Used Celtic Lathe for sale (5,352)

Condition: used, turning diameter over bed 600 mm turning length 2800 mm centre height / mm VDF-Heidenreich & Harbeck E3 H – Conventional Lathe Offered for sale is a robust, high-performance VDF-Heidenreich & Harbeck E3 H conventional lathe. The machine features a distance between centers of approx. 2,800 mm and a turning diameter of approx. 600 mm. Its generous distance between centers makes it particularly suitable for machining long and large-volume workpieces. Technical Specifications Manufacturer: VDF-Heidenreich & Harbeck Model: E3 H Hnedpfx Acjzu A T Hsqjr Machine Type: Conventional lathe Distance between centers: approx. 2,800 mm Turning diameter: approx. 600 mm Includes: 2 steady rests Robust and durable construction Suitable for single-part production, repair work, and general machining operations This machine is ideal for workshops seeking a classic, robust, and versatile lathe for machining large and long workpieces. Sold as-is (as inspected). Viewing available by appointment. Technical specifications subject to change and provided without guarantee.

Condition: used, Year of construction: 1999, turning diameter / mm Hsdpfx Acszu A Tteqsnr turning length / mm control /

Condition: good (used), Year of construction: 2003, *Description* ROSILIO TBI 280, a 2-axis CNC lathe in good overall condition. This robust 2200 kg machine is ideal for subcontracting and small production runs. User-friendly FAGOR 8055TC-A control system with a color screen. The machine is well-maintained and can be viewed in operation. *Technical Specifications* - *Make / Model*: ROSILIO TBI 280 - *Year*: 2003 - *Serial Number*: CNC 0315063 - *Numerical Control*: FAGOR 8055TC-A - *Type*: 2-axis X-Z CNC Lathe - *Weight*: 2200 kg - *Dimensions*: L 2.0 m x W 1.45 m x H 1.8 m - *Voltage*: 400V 3-phase - 50/60Hz - *Installed Power*: 15 KVA - *Air Pressure*: 6 kg/cm² Hnodpfxjzt Tk He Acqor *Equipment* - Fagor 8055TC control panel with electronic handwheel - Coolant system - Hydraulic system - Automatic lubrication pump - Complete electrical cabinet

Condition: used, Year of construction: 2004, spindle bore 58,0 mm turning diameter 430 mm turning length 760 mm Hedpfjzuppnjx Acqsnr turning dia. in gap 690 mm turning speeds 20 - 2000 U/min quill: 4 MK bed width 300 mm weight of the machine ca. 1700 kg Features: - Digital display - Schunk 3-jaw chuck - Multifix tool holder - Removable bed bridge - Machine light - Chuck guard - Lathe steady - Emergency stop - Operator's manual

Condition: used, Year of construction: 2007, turning length 1500 mm control FAGOR 8055i/A TC centre height 230 mm greates pass round over bed 475 mm swing diameter over slide rest 240 mm bed width 355 mm max. workpiece weight 1500 kg spindle bore 65 mm spindle turning speed range 100-4500 U/min weight of the machine ca. 3,15 t Hnsdpjv Hhv Ujfx Acqer required space 3,51 x 1,80 x 2,02 m

Condition: used, turning diameter over slide rest 800 mm Control Siemens 802D swing diameter 2000 mm Hedpfx Aev H Etdocqonr centre height 1000 mm

Condition: used, Year of construction: 1982, turning diameter over bed 500 mm turning length 1500 mm centre height 250 mm spindle passage 70 mm swing diameter over face slide 285 mm turning speeds 11,2 - 2240 U/min Hedpfx Acsqy Rp Uoqenr

Condition: used, Year of construction: 2001, Technical data: Okuma Space Turn LB 300 MY Year of manufacture: 2001 Control: OSP U 100 L Max. Turning length: 340 mm Chuck diameter: 10 inch X-axis: 280 mm Y-axis: 120 mm Z-axis: 500 mm C-axis: 360°(0.0001°) Spindle: 4500 rpm Spindle clearance: 62 mm Weight: 6000 kg Accessories: -Driven tools Hsdpfx Acoqucnbeqsnr -Chip conveyor -Transformer -Manuals

