Used Moving Column Machining Center for sale (72,140)

Condition: good (used), Year of construction: 2016, Traverses X Y Z: 508 x 406 x 394mm, Table 660 x 381mm, Spindle taper BT30, 11.2kW Spindle Motor giving 15,000rpm, Godpj Agn I Dofx An Eoui HAAS Control, 20 Station ATC, Coolant.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: chip conveyor, documentation/manual, Modern 5-axis machining center for the complete and highly efficient production of “BLISK” (integral rotor blade assemblies) - Year of construction: 2019 - Maximum diameter of the rotor disc: Ø750 mm - Travel range X-axis: 700 mm - Travel range Y-axis: 400 mm - Travel range Z-axis: 400 mm - Swivel range A-axis: 360° (continuous rotation) - Swivel range B-axis: ±87° - Rapid traverse rate X-axis: 62 m/min - Rapid traverse rate Y-axis: 62 m/min - Rapid traverse rate Z-axis: 62 m/min - Rapid traverse rate A-axis: 200 rpm - Rapid traverse rate B-axis: 60 rpm - Maximum spindle speed: 18,000 rpm - Spindle motor power: 28 kW - Torque at 100% load: 181 Nm - Tool interface: HSK-A63 Gedpfx Anj Ah E Tvs Ejui - Tool magazine capacity: 62 positions (ATC) - Maximum tool diameter: Ø150 mm - Maximum tool length: 250 mm - Maximum tool weight: 6.5 kg - Tool change time: 8 s - Tool change system: Dual gripper - Overall length: 5000 mm - Overall width: 3260 mm - Overall height: 3200 mm - Machine weight: 12,000 kg Equipment - Coolant filtration system: KNOLL – paper filter system - Chip conveyor: KNOLL 450-K1 - Laser tool measuring system: BLUM - Measuring probe: RENISHAW - Cooling unit: STARRAG - Flushing gun - Chip container - Electronic handwheel - Operating manuals

Condition: good (used), Year of construction: 2018, Traverses X Y Z: 1,525 x 660 x 610mm, Table 1675 x 660mm, table load 2,000 kgs, Spindle speed 12,000 rpm, input 18Kw, Hurco Winmax 5Control, Spindle taper Din 40, 30 ATC, Coolant, Low volt light, Swarf Conveyor, spindle probe Gujdozh I Ebepfx An Eoi

Condition: used, Year of construction: 2016, Two-spindle CNC machining center MAG SPECHT 450 DUO for the precise and highly productive series machining of metal components. Manufacturer: MAG IAS GmbH Model: SPECHT 450 DUO Machine identification: AF210.9 Year of manufacture: 2016 Machine type: CNC double-spindle machining center Number of working spindles: 2 CNC control: Siemens SINUMERIK Travel in X-axis: 510 mm Travel in Y-axis: 600 mm Travel in Z-axis: 660 / 700 mm (depending on axis design) Spindle distance: 540 mm Max. axis speed: 70 m/min Axis drive: Ball screw drive Connection voltage: 400 V, 3~, 50 Hz Control voltage: 24 V DC Valve voltage: 24 V DC Electrical rated power: 50 kW Total rated current: 70 A Max. protective fuse: 100 A Equipment: - Siemens SINUMERIK CNC control with operating panel - Separate magazine control panel - Tool magazine - Enclosed machining area with protective doors - Lubrication and supply units - Integrated sensors and valve control - Siemens SENTRON PAC4200 energy meter - Electrical control and drive cabinets Godpfxe Akhz Tj An Esui The specified travels, spindle distance, and maximum axis speed correspond to the manufacturer's technical specifications for the MAG SPECHT 450 DUO series. The exact machine-specific configuration still needs to be confirmed. Location: Germany Inspection possible by appointment. For further information, technical documents, or questions about the machine, please contact us.

