Used Mazak Integrex 40 Atc for sale (354)

Condition: used, Year of construction: 2007, MAZAK QTN 250IIM Year 2007 MATRIX C axis, driven tools Turning length: 1000 mm Chuck: 10 inch Spindle bore: Ø 77 mm Njdpfx Abjx Hxzgj Tocn Max turning diameter: Ø 380 mm Spindle speed: 35–4000 rpm Spindle nose: A2-8 Spindle power: 26 kW 12-station turret – all driven positions Driven tools: 4500 rpm – 5.5 kW -Tailstock -Tool measuring probe -Chip conveyor Specification in PDF file below

Condition: used, Year of construction: 2000, x-travel 1.120 mm y-travel 510 mm z-travel 510 mm Control Mazatrol 640M 800 kg Ncodjyigarepfx Ab Ten surface area 1.500 x 500 mm spindle tunring speed 12.000 U/min number of tool places 24 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: good (used), Year of construction: 2006, turning length: 1,000 mm, Machine details Manufacturer/Model: Mazak Quick Turn Nexus 250M Year of manufacture: 2006 (11/2006) Control: Mazatrol 640T Nexus Turning length: 1,200 mm Max. swing diameter: 750 mm Standard machining diameter: 336 mm Max. machining diameter: 420 mm Nsdpfewfynfjx Ab Tocn Bar capacity: 102 mm Max. spindle speed: 4,000 rpm Turret: 12-station Chuck: Kitagawa 12" hydraulically actuated 3-jaw chuck Tailstock present Machine weight: approx. 7,500 kg Accessories 4 × driven tools Multiple Mazak tool holders in the turret Additional jaws and accessories available Chip conveyor, coolant tank Loaded onto truck, free of charge.

Condition: used, Year of construction: 2008, functionality: fully functional, 5-Axis Simultaneous Machining Center MAZAK Variaxis 630-5X II T with Turning Function Control: MAZATROL Matrix Year of manufacture: 2008 Travel - X: 630 mm Travel - Y: 765 mm Travel - Z: 600 mm a-axis: +30 ~ -120° c-axis: +/- 360° Max. machining diameter: 730 x 500 mm Max. working height: 500 mm Number of tool changer positions: 120 Tool holder: HSK 63T Max. spindle speed: 18,000 rpm Ncjdpfx Ajx Db D Aeb Tjn Max. rotary table speed: 1,100 rpm Rotary table diameter: 630 mm Workpiece swing diameter: 730 mm Accessories: - Chip conveyor and tank - Through-spindle coolant (IKZ) - Showa oil mist extraction system - Renishaw probe The machine is in very good condition and can be inspected under power at its current location.

Condition: used, Year of construction: 2004, MAZAK VTC 200B II, year 2004 X axis: 1120 mm Y axis: 510 mm Z axis: 510 mm Spindle: max. 12,000 rpm SK40 Ncjdpfx Abjylnxko Tsn Through-spindle coolant (IKZ) Table length: 1460 mm Table width: 510 mm Table load: 800 kg Tool changer: 30 positions Spindle power: 18.5 kW Spindle speed: 12,000 rpm Tool changer: 30 positions IKZ: Yes Number of controlled axes: 3 Chip conveyor: Yes Cooling system: Yes

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2002, operating hours: 25,769 h, machine/vehicle number: 159687, laser power: 2,500 W, travel distance X-axis: 3,335 mm, travel distance Y-axis: 1,545 mm, travel distance Z-axis: 420 mm, swivel angle A-axis (max.): 360 °, No reserve price - guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 3335 mm Travel Y-axis: 1545 mm Travel Z-axis: 420 mm A-axis: ±360 ° B-axis: ±135 ° Maximum workpiece dimensions: 3050 x 1525 x 22 mm Maximum table load: 810 kgf MACHINE DETAILS Laser power: 2500 W Laser model: YB-L250A8M NC control: Mazak & Fanuc L-64 Dimensions & Weight Ncsdjymfmbjpfx Ab Tsn Machine dimensions: 7,525 x 2,875 x 2,300 mm Chiller dimensions: 920 x 1,600 x 1,780 mm Extraction unit dimensions: 850 x 850 x 930 mm Machine weight: 14.6 t Operating hours: 25,769 h EQUIPMENT Chiller Extraction unit

