Used Frame Hydraulic Press for sale (41,655)

Condition: new, Year of construction: 2025, TECHNICAL DATA Pressing force 30t max. load prism jaw 7.5t piston stroke 160mm piston travel 550mm Dimensions and weights length (product) approx. 1240mm width/depth (product) approx. 650mm Height (product) approx. 1920mm Weight (net) approx. 280kg Clear width 790mm Installation height max. 1030mm Frame depth 200mm SCOPE OF DELIVERY 2-part prism set for inserting round material Hand and foot lever Winch for lifting and lowering the table Location: Ex works Rsdpei Amnpofx Abtjch - available at short notice -

Condition: excellent (used), Machine: Used Lindemann Sobod 8 Metal Baler Bale size: 400mm x 400mm Rodpfoxrz S Asx Abtech Specifications: see table Status: ready to use Condition: in very good maintenance condition Year of manufacture: unknown Power: electric Availability: March/April 2025

Condition: used, Hydr. differential stroke press, toggle lever hydraulic press, automatic punching press BRUDERER - LEINHAAS type AR 11-100.H Fine blanking press, knuckle-joint press Machine. No. P247 Year of construction 1991 Pressing force 100 ton (1000 kN) Installation height max. 380 mm Table surface 1100 x 700 mm Outlet hole 800 x 220 mm ram surface 690 x 315 mm Frame width 1150 mm Lateral upright width 410 mm Stroke rate 45 and 80 strokes/min. Clamping pin bore Ø 50 mm Compressed air requirement 8-10 bar Hydraulic tank capacity approx. 700 liters Rcjdogp T Euopfx Abteh Motor power main drive 22 kW Mains connection 400 Volt, 50 Hz, 28 kW - 2 speed settings for the number of strokes (45 and 80 strokes/min.) - electronic cam controller BALLUFF, type Minicontroller BMC4K - electronic tool monitoring EBERLE, type PLS 509S - KISTLER press force monitoring system - table surface with 22 mm T-slots and ram surface with 14 mm T-slots - Electronic stroke counter - motorized height adjustment for the ram - central oil lubrication - Work area shielding through pneumatic opening protective screen - adjacent control cabinet and electrical cabinet - 2 oil coolers with FLUTEC cooling fan (oil-air cooling) - Electrical circuit diagram and printout of PLC program available - Two-hand operation on the machine Space requirement (control cabinet) L x W x H 700 x 700 x 2100 mm ( approx. Space requirement (electrical cabinet) L x W x H 1700 x 650 x 2100 mm Space requirement (press) L x W x H 2350 x 1700 x 3300 mm Weight of the press 8500 kg Very good condition

Year of construction: 2012, condition: ready for operation (used), This MILLUTENSIL Mil 303 hydraulic press was manufactured in 2012. It features a usable table of 3000 mm by 2000 mm, with a maximum load capacity of 30,000 kg on the upper table and 70,000 kg on the lower table. The press operates with a total power of 31.1 kW and offers adjustable hydraulic pressure up to 240 bar. Consider the opportunity to buy this MILLUTENSIL Mil 303 hydraulic press. Contact us for more information. Application Types Bending Rcjdpjxnr Dhefx Abtsh

Year of construction: 1994, condition: ready for operation (used), Pressing force: 3150kN, table dimensions X/Y: 2500mm/1600mm, stroke (fixed): 280mm, stroke rate: 20-80strokes/min, weight: approx. 68000kg. Including Dreher transfer and feed line. The control system is defective. Documentation available. An on-site inspection is possible. Rjdpfx Aboxtff Aetech

Condition: used, Year of construction: 1978, functionality: fully functional, machine/vehicle number: 3073, table height: 900 mm, installation height: 350 mm, pressing force: 200 t, table width: 690 mm, table length: 530 mm, overall weight: 2,900 kg, stroke length: 180 mm, Used EXNER embossing press Model: H4SP 200 Year of manufacture: 1978, retrofit in 2008 Ram stroke: 180 mm Rjdpfxsxrq Tcs Abtech Installation height: 350 mm Press table: 690 x 530 mm Table height above floor: 900 mm Sick light curtain Front column clearance: 420 mm Side column clearance: 220 mm

