Used Tooth Flank Grinding Machine for sale (86,953)

Condition: like new (used), Year of construction: 2020, operating hours: 18,000 h, functionality: fully functional, As-new Gear Grinding Machine KLINGELNBERG VIPER 500 W All-inclusive machine equipped for internal and external gearing Ijdpfx Aexx T N Togzetr Equipped with a special converter from EUR kW to US standard connection (simplified global connection) Available due to restructuring at a high-tech family-run company (no automotive production) Working Area and Capacities Max. workpiece diameter: 500 mm Max. grinding stroke: 500 mm Working area over table (min.–max.): 300 – 800 mm Distance between spindle center and table (min.–max.): 442 – 1042 mm Module (generating grinding module): 0.5 – 22 Swivel angle (min.–max.): –180° to +45° Grinding System Grinding wheel diameter (min.–max.): 221 – 350 mm Grinding worm diameter (min.–max.): 221 – 350 mm Max. grinding wheel width: 75 mm Max. grinding worm width: 150 mm Grinding spindle power: 37 kW Max. grinding wheel speed: 6000 rpm Table and Feeds Table diameter: 400 mm Table bore Ø × depth: 100 × 500 mm Max. table speed: 1000 rpm Max. axial feed: 20,000 mm/min Max. radial feed: 12,000 mm/min Max. tangential feed: 20,000 mm/min Connections and Dimensions Total connected load: 60 kVA Machine dimensions (L × W × H): 4220 × 3120 × 2526 mm Filter unit dimensions (L × W): 3490 × 2250 mm Net weight approx.: 19,300 kg Machine Configuration – VIPER 500 W Base Machine and Options VIPER 500 W base machine Preparation for internal grinding arms Internal grinding unit V5 for straight or helical internal gears Measuring system for profile, lead, and pitch of external gears Measuring system for profile, lead, and pitch of internal gears V5 Touch Trigger Phasing System Power supply with ESR voltage drop compensation 100 mm table adapter Preparation for hydraulic clamping devices Hydromechanical unit for drawbar clamping systems Grinding oil filtration system with band filter 100 Fire extinguishing system Automatic work area door Cleaning system with spray gun Crane/hoist integrated into enclosure Isolation transformer Voltage stabilizer and isolation transformer Signal light/beacon tower Software Packages Gear PRO software Software for grinding of spline shafts Software for testing of spline shafts BIAS control software for gear grinding CBN grinding wheel software ADI dressing process optimization DLC lifetime monitoring for dressing tools Flexible profile correction for grinding operations Consumables Endless filter band Assembly/disassembly aid for filter band 100 Diamond dressing rollers CVD dressing roller D200 R1 for profile grinding CVD special dressing roller for generating grinding Grinding wheels Grinding wheel D350 B60 for profile grinding Grinding wheel D350 B45 for profile grinding Profiled grinding wheel D350 B150 for generating grinding Distance rings/intermediate plates 4 intermediate plates B100 22 intermediate plates B60 30 intermediate plates B45 37 intermediate plates B30 Additional Components Grinding wheel flange without intermediate plate Set of standard probes / measuring probes Additional Options Warranty extension from 12 to 24 months Closed Loop 1.0 basic version Interface for external automation

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 1191, rotational speed (min.): 4,000 rpm, rotational speed (max.): 10,000 rpm, tool length: 210 mm, TECHNICAL DETAILS Largest workpiece diameter: 180 mm Module range: 1 - 5 Minimum number of millable teeth: 7 Milling head swivel angle: ±35° Resolution accuracy: 0.1 degrees Workpiece table load: 17 kN Tool data Infinitely variable tool speed range: 4,000 - 10,000 rpm Number of tool threads: 1 - 7 Tool diameter for generating grinding: max. 145 mm Tool diameter for form grinding: max. 175 mm Tool length: max. 210 mm Total tool travel in the V-axis: max. 200 mm Shift travel from machine center - plus (+) direction: max. 100 mm Iedpfjwmb Amox Agzjtr Shift travel from machine center - minus (-) direction: max. 100 mm MACHINE DETAILS Operating voltage: 400 V Control voltage: 24 V Frequency: 50 Hz Maximum rated current: 65 A Fuses in the supply line: 80 A Ambient temperature: +15 °C - +38 °C Relative humidity: max. 90% at 20 °C Relative humidity: max. 50% at 38 °C Operating noise: 80 dB(A) EQUIPMENT - With counterholder - No dresser - CBN wheels only