Condition: good (used), Year of construction: 2005, Ref. -No.: 10627 Manufacturer: AUERBACH Type: IA 5B 3200 RT Year of construction: 2005 Godjy Ed R Depfx An Eoui Type of control: CNC-Steuerung Control: Heidenhain 530 Storage location: Halbrstadt Country of origin: Germany X-Travel: 3200 mm Y-Travel: 2000 mm Z-Travel: 1600 mm B-Axis: 360 ° C-Axis: 360 ° Spindle Taper: SK 50 Rotary Table (Lxw): 2500 x 2000 mm Table Load: 20.000 kg Tool Piece Magazine With: 100 Pcs./pcs. Operating hours: 75.377 H Spindle hours: 28.246 H Machine length: 7300 mm Machine width: 7700 mm Machine Height: 4350 mm Weight Of The Machine Ca.: 28 t Further information: - with H / V head Machine can be viewed under power by arrangement

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, table load: 2,000 kg, overall weight: 24,000 kg, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 60, Completely overhauled by DMG in 2011. Tool holder: SK50 with tool storage for 60 tools. IKZ (internal coolant supply). Max. spindle speed: 8,000 rpm. 30 kW spindle with swiveling milling head (B-axis). Infrared measuring probe. NC rotary table with pallet changer. Gujdpfs Agaznsx An Eji

Condition: used, Year of construction: 2002, functionality: fully functional, 4-axis machine with WOODWOP 4.5, from a carpentry workshop Working dimensions: X-axis 3,200 mm Y-axis 1,250 mm Work table: 6 pcs workpiece supports, each with 3 vacuum cups 4 pcs lifting rails for heavy workpieces 1 rear and 1 front stop row Vacuum pump 100 m³/h Tool arrangement: Main spindle 7.5 kW HSK 63 F with water cooling Speed 1,500 - 18,000 rpm with C-axis / positioning axis for adapter tools Drilling unit with 18 vertical spindles 6 drilling spindles horizontally Dado saw unit fixed in the X-direction Tool changer magazine, 8 positions, mounted at the rear of the support, moving in the X-direction, for milling tools and units Control: HOMATIC 2000 with WOOD WOP 4.5 Safety equipment: ----- * Foot mat protection in front of the machine Without tools Gjdpe Afh Izjfx An Eeui

Condition: used, Year of construction: 2011, Technical details: x-travel: 660 mm Guodpfjzq S D Tex An Esi y-travel: 355 mm z-travel: 500 mm total power requirement: 19 kW weight of the machine ca.: 4,1 t

Condition: used, Year of construction: 2009, travel -x axis 1.760 mm travel -y axis 800 mm travel -z axis 850 mm control SIEMENS - 840 D Spindle speed 30 - 6.000 min -1 numbers of positions in the tool changer 52 tool taper SK50 table dimension (L x W) 1.350 x 900 mm rotary table dia. 800 mm Total clamping area 2.200 mm Milling Machine - Vertical | AXA - VHC3 - 1760 XTS 50 equipped with 52-position automatic tool changer, NC rotary table (Ø 800 mm), Chip conveyor, Coolant system with belt filter unit. Additional information: - 1 NC swivel head, continuously positionable - 1 NC rotary table, type: RTA 4L – 800 - Electronic handwheel, type: BHG, manufacturer: Siemens - 3D touch probe, type: OMP 60, with receiver, manufacturer: Renishaw Guedpfe Ai Ugdsx An Eji The machine is in a well-maintained condition and can be inspected under power at any time in the factory location. The machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VHC3-1760XTS | VHC 3 1760 XTS | VHC-3-1760-XTS | VHC3-1760 | VHC1760XTS

Condition: used, Year of construction: 2011, operating hours: 10,550 h, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, torque: 84 Nm, controller manufacturer: Heidenhain, controller model: iTNC530, workpiece weight (max.): 1,200 kg, table width: 600 mm, table length: 1,400 mm, table load: 1,200 kg, spindle speed (max.): 20,000 rpm, operating hours of spindle: 10,550 h, coolant supply: 70 bar, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Selling a well-maintained Mikron HPM 1200 HD milling machine, manufactured in 2011, with a Heidenhain iTNC530 control system. Travel distances: X: 1200mm Y: 600mm Z: 500mm Equipment: Table dimensions: 1400 x 600mm Godpfx Aozkbr Ten Esui Table load capacity: 1200kg Control system: Heidenhain iTNC530 Chip conveyor Spindle mount: HSK-A63 Spindle speed: 20000 RPM Tool changer: 60 positions Electric handwheel Tool measurement 3D measuring probe IKZ 70 bar Weight: 15 tons Accessories: 1 vise 3D measuring probe Complete documentation Machine feet The machine can be inspected and tested under power after prior appointment.