Condition: used, Year of construction: 2014, control FANUC Series Oi-TD greates pass round over bed 670 mm swing diameter over slide rest 500 mm max. turning diameter 400 mm max. turning length 600 mm spindle nose A2-8 spindle passage 90 mm diameter in the front bearing 130 mm Hnedpozupqlefx Acqsr spindle tunring speed 35 - 3.500 U/min number of tool places 12 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 1973, turning diameter over bed 2235 mm turning diameter over slide rest 2997 mm turning length 12200 mm Control SIEMENS faceplate diameter 2000 mm required space ca. 7 x 22 m weight of the machine ca. 220 t HOESCH MFD CNC HEAVY DUTY LATHE WITH SIEMENS CONTROL Type: D2000 SGK-1 Technical documentation is included Technical Specifications Space requirement: 7 x 22 metres + control cabinet 4.7 x 0.5 x 2 metres Faceplate 2006mm Centre Height 1,499mm Swing Over Saddle 2235mm Swing Over Bed 2997mm Turning Length 12192mm Min/Max Workpiece Held In Chuck Ø457/1600mm Maximum Workpiece Weight 110 Ton Speed Range 0.5- 140rpm (300hp Motor) Feed Range 0.0118-7.08''/Rev. Steady Capacity Ø356-902mm Copying Depth 508mm lnductive Maximum Cutting Force 30,000Nm Twin Barrel Steady Capacity Ø356- 902mm, 50 Ton Capacity, Roller Type. Machine Data Hnodpfx Aot Ei Huscqsr 1.1 Total Machine Max. Swing over bed slide 2,000 mm Center height over bed 1,500 mm Distance between centers 12,000 mm max. weight of workpiece 100,000 kp height measured from shop floor level up to machine axis 2,200 mm 1.2 Headstock Diameter of main spindle 670 mm Diameter of faceplate 2,000 mm Max. chucking diameter 1,600 mm Min. chucking diameter 455 mm Dead Center Angle 80 ° Faceplate Speed: Constant torque 1st range 0,5 – 2,6 2nd range 1,25 – 7,2 3rd range 3,1 - 18 4th range 7,8 - 45 Constant capacity 1st range 9,0 2nd range 22,6 3rd range 56 4th range 140 Capacity of Main Drive 220 HP Max. Torque faceplate 30,000 kpm Key Speed 5,7 rev/min 1.3 Saddle Max. admissible main cutting force 30,000 kp Feed Speed longitudinal 0,3 – 120 mm / min Feed Speed transverse 0,3 – 120 mm / min Rapid Traverse Speed longitudinal 2,000 mm/ min Rapid Traverse Speed transverse 1,000 mm/ min Max. copying depth 500 mm Max. length of tool carrier measured from front edge cross slide to front edge tool carrier 700mm Tool carrier – width 60mm 35 mm Cutting Edge height of tool units 60 mm Cutting edge height of shank-type tools beeing located on the clamping table 100 mm Travel of upper tool post 820 mm 1.4 Tailstock Tailstock barrel diameter 580 mm Adjustment of the barrel 150 mm Dead Center angle 80 ° Speed of rapid traverse 2,000 mm / min Positioning speed 500 mm / min 1.5 Steady Clamping range 350 – 900 mm ...

Condition: used, Year of construction: 1953, turning length / mm turning diameter over plate // mm faceplate diameter / mm Plane disc diameter: approx. 3600mm Centre height above plate: approx. 1500mm Turning diameter over plate: 2600mm Turning diameter in the pit: 3600mm Turning diameter over bed: 1300mm Turning length: approx. 2400mm Max. Workpiece weight: 22000kg Max. Torque on the faceplate: 5000 mkg Faceplate gear rim pitch circle diameter: 1900mm Main spindle bore: 120mm Speed range Hnodpeua Iw Tjfx Acqer normal: 0.71-35.5 rpm increased: 1-50 rpm increased: 1.4-71 rpm Total power: 38kW Total weight: approx. 42.5 tonnes

