Used Crosscutting Saw for sale (5,453)

Condition: new, A heavy duty German built radial arm crosscut saw with swivel and tilting capability and a large cutting capacity of up to 200mm deep. A unique feature on this model of machine is that when angle cutting is required the saw unit pivots about a central point thus always maintaining the same cutting length. Both optional vertical (tilting) and standard horizontal (swivel) angles can be adjusted manually with either graduated scales or with an optional digital display unit for reading the position. The saw is also available with an optional automatic NC positioning system with 4 memorised pre set positions. The machine is ideally suited for easy and accurate cutting of compound angles for furniture and joinery components. The machine can be specified to cut wood, aluminium, plastics or composite materials. Precision ball bearing movement on hardened steel runners. Sturdy cast iron construction with steel base stand Heavy duty 5 KW motor. Spring return of saw carriage. 1 x 520mm dia TCT x 4.4mm kerf x 50mm bore - 60 teeth WZ saw alternate bevel. 50mm spindle diameter. 22 - 90 - 45 horizontal movement. (Swivel) 30 - 90 - 60 vertical movement. (Tilt - optional N model) Adjustable upper protection. Duedpody Hm Njfx Abhjp 520mm TCT sawblade Z60. Cutting Capacity: 420 wide x 200mm deep at 90 degrees. 295 wide x 200mm deep at 45 degrees. 420 wide x 140mm deep at 45 degrees. (Tilt- optional N model). Dust extraction outlet 100mm. Working height of table 900mm

Condition: used, Year of construction: 2014, Stromab CT600 Automatic Upstroke Crosscut Saw for Straight and Angled Cutting - 2014 CE 6000mm infeed capacity 2000mm Outfeed table 12" Touch screen graphic display Power 1000 controller Remote programming of cutting list via colour graphic touch screen controller - connection via USB key. 5 optimising criteria - longest size, minimum waste, priority size, by volume or by value. Cutting list entered via controller key pad Graphic description of the workpiece. 10hp motor Rack & pinion drive system for pusher with magnetic reading strip to give a high level of  repeat cutting accuracy 600mm diameter blade CUTTING CAPACITY POSITION A) # max height At 0°: mm. 200x215 or 50x370 At 30°: mm. 200x185 or 50x325 At 45°: mm. 200x150 or 50x265 CUTTING CAPACITY POSITION B) # max. width At 0°: mm. 160x315 or 40x410 At 30°: mm. 160x270 or 40x350 At 45°: mm. 160x220 or 40x285 Angle setting -70 degrees, 0 degrees, + 70 degrees Adjustable saw stroke speed Dedpfx Aowl Hyujbhsup Vertical clamping Horizontal clamping Dust extraction 1 off 100mm, 1 off 120mm. Plexiglass hood with gas springs Year - 2014 CE

Condition: used, Hydr. hacksaw KASTO HBS 210 / 240 Duedpfx Asuqgbtobhsp Machine no. No. 1116 145 220 Year of construction 1994 Sawing range at 90° round 210 mm flat 240 x 190 mm square 210 x 210 mm at 45° round 150 mm Saw blade length 400 mm Number of strokes 62 / 125 strokes per min. Material support height 500 mm Motor power 0.5 / 0.75 kW Mains connection 400 Volt, 50 Hz - Drive motor with 2 speeds - Coolant pump in the machine base frame Space requirement L x W x H 1200 x 500 x 1200 mm Weight 170 kg Good condition

Condition: excellent (used), functionality: fully functional, cutting height (max.): 150 mm, cutting width (max.): 400 mm, extraction nozzle diameter: 125 mm, BOTTENE R500 Pendulum Crosscut Saw Specification: • Condition – used, after inspection • Manufacturer – BOTTENE • Motor power – 5.5 kW • Blade diameter – 500 mm • Motor speed – 2,900 rpm • Max cutting width – 400 mm • Max cutting height – 150 mm • Extraction port – 125 mm • Adjustable cutting head for angled cuts • Wheels for easy movement of the saw Dsdpfex Ih Aiox Abhoup • Table width – 48 cm • Overall dimensions when assembled – 409 x 130 x 165 cm (L x W x H) Additional information: • Very good original technical and visual condition • The photos shown reflect the actual condition of the item for sale • Possibility to test the machine on site

Year of construction: 2024, condition: new, - Semi-automatic - Saw blade 420 mm - Double mitre - 4 Pneumatic clamps - Spray lubrication system - Roller conveyor 300 cm with length stop - Blow gun - Protective cap - Technical documentation Duedpfx Ajgg N A Rsbhjp - 400V

Year of construction: 2020, condition: new, Crosscut saw AS-1000 New machine Saw blade diameter 1000mm. Pneumatic minimum quantity lubrication (optional). Hydraulic material clamps (with pressure control). Duedpfx Abofciv Uehsp Hydraulic saw feed (with pressure and flow control). Infinitely variable speed control via frequency converter.