Condition: excellent (used), x-travel 16500 mm y-travel 2000 mm z-travel 1200 mm Control HEIDENHAIN TNC-640 spindle speed: 4000 U/min. rapid traverse 25 m/min tool change unit 60 coolant IKZ dividing each Kopfachse 2,5° tool taper ISO SK-50 total power requirement 68 kVA weight of the machine ca. 51 t Godpfx Anj Aiv Hns Eeui

Condition: good (used), Year of construction: 2010, Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Type: Alpha 1000 Year of construction: 2010 Type of control: CNC-Steuerung Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe - Chip conveyor - Coolant system Godpfxoy Ed Ehs An Ejui - Coolant through the spindle - Pallets with 5-way media connection and clamping hydraulics - Extraction system - Swivel spindle A-axis 0 - 90 - NC rotary table B-axis

Condition: used, Alzmetall AC 32 Turret Double-Head Drilling Machine An extremely robust and rare double-head drilling machine based on two Alzmetall AC 32 drilling head units. This machine is a high-quality industrial design intended for highly efficient series or multi-stage machining. Guedpfx Aneznic Uo Eoi Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g., centering, drilling, countersinking, threading) without the need for manual tool changes. Technical specifications & equipment (per head / total system): Manufacturer of drilling head units: Alzmetall (Germany) Model: AC 32 (Electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Tool changer: 2x pivoting turrets with multiple stations Machine table: Solid, ground cast iron table with T-slots for flexible setup Safety: Complete enclosure of the work area (protective cabin) with viewing windows for optimal chip and splash protection Additional functions: Integrated coolant system, compressed air blow-off gun, central counterweight system for easy vertical adjustment of the entire beam More items – new and used – can be found in our shop! International shipping costs available upon request!

Condition: like new (used), Year of construction: 2022, operating hours: 2,000 h, functionality: fully functional, Control: HAAS Table size: Ø 400 mm Max. table load: 227 kg X-axis: 610 mm Y-axis: 406 mm Z-axis: 406 mm B-axis: +120° to -35° Godpo Ai E E Dsfx An Ejui C-axis (Rotation): 360° Spindle taper: SK 40 / Inline direct drive Spindle speed: 10,000 rpm Drive power: 22.4 kW Tool capacity: 30+1 tools Tool holder type: SK40 Machine weight: approx. 5150 kg Dimensions (W x D x H): approx. 2950 x 3000 x 2700 mm Accessories, Equipment • Coolant system • Chip conveyor • Through-spindle coolant (TSC), 20 bar • RENISHAW OMP60 optical part-setting probe • RENISHAW TS27 tool setter • Documentation The machine is in near-mint condition and has barely been used. Under power in Hungary. Would you like me to adapt this translation into a professional sales listing format or modify any specific industry terms for an online machinery marketplace? Az AI-válaszokban előfordulhatnak hibák. További információ

Condition: good (used), Year of construction: 2002, Ref. -No.: 10633 Manufacturer: ANAYAK Type: VH Plus 2000-MG Year of construction: 2002 Type of control: CNC-Steuerung Control: Heidenhain Storage location: Halberstadt Country of origin: Germany serial number: M200XXX X-Travel: 2000 mm Guodpfo Ain Rkox An Esi Y-Travel: 1500 mm Z-Travel: 1500 mm No. Of Working Stations: 90 Control: 106.253 H machine: 93.170 H Program run: 41.859 H Head and turntable: 1600 x 1450 mm

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Gjdogb Ec Hspfx An Eeui Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Semi-Automatic, CNC Control Panel : Beckhoff CNC Movements : Z-Axis Indurstry 4.0 Compatibility : Available Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use CNC Control Panel: Benefit from very simple operation and grinding program recording with the Beckhoff control panel and Z-axis servo movement. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex SA-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex SA-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Z-Axis movement is provided by servo motor in CNC form. The part is loaded-unloaded and clamped manually. Settings are made from CNC control panel and grinding is started by pressing the start button. No other manual setting or control is made during grinding. Contact us for more details.