Condition: excellent (used), Year of construction: 1995, Mazatrol M32 B control Ncedpfsyiu Rhsx Ab Tjn Travel X/Y/Z: 1660/510/510 mm Spindle speed: 7000 rpm Tool magazine for 24 tools, SK 40 Table size: 2000x510 mm

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Ncedpfx Abju U R E Ao Tsn

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. Ncodpfxjtuggcs Ab Ton EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: used, turning diameter 340 mm turning length 575 mm control Mazatrol SmoothEZ max. swing diameter over bed 695 mm Standard machining diameter 235 mm bar material dia. max. 65 mm x-axis 215 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 10 m/min z-axis 605 mm rapid traverse Z-axis 30 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 15 KW 11 KW Max. Torque 167 Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (40%ED) ca. 7,5 KW Power (continuous operation) 5,5 KW Max. Torque 53 Nm Milling spindle speeds ( driven tools) 20 - 4500 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 coolant tank 225 l Chuck diameter main spindle 8 '' Chuck diameter counter spindle 6 '' w-axis 585 mm rapid travel W 30 m/min c-axis 555 weight of the machine ca. 4,9 t dimensions of the machine ca. 2,8 x 2 x 1,8 m Special accessories: - Chip conveyor, hinged belt, side ejector - Production package, this package includes Preparation for bar feed Automatic parts catcher (Ø:80mm x L:120mm x 2.5 kg) 15 bar high-pressure coolant system Preparation for chip conveyor (lateral) Signal light (3-colour LED), rectangular C-axis counter spindle 0.0001° Automatic tool eye 8" power chuck Kitag. BR08 & Cyl. SR1566C (HD1) GENERAL MACHINE OPTIONS Air blowing device on the chuck (counter spindle) Transformer for the European market Linear roller guides SD MEMORY I/F(1P) + USB MEMORY I/F(1P) Ncodpfx Abowngklo Tjn 1 x USB - Memory Interface (1 slot) CE marking CE marking, metric, 50 Hz Counter spindle positioning 0.0001 degrees without C-axis Tool turret with 12 stations Y-axis control ADDITIONAL PROCESS SOFTWARE Smooth restart function / restart mode Set of manuals in electronic form on CD Main spindle motor AC 15 kW (20 hp) 2nd spindle motor AC 7.5kW (20 hp) Main spindle motor AC 7.5kW MAIN SPINDLE C-axis main spindle Input accuracy (contour/index) 0.0001° Mazak standard colour (F white(fine)/S black) Automatic switch-off via circuit breaker trip Double foot switch Hydraulic pressure interlock RFID door interlock Safety foot switch with locking mechanism Safety measures according to worldwide standard Work area lighting Complete coolant system Automatic opening/closing of chuck jaws (main and counter spindle) Feedback of the chuck status (main and counter spindle) Feedback of the chuck status via sensors. 8" power chuck 6" power chuck (counter spindle) Absolute positioning system Synchronous tapping with milling spindle Relocation Detector NC control Mazatrol SmoothEz 15" colour Lcd (touch screen) User macro (common variables: 600 pairs) EIA/ISO package EIA/ISO - input function EIA/ISO - additional functions Bolt line interpolation 3D tool compensation Workpiece coordinate rotation Geometric function Scaling External data input/output Tapping function (G33) Reverse feed rate G93 G37 Tool length measurement Polar coordinate input (EIA) Optional stop Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak tapping/drilling cycle EIA/ISO - input function Scaling External data input/output Thr...