Year of construction: 1998, condition: good (used), CHEVALIER FSG 1640 AD SURFACE GRINDING MACHINE MAKE CHEVALIER, MADE IN TAIWAN MODEL FSG-1640 AD YEAR 1998 TABLE SIZE 1000 x 400 mm GRINDING WHEEL SIZE 445 mm Itedpsirfpgsfx Agzjr TRAVERSES 400 x 1000 mm MAX HEIGHT FROM TABLE TO SPINDLE CENTRE 445.0 mm TOTAL POWER REQUIRMENT 7.4 kW PLUS AUTOMATIC DOWN FEED WHEEL-MOUNTED WHEEL DRESSER SYSTEM HYDRAULIC MOVEMENT COOLANT SYSTEM 400.0 x 1000.0 mm ELECTRO MAGNETIC CHUCK MACHINE MANUALS

Condition: good (used), Year of construction: 2015, operating hours: 250 h, functionality: fully functional, For Sale: Guideway Grinding Machine (Retrofitted from Metal Planing Machine) We offer a robust guideway grinding machine, which has been professionally converted from an original metal planing machine. The main advantage lies in its relatively compact footprint in relation to the workpiece capacity. Technical Specifications: • External dimensions (LxWxH): 4,800 x 2,500 x 2,000 mm • Required floor space: 4,800 x 3,500 x 2,700 mm (+ control cabinet, coolant tank, access) • Table size: 2,000 x 800 mm • Distance between columns: 1,000 mm • Travel paths (X/Y/Z): 2,000 / 1,000 / 600 mm Upgrades & Features: • New ball screw spindles and bearings • 2 new motors + 2 overhauled motors • 3 new frequency inverters • New Siemens SINUMERIK 802C baseline CNC system • Large grinding spindle: 2,840 rpm – refurbished + new motor Itjdpfexx Uudsx Agzor • Small grinding spindle: 18,000 rpm – refurbished • Including control cabinet, coolant tank with pump, and separate, wall-mounted inverter for small spindle Inspection and trial run possible by appointment. Please contact us for more information.

Condition: as good as new (ex-display), functionality: fully functional, Table size 540 x 250 mm Max table travel 560 x 260 mm Max distance from table to spindle center 450 mm Itjdpsu Hzg Rsfx Agzer Table slide-way Double-V rail Feed of cross handwheel, per revolution 5 mm Feed of cross handwheel, pe graduation 0,02 mm Feed of vertical handwheel per revolution 1,25 mm Feed of vertical handwheel per graduation 0,01 mm Wheel speed (50 Hz) 2850 rpm Wheel speed (60 Hz) 3440 rpm Wheel size 200x31,75x20 mm Power of spindle motor 1500 W Hydraulic station motor 1500 W Working pressure 3 Mpa Max runoff 18 L/min Fuel tank capacity 80 L Coolant pump 40 W Machine's net weight 900 kg Size 1,80x1,40x1,80 m Robust and reliable construction. Zero working hours Price should remain the same till end of December.

Condition: excellent (used), Year of construction: 1988, operating hours: 1,000 h, functionality: limited functionality, machine/vehicle number: 99223, overall weight: 2,800 kg, Grinding Dia: min=0.8 to max 250 mm; Vertical stoke : 90 mm; Max. travel of the grinding head :300 mm Table size :320x600 mm; Max stroke of the table Tranversal 250 mm, Longitudinal 400 mm; Electric motor speed 80000 rpm, Pneumatic 180000 rpm. Dimensions 1585x1260x2665 mm, Weight: 2800 kg Isdexvccdspfx Agzstr