Condition: new, Year of construction: 2025, For sawing e.g. stainless steel, tool steel, hollow sections and solid materials Two-pole drive motor enables saw band speeds of 30 and 65 m/min Monitoring of saw blade tension electromechanically via microswitch When the saw arm is raised, the lowering cylinder locks in the upper position via the solenoid valve - additional locking at the cylinder is therefore not required Saw arm inclined by 25°, thus longer service life of the saw band Precise and robust band guides with adjustable HM plates After completion of the cutting process the saw band stops automatically in the lower end position Lowering of the saw arm by gravity or manually With infinitely adjustable, constant saw arm lowering speed via hydraulic cylinder Dimensions and weights length approx. 1200 mm width/depth approx. 650 mm height approx. 1800 mm Weight approx. 270 kg Electrical data Supply voltage 400 V Rcodog U Uv Rjpfx Abtsh Mains frequency 50 Hz Machine data Saw band speed(s) 30 / 65 m/min Speed levels 2 Saw band length 2450 mm Saw band width 27 mm Saw band thickness 0,9 mm Material feed Table height material feed 925 mm Cutting range 0° round (tube) 220 mm 0° round (solid material) 120 mm 0° rectangular lying (hollow profile) 230 x 150 mm 0° bundle (tube) 230 x 120 mm -45° round (tube) 160 mm -45° round (solid material) 85 mm -45° rectangular lying (hollow profile) 160 x 90 mm -60° round (tube) 90 mm -60° round (solid material) 55 mm -60° rectangular lying (hollow profile) 90 x 90 mm Art. No.: 3680001 S

Condition: good (used), Year of construction: 1993, functionality: fully functional, Technical data : Pressing force adjustable 10 - 100 kN throat depth 210 mm Table size W x D approx. 500 x 400 mm Installation height with/without clamping plate 300 mm Stroke 100 mm Total power 2.5 kW Weight approx. 2.5 tons Oil filling approx. 150 ltr. Space requirement W x D x H approx. 0.95 x 1.5 x 1.95 m . Equipment and scope of delivery : . Travel / pressure changeover Pressure control valve with display on pressure gauge Adjustable holding time documentation . Rsdpfxsxn Slle Abtech

Condition: excellent (used), Year of construction: 2014, Hydraulic Press Bunorm 4S-500 Manufacturer: Bunorm AG Model: 4S-500 Year of Manufacture: 2014 Pressing Force: 500 kN Maximum Pressure: 225 bar Weight: 3,200 kg Electrical Connection: 3×400 V + N + PE Frequency: 50 Hz Protection: 20 A Control System: Siemens Simatic HMI Touch Safety System: SICK C4000 Light Curtain SCOPE OF DELIVERY Includes, among others (non-exhaustive list): Hydraulic Press Bunorm 4S-500 Exact scope of delivery as shown in the photo series. The Bunorm 4S-500 hydraulic press impresses with its robust construction and a pressing force of 500 kN at a maximum pressure of 225 bar. With its solid build and a weight of 3,200 kg, the press is suitable for demanding production applications. The integrated Siemens Simatic HMI Touch control system enables precise and user-friendly operation. Thanks to the modern SICK C4000 light curtain safety system, a high level of operator protection is ensured. This machine is the ideal solution for companies that value reliability, precision, and safety. No guarantee is given for the correctness, completeness, or currentness of the information provided. Rcsdpfxoxfl Axo Abtoh

Condition: new, Bernardo Frame Press HRP 3000 Robust and torsion-resistant hydraulic frame press with high-quality pressure cylinders. Whether it is used for furniture or door production, block or frame gluing, the high pressing force of 2,000 kg per cylinder and precise, angle-accurate pressing of large-sized components enable all tasks to be carried out effortlessly. Technical Specifications Working length: 2,400 mm Working height: 1,550 mm Cylinder stroke: 95 mm Pressing force: 2,000 kg Vertical hole pitch: 50 mm Horizontal hole pitch: 160 mm Overall length: 3,250 mm Rcedpfxexrnvbo Abtoh Overall height: 2,070 mm Frame depth: 925 mm Weight: approx. 315 kg Features • Versatile use, e.g. for frame, window, and door production • Robust frame press with solid steel construction • Centralized control of the hydraulic cylinders including pressure gauge • Efficient gluing thanks to hydraulic design • Pressure cylinders equipped with rocker plates as standard Scope of Delivery • 4 movable pressure beams, each with one vertical hydraulic cylinder and counter support • 1 movable pressure beam with two horizontal hydraulic cylinders • 1 movable, adjustable pressure yoke