Year of construction: 2018, condition: as good as new (ex-display), Crosscut saw AS-600 Vorfürmaschine Incl. blade diameter 600 mm. Incl. Automatic minimum quantity lubrication. Dsdpfx Aed A T Efjbhsup Incl. smooth lift and manual length stop. Machine can be visited, by appointment, on the spot.

Condition: new, Year of construction: 2024, cutting hight at 90°: 200 mm cutting width: 410 mm Dusdoiuld Sjpfx Abhsp miter square horizontal: 45° - 90° - 25° miter square vertical: 60° - 90° -30° roller convoyer/ supporting table: no saw blade diameter: 520 mm speed: 2800U/min motor power: 5 kW motor brake: yes suction connection: 100mm machine length: machine width: Gewicht: 300kg

Condition: good (used), Year of construction: 1999, machine/vehicle number: 2396, functionality: fully functional, rotational speed (min.): 2,800 rpm, overall weight: 140 kg, Total width: 240 mm Total height: 120 mm Spindle speed (min): 4,000 rpm Spindle speed (max): 7,000 rpm Total weight: 300 kg Rotation speed (max): 7,000 rpm Rotation speed (min): 4,000 rpm Input voltage: Djdpfxswhpnao Abhoup 400 V Equipment: Rotation speed infinitely variable Soundproof automatic overhead milling machine. Adjustable feed and rotation speed. Milling at an angle from -45° to 45° by adjusting the fence. Easy and quick blade change thanks to the pneumatic quick coupler. Pjbtxbovf Nw Roq H Iepr

Condition: good (used), Year of construction: 2010, machine/vehicle number: 89336, Offer 25433 Technical specifications: - Saw blade diameter: 350 mm - 2 saw blade spindle speeds: approx. 40 + 80 rpm - Cutting range at 90°: - round: 110 mm - flat: 120 x 80 mm - Cutting range at 45°: - round: 80 mm - flat: 80 x 80 mm - Mitre adjustment: left up to 45°, right up to 45° - Manual saw blade feed Dujdpfx Abjxx Sgkjhjp - Material clamping vice - Drive: 400 V / 1.8 / 2.4 kW - Coolant system - Space requirement: approx. W 1000 x H 1500 x D 1200 mm - Weight: approx. 300 kg

Condition: good (used), Year of construction: 2009, machine/vehicle number: 87376, Offer 23330 Technical Data: Dsdpfoxx R Tiox Abheup - Semi-automatic sawing machine with hydropneumatic feed - Saw blade feed – vise - Saw blade diameter: 350 mm - 2 saw blade spindle speeds: approx. 40 + 80 rpm - Cutting capacity at 90°: round 110 mm; flat 120 x 80 mm - Cutting capacity at 45°: round 80 mm; flat 80 x 80 mm - Mitre adjustment: left up to 45°, right up to 45° - Infinitely variable saw blade feed - Pneumatic material vise - Electric foot switch - Pneumatic connection: 6 bar - Drive: 400 V / 1.4 / 1.8 kW - Coolant system - Space required: approx. W 1000 x H 1500 x D 1200 mm - Weight: approx. 300 kg

Condition: good (used), Year of construction: 1997, Under-table cross-cut saw Dodpfxjxtwk Dj Abhsup max. cutting width: 800 mm max. cutting height: approx. 150 mm saw blade: 550 mm with 2 roller conveyors, the right one with stop and measuring scale

Condition: used, Year of construction: 2006, Description Brand: H&M Type: HM-Z/4 F Year of manufacture: 2006 Feed length: 8500 mm Industrial PC. Saw blade diameter: 700 mm Angle adjustment: 0-180º Tilting angle: 0-45º Dujdpfx Aowzkyqebhjp Z-axis adjustment: 200 mm Maximum cutting height: 250 mm Discharge system with pushers

Condition: excellent (used), Year of construction: 1989, RANDEK SP700 cut saw manufacture Randek Sweden Year 1989 SN 1989-02-08 in good condition, cleaned and checked Dedoivaryjpfx Abhsup Randek’s SP700 series provides reliable cut saws that are a major asset to roof truss and house producers around the world. The SP700 cut saw is effective, easy-to-use and accurate. It has been on the market for a long time and is continuously improved in close contact with our many customers. The blade on this semi-automatic saw supports angled cuts, which mean it can make any cuts you may require. You can also use the large diameter blade (700mm ) to cut several sections of stacked timber simultaneously. • Angled cuts from 0° to 360° • Cut heights up to 250 mm, possible to cut three boards each cutting cycle • PLC programmable saw • Fixation of timber near the cutting area resulting in accurate cutting roller conveyor system with 5 adjustable pneumatic stoppers . Length 6,25m out feeding roller conveyor 4,10m Complete line: 11,5m technical information under subject of correction

