Used Drill Bit Sharpening Jig for sale (6,071)

Condition: used, Technical details: bore capacity in steel (diameter): 13 mm throat: 160 mm bore stroke: 60 mm spindle taper MT: MK2 Ijdpfx Aovgbdxjp Deih spindle speed:: 210 - 2580 / 16 step U/min feed: manual mm/U table clamping surface:: 200 x 185 (fest) mm Distance spindle/table max.: 620 mm table clamping surface:: 260 x 265 (verstellbar) Distance spindle/table max.: 160 - 460 mm table rotating: ja ° drill table adjustment: 300 (Handkurbel) mm column diameter: Ø ca. 70 mm total power requirement: 900 Watt weight of the machine ca.: 90 kg dimension machine xH: 0,6 x 0,31 x 1,7 m The machine is equipped with a RÖHM 1-13 drill chuck incl. drill chuck key. Spindle run right. Small vice included *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm throat: 320 mm bore stroke: 250 mm spindle taper MT: MK 4 spindle speed:: 63 - 710 / 8step U/min feed: 0,07; 0,13; 0,254; 0,42 mm/U Distance spindle/table max.: 600 mm table clamping surface:: Ø 450 mm table rotating: 360 ° clamping table - swivable: ja Grad drill table adjustment: 600 mm column diameter: 215 mm total power requirement: 2,2 kW weight of the machine ca.: 730 kg dimension machine xH: 1,0 x 0,58 x 1,4 m Equipment: Quick-action drill chuck RÖHM Supra 16mm Iodpfxjwcygcs Ap Deih Coolant tank with pump Socket for 220V *

Condition: as good as new (ex-display), Year of construction: 2013, machine/vehicle number: I1305008, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, spindle mount: MK 3, drilling depth: 130 mm, height adjustment type: mechanical, throat depth: 250 mm, overall weight: 320 kg, drilling capacity: 25 mm, column diameter: 110 mm, spindle speed (max.): 2,880 rpm, spindle speed (min.): 125 rpm, Dear Sir or Madam, We are offering a demonstration pillar drill "HXMC model Z5025" with paint damage. We are happy to answer any questions. This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Iijdpfev T Anrsx Ap Deh Please check the information in the PDF. No returns accepted.

Condition: as good as new (ex-display), Year of construction: 2013, machine/vehicle number: F130507, functionality: fully functional, input voltage: 400 V, spindle mount: MK 3, drilling depth: 135 mm, height adjustment type: mechanical, total width: 510 mm, total length: 870 mm, total height: 2,050 mm, throat depth: 320 mm, table width: 450 mm, table length: 500 mm, drilling capacity: 30 mm, column diameter: 120 mm, spindle speed (max.): 2,600 rpm, spindle speed (min.): 65 rpm, Dear Sir or Madam, We are offering a demonstration pillar drill "HXMC model Z5030A" with paint damage. We are happy to answer any questions. This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Please check the information in the PDF. No returns accepted. Iisdpfx Aov T Atnjp Deh

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1250 Iisdpswid Ausfx Ap Djh workpiece height max.: - mm distance column till spindle centre: 1250 mm drill head horizontal traverse: 980 mm vertical adjustment of arm: 800 mm distance table - lower edge spindle: 2,05 x 9,2 x 2,85 mm spindle taper MT: MK4 bore spindle stroke: 280 mm range of revolutions per minute - continous: 28-1.195 3 Steps U/min swivel range of the arm: 90 Grad feed: 0,1/0,2/0,3/0,4/0,8/1,2 6 Steps mm/U column diameter: 300 mm base plate surface area: 1.370 x 750 mm weight of the machine ca.: - t dimension machine xH: 2,05 x 9,2 x 2,85 m Cooling water system with feed Table with clamping surface 1,370mm x 750mm incl. drilling cube *