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, total height: 2,300 mm, installation height: 400 mm, total width: 1,620 mm, total length: 2,240 mm, pressing force: 61 t, table width: 450 mm, table length: 450 mm, overall weight: 3,800 kg, ram plate width: 160 mm, ram plate length: 160 mm, type of input current: three-phase, stroke length: 150 mm, input voltage: 400 V, Equipment: documentation/manual, DR. Fritsch DSP 515 Pressure Sintering Press Machine Type: Pressure Sintering Press Year: 2008 Condition: Very Good. Decommissioned Includes Manual Technical Specification Main Cylinders: 1 Cylinder Diameter: 160mm Cylinder Stroke: 150mm Piston Rod Diameter: 140mm Effective Pressing Surface: 201.1cm2 Auto Pressure Control: 60-603kN Internal Dimensions: 450 x 450 x 400mm Self Baking Electrodes Dimensions: 180 x 180 x 60mm Inner Width of Electrodes: 145mm Temperature Range: 0-1,100 Deg C Sintering Mould Height: 60-120mm Sintering Surface: 150cm2 Total Connected Load: 155kVA Total Supply Voltage: 3 x 400V 50/60cps Total Nominal Current: 3 x 224A Operating Voltage: 3 x 400V 50/60cps/ 1 x 230V 50/60cps Control Voltage: 24V DC Cooling Water Consumption: 120-150L/min Water Quality: Drinking Water Recommended Water Supply Temp: 15 - 25 Deg C Water Pressure: 2-4 Bar Differential Pressure: 1-2 Bar Compressed Air Consumption: Approx. 20L/min Redpfxov Rz Ifo Abtjch Air Pressure: 4-6 Bar Protective Gas Consumption: Approx. 300-1000L/h Gas Pressure: 1-5 Bar Dimensions: 2240x1620x2300mm Weight: 3800kg

Condition: not inspected (used), Press for bending and straightening trusses. Machine has not yet been tested Rodpfx Abexq S Ufjtjch

Condition: new, Year of construction: 2025, For sawing tubes and solid materials made of stainless and tool steelTwo band speeds by means of pole-changing motorRobust gear with hardened and ground shaftPrecise and robust band guides with adjustable carbide platesLonger service life of the saw band due to saw arm inclination of 25°Efficient coolant application to the saw band guidesElectromechanical monitoring of the saw band tension, In case of deviations, a microswitch switches off the machine chip clearing brush for optimum cleaning and maintenance of the saw band function of the semi-automatic machine:Automatic workpiece clamping after the start of the cutting cycleExecution of the saw cut at the selected band speedAutonomous stop of the lowering movement and of the saw band in the lower end positionAutonomous return movement of the saw arm to its upper end positionOperator only has to move the material automaticallyEquipment:Two band speedsCut-off buttonCoolant systemChips clearance brushSaw band tension monitoringSwivelling control panelLength approx.1860 mmWidth/Depth approx.1045 mmHeight approx.1750 mmWeight approx.405 kgPower consumptionPower consumption1.5 kWElectrical dataConnection voltage400 VMachine dataSaw blade speed(s)20 - 100 m/minSpeed steplessSaw blade length2720 mmSaw blade width27 mmSaw blade thickness0,9 mmSaw blade 60 - -45 °Cutting ranges0° round (tube) Rcedpjd Hx Uqjfx Abtjh

Condition: excellent (used), functionality: fully functional, Horizontal hydraulic layer press Two-hand operation Electrical connection 400V/50Hz, 200kg Rcodsxbgftepfx Abtsh