Condition: new, Year of construction: 2025, A superfine ball mill is a type of milling machine that is used to grind materials into very fine particles. This type of ball mill has some distinctive features that make it especially suitable for processing even the hardest materials with low contamination and minimal wear. It is commonly used in various industries, including pharmaceuticals, minerals, pigments, and chemicals, for producing micro powder or nanoparticles. Here are some key features and considerations for a superfine ball mill for micro powder: 1. High Grinding Efficiency: Superfine ball mills are designed to achieve high grinding efficiency by utilizing grinding media with a relatively small size, leading to a large surface area for grinding. 2. Precision Control: These mills often come with advanced control systems to regulate parameters like rotation speed, temperature, and grinding time, allowing precise control over the particle size distribution. 3. Specialized Design: The mill is typically designed with features to minimize contamination, such as using materials resistant to wear and corrosion. Some mills also have cooling systems to prevent overheating during the milling process. 4. Variety of Materials: Superfine ball mills can handle a wide range of materials, including both brittle and fibrous substances. They are often used for milling hard materials that require fine grinding, such as ceramics, minerals, or pigments. 5. Size Reduction to Micro or Nano Level: The primary goal of a superfine ball mill is to reduce particle size to the micro or even nano level. This is achieved by the intense grinding action that occurs within the mill. 6. Classifier System: Some superfine ball mills incorporate a classifier system to control the particle size distribution more precisely. This allows for the separation of fine particles from coarser ones during the milling process. 7. Batch or Continuous Operation: Depending on the specific design, these mills can operate in either batch or continuous mode, offering flexibility based on the production requirements. Itedpfxoq Nf Uws Agzsr 8. Safety Measures: Safety features may be included, such as monitoring and control systems to prevent overloading, overheating, or other potential issues during operation. When selecting a superfine ball mill for micro powder production, it's important to consider the specific requirements of your application, the characteristics of the materials you're working with, and the desired final particle size distribution. Always follow the manufacturer's guidelines for operation, maintenance, and safety to ensure optimal performance and longevity of the equipment.

Condition: new, Year of construction: 2024, functionality: fully functional, This powerful machine to meet the requirements of larger woodworking companies, ensuring exceptional sharpening results. Equipped with an electronic tooth counter and an autonomous cooling system. The ZM150 offers precise sharpening while maintainingoptimal operating conditions. With two electric motors, including a 150mm CBNdisk for sharpening and a motor reduction group for precise blade movement,this sharpener delivers outstanding performance. Power supply voltage - 380-400V Frequency - 50Hz Power - 0.20kVa Capacity - 65 teeth per min Blade width - 20 to 100 mm Tooth pitch - 6 -25mm Sharpening disc - Profiled 150mm CBN disc Weight - 115kg Iedpjxiv Ugofx Agzjtr

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: MGB1320E, center height: 180 mm, workpiece weight (max.): 100 kg, grinding length: 500 mm, grinding wheel diameter: 400 mm, total width: 14,150 mm, total length: 18,000 mm, total height: 14,750 mm, grinding diameter: 320 mm, workpiece length between centers: 350 mm, grinding wheel width: 50 mm, spindle speed (max.): 3,000 rpm, feed length X-axis: 500 mm, feed length Z-axis: 150 mm, feed rate X-axis: 10 m/min, feed rate Z-axis: 1 m/min, overall weight: 2,100 kg, workpiece spindle speed (max.): 400 rpm, Equipment: rotational speed infinitely variable, Beijing Second Machine Tool Itjdpfstr Azksx Agzsr Beijing Second Semi-automatic High Speed Cylindrical Grinding Machine MBS1320E On-line production equipment; test machine available; roundness within 0.001 beier machine tool works co ltd Online production equipment machine testing available The roundness within 0.001

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 199851086/1098, table width: 1,600 mm, overall weight: 6,700 kg, travel distance X-axis: 1,200 mm, travel distance Y-axis: 680 mm, travel distance Z-axis: 400 mm, TECHNICAL DETAILS X-axis travel: 1,200 mm Y-axis travel: 680 mm Z-axis travel: 400 mm Table width: 1,600 mm Table depth: 670 mm Magnet width: 1,200 mm Magnet depth: 600 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 5,900 x 3,000 x 2,500 mm Net weight: 6,700 kg Control: Conventional Iodpfsx Hzuvjx Agzstr Power: 11.0 kW EQUIPMENT Documentation CE marking

