Used Drill Tap Center for sale (18,252)

Year of construction: 2026, condition: used, consisting of: 1x 20-foot sea container converted into a roll-off container, dimensions: height approx. 2.78 m, width approx. 2.45 m, length approx. 6.15 m, 1x horizontal drilling rig, manufacturer unknown, 1x mixing/pumping system, manufacturer unknown, 1x diesel generator, brand Honda, various accessories, including drilling rods, hoses, approx. 2 access ramps, warning signs and small parts, completeness cannot be guaranteed, inspection recommended after scheduling an appointment. Hedpfx Aqezha D Noqep

Condition: used, Year of construction: 2002, functionality: fully functional, spindle mount: MK 3, throat depth: 297 mm, overall weight: 680 kg, L.-No. 4.1-551 1 used Pillar Drilling Machine, Manufacturer: ALZMETALL, Model: AC 25, Year: 2002 Height-adjustable drilling head, fixed table, coolant device. Technical details: Drilling capacity steel/cast iron: 25/30 mm Spindle taper: MK 3 Feed: 35-1400 rpm Hsdpey Hik Ssfx Aqqsp Spindle stroke: 120 mm Spindle-column overhang: 297 mm Tool fitting: MK3 Machine weight: 680 kg Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 860 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 600 mm, CNC control Heidenhain iTNC530 24-fold automatic tool changer electronical handwheel chip conveyor coolant through spindle device Technische Daten / technical details: X-Weg / X-travel 860 mm Y-Weg / Y-travel 560 mm Z-Weg / Z-travel 600 mm Spindelaufnahme / spindle taper SK 40 Drehzahlbereich / spindle speed 0-10000 UpM /rpm Eilgang X,Y,Z / rapid feed X,Y,Z 24,24,20 m/min Tischaufspannfläche / table clamping area 1000x560 mm Werkzeugwechselmagazinplätze / number of tool places in changer 24 Antriebleistung Spindel 40%ED / drive capacity spindle 40%ED 18,5 kW Gewicht ca. / weight 6.500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Hodpjy Hqmhefx Aqqsp Technical data, accessories and description of the machine are not binding.

Condition: excellent (used), Year of construction: 2017, operating hours: 47,000 h, functionality: fully functional, DMG MORI DMU 60 eVo, year of manufacture 2017 5-axis universal machining center in very good condition Technical data / equipment: Manufacturer: DMG MORI Type: DMU 60 eVo Year of manufacture: 2017 Control system: Heidenhain TNC 640 User interface: ERGOline Control with 19" screen Travel ranges: X-axis: 600 mm Y-axis: 500 mm Z-axis: 500 mm Spindle: speedMASTER motor spindle Tool interface: SK 40 / BIG-PLUS Speed: 18,000 rpm Power: 35 kW at 40% duty cycle / 25 kW at 100% duty cycle Air blow-through through spindle center NC rotary table: Clamping surface: 600 x 500 mm B-axis: -5° to +110° C-axis: 360° Max. table load: 400 kg Direct measuring systems Table cooling Tool magazine: 120 tool positions Chain magazine with dual gripper Cooling / chip removal: Internal coolant supply (ICS) 40 bar / 23 l/min 600 liter tank Paper band filter Extended chip flushing Scraper conveyor Bed flushing Flushing gun Rotating viewing window Oil and emulsion mist separator Measuring and monitoring systems: Renishaw OMP60 measuring probe Tool breakage detection TRS2 3D quickSET preparation Process monitoring operating mode 4 Electronic handwheel Signal light, four-color DMG MORI Messenger DMG MORI Netservice Client Automation / preparation: Preparation for EROWA handling system M65 interface Extended M65 interface for EROWA Job Management System Operating hours according to current geometry protocol: approx. 47,589 h Hodpfx Aozhit Hsqqjp Spindle hours according to current geometry protocol: approx. 28,638 h Current geometry protocol dated 08.12.2025 available. The machine's geometry is in very good condition. All documented measured values are within the permissible tolerances. Particularly noteworthy are the very good parallelism values of 0.003 mm and 0.004 mm, as well as the very good roundness values of the vertical spindle of 0.002 mm and 0.008 mm. The squareness of the vertical spindle is also within the permissible specifications, at 0.003 mm and 0.014 mm. The machine is equipped with high-quality components and is ideal for precise 5-axis machining, tool and mold making, as well as demanding single-part and series production. Sale subject to prior sale. Technical data without guarantee. Inspection possible by arrangement.