Condition: used, Year of construction: 2011, 2011 Kitamura Mycenter HX800iL Twin Pallet CNC Horizontal Machining Center With Fanuc Series 16i-MB Control Pallet Table Dimension 800 x 800mm (Sub Table 1,000 x 1,000mm (7 'T' Slots). Maximum Component Dimension 1,500 x 1,500mm. Maximum Table Load 1,500kg. Axis Travel 'X'=1,400mm, 'Y'=1,250mm, 'Z'=1,325mm, 'B'=360° (0.001° Increments). Rapid Traverse 'X=50m/min, 'Y'=50m/min, 'Z'=50m/min, 'B'=8°/min. Maximum Spindle Speed 8,000rpm (40kW Motor). 50 Position ATC. Spindle Taper BT50. Maximum Tool Ø125mm, Maximum Tool Weight 30kg. Power Requirement 70kVA. S/No. 48036 (2011). Sale includes2 x 1mtr. tables as pictured. Gjdpfx Ano Ad Df Ho Eeui With Through Spindle Coolant System, Dual Auger To Hakusan Chip Conveyor, Cleanmist CM 2300/3 Oil Mist Extraction Unit (With Spare Filter), Oil Chiller, Additional Sub Plate 1,000 x 1,000mm, Renishaw OMP60 Spindle Probe, Hand Wheel & Manuals.

Condition: good (used), Year of construction: 2006, Ref. -No.: 10651 Gujdpfx Ane Ahkyao Eoi Manufacturer: CHIRON Type: Mill 2000 Year of construction: 2006 Type of control: CNC Control: SIEMENS SINUMERIK 840 D - Safety Integrated Storage location: Halberstadt Country of origin: Germany Machine-No.: 498-XX X-Travel: 2000 mm Y-Travel: 500 mm Z-Travel: 640 mm Total Power Requirement: 29 kW Weight Of The Machine Ca.: 9,6 t Further information: 3-axis machining center equipped with a Siemens CNC control system and a 40-position tool magazine. The machine allows pendulum operation on two separate machining areas. Tool Interface: SK40 Working Area: X-axis: 2,000 mm (can be divided into 2 × 850 mm) Y-axis: 500 mm Z-axis: 640 mm Equipment: Screw chip conveyor with discharge to the left side Stand-alone Knoll coolant system for tool coolant supply and machine sump flushing The machine can be inspected under power.

Condition: good (used), Year of construction: 2008, operating hours: 7,360 h, functionality: fully functional, machine/vehicle number: 11790000557, travel distance X-axis: 200 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 280 mm, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 40 m/min, spindle speed (max.): 42,000 rpm, DMG SAUER ULTRASONIC 20 Linear – 5-Axis CNC Machining Centre - Year: 2008 - Serial Number: 1179 000 0557 - CNC Control: Siemens SINUMERIK 840D Powerline - Number of Axes: 5 - Linear Drive Technology - Ultrasonic-Assisted Machining Technology - Made in Germany Working range - X-Axis Travel: 200 mm - Y-Axis Travel: 200 mm - Z-Axis Travel: 280 mm Gedpfx Ae Aivw Asn Eeui - A-Axis Swivel Range: approximately −5° to +130° - C-Axis Rotation: 360° - Rotary Table Diameter: approximately 190 mm - Maximum Table Load: approximately 10 kg - Rapid Traverse X/Y/Z: up to 40 m/min Spindle and tooling - Maximum Spindle Speed: 42,000 rpm - Tool Holder: HSK-E32 - Ultrasonic Frequency: up to 30 kHz - Automatic Tool Changer: 24 positions - High-Pressure Through-Spindle Coolant - Ultrasonic and conventional HSC milling capability Equipment - Integrated A/C Swivel Rotary Table - Chillers and Cooling Units - Hydraulic Unit - Coolant Filtration System - Spindle and Linear-Drive Cooling - Manuals - Additional Machine Parts - Electrical Cabinet Cooling Electrical and dimensions - Electrical Supply: 230 V / 50–60 Hz - Approx. Main Machine Dimensions: 2,184 × 1,981 × 2,108 mm - Approx. Main Machine Weight: 3,800 kg - Approx. Total Shipment Weight with Auxiliary Units: 4,500 kg - Shipment: 7 packages Suitable applications Designed for high-precision machining of: - Ceramics - Glass and glass-ceramics - Carbide - Sapphire - Corundum - Silicon - Composite materials - Dental and medical components - Optical and precision components - Mould and tool manufacturing

