Used Horizontal bending machines - bending force 26t to 39t for sale (12)

Condition: new, Year of construction: 2025, Omach / Karbend benders Bp10 Bp20 Cebefd Ib Ds Hn N Syogt Bp30 Bp40 Bp 100 Available from stock

Condition: good (used), Good condition with accessories Cgjbewg Tbue Hn N Syet

Condition: good (used), Hydraulic Press Brake PROMECAM RG 35-20 Slide travel: 100 mm Cob Hnsvwm Aze N Sysgt Distance between colums: 1690 mm Throat depth: 200 mm Capacity: 35 T Bending length: 2000 mm Mechanical Back rear Gauge - Back gear gauge travel: 350 mm Voltage: 380 V Length: 2200 mm Depth: 1300 mm Total height: 2000 mm Weight: approx 3,5 T

Condition: ready for operation (used), Year of construction: 2014, Functionality: fully functional, stroke distance: 350 mm, pressing force: 30 t, controller model: Siemens SPS, TECHNICAL DETAILS Pressure: 30 t Stroke: 350 mm Clearance: 450 – 570 mm Max. tool height: 300 mm Operating pressure: 315 bar Control: Siemens PLC Bending capacity Bending capacity: 300 x 25 mm at V 160 Bending capacity: 300 x 32 mm at V 200 Straightening capacity: 30 t at 1,500 mm Cgsb Hsv Un Tcjn N Syst MACHINE DETAILS Dimensions L x W x H: 1,600 x 900 x 1,100 mm Weight: 800 kg Total power requirement: 7.5 kW EQUIPMENT - Straightening beam with bolts - Round material bender with 1 x roller set

Condition: good (used), Year of construction: 1997, 1 used horizontal bending machine Make Apollo Type P 400 Year of manufacture 1997 Technical data: Pressing capacity 40 t Table dimensions 500 x 760 mm Stroke of the working ram 250 mm Working speed 9 mm/s Bending capacity 200 x 20 mm Cutting capacity 150 x 12 mm Maximum pressure 280 bar Tank volume 60 l Motor power 5.5 kW Cjb Hjvzrdfsn N Syjgt Dimensions (W x D) 1,260 x 500 mm Height 1,100 mm Weight 820 kg

Condition: used, Year of construction: 1987, pressure / t stroke / mm Cgsb Hn N Seuddcasyjt table-size / mm weight of the machine ca. 65000 kg Make: Shepherd Type: SVRM 4-roller bending machine: Year of construction: 1986 Working width: 3000cm Smallest pipe diameter with 600 mm roller: Ø 720 mm Smallest tube diameter with 360 mm roller: Ø 460 mm Sheet thickness up to (depending on the material): 50 mm Material SA- 738 B Working width: 2500 mm Material SA- 738 B Material thickness: 35 mm conical bending: Except for the top roller, all rollers can be moved in an inclined position for conical bending. The roller positions can be read on display instruments. For semi-automatic or fully automatic operation of the machine, the bearing jewels of the rollers are equipped with scale bars and slide cams for limit switch actuation. This allows the rollers to return to the same set position over and over again, giving a very high level of uniformity in the shot wefts being bent.

Condition: new, Year of construction: 2024, Horizontal bending machine T 300 Multi - ZOPF - with semi-automatic control - (99 bending programs each 16 steps) - hydraulic pressure 30 to. - length of stroke 250 mm - bending speed adjustable - max. working speed 10 mm/sec. - return speed 20 mm/sec. - hydraulic pressure adjustable Cgsb Hjfh Tntsn N Syst - maximum bending high 250 mm - motorcapacity 3,0 KW - 400 V 50 hz 3 ph. - working height 900 mm - closed table - replaceable wear plate - weight 950 kg - colour RAL5012 / RAL7015 - bending capacity: flat material max. 200x20 mm round tube 3/8" - 2"