Condition: used, Technical details: bore capacity in steel (diameter): 40 mm throat: 360 mm Ijdpfxswid Uwe Ap Doih bore stroke: 280 mm spindle taper MT: MK 5 spindle speed:: 32 - 1400 U/min feed: 0,11-1,73 mm/U connected load: 6 kW Distance spindle/table max.: 750 mm table clamping surface:: 780+650 mm drill table adjustment: verical 800 mm column diameter: Größe: 230 x 950 mm dimension machine xH: 1,1 x 0,8 x 2,8 m weight of the machine ca.: 1,5 kg for thread cutting clockwise and counter clockwise operation *

Condition: used, Technical details: bore capacity in steel (diameter): 30 mm throat: 260 mm bore stroke: 160 mm spindle taper MT: MK3 feed steps: 0,1; 0,2; 0,3 mm/U und manuell spindle speed:: max. 1800 stufenlos U/min Distance spindle/table max.: 750 mm table clamping surface:: L: 280 x B: 355 mm table rotating: nein ° clamping table - swivable: 360 Grad Iiedpjva Higjfx Ap Djh drill table adjustment: vertikal: 600 mm column diameter: 130 mm threading: Nein / no total power requirement: 1,1 kW weight of the machine ca.: 570 kg dimension machine xH: 0,9 x 0,9 x 1,9 m This machine has 2 tables. Drilling table LxW: 370 x 500 mm Attachment table: LxW: 420 x 750 mm Clamping surface = 320 x 600 mm, transverse displacement (X-axis) 250 mm possible Ejection of tool via ejector wedge accessories: vice machine base *

Condition: used, Year of construction: 1971, Technical details: Iodpou Idhmjfx Ap Djih bore capacity in steel (diameter): 16 mm throat: 250 mm bore stroke: 125 mm spindle taper MT: MK 2 spindle speed:: 350 - 2000 / 8step U/min table clamping surface:: 280 x 355 mm table rotating: ja ° drill table adjustment: 520 vertical mm distance table - lower edge spindle: max. 600 mm column diameter: 110 mm total power requirement: 1,1 kW weight of the machine ca.: 272 kg dimension machine xH: 0,6 x 0,5 x 1,8 m Equipment: -Drill chuck 13 mm -twist drill 10 mm with 45° countersunk cut -machine vice *

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. Iisdpfx Apju Idkzs Doh *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 2-16 mm bore stroke: 140 mm drill spindle - Morse Taper: MK 3 spindle throat: 280 mm spindle distance: 455 mm headstock adjustment: 250 via Hand - Kurbel mm feed:: 0,08 - 0,12 - 0,20 - 0,31 / 4 steps mm/U feed:: automatic + manuell spindle speed:: 180 - 2000 / 8 steps U/min Iijdpfx Aeu Idugjp Djh distance between table/spindle: min. 3x 140mm und 1x 260mm mm distance between table/spindle: max. 3x 700mm und 1x 820mm mm table surface area: 1800 x 350 mm table adjustment: 300 via Hand mm total power requirement: 6,3 kW weight of the machine ca.: 2,4 t dimension machine xH: 2,1 x 0,9 x 2,2 m Application: Drilling, countersinking; reaming and thread cutting. Each drill spindle has its own drive motor Equipment: Foot pedal/operation Hand crank *

Condition: used, Year of construction: 1984, Technical details: grinding diameter min/max: 8 / 40 mm number of spindle speeds: 3000 U/min total power requirement: ca. 1,2 kW weight of the machine ca.: 0,24 t dimension machine xH: 0,7 x 0,9 x 1,3 m The grinding spindle is equipped with two hand levers: Working range left = manual grinding device for small shank drills. working range right = swiveling device of conical shank drills Iijdpfsu Ng Irjx Ap Djh cutting angle max 180 Drill swivel arm small: clearance angle 5° - 9°; drill Ø 8 - 15mm manually adjustable; grinding wheel cup wheel Ø 200 x 40mm with holder Ø 32mm Drill swivel arm large: clearance angle 5° - 9°; drill Ø max 400mm; pitch 6x with index grid manual; grinding wheel currently clamped Ø 180 x 31mm with receptacle Ø 32mm Grinding modes: Normal grinding, DK grinding, center grinding, spiral countersink, multiple step drill. *