Condition: excellent (used), Year of construction: 2004, turning length / mm turning diameter over bed / mm turning diameter over slide / mm control / Universal lathe VDF Boehringer DUS 1000 ti OPTIONAL EQUIPMENT SURCHARGE: C-AXIS MILLING TOOL Machine no. 2042.6616-05 Year of construction 2004 Turning length approx. 2200 mm Swing diameter over bed 1,000 mm Swing diameter over bed 1,000 mm Centre height over flat track 500 mm Bed width 560 mm Bed slide guide length 800 mm Spindle diameter front bearing 170 mm Spindle bore 128 mm Infinitely variable three-phase motor (AC motor) Drive power 37 kW Torque max. 4,069 Nm Total speed range 6.4 - 1,600 Gear stages 2 Heidenhain control Manualplus 4110, completely renewed approx. 1 to 2 years Hjdpfjud In Hsx Acqenr ago renewed 2 lynchets Equipped with roto power chuck, diameter approx. 500 mm. Including many accessories of clamping jaws, estimated 15 sets, as well as approx. 15 sets of Multifix basic holders, size D. Machine was equipped with a separate milling device, with its own control, value approx. 20.000,00 €. OPTIONAL EQUIPMENT SURCHARGE: C-AXIS MILLING TOOL Only operated by the owner, very good condition!

Condition: used, Year of construction: 1972, turning length / mm turning speeds / U/min centre height / mm LÖW Universal Lathe V 1000 Details of Model V 1000 Machine no. HO 1026 Centre height over flat track 500 mm Swing diameter over bed 1,000 mm Bed length 6,200 mm Turning length 4,000 mm Spindle bore 104 mm Face disc diameter 900 mm Max. workpiece weight between centres 5,000 kg max. workpiece weight with 1 vice 6,000 kg Hnsdpfezcgi Nsx Acqsr max. workpiece weight with 2 setting vices 7,100 kg incl. documentation

Condition: used, Year of construction: 1988, turning diameter over bed 2000 mm turning diameter over slide rest / mm turning length / mm - Type 1 K 671 320 F3 Hodpfx Aexn Tz Ijcqenr - Year of manufacture 1988 (first commissioned in 1998) - Turning length 10,000 mm - Turning diameter over bed 2,000 mm (modified) - Faceplate diameter 1,950 mm - Faceplate clamping range 400 - 1,350 mm - Speeds 1.00 - 140 rpm - Torque 125,000 Nm - Main cutting force 130 kN max. - Automatic swiveling tailstock - Max. workpiece weight 70 tonnes - Max. workpiece weight with steady rest 100 tonnes - Drive power 100 kW - Number of bed ways 4 - Dimensions 22,000 x 6,200 x 2,900 mm - CNC control SIEMENS 840D (2010 for €220,000.00) - Support feed X-Z 0.3 - 4,000 mm/min. - Support rapid traverse X-Z 4,000 mm/min. - Inner cone dimensions 140 x 1:7 - The machine complies with CE guidelines - Includes 2 steady rests, 1 roller block, 4 jaws, boring device - Condition: very good condition

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Hnsdpfx Acsuddcgeqer Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 1980, turning diameter 7000 mm faceplate diameter 3500 mm workpiece height 3000 mm 160 mm 1998 Control Siemens 840 C max. table load 60000 kg Hnsdpfjuddlzox Acqor electr. connected load 400 V Serial number 11 33 0051 total power requirement 71 kW weight of the machine ca. / t required space 13 x 6 m The SCHIESS-FRORIEP 40 DV is a vertical lathe built in 1980. The machine was modernized and improved in 1998. Among other things, a driven tool system (C-axis) was installed. In addition, the control system was modernized to SIEMENS 840 C. The large open-sided vertical boring mills with travelling column - type DV - are particularly suited to situations where likely workpieces frequently change in diameter but where maximum workpiece dimensions are rare. Decisions in favour of this type of machine are generally due to minimum floor space requirement, universal adaptability and economical advantages. The modern design of these machines is characterized by rigid all-steel construction optimized by computer - SCHIESS can claim to have done much valuable pioneering work in this area of heavy-duty machine tool building.