Condition: good (used), Year of construction: 2008, Ref. -No.: 10641 Manufacturer: HERMLE Type: C 1200 V Guedps Ahmvusfx An Eji Year of construction: 2008 Type of control: CNC-Steuerung Control: Heidenhain TNC 430 Storage location: Halberstadt Country of origin: Germany Machine-No.: 193XXXX X-Travel: 1200 mm Y-Travel: 900 mm Z-Travel: 500 mm Tool Taper: HSK 63 Tool changer: 30 Spindle Speed: 16000 RPM Weight Of The Machine Ca.: 14 t Further information: The machine can be viewed while it is powered on, subject to prior arrangement.

Condition: excellent (used), Year of construction: 1998, Control system: Fanuc OM Travel ranges X/Y/Z: 450 x 300 x 400 mm Table size: 600 x 300 mm Spindle speed: 8,000 rpm Guedpfx Anj Ai H N Aj Eei Tool magazine for 16 tools, SK 30.

Condition: reconditioned (used), Year of construction: 2018, functionality: fully functional, CNC Vertical Machining Center DECKEL MAHO DMF 260 / 7 NEW DMG Design With Heidenhain TNC 640 control system Year of manufacture: 2018 Travel distances: X 2600, Y 700, Z 700 Spindle speed range: 20 – 20,000 rpm, continuously variable (SK 40) With the following accessories: Fixed angular table, 2920 mm x 750 mm clamping surface With integrated NC rotary table, 750 mm Controlled swivel milling head (B-axis) Gujdpfx Ae Ai Dydsn Eei Vertical tool changer with 60 magazine positions (SK 40) Electronic handwheel 3D measuring probe Renishaw 2 x BLUM Laser A3 Operating mode 4 IKZ 40 bar Chip conveyor 2 x Rotoclear (rotating viewing window) Full protection enclosure with sliding doors and interior lighting Partition Oil mist extraction Coolant system Control cabinet cooling unit RITTAL 4 adjustable machine feet Operating manuals

Condition: good (used), Year of construction: 2000, Ref. -No.: 10468 Manufacturer: DECKEL MAHO Type: DMU 80 Year of construction: 2000 Control: Heidenhain Millplus Storage location: Halberstadt Country of origin: Japan Machine-No.: 111xxxxx X-Travel: 800 mm Y-Travel: 700 mm Z-Travel: 600 mm Number of T-slots: 9 / 14 Clamping Area: Ø 900 x 630 mm T - slot spacing: 63 mm Tool Taper: SK 40 Tool changer: 30 Spindle Speed: 12.000 RPM Max. Torque: 2659 Nm Operating hours: 67.452 H Center hole: Ø 50 mm Holding torque: 4500 Nm Max. rotation of the table top: 10,7 rpm Feed: 3600 °/min. Resolution of the measuring system: 0,001 ° NC rotary table: 800 kg NC swivel rotary table: 600 kg Further information: - Clamping table 900 x 630 mm - Chip conveyor, sheet metal technology - Belt filter system, manufacturer Interlit - Type SK 200-760 - Oil mist separator - Set of tool holders, - Workbenches - 2x 6 drawers Gsdpfx Anj Ain Iwo Esui - Vise - Jaw width 125 mm - Roller shutter cabinet with 1 door The machine can be viewed under power by arrangement.