Condition: like new (used), Year of construction: 2024, pressing force: 200 t, Main Cylinder Press Capacity: 200 T - Maximum working pressure: 285 bar - Cylinder stroke: 1500 mm - Clear width / clear height: 1500 mm - Distance between columns: 2050 mm - Maximum lateral cylinder displacement: 1450 mm - Maximum longitudinal frame displacement: 2800 mm - Table plate dimensions: 4000 x 2000 mm - Hydraulic power unit output: 5.5 kW - Approach speed: 20 mm/s - Working speed: 2 mm/s - Hydraulic oil is not included in the delivery scope - Hydraulic power packs are mounted on top of the press - Hydraulic manifold and valves by Rexroth - Air filter brand: FILTREC - Oil filter brand: FILTREC - Hydraulic cooling by air and water cooler - Stroke cylinders integrated into the working table Rod diameter: 25 mm - Stroke: 80 mm - Control via cylinder control system or hydraulic power unit with manual lever control - 10 stroke cylinders installed - Digital control with stroke measurement via encoder and pressure measurement with digital readout - Siemens KTP 900 – 9" touchscreen for programming (up to 99 programs): - Maximum up and down stroke of the cylinder - Pressure holding time at the lower table - Decompression time - Working pressure setting - Piece counter - Pre-stop up/down stroke with accuracy of 0.1 mm - Alarm management - Frame-mounted display for real-time operating parameter monitoring - Wireless remote control with two buttons for simultaneous operation - Control cabinet with Siemens CPU - Hydraulic power pack with solenoid valves (replaces pendant control panel) - Air/oil heat exchanger with decompression valve 5. ELECTRICAL INSTALLATION AND SAFETY - PLC system by SIEMENS (S7-1200 series) Rcedjxrb Nbepfx Abtsh - Siemens LCD touchscreen (9") MTP900 fitted in the control cabinet - Electrical components from SIEMENS, ALLEN BRADLEY and PHOENIX - System pressure of the pressure cylinder adjustable via LCD touchscreen - Operating mode (semi-automatic and automatic), power, vertical stroke, and dwell time of the upper cylinder are programmable - 99 recipes storable; all aforementioned values can be programmed per recipe - Activation via wireless remote - Dual button for slow/fast up and down movement, emergency stop, and movement confirmation - Touch-sensitive safety strip mounted at the bottom of portal columns for safety - Control cabinet mounted to bridge sidewall - Anti-rotation device for the cylinder - Oil temperature displayed on LCD touchscreen - Overheat warning for hydraulic oil displayed on LCD touchscreen - Filter contamination status displayed on LCD screen - System faults displayed on LCD touchscreen - Pressing status information displayed on LCD display - Once oil temperature reaches 45°C, the air cooler begins operating to cool the oil. If 65°C is reached, the machine stops operation until it cools back to operating temperature. - Operating manual included - System complies with all essential safety and health requirements according to CE regulations.

Condition: used, Year of construction: 2011, -Special price Machine brakes defective- Rsdpfxexnyhbe Abtech Pressure: 36 t Bending length: 1020 mm Distance between uprights: 932 mm Stroke: 120 mm Installation height: 295 mm Throat depth: 150 mm Machine weight approx.: 2,600 kg

Condition: excellent (used), Year of construction: 1984 Pressing force: 10 t Total pressing area: 300 x 300 mm Stroke: 540 mm Dimensions W x D x H: approx. 900 x 500 x 2150 mm Rjdoryn S Ajpfx Abtech

Condition: ready for operation (used), Year of construction: 1977, Immediately available ex location: Hydraulic double-column straightening press Dunkes Type HDSR 75 Year of manufacture: 1977 Pressing force: 165 t 3 cylinders, pressing force per cylinder: 75 / 65 / 25 t Table: 1500 x 500 mm Stroke: 350 mm Rodpfjxrbnwjx Abtjch Drive power: 3 / 15 kW Weight: 6 t Price: EUR 2,750— plus VAT, ex location

Year of construction: 1994, condition: good (used), machine/vehicle number: 24.105, A used, well-preserved hydraulic press brake HATASTAR equipped with: - CYBELEC DNC 70 control - Controlled axes Y1;Y2;X;R - Hydraulic upper tool clamping - Hydraulic crowning Redpofthzksfx Abtoch - FIESSLER AKAS safety system - Tools - Press book - Documentation bending length 4600mm Stands width 4100mm Press force 1350kN stroke 220mm Rapid traverse 140mm/sec working speed 10mm/sec Retraction speed 100mm/sec Further tech. data see pdf.- document Tech. Data and dimensions: Errors excepted.