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min spindle nose A2-8'' spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5,0 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Njdpfx Absv Dxw Rs Tocn Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm 2 pcs. horizontal machining centers (HCN 6000-II + HCN 6000, 2005), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, Ncedpfxswix Hhe Ab Ten *

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm Ncsdpfx Abewix E Re Ton 2 pcs. horizontal machining centers (HCN 6000 + HCN 6000-II, 2008), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, *

Condition: used, Year of construction: 2000, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, workpiece weight (max.): 1,200 kg, total height: 2,900 mm, total length: 2,995 mm, total width: 2,350 mm, overall weight: 6,700 kg, table length: 550 mm, table width: 1,200 mm, coolant supply: 15 bar, rotational speed (max.): 12,000 rpm, rotational speed (min.): 35 rpm, table load: 1,200 kg, CNC Vertical Traveling Column Machining Centre CNC Control Mazatrol 640 M Table size 1200 x 550 mm Table load 1200 kg Number of pallets: 1 x Movement X-axis 1020 mm Movement Y-axis 510 mm Movement Z-axis 460 mm Ncedjygw D Eopfx Ab Ten Spindle taper MAS BT 40 Spindle speed 35 - 12.000 1/min Spindle motor 22/15 kW Magazin capacity 30 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, table load: 1,200 kg, rotational speed (max.): 8,000 rpm, TECHNICAL DETAILS X-axis: 1,660 mm Y-axis: 760 mm Z-axis: 660 mm Table size: 760 x 2,000 mm Max. table load: 1,200 kg Tool holder: SK 40 Tool changer: 2 x 24 Max. tool diameter: 80 mm Max. tool diameter with adjacent pocket free: 110 mm Max. tool length: 350 mm Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min MACHINE DETAILS Nsdpfxeymw Nho Ab Tscn Control: MAZATROL M-PLUS Dimensions & Weight Required space: approx. 6.0 x 4.0 x 3.5 m Machine weight: approx. 8.1 t Total power requirement: 32.8 kVA The machine has been serviced regularly.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Main spindle 10” 4000 rpm Turret 12 stations Live tool speed 4500 rpm Ncedpsylxbiefx Ab Tsn Spindle bore 91 mm X-axis: 215 mm Z-axis: 605 mm Machine dimensions: 2700 x 1690 x 1725 mm Weight: 4600 kg Without chip conveyor

Condition: excellent (used), Year of construction: 2025, functionality: fully functional, Options: Chip conveyor, Z travel 1000 mm, 16-position powered turret, productivity package, bar feeder interface, robot interface, memory extension, overload detection, high-pressure coolant, 3-color signal lamp, tooling Ncodpfx Aoymlkasb Ton

Condition: reconditioned (used), Year of construction: 2007, MAZAK QUICK TURN NEXUS 200-II MSY Max. turning diameter: 380 mm Max. machining length: 511 mm Max. milling speed: 4,500 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Machine is equipped with: - CNC control Mazatrol Matrix - KITAGAWA three-jaw chuck for main spindle, diameter 210 mm Ncsdpfx Absyhwy Io Ten - KITAGAWA three-jaw chuck for secondary spindle, diameter 169 mm - Tool Eye - C-axis - C-axis on sub-spindle - Y-axis - Interface for bar loader magazine - Automatic parts catcher - Reinforced coolant pump - Chip conveyor - 8 stationary tool holders - 2 driven tool holders

Condition: used, YOM 2004 Ncjdpfx Abev Ax Uye Tsn Mazatrol PC Fusion 640 M Axis X 1660 mm Axis Y 510 mm Axis Z 510 mm Table length 2000 mm Table width 510 mm Max. part weight 1000 kg Number of tool pockets 30 Spindle taper CAT 40 Max. spindle speed 10000 rpm Spindle motor power 18.5 kW