Condition: good (used), Year of construction: 2013, TOYODA (JTEKT) GL32M-63 CNC UNIVERSAL CYLINDRICAL GRINDER Equipped with: CBN Grinding Wheel Flagging Steady Rest Workhead Mounted Rotary Dresser Marposs P3SE System Monitoring Toyoda In Process Gaging Marposs E20N Acoustic Controller Air Gap Eliminator Workpiece Collision Control Coolant Pumps W/Magnetic Separator Pendant Control RH Workhead with Center LH Workhead with Center Work Rests Worklight Light Curtains Stacklight Extra Wheels Specifications: -Grind Center to Floor: 1,000 mm -Swing Over Table: 320 mm Iodpfx Agortrzpszetr -Distance Between Centers: 630 mm -Grinding Diameter Range: 10 - 150 mm -Floor Space (Base machine w/auxiliary equipment): 3,400 x 5,000 mm -Net Machine Mass (approx.): 10,500 kg Grinding Wheel: -Type: CBN Wheel -Wheel Size (OD): 350 mm -Maximum Wheel Width: 60 mm -Surface Speed: 120 m/s Wheelhead: -Spindle Bearing: TOYODA STAT Bearing -Slide: V and Flat -Feed System: Ballscrew -Rapid Feed (on diameter): 30 m/min -Minimum Incsrement (on diameter): 0.0001 mm Workhead: -Type: Dead Spindle -Work Speed (Max): 500 rpm -Center Taper: MT #4 Footstock: -Type: Hydraulic -Taper Compensation: Manual -Maximum Center Retraction: 60 mm -Center Taper: MT #4 Motors: -Wheel Drive Motor: 15 kW, Belt-Drive -Wheelhead Feed Servomotor: 1.3 kW Tank Capacities: -Wheel Spindle Lubrication Oil: 80 L -Hydraulic/Lubrication Oil: 20 L

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Isdpfx Agsxh Rqtjzetr Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Manufacturer: Schwabe, double grinding wheel type EK4/4 -Grinding wheel: max. Ø 400 mm / Actual Ø 360 mm -Speed: 1400 rpm -Operating voltage: 380/660 volts -Motor power: 3 kW -Dimensions: 1320/930/H1450 mm -Weight: approx. 500 kg Iedpfxelmrkhe Agzstr

Condition: excellent (used), Brand: ESTARTA Model: 312 Type: Centerless grinding machine Grinding Wheel dimensions: 508 x304,8 x 160 mm Ø min/max to grinding: 1,5 / 75 mm Regulating wheel width: 160 mm Itodpfx Ajx Iu E Degzer Regulating wheel dimensions : 304,8 x 190,5 x 160 mm Maximum length to rectify in plunge : 160 mm Maximum length to rectify in plunge : 160 mm Grinding wheel head motor power : 11 kw Machine size : 2015 x 1280 x 1440 mm Weight : 3500 kgs

Condition: used, Year of construction: 2006, grinding diameter 250 mm grinding length 1000 mm Control Kavalir K 51 peripheral speed 25 - 45 m/sec max. workpiece weight between centres 80 kg Itodox I Sigspfx Agzsr voltage 400V AC 50 Hz control voltage 24V AC/DC current -Sicherung für Zuleitung 35 A weight of the machine ca. 3,8 t

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 430290898, table width: 2,000 mm, spindle speed (max.): 3,000 rpm, travel distance X-axis: 1,500 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 550 mm, TECHNICAL DETAILS X-axis travel: 1,500 mm Y-axis travel: 900 mm Itjdpjx Hztljfx Agzjr Z-axis travel: 550 mm Table width: 2,000 mm Table depth: 900 mm Magnet width: 1,500 mm Magnet depth: 800 mm Power: 60.0 kW Max. spindle speed: 3,000 rpm MACHINE DETAILS Weight: 21,000 kg Control manufacturer: Unicon EQUIPMENT CE marking Documentation

Condition: good (used), Year of construction: 2011, LANDIS LT-2 TWIN WHEEL CNC ORBITAL CRANK GRINDER Equipped with: Landis 6400 CNC Control Siemens TOUCH HMI Arobetech Steady Rest Marposs P7 Gage System Lateral Locator Twin CBN Grinding Wheels Rotary Dresser Headstock Isdpfx Aortrxxegzstr Tailstock Rittal AC Units Specifications: Maximum Center Distance: 680 mm

Condition: used, Year of construction: 2001, tip circle diameter 1000 mm root circle diameter 50 mm max. module 18 mm min. module 1 mm Ijdpfx Agewp S Thezetr max. wheel diameter 1000 mm gear width 630 mm Profile height max. 41 mm helical angle (left/right) max. 45 ° table diameter 720 mm max. table load 1500 kg grinding wheel diam. min/max. 180 / 400 mm grinding wheel width 60 (45/30) mm grinding spindle speed 0 - 3100 U/min total connected load 30 kVa

