Used Drilling Frame for sale (13,532)

Condition: excellent (used), functionality: fully functional, Erlo TSR 32 drill press, a geared head column drill with automatic feeds. Head speeds range from 45-1420 rpm, complete with chuck and safety guard. The machine is in good condition. Itsdez Rl E Aspfx Ap Dsn

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, input voltage: 380 V, input frequency: 50 Hz, total width: 1,000 mm, total length: 2,000 mm, total height: 2,300 mm, table length: 400 mm, overall weight: 380 kg, The ayen alomat automatic veneer layering machine, a single-unit model, is in perfect working order and features an automatic glue dispensing system. It requires no additional financial investment. Ijdjz Rzvwepfx Ap Detn

Condition: reconditioned (used), Year of construction: 2014, Working width 4000 mm Working height 2550 mm Number of cylinders 6 St. Dimensions (L/W/H) 5.000 x 1.200 x 2.900 mm loading dimensions L x W x H 5.000 x 1.200 x 2.900 mm S+S Bavaria 2000 L window frame and sash press The press was partially reconditioned at our warehouse, immediately available! Technical specifications: - Working dimensions: 4000 mm x 2550 mm (length x height) - Abutment and pressure plate depth: 100 mm - Automatic press cycle for "mortise and tenon" corner joints - hand control for manual pressing mode - 1 central pressure beam (accommodates heights up to 2550* mm) - 1 transverse pressure unit - 1 shut-off valve for the 3rd vertical cylinder - 1 shut-off valve for the upper horizontal cylinder - 3 controls for angled window processing (vertical cylinders) Itedpfxezpblkj Ap Djn - 3 attachable pivoting pressure plates for pressing angles up to 60 degrees - 2 extensions for pivoting pressure plates (for triangular/pointed windows) - Surcharge for minimum dimensions - All pressure plates and abutments faced with plastic - Control cabinet located on the inside of the left base leg - Press can be completely disassembled if required (price on request!) - Finish: RAL 7035 Light Grey and RAL 7016 Anthracite Grey (Technical specifications provided by the manufacturer – subject to change/no guarantee)

Year of construction: 2021, condition: used, Engine: 4-cylinder turbo diesel engine, engine power: 140kW (190hp), drill mast: XL series, pullback force: 150kN, undercarriage: crawler undercarriage with 450mm wide rubber tracks, drilling drive: dual-head drilling gearbox. No known damage. Documentation available. Inspection possible by arrangement. Iedpfsz R A Inox Ap Dotn

Condition: used, Year of construction: 2024, DOWEL HOLE DRILLING MACHINE GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW, complete in standard design with: - Fully automatic electronic control with pulse operation via foot valve for clamping-drilling-releasing, electric intermittent operation. - Automatic retraction of the drilling unit after reaching the set drilling depth. - Automatic extension of the drilling hole depth when drilling on the end face. This eliminates the need to adjust the drilling hole depth from flat-face to end-face drilling (+10 mm, e.g. for a dowel length of 35 mm, drilling depth on the flat face 14 mm and drilling depth on the end face 24 mm). - 1 drilling bar with 21 spindles, pitch 32 mm, motor 1.5 kW (drilling feed 0-70 mm), incl. 21 quick-change chucks (Ganner system) for easy changing of the drill bits. - Easy pivoting of the drilling unit from 0° to 90°, supported by gas cylinders. - 1 clamping support movable in the Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. Ideal stop system consisting of: - 1 stop rail 1800 mm for drilling shelves (aluminum profile 40x40 mm) with 3 stop blocks, with quick-change system, easily interchangeable from right to left stop side for drilling shelves in carcass structures in mirrored fashion, also suitable for row drilling in the 32 system. - Side stops and position settings, as well as the position of the drilling height above the support table, are adjusted by means of mechanical digital counters. - Side stops can be easily pivoted away, for the shortest possible conversion from carcass to frame and row drilling. - Clamping arms for the clamping support designed for row drilling positions up to max. 300 mm. - Ideal three-stage tool system. - 1 set of drill bits for dowels: - 5 carbide dowel drill bits, Ø 8x77 mm, right-hand - 4 carbide dowel drill bits, Ø 8x77 mm, left-hand Basic machine DOWEL HOLE DRILLING MACHINE GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW, complete in standard design with: - Fully automatic electronic control with pulse operation via foot valve for clamping-drilling-releasing, electric intermittent operation. - Automatic retraction of the drilling unit after reaching the set drilling depth. - Automatic extension of the drilling hole depth when drilling on the end face. This eliminates the need to adjust the drilling hole depth from flat-face to end-face drilling (+10 mm, e.g. for a dowel length of 35 mm, drilling depth on the flat face 14 mm and drilling depth on the end face 24 mm). - 1 drilling bar with 21 spindles, pitch 32 mm, motor 1.5 kW (drilling feed 0-70 mm), incl. 21 quick-change chucks (Ganner system) for easy changing of the drill bits. - Easy pivoting of the drilling unit from 0° to 90°, supported by gas cylinders. - 1 clamping support movable in the Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop rail 1800 mm for drilling shelves (aluminum profile 40x40 mm) with 3 stop blocks, with quick-change system, easily interchangeable from right to left stop side for drilling shelves in carcass structures in mirrored fashion, also suitable for row drilling in the 32 system. - Side stops and position settings, as well as the position of the drilling height above the support table, are adjusted by means of mechanical digital counters. - Side stops can be easily pivoted away, for the shortest possible conversion from carcass to frame and row drilling. - Clamping arms for the clamping support des Itedoxnlflopfx Ap Den