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 900 mm, travel distance Y-axis: 430 mm, controller manufacturer: MAZATROL, controller model: Smart, spindle speed (max.): 12,000 rpm, spindle motor power: 18,500 W, number of axes: 3, This 3s Mazak VCS 430A vertical machining centre was manufactured in 2011. It features a powerful 18.5 kW spindle with a speed of 12,000 rpm and a table size of 900 x 430 mm. The machine offers rapid traverse of 42 m/min and includes a high-pressure coolant system, synchronized tapping, and tool length measurement. If you are looking to get high-quality machining capabilities, consider the Mazak VCS 430A machine we have for sale. Contact us for further details. • Operating hours: 33,000 • Spindle hours: 22,000 • Rapid traverse: 42 m/min • Installed options/software: • High-pressure coolant (through-spindle), 15 bar • Synchronized tapping • Tool length measurement • Workpiece air blast • Hand-held coolant nozzle • Automatic peck drilling cycle with load detection • G00 slope constant function • High surface smoothing on contours (High Smoothing Control) • Mazatrol-to-ISO program conversion • Program memory expansion • Preparation for workpiece probe (OMP60) • Preparation for chip conveyor (left side) • MAZACC-3D high-speed software package • CNC functions and connectivity: Nedoyhcviopfx Ab Tecn • NC user macros • Mazak drilling/tapping cycles (Mazatrol & EIA) • EIA/ISO code input • Constant tool tip speed function • Programmable block stop (M01) • Background tool path verification (MAZACC-2D) • Up to 300 workpiece coordinate systems • Thread cutting functions • EIA canned cycles (chamfering, arc machining) • USB interface (2 ports) • LAN port Additional equipment • Chip conveyor, left-hand, hinge type (Mayfran) • 4th-axis simultaneous kit: Kitagawa NC rotary table (MR200) Technical Specification Taper Size ISO 40

Condition: good (used), Mazak Integrex E-410H Multi-Tasking Lathe Mazatrol 640M Pro Control, 610mm Turning Dia Serial No. 164385 (2003) Ncedpfsvgzuwsx Ab Ton

Condition: used, Year of construction: 2007, Main data - X travel (table longitudinal travel): 1050 mm - Y travel (table transverse travel): 530 mm - Z travel (spindle vertical travel): 510 mm Njdpfx Aboygipgs Tscn Spindle - Spindle motor: AC 18.5 kW (5 min rating) - Rapid traverse X / Y / Z: 36 / 36 / 36 m/min - Tool magazine: 30 stations - Spindle taper: ISO 40 - Spindle bearings: Ø 70 / 110 mm - Speed range: 12,000 rpm - Number of speed ranges: Direct drive - Max torque: 95.5 Nm X-axis - X travel (table longitudinal travel): 1050 mm - Guides: Linear ball guides Y-axis - Y travel (table transverse travel): 530 mm - Rapid feed: 36 m/min - Working feed rate: 1 – 36,000 mm/min - Guides: Linear ball guides Z-axis - Z travel (spindle vertical travel): 510 mm - Spindle nose to table top distance: 150 – 660 mm - Distance from column to spindle center: 576 mm

