cutter length max. 105 mm axis distance between cutter and workpiece - max. 138 mm axis distance between cutter and workpiece - min. 30 mm milling head -swivable 120 ° milling spindle speeds 70 - 400 U/min axial-feeds 0,25 - 4,0 mm/U radial feeds 0,09 - 1,5 mm/U total power requirement ca. 9,5 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1730x1400x1440 mm Equipment/accessories: - Interchangeable wheels - Milling arbors - Clamping devices - Documentation Nwjdpfx Aevzhf Sjf Iob

Year of construction: 1970, condition: ready for operation (used), Wheel diameter: 160mm, max. wheel width: 355mm, module range: 0.5-4.5, max. cutter diameter: 115mm, max. cutter length: 105mm, cutter head swivel range: 120°, speed: 400rpm, distance between centers: 410mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 3500kg. An on-site inspection is possible. Njdjxph Skjpfx Af Iewb

Condition: used, Year of construction: 1988, Control Grundig x-travel 700 mm y-travel 500 mm z-travel 400 mm weight of the machine ca. 2,8 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Nwsdpfx Afjiqu S Ee Ieb Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 1992, max. wheel diameter 160 mm gear width 710 mm max. module 4,5 Nwodpsvz Edrofx Af Ieb min. module 0,5 milling spindle speeds (infinitely variable) 70 - 400 U/min centre distance 800 mm total power requirement 11 kW weight of the machine ca. 4,7 t dimensions of the machine ca. 3,6 x 3,0 x 2,0 m 2-cut-cycle, shifting, very nice condition. Change gears, arbors.

Condition: good (used), Year of construction: 2004, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: Nwedpfeul Efmjx Af Ijb The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 1982, workpiece weight 60 kg workpiece length 700 mm diameter 500 mm total power requirement kW Nwjdpfxot Hxbqj Af Isb weight of the machine ca. t dimensions of the machine ca. m

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 52.693.00, feed length X-axis: 1,525 mm, feed length Y-axis: 1,525 mm, feed rate Y-axis: 1 m/min, feed rate Z-axis: 1 m/min, Welding Robot – Fully Equipped Vertical Bend Arm Robot 6 axes Reach: 1525 mm Equipped with automatic welding gun, type: DIX MALZ 520 Wire feed device, manufacturer: FRONIUS, type: ROB.VR1500 DINSE-ZA Njdpfxjrl S Ufe Af Iowb Includes 2 rotary welding tables Plate dimensions: each 1200 × 750 mm Pneumatically driven cleaning device Positioning and straightening station for the torch Current source, manufacturer: FRONIUS, type: welding device TPS 4000 Supplied with technical documentation Note: The machine can be transported on a standard truck. Technical Attributes Dimensions (L × W × H): approx. 4700 × 3500 × 3800 mm Weight: approx. 5000 kg Year of construction: 2000

Condition: used, Year of construction: 2001, Turning length 470 mm Max. torning dia. 390 mm Spindle speeds 3500 rpm Movements X/Z - 235/520 mm No of stations in turret 12 pcs. Control: MSG 500 Nwsdpfsxdfi Nex Af Iob Accessories: Various tool holders