Condition: good (used), Year of construction: 1990, RANDEK SP700 cut saw manufacture Randek Sweden Year 1990 in good condition Randek’s SP700 series provides reliable cut saws that are a major asset to roof truss and house producers around the world. Dujdeh Ayyqjpfx Abhop The SP700 cut saw is effective, easy-to-use and accurate. It has been on the market for a long time and is continuously improved in close contact with our many customers. The blade on this semi-automatic saw supports angled cuts, which mean it can make any cuts you may require. You can also use the large diameter blade (700mm ) to cut several sections of stacked timber simultaneously. • Angled cuts from 0° to 360° • Cut heights up to 250 mm, possible to cut three boards each cutting cycle • PLC programmable saw • Fixation of timber near the cutting area resulting in accurate cutting roller conveyor system with 5 adjusteable pneumatic stoppers . Lenght 6,25m outfeeding roller conveyor 4,10m Complete line: 11,5m technical inforamtion under subjet of correction

Condition: used, STROMAB TR 500 – Under-Table Crosscut Saw with Pneumatic Feed For sale is a STROMAB TR 500 under-table crosscut saw equipped with a pneumatic saw blade feed and a 500 mm blade diameter. This machine is ideal for precise and efficient crosscutting of workpieces in workshop environments. Year of manufacture: 2009 Machine no.: 3229 — Technical specifications • Max. cutting width: 360 mm • Cutting height: 135 mm • Saw blade diameter: 500 mm • Infeed roller conveyor length: 1,000 mm • Outfeed roller conveyor length: 1,000 mm • Table height: 850 mm • Main motor: 7.5 kW • Saw blade feed: pneumatic • Conformity marking: CE mark • Weight: approx. 420 kg — Condition & delivery The machine is in technically perfect condition and ready for immediate use. • Inspection possible at any time • Shipping securely packed on a pallet via freight forwarder possible at short notice — Contact Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg 📞 All prices are net plus 19% VAT. Subject to change and error. Dsdpfx Abjxiza Uehoup

Condition: used, - 2250 mm Cutting width - 80 mm cutting height - 2x 3,7 KW saw motors Dsdpfehkm A Nex Abhsup

Condition: reconditioned (used), - Paul crosscut saw 15 AO - hydraulic saw stroke - 150 mm cutting height - 500 mm max. cutting width Dedpfx Ajw Slgfjbheup - 1 non-driven roller conveyor approx. 1,600 mm long

Condition: reconditioned (used), functionality: fully functional, Year of manufacture 1997, connected load 380V 5.2A 2.0kW, saw blade diameter 350 mm, can be swiveled 45° on both sides, height adjustable with hand crank, cutting length 600 mm, extraction connection 100 mm, table height 890 mm, roller conveyor on the right with stop cutting length 3200 mm, roller conveyor on the left with stop cutting length 2200 mm Dedpewhn T Ujfx Abhoup

Condition: good (used), Year of construction: 1996, Offer 25115 Technical Data: - Saw blade diameter: 400 mm - Saw blade speed: 3000 rpm - Cutting height up to approx.: 125 mm - Cutting depth up to approx.: 600 mm - Bevel adjustable on 2 axes Djdpfswn D Emox Abhjup - Table size approx.: W 800 x D 800 mm - Table height: 920 mm - Drive: 400 V / 1.5 kW - Space requirement approx.: W 800 x H 1900 x D 1100 mm - Weight approx.: 200 kg

Condition: used, Year of construction: 2000, machine/vehicle number: xxxx, Order No. 22510 Technical Specifications: - Sawblade dimensions 315 x 2.5 x 32 mm - 2 sawblade spindle speeds approx. 40 + 80 rpm - Cutting range at 90°: round 95 mm - flat 110 x 70 mm - at 45°: round 90 mm - flat 85 x 70 mm - Miter adjustable left + right up to 45° - Material clamp - Drive 400 V / 0.75 / 1.3 kW - Space required approx. W 700 x H 1400 x D 700 mm - Weight approx. 200 kg Dujdpev I T Dasfx Abhjp

Year of construction: 1998, condition: good (used), machine/vehicle number: 080024-38 U, Offer 23332 Technical data: - Saw blade dimension 250 x 2 x 40 mm - Saw blade spindle speed 52 rpm - cutting range at 90° round 80 mm - flat 95 x 60 mm - miter adjustable up to 45 ° Dsdpfep Ebn Sox Abheup - Material vice - Drive 400 V / 0,5 kW - Space requirement approx. W 650 x H 1500 x D 750 mm - Weight approx. 100 kg

Condition: used, Year of construction: 1980, Maximum cutting width: 4500 mm Dusdpfx Asw E D E Uobhjp Connected load: 9.37 kW

Year of construction: 2004, condition: excellent (used), Dimter optimization crosscut saw 350 with elevation AH 1400 mm crosscut see picture crosscut saw control cabinet Scanner interface Dusdpfx Abencc Icehjp sorting 6500 mm long 3 pushers Waste flap Machine is already dismantled and immediately available Machine ran without problems until dismantling Transport can be organized

Year of construction: 2001, condition: used, Multiple crosscut saw with 4 saws Dujdpfx Ajiw El Usbhjp