Condition: used, Year of construction: 1980, Technical details: rpm spindle (continous): 2000 - 2500 U/min double strokes/min.: 25; 37; 50; 75; 100 H/min. Grinding-wheel diameter: Ø 250 mm work height max.: 1350 mm total power requirement: 2,7 kW weight of the machine ca.: 1,0 t dimension machine xH: 0,85 x 1,0 x 1,8 m Iijdpfx Apou Ng I Ej Doh Use for medium to larger metal circular saws from 250 - 1450mm. Saw blade attachment Ø 60 to Ø 80mm and shaft Ø 31,5mm Tooth pitch up to 42mm Tooth depth adjustment via scale Front cutting tooth: can be chamfered on both sides up to 45° and overcut at pitch 0.02mm *

Condition: used, Year of construction: 1979, Technical details: grinding diameter min/max: Aufnahme: Ø 200 x 32 mm number of spindle speeds: 3000 U/min total power requirement: ca. 1,2 kW Isdou Ng Ncopfx Ap Dsih weight of the machine ca.: 0,24 t dimension machine xH: 0,7 x 0,9 x 1,6 m The grinding spindle is equipped with two hand levers: Working range left = hand grinding device for small shank drills, grinding wheel currently Ø 120 x 30mm; admission=Ø 32mm; speed 3000 rpm.; with grinding support Working range right = swiveling device for conical shank drill; cup grinding wheel currently Ø 160 x 30mm; admission=Ø 32mm; speed 3000 rpm. Cutting angle max 180° for double-edged and 120° for triple-edged Clearance angle 5° - 9°; drill-Ø 8 - 40mm, possible grinding modes e.g.: normal grinding, DK-grinding, center grinding, spiral grinding, step drill grinding Machine illumination available *

Condition: excellent (used), Year of construction: 1955, Drilling capacity in steel St 37: Ø 65 mm Drilling capacity in cast iron: Ø 75 mm Spindle mount: MK 5 Overhang: 1250 mm Spindle stroke: 400 mm Spindle speeds: 22.4 – 1800 rpm Feed range: 0.056 – 0.56 mm/rev Column diameter: Ø 300 mm Motor power, 2-stage: 3.6 / 4.8 kW Clamping area, base plate: 1320 x 1000 mm Dimensions L x W x H (with motor!): 2250 x 1000 x 3100 mm Transport dimensions L x W x H (without motor!): 2250 x 1000 x 2800 mm Weight: 5100 kg Accessories / Special features: • Square table L x W x H 650 x 500 x 500 mm • Central clamping device • Feed mechanism • Right-left operation • Motorized vertical movement • High speed range up to 1800 rpm • Coolant system • Lighting Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany Isdpfetwzk Dsx Ap Dsih