Condition: good (used), Year of construction: 2015, operating hours: 5,381 h, functionality: fully functional, machine/vehicle number: AS0211, total height: 2,400 mm, total length: 4,500 mm, total width: 2,400 mm, overall weight: 9,000 kg, controller manufacturer: FANUC, controller model: SERIES 31 i-MODEL A, Equipment: documentation/manual, Technical specifications: - Operating voltage: 400 V - Frequency: 50–60 Hz - Rated current: 80 A - Control system: FANUC SERIES 31 i-MODEL A Travel ranges: - X1 / X2 axes: 180 mm each - Y1 axis: ±45 mm - Z1 axis: 704 mm - Z2 axis: 620 mm - E2 axis: 720 mm - Rapid traverse X/Y/Z axes: 30 m/min Spindle 1: - Max. speed: 5,000 rpm - Spindle nose: A6k - Spindle bore: 65 mm - Bore in clamping cylinder: 65 mm Hedev Uh Ndopfx Aqqop - Chuck diameter: 210 mm - Drive power: 24 kW Spindle 2: - Max. speed: 7,000 rpm - Spindle nose: Ø 110 mm - Spindle bore: 42 mm - Bore in clamping cylinder: 42 mm - Chuck diameter: 140 mm - Max. chuck jaw weight: 1.25 kg - Output power: 16.5 kW Tool carrier: - 1x 10-station tool turret - 1x 12-station tool turret - All stations driven (12 stations each) - Max. speed of driven tools: 8,000 rpm Accessories: - Chip conveyor from KNOLL - Tool holders (as shown in the photos, included)

Condition: excellent (used), Year of construction: 2019, Table size 3500 x 820 mm, Hodpfx Ajzd Eqajqqsp table load 2500 kgs, traverses XYZ 3000 x 800 x 720mm, Rapid federate 50m/min, Spindle power 35Kw, spindle speed 18,000rpm, 30 station ATC, Spindle taper CT40, Mazak Smooth Control, B axis +/- 110 degrees, C axis 0.001 degrees, Through spindle coolant, swarf conveyor.

Condition: used, Used 2-meter lathe by Cazeneuve Type: HB 500 Swinging diameter over bed: 460 mm Hsdpfozgcltex Aqqjp Turning length: 2000 mm Digital readout, 2 axes

Condition: excellent (used), Year of construction: 2007, BA 600-2 CNC, Horizontal Milling and Drilling Center SW Schwäbische Werkzeugmaschinen GmbH Travel: Hedpfozhlfrjx Aqqsp X axis: 600 mm Y axis (changeover position): 600 (975) mm Z axis: 500 mm Control: Siemens 840D control, side-mounted Feed/Rapid traverse speeds: X, Y, Z: 1 – 45,000 mm/min Max. feed force X, Y, Z: 15,000 N Average acceleration: X, Y, Z: 2.5 m/s² Measuring system: Direct measuring system X, Y, Z Spindles: Spindle speed (infinitely variable): 20–10,000 rpm Torque: 2 x 363 Nm (S6/40% duty cycle) Power: 2 x 38 kW (S6/40% duty cycle) HSK-A 100, horizontal tandem arrangement Spindle distance: 600 mm Spindle bearing diameter: 100 mm Motor spindles, liquid-cooled, AC technology Working area: Swing carrier with spur gearing, max. workpiece weight 2,000 kg Swivel time 0/180 degrees approx. 6.0 sec 2 NC rotary tables, hydraulically clamped, max. workpiece weight 700 kg, table speed 25 rpm Partition between machining and loading area Tool magazine: 2 x 50 tools HSK-A 100 chain-type magazine Tool change time (chip-to-chip): 4.48 sec Max. tool diameter: 100 mm 250 mm with adjacent slot free Max. tool length: 420 mm Max. tool weight: 20 kg Equipment: Central lubrication Oil minimum quantity lubrication (spindle lubrication) Chip conveyor (hinged belt conveyor) Coolant purification with compact band filter Hydraulic unit Maintenance unit Water recooler Full enclosure, crane loading possible Dimensions: approx. 5.15 x 8.50 x 4.20 m Weight: approx. 20,000 kg Year of manufacture: 2007 Other features: Very good condition Setup parallel to main time Available from December 2023/January 2024