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, drilling depth: 1,600 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 2,100 mm, feed length Z-axis: 1,500 mm, overall weight: 50,000 kg, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 2,100 mm, table width: 1,900 mm, CNC Heidenhain iTNC 640 AXES OF MOVEMENT Maximum drilling depth in a single operation (V axis): mm 1,600 Table travel, horizontal movement (X axis): mm 3,000 Vertical movement (Y axis): mm 2,100 Column approach movement (milling) (Z axis): mm 1,500 Drilling slide tilting (resolution 0.001°) (A axis): +30° / -15° Table rotation (resolution 0.001°) (B axis): 360° Max axis feed rate: mm/min 10,000 DEEP HOLE DRILLING AND MILLING SPINDLE – ISO 50 Solid drilling capacity: mm 5 – 25 Maximum drilling diameter: mm 40 Adjustable spindle speed: rpm 1 – 4,500 Spindle power S1: kW 17 Spindle torque: Nm 324 Standard drilling tool holder: mm Ø 25 x 70 Maximum internal spindle pressure: bar 120 Taper type: ISO 50 DIN 69871/A Coolant system: Yes ROTARY TABLE Rotary table dimensions: mm 1,900 x 2,100 Table rotation (resolution 0.001°) (B axis): 360° Table load capacity in rotation: kg 20,000 T-slots: mm 22 OIL SYSTEM Hydraulic pump motor power: kW 4 – 7.5 Self-regulated oil pressure: bar 15 – 120 Self-regulated oil flow rate: l/min 5 – 80 Oil tank capacity: L 800 – 1,000 Cooled oil temperature: 25 – 32 °C Filtration grade: micron 16 MACHINE DIMENSIONS AND WEIGHT Width x Length x Height: mm 7,000 x 7,900 x4,700h Machine weight: kg 50,000 DRILLING CAPABILITIES WITH GUN DRILLS Isdpfxoywnr No Ap Dotn Maximum depth: mm 1,600 Maximum rotation speed: rpm 4,500 Minimum drilling diameter: mm 6 Maximum drilling diameter: mm 40 THREADING HEAD “IMSASISTEM” WORKING FEATURES Max rotation speed: rpm 4,500 Maximum threading on C40 steel: M36 Machine equipped with: • Remote electronic handwheel Heidenhain • ISO 50 tool changer magazine with 40 positions • Fume extraction system 4,000 m³/hour • Through-spindle air/oil system • M24 threads on table side • Various tools and equipment • Tool rack with assorted gun drills • User and maintenance manual and CE declaration of conformity

Condition: new, bore capacity in steel (diameter) 30 mm throat 250 mm Ijdeu Imc Hepfx Ap Detn bore stroke 130 mm spindle taper MT 3 MK table: 380 x 380 mm column diameter 98 mm turning speeds 75 - 3200 U/min feeds mm/U total power requirement 1,1 kW weight of the machine ca. 220 kg. range L-W-H 0,5 x 0,6 x 2,05 mm Gear drill Thread cutting device Left/right barrel Tilting work table. Lighting. 2 electric Speed levels. Depth stop. Gears run in oil. Packaging dimensions: 2100x400x710mm Weight 260kg