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. Dimensions (L/W/H) 6100x1500x2300 mm Weight 950 kg 1 NEW drilling and milling center Götzinger Power Drill 300 With the Götzinger PowerDrill you can, depending on the type and design: - Drill on the front and on the long side - Dowels of front doors, pegs, fighters - The drilling patterns are freely programmable - You can drill: handle slides and corner bearings, with quick-change multiple spindle - You can: Milling lock case, pusher and PZ as well as 3D belts and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, save and call again Base frame in sturdy design, covered with sheet metal Table top 1800 x 200 mm Processing unit: X-axis - 500 mm working travel Y-axis - 0-120 mm Z-axis - 0-105 mm (above table) Horizontal aggregates: 1 horizontal drilling unit (dowel drilling unit left) ----- Drilling motor 220 V, 1.1 kW Collet holder ER 25 4,000 - 11,000 rpm adjustable 1 milling unit horizontal for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 horizontal drilling unit (dowel drilling unit right) ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 Vertical aggregates: 1 drilling unit vertical ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 1 boring unit vertical - with quick-change boring head ----- Drilling motor 1,1 KW, 3,000 rpm Included: 1 boring head BKF 2/3, for corner bearing incl. Drill set, quick-change ----- On loose item, drill assembly to customer fitting Iiedsif Az Uopfx Ap Djh 1 boring head BKF 3, for olive incl. Drill set, quick-change ----- On loose item, drill 1 cubo d = 25, 2 x dowel d = 10 1 milling unit vertical for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 piece length stop right and left, usable length 2.7 m, NC controlled Control: electro-pneumatic with three-axis NC positioning controller and integrated machine function Input via TFT display, 10 "color Machine complete, CE-compliant, with 1 set of drilling tools, DÜBO each 1 x d = 6,8,10,12 + 2 roughing cutters d = 16, ready for connection Loading dimensions: Machine L x W x H = 2.50 x 1.50 x 2.30 m, weight 850 kg Length stop L x W x H = 6.00 x 0.30 x 0.30 m, weight 100 kg ----- Total price in above mentioned version, ex works: on request Plus freight and installation / instruction (Technical information according to the manufacturer - without guarantee!)

Year of construction: 1982, condition: good (used), IESSE - multispindle boring machine model BEAVER year 1982 manufacture Biesse S.p.A Italy S/N 312/82 Technical data 1 horizontal drilling unit, 21 spindles 2 vertical drilling units, 2x10 spindles, pitch 32 mm Horizontal drilling motor 2.2 kW Vertical drilling motor 2 x 1.5 kW Spindle speed 2800 rpm Blade dimensions 10x1.5 mm Operating pressure 0> 6 MPa 7 pcs pneumatic responses with kSsi control levers weight 865 kg Isdpfx Apefrizte Dsih L x W X H 280cm × 150cm × 150cm

Condition: new, Drilling capacity cast iron / steel ----- 35 / 30 mm Tapping capacity cast iron / steel ----- 22 / 20 mm Motor ----- 1.5 kW Speed range ----- 75 ~ 3200 rpm Spindle stroke ----- 130 mm Spindle adaptor ----- MK4 Cross table ----- 600 x 190 mm Foot ----- 650 x 450 mm Diameter T-slots ----- 12 mm Maximum distance spindle - table ----- 610 mm Maximum distance spindle - foot ----- 1180 mm Weight ----- 390 kg INCLUDING * LED work light * Cooling system * Digital depth stop * Tapping function * 2-speed motor 75-3200 rpm * CE plug * Toolbox with various tools Ijdoq E N Uxjpfx Ap Dsih

Condition: new, Drilling capacity cast iron / steel ----- 35 / 30 mm Tapping capacity cast iron / steel ----- 22 / 20 mm Motor ----- 1.5 kW Speed range ----- 75 ~ 3200 o/min Spindle stroke ----- 130 mm Spindle adaptor ----- MK4 Drilling table ----- 540 x 470 mm Foot ----- 650 x 450 mm Isdpfxjq E N U He Ap Dsih Diameter T-slots ----- 12 mm Maximum distance spindle - table ----- 610 mm Maximum distance spindle - base ----- 1180 mm Weight ----- 320 kg INCLUDING * LED work light * Cooling system * Digital depth stop * Tapping function * 2-speed motor 75-3200 rpm * CE plug * Toolbox with various tools

Condition: used, Technical details: grinding wheel diameter: 160 mm saw blade diameter: 315 mm total power requirement: 1,2 kW connection voltage: 380 V control voltage: 220 V rated current: 4,6 A Iijdoz E Hdhjpfx Ap Dsh weight of the machine approx.: 370 kg Sharpening / regrinding of circular saw blades and slitting saw cutters For sharpening ball cutters with more than 20 teeth *

