gebr. Hobbing machine Fabr. PFAUTER, P630 type year of construction 1975 TECHNICAL DATA Table diameter 550 mm maximum wheel diameter 630 mm Max wheel width 425 mm maximum module 10 table bore 125 mm maximum milling length 215 mm min. number of teeth 8 Max workpiece length 825 mm Total power 20 kW Machine weight approx. 8 t Balbfvyymh more
5
max. wheel diameter 500 mm gear width - mm max. module 10 min. module - Control Liebherr CNC total power requirement - kW 39sxzmhoy weight of the machine ca. 8,5 t dimensions of the machine ca. - m more
6
x-travel: 300 mm y-travel: 50 mm z-travel: 300/430 mm max. wheel diameter: 500 mm Dvq0dm module max. : 8 work piece dimensiones: Länge=500 U/min workpiece dia.: 400 mm feed: keine Angabe mm/min tool taper: Ø=28 diameter of tools max.: 160 mm tool length - max.: 250 mm milling head -swivable +/-: 30 ° table-size: Dm=470 mm total power requirement: 9,2 kW weight of the machine ca.: ca. 5,8 t dimensions L x W x H: 2,7x1,35x2,0 m dimension coolant device LxWxH: 1,1x0,28x0,45 m table has a hole in t... more
6
Wheel diameter - 630 mm Wheel width 400 mm -Up to 8 module - up to 10 x axis 450 mm Zaxis 280 mm Table diameter 580 mm minimum number of teeth can be milled 10 Helix angle - 45 ° Milling cutter diameter 200 mm Cutter length of 250 mm 2lk0lrkqx Milling cutter speeds - variable 45-400 rpm KW total power requirement 48,50 Machine weight approx. 9.20 t E9bfwrgco Space requirement approx. 4.20 x 2.40 x 2,50 m more
5
HORIZONTAL - ZAHNRADABWAeLZFRAeSMASCHINE PFAUTER RS 1 - 20-13-008 Shipping time: immediately ID: 20-13-008 Manufacturer: Pfauter Type: RS 1 MACHINE DATA Construction year: CA 1917 L x W x h: approx. 1400 x 1200 x 1800 mm E7g3cqto0 Weight: 800 kg Very good condition TECHNICAL DATA Maximum workpiece diameter: approx. Ø 500 mm Max wheel width: approx. 200 mm Min. module: approx. 0.5 Max engine: about 4 Table hole: dia. 60 mm Table - diameter: approx. Ø 420 mm ... more
6
max. wheel diameter 600 mm gear width 280 mm max. module 5 axis height 20 / 390 mm rotary table diameter 420 mm 3uqfooxja table hole 80 mm taper MK 4 hob turning speeds 53 - 200 U/min number of feeds 10 total power requirement kW weight of the machine ca. 2,60 t dimensions of the machine ca. 2,20 x 1,50 x 2,00 m more
6
Year of manufacture 1997 Control system Siemens 840 C Assembly dimensions LxWxH (mm) ca. 8.000 x 4.330 x 3.300 Weight (kg) ca. 12.000 In general: Max. wheel diameter 500 mm Gear width 210 mm Max. module 12 X-axis 325 mm Y-axis 300 mm Z-axis 400 mm Table diameter 400 mm Table hole 125 mm Table turning speeds 1-44 U/min Spindle turning speed 40-380 U/min Swivel angle spindle +25 / -45 ° Feed 0,001 - 3 m/min Rapid traverse 3 m/min Equipment / Accessories Chip conveyor Coolant ... more
4
HORIZONTAL - ZAHNRADABWAeLZFRAeSMASCHINE WMW ZFWZ 500 X 5 - 20-13-006 Shipping time: immediately ID: 20-13-006 Manufacturer: WMW Type: ZFWZ 500 x 5 MACHINE DATA Year: circa 1970 L x W x h: approx. 2500 x 1900 x 1900 mm Weight: 1500 kg Good general condition TECHNICAL DATA Maximum workpiece diameter: approx. Ø 500 mm Max wheel width: approx. 180 mm Min. module: approx. 0.5 Max engine: approx. 5 Table hole: MK 5 Cutters - workpiece distance: 10-200 mm Tdf3cnaz... more
5
Diameter of workpiece table table 550 mm The table hole diameter 125 mm Diameter of workpiece a thorn 36 mm Largest hob diameter length 192 mm 230 mm Measure the shell end mill adapters 22 through 27, 32, 40, 50 mm, Distance between cutter and workpiece Minimum distance 50 mm Greatest distance 425 mm Taper Morse 5 for shell end mill adapters Largest cutter displacement 200 mm Speeds and feeds Cnlqovmao Cutter rotation payer RPM 45 to 280 axial feed mm/WU 0.40 to 6.30 Radial feed... more
5
Clamping surface - table diameter 600 mm The machine works and is under power. More info on request Mass – approx. 250 x 150 x 180 cm, Btto 3T Izdxae9 more


Gearwheel ...
every day

New machines via email!

Be informed!
6
MODUL ZFWZ 500 x 8 gear hobbing machine Baecp8hdjb Main technical detail of the machine are: max. wheel diameter 500 mm max. module 8 mm table size 470 mm milling head – swivable- 30 ° total power requirement 9,2 kw machine weight 5500 kg Good & functional machine. With change gears - as per attached pictures. Location: our warehouse near Oradea/Romania. Ready for delivery. more
6
gear hobbing machine Du7ea3 Manufacturer: Staehely Wuppertal Germany Type. SH 500 Nr.10591 / 60 Year: 1960 Max. Wheel diameter: 500 mm Max. Module: 6 mm Max. Gear width: 300 mm Table diameter: 430 mm Weight: about 4.2 to Equipment: various accessories and change wheels, + holding book Good used condition without any warranty, up to January 2016 even been in work deployment. more
5
Machine data name: gear hobbing machine-vertical Type: ZFWZ 500 x 5 Year of construction: 1963 3fkd7kjgd Serial number: 3663/63 Manufacturer: Module Electrical connection voltage [V]: 380/220 Total power [kW]: approx. 3.5 Parameters of machining table size [mm]: 460 Table bore [mm]: 70 Wheel diameter [mm]: 500 Wheel width [mm]: 175 Module (max.) [-]: 5 Machine parameters cutter diameter [mm]: 100 Cutter length [mm]: 115 Number of teeth [-]: 12 Milling cutter speed range ... more
6
max. wheel diameter 500 mm max. module 8 milling cutter dia. x width 160 / 160 mm table diameter 400 mm distance table / counter stay 688 mm milling spindle speeds (infinitely variable) 80-400 U/min axial-feeds 0,4-7,5 mm/U radial feeds 0,1-1,9 mm/U electrics - voltage/frequency 380 / 50 V/Hz total power requirement 20 kW 3hy7pw0sq weight of the machine ca. 6,2 t more
6
Gear Hobber FD 630 Cugir C2p2m90q Table diam: 630mm Max. diameter 630mm Modul 10 Weight : 10.500 kg more
4
Gear hobbing TOS FO 6 Made in: Czech Rep. Maximum wheel diameter: 600 mm Maximum module: 6 9hbqd93d2 Table size: 420 mm diameter Maximum tooth width: 200 mm Spindle speeds: 15-190 rpm Maximum material diameter: 600 mm Super condition With change gears With some gear cutters and accessories. more