Condition: used, Year of construction: 2011, MACHINE SPECIFICATION MAZAK VARIAXIS 500-5X II Robot is not included. - X travel (spindle longitudinal travel): 510 mm - Y travel (table transverse travel): 510 mm - Z travel (spindle vertical travel): 460 mm - A-axis (table tilt): -120° to +30° - C-axis (table rotation): ±360° Spindle: - Spindle motor AC: 22.0 kW / 15 min rating - Rapid traverse X, Y, Z: 52 m/min - Tool magazine: 40 stations - Spindle taper: ISO 40 - Spindle motor AC: 22.0 kW / 15 min - Spindle bearing bore / outer diameter: Ø 80 / 110 mm - Speed range: 35 – 12,000 rpm - Max torque: 143 Nm @ 15% ED Axes details: X-axis (spindle longitudinal travel) - Travel: 510 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min Ncodpoygimlofx Ab Ton - Guides: Linear ball guides Y-axis (table transverse travel) - Travel: 510 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min - Guides: Linear ball guides Z-axis (spindle vertical travel) - Travel: 460 mm - Spindle nose to table top distance: 190 – 650 mm - Spindle nose to table center distance: 140 – 600 mm - Rapid feed rate: 52 m/min - Working feed rate: 1 – 52,000 mm/min A-axis (table tilt) - Range: -120° to +30° - Minimum positioning increment: 0.0001° - Locking torque: 2,156 Nm - Positioning time for 90°: 1.9 s C-axis (table rotation) - Range: ±360° - Minimum positioning increment: 0.0001° - Locking torque: 2,156 Nm - Positioning time for 90°: 1.5 s Accuracy: - Positioning accuracy X, Y, Z: 0.012 mm - Positioning accuracy A, C: 21 / 14 arc sec - Repeatability X, Y, Z: 0.007 mm - Repeatability A, C: 12 / 8 arc sec Tool changer: - Type: Chain with double arm - Number of tool positions: 40 stations - Tool selection: shortest path search - Max tool diameter: Ø 80 mm - Max tool diameter when adjacent pocket is empty: Ø 125 mm - Max tool weight: 8 kg - Max tool length: 300 mm - Tool taper: CAT 40 - Pull stud: ANSI 40 type Mazak - Tool change time (chip-to-chip): approx. 4.5 s Table: - Table size: Ø 500 mm x 400 mm - Max uniformly distributed load: 300 kg - Table equipped with T-slots: 5 slots, 80 mm pitch - Center hole: Ø 50 H6 - Table height above floor: approx. 800 mm Coolant: - Through-spindle coolant: 15 bar - Tank capacity: approx. 250 L - Coolant filtration: filter - Flush nozzle: at spindle nose Miscellaneous: - Floor space (standard machine): approx. 2805 x 2950 mm - Machine height (standard): approx. 2838 mm - Weight: approx. 7,500 kg - Total fuse / power supply requirement: 50 kVA Included / options and features: - 40 tool stations - Tool identification system including pull stud with ID chip - Tool length measurement - Through-spindle coolant 15 bar + Through-Air - Spindle cooling - Machine lighting - Cooling through the ball screws on X, Y, and Z axes - HSM function for 2-D machining - Mazak “Tornado” for threading and milling - Synchronized feed/speed during threading - ISO/EIA programming - CE marking in accordance with European regulations VARIAXIS500II – Quantity: 1 unit MAZAK VARIAXIS 500-II 5X Vertical 5-axis multi-operation machine equipped with Mazatrol Matrix control system for simultaneous (ISO‑programmed) 4- and 5‑axis machining. Options / items listed: - MAZ85330 – 1 pcs – Through-spindle coolant, 15 bar - MAZ80551 – 1 pcs – Chip conveyor to side - MAZ71190X – 1 pcs – High-speed function type 1, only for ISO/EIA - High-speed function MAZACC-3D G05 P2 - Smooth transitions G61.1 - Contour compensation via parameter settings

Condition: used, Year of construction: 2008, MAZAK QTN 200IIM, year 2008 C-axis, driven tools Maximum turning diameter: 380 mm Nedpfx Abeyi U Ruj Tecn Maximum turning length: 541 mm Maximum bar diameter: 65 mm X-axis travel: 230 mm Z-axis travel: 575 mm KITAGAWA BB208 hydraulic chuck Probe 12-position turret Programmable tailstock Chip conveyor Documentation Machine in very good condition, low operating hours

Condition: used, Year of construction: 1996, x-travel 1500 mm y-travel 650 mm z-travel 650 mm size of pallet 1740 x 650 mm spindle taper SK 50 spindle turning speed range 25 - 6000 U/min feeds longditudinal/cross/vertical max. 8 mm/min Ncedpfjyg N Shjx Ab Tjn rapid traverse longitudinal and cross 26 m/min rapid traverse vertical 20 m/min spindle throat 665 mm distance spindle nose and table 200 / 850 mm drilling in full material 50 mmø threading M 45 ATC 60 Pos tool diameter 125 mm wotkpiece diameter with 2 vacant positions 260 mm workpiece length 400 mm weight of tools max. 20 kg spindle drive 18,5 kW control MAZATROL M PLUS Accessories: chip conveyor, coolant