Condition: excellent (used), Year of construction: 2007, Control: Siemens 840D powerline Travel paths X/Y/Z: 630/630/630 mm 2-fold pallet changer Guedpj Ai H Iwsfx An Esi Spindle speed: 10,000 rpm Knoll coolant system with paper band filter Tool holder: SK40 Tool magazine with 80 stations

Condition: used, Year of construction: 2014, Processing length 3200 mm. Vertical machining center for drilling, milling, and grooving. Maximum flexibility and versatile applications with minimal space requirements. Modern industrial design, built with high-quality components, offering an optimal view of the machining process and perfect access to the tools. Machine frame in welded construction with ground and hardened prism guides. Ball screw spindles in the X, Y, and Z axes for precise positioning and perfectly fitting workpieces. Workpiece-friendly clamping system using vacuum cups with automatic cup positioning. Extremely short setup times. Workpiece fixing on the back allows machining of the entire circumference without additional re-clamping (up to workpiece lengths of 1300 mm). This ensures the fastest machining cycles and the highest accuracy. Program-controlled adjustment of workpiece thickness; material thicknesses from 8 to 70 mm are possible. 1 machining field with length stop. Material support. 1 roller track for supporting the workpieces downwards. 4 roller tracks for gentle support of sheet material. Height-adjustable infeed roller track for 4-sided milling. Complete finishing of the workpieces through precise milling of all 4 workpiece edges. Extraction: Machining head extraction with extraction nozzle Ø 120 mm and extraction nozzle in front of the drilling head Ø 140 mm, both leading upwards. Underfloor extraction with extraction nozzle Ø 120 mm; connection at the bottom on the left side or from the top of the machine. Safety guard according to CE standard. Enclosing guard with viewing window and safety interlock on the door. Gusdpj Ahhmbjfx An Eei TECHNICAL DATA Workpiece size: X = 200 - 3200 mm (longer with additional support); Y = 70 - 920 mm. Material thickness: Z = 8 to 70 mm. Max. travel in X-direction without reclamping: X = 1500 mm. Z-travel: Z = 240 mm. Maximum programmable speed: Vector speed: 68 m/min; X = 25 m/min, Y = 60 m/min, Z = 20 m/min. MACHINE OPERATION / SOFTWARE CAMPUS V6 - Single Evolution. Software for CNC machines of the Evolution type with automatic generation of the division of workpieces for machining. 1 software license for the machine - secured via a license plug. Consisting of: 1. CAMPUS NC-HOPS; 2. CAMPUS aCADemy; 3. CAMPUS MT-Manager; 4. CAMPUS Workcenter; 5. CAMPUS process simulation. CAMPUS NC-HOPS: Graphical variant system with WOP and CAD/CAM features for creating part variants and macro technology. CONTROL PC control. Remote maintenance: Integrated network card for data transfer of control and program data. Data transfer takes place via a high-speed internet connection. Requirement: High-speed internet connection at the machine. The use within the warranty period for warranty cases is free of charge. 19" flat screen for easy and clear machine operation. USB port for data backup or for direct input of machining programs at the control panel. DRILLING UNIT Drilling unit 7883, 15 spindles. Drive power 1.7 kW. 9 vertical spindles, individually selectable. Arrangement in L-shape, 5 in X and 4(5) in Y direction, 32 mm pitch. Max. drilling diameter: 35 mm. Total drill length: 70 mm from the mounting end (depending on plate thickness). Spindle extension stroke: 70 mm. Rotation direction: Alternating right/left. n(max.) 1000 - 4400 min-1, continuously adjustable. Mounting: M 10 thread - 11 mm smooth shank, without tool, without chuck. 6 horizontal spindles. 2 double drilling spindles in X direction. 1 double drilling spindle in Y direction. Mounting: M 10