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Control system: Siemens 840D-SL Tool positions: 160 Tool holder: HSK 63 Hsdpfx Aqezhlbgeqop Spindle speed: 10,000 rpm / 242 Nm Pallet size: 630 x 500 mm Number of pallets: 2 X-axis: 800 mm Y-axis: 800 mm Z-axis: 1000 mm Table load capacity: max. 1000 kg

Condition: used, Year of construction: 1988, Dalmastroj BRB-3 Conventional quick-feed radial drilling machine Condition: Used Year of manufacture: 1988 Technical data: Drilling capacity in steel: Ø 30 mm Overhang: 430 - 1000 mm Column diameter: 200 Workpiece height: 500 mm Drill spindle taper: MK 4 Speed range: 100 to 1120 rpm (8 speeds) Head swivel: 360° Hjdjzhualopfx Aqqsp Motor power: 1.4 / 1.8 kW Connection: 400 V Machine weight: approx. 2100 kg incl. accessories Equipment: - Coolant foot with pump - Thread cutting device - Drilling depth stop - Drill chuck

Condition: good (used), Year of construction: 2000, operating hours: 74,800 h, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, controller model: Mill Plus, spindle speed (max.): 18,000 rpm, operating hours of spindle: 1,234 h, coolant supply: 40 bar, Equipment: chip conveyor, IKZ (Internal Coolant Supply) NC rotary table (C-axis) NC swiveling head Tool holder: HSK 63, NEW spindle, 1023 operating hours FD function (presumably referring to a specific machine function) Pallet changer Measuring systems: Infrared probe for workpiece measurement Additional magazine with 120 positions Hsdpfx Asy Ep Rtoqqsp Spindle has already been replaced

Condition: excellent (used), FANUC 0i TC control Turning diameter 520 mm Turning lenght 1090 mm Spindle speeds -3'500 rpm Turret tool holder 12 Positions Chip conveyor Misc.accessories Hjdpfx Aqszhmydoqjp MARCELS MASCHINEN CH

Condition: excellent (used), With C-axis With driven tools FANUC 21i TB Manual Guide control Turning diameter max 355 mm Turning length -1330 mm Spindle speeds -2'800 rpm Top turret tool holders 12 driven positions Hsdpfx Aqszhmnbjqep Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), With sub-spindle With C-axis With Y-axis FANUC 18i TB Manual Guide control Turning diameter max 280 mm Hodpszhmi Sofx Aqqop Turning length -400 mm Spindle speeds -6'000 rpm each C-axis dividing 0.001 ° Spindle taper ASA A2-5 Top turret tool holders 12 driven positions Barloader Piece catcher attachement Chip conveyor Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2010, chuck diameter 210 mm max. swing diameter over bed 500 mm swing diameter over slide rest 290 mm turning diameter 200 mm centre distance 700 mm turning length 500 mm travel -y axis 80 (+/-40) mm travel -x axis 190 mm Hedszhpamopfx Aqqsp travel -z axis 525 mm spindle bearing diameter 100 mm bar capacity 65 mm spindle bore 73 mm spindle turning speed range 6000 U/min turret (x-stations) 12 work piece power 4,18 kW speeds of tool 5000 U/min VDI 30 control Siermens 840D total power requirement 20 kW weight of the machine ca. 4,3 t dimensions of the machine ca. TBH 2,2 x 4,5 x 1,82 m Very well-maintained machine from a training workshop that has closed down. Power-on hours: 14,944 h. Spindle hours: 2,233 h. Includes current measurement report (available upon request) Includes Y-axis Includes C-axis Includes approx. 10 tool holders (including 2 driven units: EWS axial/radial) Includes SMW 3-jaw chuck Includes tailstock center Includes tool probe arm Includes chip conveyor Includes parts unloading arm with conveyor belt Includes coolant system Includes documentation

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, SPM2 - 2600 - 2600 Can be inspected during operation. Training possible on request - Automatic panel infeed - Lifting table 2600 x 6000 Aggregates - SPM-FF6-23U Finger router 6 Kw max. 23170 rpm - SPM-KSK3 4-axis circular saw unit 3 kW saw blade 220mm - SPM-5F 5-axis milling unit 6.0 kW (special motor 24,000 rpm - 5-axis unit) - SPM-IJ Ink marking system - InkJet HP system Component delivery - SPM-SHP-6000 Special lifting table Panel removal 2600 x 6000 - Access guarding of discharge area Hjdju H Uqcepfx Aqqsp