Condition: ready for operation (used), Year of construction: 2012, operating hours: 67,352 h, Functionality: fully functional, working height: 1,150 mm, stroke distance: 120 mm, pressing force: 36 t, feed length X-axis: 240 mm, back gauge travel distance R-axis: 80 mm, distance between stands: 932 mm, The brake was converted to the new variant in 2017. PCCS was renewed in 2021. TECHNICAL DETAILS Max. pressing force: 360 kN Mounting height: 300 mm Clearance between the columns: 932 mm Arm reach: 150 mm Working height: 1,150 mm Control: TRUMPF TASC 6000 Speeds and axis data Y-axis working speed: 220 mm/s Y-axis maximum stroke: 120 mm Inertia run time: max. 90 ms Minimum safety distance: 180 mm Reverse speed: 220 mm/s X-axis speed: 1,000 mm/s R-axis speed: 330 mm/s Z-axis speed: 1,000 mm/s X-axis positioning speed: 0.04 mm R-axis positioning speed: 0.06 mm Travel path X-axis: 240 mm R-axis travel: 80 mm MACHINE DETAILS Space requirement: 1,805 x 1,330 x 2,380 mm Machine weight: approx. 2,600 kg Total connected load: approx. 6 kVA Ceb Hjvxkchjn N Syegt Operating hours: 67,352 hours at 8851,728 strokes EQUIPMENT - Back stop system (6 axes) - Foldable comfort support table at the front - Comfort footrest - Work area lighting at the front (LED) - Swiveling control unit - BendGuard safety device with block laser - Automatic tool clamping at the top and bottom

Condition: used, pressure 32 t stroke 250 mm table-size 500 x 760 mm work height max. 925 mm bending speed max. 25 mm/sec tank capacity 80 l Pressure power 320 bar total power requirement 5,5 kW weight of the machine ca. 0,8 t dimensions of the machine ca. 1,3 x 0,5 x 1,3 m ding height: 200 mm Cutting capacity max. (St): 150 x 14 Punching capacity max. (St) Ø 35 Guide height: 200 mm Ceb Hnogvkigj N Syogt

Year of construction: 2022, Condition: new, pressure 28 t piston stroke 180 mm diameter of piston 130 mm table-size 300 x 550 mm working feed 2 - 9,8 mm/sek return speed 20 mm/sec Max. pressure 200 bar bending capacity - flat iron 200 x 10 mm weight of the machine ca. 800 kg dimensions ca. 1150 x 1103 x 750 mm Ceb Hnsqzmgqj N Sysgt The horizontal hydraulic press (28 ton) can be used for many different metal working jobs. The press has a piston stroke of 192 mm and can be equipped with all kinds of tooling for specific bending or straightening jobs. We supply a standard toolingset with this press including a stampholder and backgauge. However, we also produce custom-made tooling for your specific request. Thanks to the NC-control you can easily set the cylinder stroke and save up to 100 working cycles. With this horizontal hydraulic press you are able to bend, straighten, notch, cut and form. A universal hydraulic press that serves all your needs in cold metal working processes.

Condition: new, Horizontal bending machine Fastech FP 30 Description - Pressure: 30t - Stroke: 285mm - Max. tool height: 250mm - Flat bar over high edge: 200 x 18mm - Working speed: 10,0mm/sec - Returning speed: 10,0mm/sec - working height: 930mm - table: 660 x 1250mm - total power requirement: 3,0kW - Motor: 400 Volt 50Hz - weight: 1050kg - dimension L-W-H: 1250 x 650 x 1250mm - Oil capacity: 40,0l Equipment: - Hydraulic horizontal bending machine - Solid working surface made of stabilized steel Ceb Hnjfg Eu Ue N Syogt - Machine made of hardened and ground forged steel - Digital display for stroke adjustment - 1x set of tools - Double foot switch

Condition: new, pressure 28 t stroke 180 mm table-size 300 x 550 mm diameter of piston 130 mm work speed min. 2 m/sec work speed max. 9,8 m/sec return speed 20 mm/sec Max. pressure 200 bar weight of the machine ca. 0,65 t total power requirement 4 kW Cgob Hn N Ssgvkmreyjt dimensions of the machine ca. 1,15 x 0,75 x 1,1 m • The horizontal bending and straightening press from Profi Press is a universal one Hydraulic press specially designed for performing bending, profiling and Straightening work is designed. The applications of the machine are different and depend on the accessories that are on the work table, the Tool holder and are installed in the holes and pin holes. • The HB-28 model is used for light bending measurements on the work table equipped with an angle scale, and the press can also be equipped with tools are supplied (for example block punching) that are placed on the tool holder Can be assembled, as well as tools that are in the holes and pin holes can be installed to carry out various types of work. • The hydraulic system can be adjusted with the help of the pressure and flow adjustment valves can be regulated, which is the pressing force and the speed of the press influence. The press is equipped with a built-in manometer. • The control panel is used to operate and display the piston stroke and for Choice between manual or automatic operation, and the HB-28 model is also with a built-in memory for up to 4 different programs fitted. • Operation is via electric foot pedals. • The Profi Press HB-28 model can be equipped with various optional accessories hearing parts and tools for installation on the workbench and the Tool holder to be delivered.