Condition: excellent (used), Year of construction: 1989, turning length / mm turning diameter over bed / mm turning diameter over slide / mm control / WOHLENBERG PT1-1070II Heavy-duty lathe Very good condition heavy duty lathe, make Wohlenberg. The machine was partially overhauled in 2013! Type PT1-1070II Year of manufacture 1989 partially overhauled in 2013 Country of origin Germany CNC control Siemens 840 D extended from 7 m to 11 m turning length Santer turret geometry Turning diameter over bed 1,070 mm Turning diameter over support 710 mm Turning length 11,000 mm Hsdpeud Ipkjfx Acqjnr Bed width 710 mm 2 gear stages Speed 3.55 - 710 rpm Quill diameter 200 mm Quill stroke 350 mm Spindle clearance 128 mm Chip conveyor Boring tower incl. boring bar Length approx. Ø 200 x 2,430 mm Face plate 1,000 mm Steady rest 4 quills 500 mm open Main drive motor 71 kW incl. documentation

Condition: used, Year of construction: 1962, faceplate diameter 2250 mm swing diameter 4500 mm turning height 2000 mm turning diameter 3150 mm workpiece weight max. 25000 kg total power requirement 55 kW weight of the machine ca. ca. 32 t Hnodsuc Aldspfx Acqsr required space / m

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Faceplate diameter (removable): 1650 mm Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Special equipment Copying device for first support Hnedpfxexddvns Acqer Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. 125 kg auxiliary crane on spindle box.

Condition: used, turning diameter over bed / mm turning diameter over slide rest / mm Hedpowgi Tmofx Acqjnr turning length / mm

Condition: used, turning diameter over bed / mm turning diameter over slide rest / mm turning length / mm Conventional lathe with copying attachment and extensive accessories Turning diameter over cross slide: 240 mm Spindle bore: 52 mm Turning diameter: 360 mm Center height: 180 mm Turning length: 1,000 mm Overall length: 2,200 mm Overall width: 750 mm Overall height: 1,400 mm Maximum spindle speed: 1,750 rpm Min. spindle speed: 60 rpm Total weight: 1,800 kg Hnedpov Rgzwofx Acqer All technical specifications are subject to change without notice. Deviations may occur depending on the year of manufacture, model, or condition of the machine. We assume no liability for the accuracy or completeness of this information.

Condition: used, Year of construction: 2011, turning length 1500 mm control SINUMERIK 828D centre height 270 mm greates pass round over bed 540 mm swing diameter over slide rest 310 mm bed width 350 mm max. workpiece weight 1500 kg spindle bore 85 mm turning speeds 27 - 2250 U/min main drive DC 11 kW MACHINE EQUIPMENT: - AME chip conveyor - Lynette Hnedpfx Asxyaf Rscqjr - Heavy grey cast iron bed for optimum damping and reduced tool wear - Inductively hardened and parallel synchronised bed guides - Counter guides completely Turcite-coated and hand-scraped - Hardened and ground ball screws - Thermosymmetrical headstock - Main drive 11 kW - Infinitely variable speed range 27-2250 rpm with 3-stage gearbox

Condition: used, Year of construction: 1969, turning diameter over bed 500-600 mm turning length 2800 mm bore diameter 130 mm weight of the machine ca. 5,25 t required space / m Hnjdpfx Acovdx I Aeqer

Year of construction: 1961, condition: used, centre height 235 mm turning diameter 470 mm turning speeds 2700 U/min turning length 1500 mm inkl. Zubehör (siehe Bilder) Hedpfx Ajl Ab Htecqjnr

Condition: used, Year of construction: 1972, turning diameter over bed 1650 mm turning diameter over slide rest 1350 mm turning length 10000 mm turning speeds 1,4 - 280 U/min greates pass round over bed 1580 mm center height over square guideway 825 mm bed length 13.350 mm bed width 1.120 mm spindle diameter in front bearing 260 mm spindle bore 82 mm upper head travel 500mm tailstock quill diameter 200 mm max. workpiece weight between centres 10.000 kg weight of the machine ca. 25,5 t Power 45 KW The machine is a first-hand purchase, is free from defects and is in very good condition. In 2023, the headstock was overhauled; this included replacing the main spindle bearings, chrome plating and reworking the main spindle and bottom wheel (bearing seat). The guideways are also in very good condition, considering their age. Hnsdjy S Duvjpfx Acqsr Accessories - Feed guard Equipment - 3-axis digital display - 1 x faceplate - 1 x roller stand - Chip conveyor (Kabel Schlepp 300/100)