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Hjdpjvvi I Rofx Aqqep

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Hodpfxjvwbp Ae Aqqjp

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Hodjvvi Htopfx Aqqep Safety: Safety tread mats Storage location: Sonnefeld

Condition: used, Year of construction: 2004, Storage location: Nattheim Hsdpfjvvi Hyjx Aqqop

Condition: used, Year of construction: 1994, Storage location: Nattheim Hodpfowmm Nrsx Aqqjp

Condition: used, Year of construction: 2000, Storage location: Nattheim Hjdovvi Ikjpfx Aqqep

Condition: used, Year of construction: 2002, Machining dimensions (tool diameter 25mm): X=3015 mm Y=1483 mm Z=325 mm Max. travels: X=3268 mm Y=1483 mm Z=325 mm Max. programming speed: X/Y = 75 m/min / Z = 30m/min Tool holder HSK 63F Drilling unit 7964, 14 vertical drilling spindles with 32 mm grid (10 in x / 4 in y) Sawing unit 7946 3.6 kW, 90° pneumatically pivotable Milling unit 7933 9 kW Wood Her Vector axis (C-axis) Tool magazine (6 disk places) Hand control unit Laser device (positioning of the suction cups) PC control panel with 17" monitor Operating system Windows 2000 Software: TwinCAM32 - office version Vacuum pump 100 m³/h Dry running Selective safety mats (3-field division) Storage location: Nattheim Hjdevvi Nbjpfx Aqqjp

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground ball screws of the highest precision class. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. Such characteristics are important for ensuring balanced movement even in more complex tasks. The movement of the various axes is controlled by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters that can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different P Hedpfsvvi Nzox Aqqsp

Condition: used, Year of construction: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTIONAL TABLE - WORK CELL VERSIONX400 CELLDrilling and milling made for you!The numerically controlled machining center is equipped with a wide range of milling/drilling tools to meet every need in the processing of wood and similar materials.- More powerful, with drilling spindles with 8,000 rpm and . Technology, the toughest spindle available on the market, with over 1,000 maintenance-free hours of use. Better and more comprehensively equipped, with various configuration options thanks to the multifunctional table to optimally equip the machine according to your needs. Easier and more understandable programming thanks to the integrated MAESTRO CNC CAD-CAM module. Easier to use: the work table is accessible at all times, the electrical cabinet and vacuum pump are integrated, and in the PRO SPACE configuration there are no guards. Supporting structure. The supporting structure consists of a particularly strong monolithic steel base, heavily ribbed and very rigid. The particularly wide support was specifically designed to give the machine stability, ensuring consistent precision regardless of the working conditions and eliminating the need to anchor the machine to the floor. The base forms a large and solid support for the mobile column: the work unit is thus equipped with a balanced, stable, and durable support that can withstand the most extreme stresses, ensuring higher quality performance and greater precision. The mobile gantry consists of a single, solid unit anchored to the base on both sides and slides on pyrotechnic guides with top-quality ball-return slides. The dual motorization along the X-axis ensures top performance even under demanding working conditions. The movement of the lower moving unit (X-axis) and the working unit along the rod of the moving unit (Y-axis) is achieved thanks to a rack/pinion transmission with helical teeth. this creates a greater tooth-to-tooth thrust which achieves greater acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures less wear on the mechanical components and less noise. The vertical Z axis is driven by a screw with ball return which ensures perfect balance with dynamic loading and strong acceleration and deceleration. The main milling unit is directly coupled to the Z axis carriage and ensures absolute quality of finishes as any vibrations are completely eliminated. Translation along the X-Y-Z axes is carried out by brushless motors driven by static inverters; These ensure: - Reduced processing times thanks to improved acceleration - Better positioning accuracy thanks to the high-resolution encoder - Zeroing of setup operations when switching on the machine thanks to absolute encoders - Zeroing of general maintenance operations since there are no brushes with the "brushless" system The management of the axis displacement and, in general, of the machine's working elements is carried out by an industrial NS module with digital D Hjdpovvi N Ijfx Aqqsp