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder Iedsb A Id Hopfx Agzotr -Motor power: 1.35 kW -Speed: 1500 rpm -Grinding discs: Ø 300 x 40 mm -Operating voltage: 380 volts

Condition: used, Year of construction: 2007, grinding range 600 x 450 mm magnetic plate size 600 x 400 mm grinding wheel size 300 x 50 x 76,2 mm total power requirement 11 kW Itedpfx Aox I Siaegzer weight of the machine ca. 2,1 t In our opinion, the machine is in good used condition and can be inspected condition and can be inspected under power by appointment. Accessories, illustrated tools and clamping devices are only included in the scope of delivery if this is noted in the additional information . Changes and errors in the technical data and information as well as prior sale reserved. subject to prior sale

Condition: good (used), Year of construction: 2011, CNC 235 BUDERUS HARD TURNING/GRINDING CENTER, 2011 Ijdpsrtryyefx Agzotr Equipped with: Main Spindle 2-I.D. Grinding Spindles 8 Position Turret Siemens 840D Control Hydraulic Chucking Rotary Dresser Chip Conveyor Gantry Loader Marposs E9066M Hydraulic System Chip Bucket Fire Suspension Sysem Chiller Specifications: Number of Main Spindles: 1 Maximum Work Part Diameter: 200 mm Maximum Part Length: 150 mm Maximum Number Machining Station: 4 Rapid Feed/Speed X/Z: 90/30 m/min

Condition: used, Year of construction: 2009, internal diameter max. 600 mm grinding depth max. 800 mm grinding length max. 600 mm control Siemens 840 D grinding diameter - internal max. 600 mm grinding diameter - cylindrical max. 800 mm workpiece length - max. 380 mm external grinding length max. 600 mm travel - x1 axis 150 mm travel - z1 axis 1100 mm travel - x2 axis 470 mm travel - z2 axis 800 mm workpiece spindle 8,5 kW turning speed range - stepless 1-795 U/min Equipment / Accessories: Workpiece spindle unit (U/B1/L adjustment): - Travel (U-axis): 300 mm - Swivel angle (B1 axis): -0,5°/+12° - Drive power of the workpiece spindle: 8.5 kW - Speed range (infinitely variable): 1-795 rpm - Set-up speed (jogging): 10 rpm - Spindle head size A 8 according to DIN 55026 - Through-hole 58.5 mm - Workpiece diameter max. 830 mm - Workpiece length (overhung clamping) max. 800 mm - Workpiece length (clamped between centers) max. 800 mm - Load capacity at spindle head max. 6100 N Internal grinding device (Z1/X1/B2): - Travel (Z1 axis): 1100 mm - Travel (X1 axis): 150 mm - Swivel angle (B2 axis): 270° - Manual longitudinal adjustment of internal grinding axis on table: 780 mm - Drive power of the internal grinding spindles (infinitely variable) Belt-driven grinding spindles: 7.5 kW - Grinding block mounting hole (diameter): 100 mm / 125 mm - Mounting length of sanding block: 220 mm - Sanding diameter: max. 600 mm Ijdpfswp S Tnsx Agzstr - Sanding depth: max. 800 mm External and surface sanding device (Z2/X2): - Travel (Z2 axis): 800 mm - Travel distance (X2 axis): 470 mm - Swivel angle (B2 axis): 270° - Drive power of the external grinding spindles: 7.5 kW - Grinding block mounting hole: Ø 140 mm - Sanding diameter: max. 800 mm - Sanding length max. 600 mm - Grinding wheel dimensions: max. Ø 450 x 50 x Ø 127 mm

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Motor power: 3 kW Itedpfxsb A If Tj Agzjr -Grinding discs: Ø 400 mm -Operating voltage: 380 volts -Weight: 200 kg

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Ijdsrtr D Iepfx Agzotr Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In.

Condition: good (used), Year of construction: 1975, Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Motor power: 1.1 kW Itsdpfsb A I T Iex Agzjr -Speed: 1745 rpm -Grinding discs: max. Ø 315 mm -Operating voltage: 380 volts -Weight: 230 kg