Condition: new, grinding range 3 -28 mm angle adjustable from - to horizontal 0-180 Grad angle adjustable from - to vertikal 0-45 Grad angle adjustable from - to negativ 0-52 Grad clamping range 3 - 28mm mm 0 5200 U/min connected load 230 / 250 Volt / Watt wheel diameter 100 x 50 x 20 mm weight of the machine ca. 45 Kg dimensions 0,5 x 0,4 x 0,4 m This grinder is ideal for regrinding tools such as end mills, drills, TIG welding needles and much more. comes standard with: Lathe tool accessories Drill accessories Accessories for milling 5C spring collet (4-6-8-10-12 mm) Clutch key 38-42 Grinding wheel wrench Allen key M3-M8 screwdriver Diamond grinding disc Ø 100 x 50 x 20 Grinding wheel: Ø 100 x 50 x 20 Diamond pen Itsdpfxjvn U Ado Ap Den Spring collet: 3/16" - 5/16" - 3/8" - 1/2"

Condition: new, bore capacity in steel (diameter) 40 mm throat 300 mm bore stroke 120 mm spindle taper MT 4 MK table: 500 x 460 mm column diameter 115 mm turning speeds 75- 3200 U/min feeds 0,1 - 0,18 - 0,26 mm/U total power requirement 1,5 kW weight of the machine ca. 350 kg range L-W-H 2,2 x 0,8 x 0,7 mm Column drilling machine with: Thread cutting function. Digital depth display Coolant system 2 stage motor Spindle protection Iedpevn U Awsfx Ap Detn Swivel table Pivoting drill head LED lighting Packaging dimensions: 730x760x188mm Weight 340kg

Condition: used, WFL M 35 G MILLTURN is a CNC Turning‑Milling‑Drilling Center delivering high precision, accuracy and reliability. Capacities: distance between centres 2000 mm, max turning Ø 520 mm, spindle bore 77 mm; travels Z1 1500 mm/X1 550 mm, Z2 1355 mm/X2 230 mm, Y 250(-100/+150), B 220°. Specs: main/back spindles up to 4000 rpm, 29/33 kW (551/630 Nm), driven tools 6/13 kW, milling spindle 9000 rpm 15/20 kW (165 Nm); rapid traverses Z 40 m/min X 30/10 m/min; weight ~20000 kg; size 7900×5700×3250 mm. Accessories: lamp, coolant system, paper filtration, oil mist extractor, chip conveyor, automatic load/unload, Renishaw measurement. Enables tight tolerances; suited for automotive, aerospace, medical, watchmaking and machine‑tool sectors. Isdpfx Apjz Dv Dbo Djtn

Condition: ready for operation (used), Year of construction: 1985, Available for immediate pickup at our location: Radial drilling machine TOA Type TRD 1000 F Year of manufacture 1985 Outreach 1000 mm Installation height 800 mm Taper shank MK 4 Spindle speeds 50 – 1230 rpm Drive power 4 kW Rotary table Iedpfxez I Nkve Ap Djtn Vise Weight 2 tons Price: EUR 1,750.00 plus VAT, ex works

Condition: used, Year of construction: 2011, working width: 1,300 mm, workpiece height (max.): 50 mm, working length: 3,000 mm, TECHNICAL DETAILS Working area, X-axis: 3,000 mm Working area, Y-axis: 1,300 mm Maximum workpiece thickness: 50 mm Number of working areas: 2 Number of controlled axes: 3 Drilling units Number of drilling units: 4 Drilling unit 1: Top Iodpfx Asz Ekggsp Dstn Vertical drilling spindles: 51 Horizontal drilling spindles in X-direction: 4 Drilling unit 2: Top Vertical drilling spindles: 51 Horizontal drilling spindles in X-direction: 4 Drilling unit 3: Bottom Horizontal drilling spindles in Y-direction: 42 Drilling unit 4: Bottom Horizontal drilling spindles in Y-direction: 42 Milling units Number of milling units: 2 Milling unit 1: Top Controlled axes: 3 Motor power: 6.6 kW Milling unit 2: Top Controlled axes: 3 Motor power: 6.6 kW Sawing units Number of sawing units: 2 Sawing unit 1: Top Design: Fixed unit for grooving in X-direction Maximum tool diameter: 125 mm Sawing unit 2: Top Design: Fixed unit for grooving in X-direction Maximum tool diameter: 125 mm EQUIPMENT Albatros machine programming software Collets for workpiece clamping The machine is sold and delivered in its actual and legal condition (“as is, where is”) based on photo documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 5446