Condition: excellent (used), Catalog number: 7859 ADVANTAGES – for 8 spindles – with oscillation – variable spindle spacing (adjustable) – 2 worktables – unpainted – used drilling machine, very good condition Iisdpfezxg A Tex Ap Djh TECHNICAL DATA drilling spindles 2 x 4 pcs oscillation range right/left 40 mm per side oscillation speed adjustment via frequency inverter head with spindles adjustment up/down each pair of spindles (2 pcs) adjustable right/left 2 types of rotation speeds + right/left max. tool diameter 15 mm table adjustment up/down table dimensions 700 x 200 mm 4 hydraulic cylinders motor power 2 x 2 kW oscillation motor 0.75 kW dimensions L/W/H 1800 x 1350 x 1300 mm weight 862 kg Net price: 16,900 PLN Net price: 3,930 EUR Net price calculated based on an exchange rate of 4.3 PLN/EUR (in case of significant exchange rate fluctuations, the price may change)

Condition: good (used), Hello, We are pleased to offer the following drilling rig: Hausherr HS2000 X Drilling rig: Hausherr Make: Hausherr Model: HS2000 XXL Model year: 2004, used, refurbished in 2006 Engine: Caterpillar D12 Compressor: Atlas Dimensions & weight Length: 11 meters Width: 2.7 meters Height: 3.75 meters Weight: 18000 kg Included tools or accessories Mincom pipe, 76mm diameter, 5m, 14 new ones included + 5 in the machine Rebuilt levers, but original levers included, see pictures 6 new drill bits, 4 neck adapters, 2 drill necks As well as various other accessories and spare parts included. Spare parts worth approximately 35,000 euros are included, see pictures. No visible leaks were observed during the function test filming, see videos. Seller's comments: Serviced every 250 hours until 2023 (15,126 hours). Now inspected and serviced at 15,200 hours. Price: 59,000 euros Ex our Yard Technical data: Year of construction: 2004 Operating hours: 15,200 h Ijdez Rp A Sjpfx Ap Deih Engine manufacturer: CATERPILLAR Engine: D12 Emission stage: Stage IV Certificates: CE Delivery condition: EXW Location: Bro, Stockholm County, Sweden Equipment: Fuel filling pump, Air conditioning, Rear camera, Automatic feed setting, Safety cage, Extra-long feed rail, Power take-off, CLS lubrication system for rock drilling, Anti-freeze system for air lines, Hydraulic winch, Hose reel, Central lubrication, Swivel boom, Track support, 3-cam track plate, Hydraulic ground support, Two-speed travel motor, Engine heater, Radio, Diesel heater.

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Iodpfxsvvi I Ro Ap Doih

Condition: used, functionality: unexamined, For sale here is a benchtop drilling machine from O. B. T. Iiedpfez Rqd Dsx Ap Djh

Condition: used, functionality: fully functional, Jig boring/Milling machine HAUSER OP3 Travel X: 400 mm Travel Y: 250 mm Travel Z: 400 mm Cone: CM2 Spindle exit: 130 mm Spindle speedfrom 60 to 3000 RPM Table size: 590 x 320 mm Maxi distance spindle/table: 570 mm Drilling capacity in steel: 20 mm Scale 2 axes MITUTOYO Auto descent: 0,03 mm/min - 0,06 mm/min Variable speed drive at the spindle Voltage: 220 V Tri Width: 1600 mm Depth: 1600 mm Iedpjz Synbsfx Ap Deih Total height: 1600 mm Weight: approx 1,4 T Machine supplied with many accessories (see photos)

Condition: new, Motor: 750W - 230V - 1 Phase Drilling capacity: 20 mm Spindle stroke: 85 mm Spindle taper: MK2 Number of speeds: 16 Spindle speed: 220-2840 rpm Work table: 305 x 305 mm Base: 460 x 280 mm Column diameter: 72 mm Overall height: 990 mm Weight: 60 kg Packaging: 820 x 500 x 290 mm INCLUDED Iodpfjk Iuqyex Ap Deih * Digital depth stop * CE protective shield * Laser guide * LED lighting * CE emergency stop * Drill chuck with MK2 taper * Ejector pin