Year of construction: 1991, condition: ready for operation (used), Available immediately, ex works: Drill press, Metalac Type BR 32 Year of manufacture 1991 Spindle taper MK 3 Drilling capacity: 32 mm steel, 40 mm cast iron Automatic feed Table: 600 x 470 mm Drilling stroke: 180 mm Isdpfoz Ixmajx Ap Dotn Overhang: 280 mm 2 vices Coolant system Weight: 750 kg Price: EUR 1,250.00 plus VAT, ex works.

Condition: used, Workbench Drilling Machine GUILLARDON GT 16 Cone: CM2 Spindle exit: 150 mm Rotation: from 150 to 3000 RPM Table size: 400 x 400 mm Rotation right / left Throat depth: 280 mm Spindle diameter: Ø 60 mm Column diameter: Ø 105 mm Itsdpfx Ajz I Diaop Dsn 2 speeds motor Speed variation by belt drive Non-functional electronic drive Manual Descent Maxi height mandrel/table: 450 mm Mini height mandrel/table: 150 mm Sold with the table Voltage: 380 V Width: 500 mm Depth: 900 mm Total height on the table in high position: 2100 mm Total height on the table in a low position: 1700 mm Weight: approx 350 kg

Condition: ready for operation (used), functionality: fully functional, gearing type: mechanical, fuel type: diesel, color: white, overall weight: 58,000 kg, empty load weight: 44,000 kg, first registration: 01/2001, mast type: telescopic, suspension: steel, Year of construction: 2001, operating hours: 15,000 h, machine/vehicle number: 03/2001, Equipment: cabin, onboard computer, steel tracks, trailer coupling, Itjdpfx Apozu S Rze Den

Condition: used, Year of construction: 1990, Radial Drilling Machine Z3050 x 16 I Spindle: Ø 80 mm Spindle exit: 300 mm Spindle speed: from 25 to 2000 RPM Arm travel: 1600 mm Year of construction: 1990 Column diameter: Ø 320 mm Maxi distance spindle nose/table: 1800 mm Mini distance spindle nose/table: 1200 mm Table useful dimensions: 1700 x 1000 mm Isdpfx Apjz Nxnus Djtn Tailstock CM5 Hydraulic clamping trolley + arm + column Auto advance non-functional Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2400 x 1200 x 3200 mm Weight: approx 4 T

Condition: good (used), - Drilling diameter: 5-30 mm - Drilling depth: 750~900 mm Iedpfx Ao Dcz Dsp Djtn - Modifications according to customer requirements

Condition: new, bore capacity in steel (diameter) 15 / 18 mm throat 180 mm bore stroke 80 mm turning speeds 200 - 4000 U/min 250 x 220 mm distance drilling head - clamping area max. 380 mm total power requirement 1,1 / 400 kW / Volt column diameter 65 mm tool taper MK 2 Itodsfg U Thepfx Ap Don weight of the machine ca. 0,08 t dimensions 0,4 x 0,5 x 0,9 m Precise table drill: - high accuracy and quality - Drill table adjustable via rack and swiveling around the column - Full engine protection - Star grip - 230 volt mains connection

Condition: new, bore capacity in steel (diameter) 15 / 18 mm Itjdpfx Asfg U Tiep Den throat 180 mm bore stroke 80 mm turning speeds 200 - 4000 U/min 250 x 220 mm distance drilling head - clamping area max. 380 mm total power requirement 1,1 / 400 kW / Volt column diameter 65 mm tool taper MK 2 weight of the machine ca. 0,08 t dimensions 0,4 x 0,5 x 0,9 m precise bench drill: - Large speed range - Programmable thread cutting - high accuracy and quality - Drill table adjustable via rack and swiveling around the column - Full engine protection - Star grip - 230 volt mains connection

Condition: new, bore capacity in steel 30 mm threading cutting capacity: M20 throat 260 mm bore stroke 125 mm spindle taper MK 3 feed range - spindle 0 mm/U spindle turning speed range 80 - 1440 / 180 -3200 U/min transmission ratio 2 Stufen column diameter 110 mm table surface area 500 x 365 mm total power requirement 0,8 / 1,4 kW weight of the machine ca. 0,27 t dimensions of the machine ca. 0,4 x 1,2 x 1,9 m Equipment: - Gears made of hardened and ground steel - Front speed selector lever - Gear lubrication by automatic oil pump - Integrated coolant device - Machine lamp - Rotatable and tiltable table - Automatic feed with electromagnetic clutch - Handwheel for manual fine feed - automatic tool ejector - Integrated electrical controls in the drill head - Pushbutton for EMERGENCY STOP Iedpfefg U Tnox Ap Detn - Switch for right / left rotation - Height-adjustable chip protection hood with microswitch - CE mark

Condition: new, bore capacity in steel (diameter) 60 mm bore capacity in cast iron (diameter) 70 mm threading cutting capacity: M50 throat 420 mm bore stroke 260 mm spindle taper MK 5 feed range - spindle 0,1-0,2-0,3-0,4-0,5-0,6 mm/U spindle turning speed range 64 - 1210 U/min transmission ratio 12 Stufen column diameter 220 mm table surface area 600 x 600 mm total power requirement 4 kW weight of the machine ca. 0,82 t dimensions of the machine ca. 0,7 x 1,2 x 2,7 m Equipment: - Gears made of hardened and ground steel - Front speed selector lever - Gear lubrication by automatic oil pump - Integrated coolant device - Machine lamp - Rotatable and tiltable table - Automatic feed with electromagnetic clutch - Handwheel for manual fine feed Itjdjfg U Tuopfx Ap Djn - automatic tool ejector - Integrated electrical controls in the drill head - Pushbutton for EMERGENCY STOP - Switch for right / left rotation - Height-adjustable chip protection hood with microswitch - CE mark

Condition: new, bore capacity in steel (diameter) 20 mm throat 195 mm bore stroke 80 mm boring spindle MK 2 table surface area 320 x 300 mm total power requirement 0,75 kW weight of the machine ca. 0,072 t Itedpfxjiiq S Ne Ap Djn dimensions of the machine ca. 0,7 x 0,4 x 1,1 m

Condition: new, Boring power 35 mm turning speeds max. 810 U/min core drilling diameter max. 35 mm tool taper Weldon 19,05 mm bore stroke 210 mm weight 11 kg connected load frequency 230 V engine output 1,6 kW Dimensions (LxWxH) 0,4 x 0,25 x 0,275 m Itsdpfx Apjidabvo Dsn Magnetic drill with: 2-speed motor. Coolant system. Robust mobile storage / carrying bag. MAGNET HOLDING FORCE 1800 kg

Condition: new, bore capacity in steel 30 mm threading cutting capacity: M20 throat 260 mm bore stroke 125 mm spindle taper MK 3 feed range - spindle 30 - 400 mm/U spindle turning speed range 80 - 1440 / 180 -3200 U/min transmission ratio 2 Stufen column diameter 110 mm table surface area 500 x 365 mm total power requirement 0,8 / 1,4 kW weight of the machine ca. 0,27 t dimensions of the machine ca. 0,4 x 1,2 x 1,9 m Equipment: - Gears made of hardened and ground steel - Front speed selector lever - Gear lubrication by automatic oil pump - Integrated coolant device - Machine lamp - Rotatable and tiltable table - Automatic feed with electromagnetic clutch - Handwheel for manual fine feed - automatic tool ejector - Integrated electrical controls in the drill head - Pushbutton for EMERGENCY STOP - Switch for right / left rotation - Height-adjustable chip protection hood with microswitch - CE mark Itsdpfxjpam Hrs Ap Don

Condition: new, bore capacity in steel (diameter) 40 mm throat 350 mm bore stroke 180 mm spindle taper MT 4 MK table: 560 x 560 mm column diameter 140 mm turning speeds 50 - 1450 U/min feeds 0,1 - 0,2 mm/U total power requirement 1,5 kW weight of the machine ca. 580 kg range L-W-H 2,27 x 0,7 x 1,1 mm • machine base for clamping high workpieces • Digital Depth Gauge • Gearbox swivels 180 ° • silent running through geärtete, ground oil-cooled gears Isdpfx Asupxhijp Detn • Tapping Function • electromagnetic clutch for drill feed • automatic feed • electric drive for table height adjustment