Condition: used, Working width 3500 mm Working height 2550 mm Number of cylinders 6 St. loading dimensions L x W x H 4500x950x2900 mm Hess Speedy frame press ----- will be checked Insertion dimension / pressing length max. 3,500 mm Insertion dimension / pressing height max. 2,550 mm Sliding carriage for width adjustment locking in 50 mm Double hole grid system Electric height adjustment of the long-stroke cylinders (hydraulic) Insertion height of the abutment plates can be preselected in 4 positions Rodpfjxnqw Tex Abtsch 3 vertical printing cylinders stroke 1000 mm Pressure force per cylinder 2000 kN / 20000 N 3 horizontal printing cylinders stroke 80 mm Pressure force per cylinder 1250 kN / 12500 N Printing plate depth 100 mm width 140 mm Grid for cylinder fixation/rear bearing 50 mm Medium pressure beam with shut-off valve Final pressure switch-off and pressure control Control and pressing process in touch button operation Adjustable pressing pressure min. 25 – max. 160 bar Electrical connection 2.2 kW / 400V Image and video not original, show identical model ----- (technical data according to the manufacturer - no guarantee!)

Condition: like new (used), Year of construction: 2024, functionality: fully functional, pressing force: 40 t, table width: 1,000 mm, table length: 600 mm, 40T H-Frame Press with Ram Table • Press capacity: 6-40 T (adjustable) • Maximum installation height: 700 mm • Usable area, lower table: 1000 x 600 mm • Usable area, ram: 1000 x 600 mm • Frame type: H-frame • Guide column diameter: Ø 100 mm (4 pcs, at the corners) • Table height from floor: 800 mm • Overall dimensions approx. (W x D x H): 2,100 x 1,600 x 3,500 mm • Total weight approx.: 3,500 kg • T-slots and drill holes made to customer specification. HYDRAULIC CYLINDER: • Piston stroke: 0-500 mm (adjustable) • Cylinder diameter: Ø 140 mm (1 pc) • Piston rod diameter: Ø 80 mm (1 pc) • Max. operating pressure: 260 bar • Return speed: 90 mm/sec • Ram speed: 9 mm/sec • Idle speed: 80 mm/sec HYDRAULIC UNIT: • Hydraulic pump (brand: ASC): 67+8 L/min (1 pc) • Motor power: 4 kW (1 pc) • Pressure accuracy during pressing stroke: +/- 5 bar • Hydraulic unit is mounted at the rear upper section of the press. • Hydraulic manifold and valves by DUPLOMATIC. • Manometer for pressure display. • Air filter and oil filter brand: FILTREC. • Equipped with an electronic oil level switch. • Air cooling (cooler) is used for hydraulic cooling. • Pressure adjustable via pressure switch. • Control via sensor. • Safety cover (door) located at the rear of the press. • Safety light sensors and internal lighting included. ELECTRICAL CONNECTION: • Main supply: 400V AC • Control voltage: 24V DC • Frequency: 50 Hz • Hydraulic unit main motor connection: 4 kW • Total power supply: Approx. 6 kW Rodpoxrby Hefx Abtoch CONTROL CABINET EQUIPMENT: • Protection class: IP 54 • Reserve space: 30% • Cooling: Yes (air cooling) • Internal lighting: Yes • Mode selector switch: Yes (lockable) • Electrical equipment brands used: SIEMENS, ALLEN BRADLEY, SICK.

Condition: used, Year of construction: 2000, Press force: 85 t Bending length: 2050 mm Distance between uprights: 1750 mm Control: DELEM Stroke: 215 mm Throat depth: 410 mm Weight: 7,900 kg Machine dimensions: 2700x2100x2400 mm Accessories: - Two-hand operation - 2 support arms - Side safety doors Rcodpfjxnxwnjx Abtsh - Lasersafe Fissler - Wila tool holder - Die shifting - Crowning - Tool cabinet

Condition: excellent (used), Maweg Frame Press Working length 3000mm Working height 200mm Foot width 95mm Number of vertical clamps 5 Number of side clamps 3 Rcjdovy A Uxopfx Abtsh Hydraulic pump motor 2.2kw

Condition: good (used), Year of construction: 1988, machine/vehicle number: 042+023-14, Offer 25379 Technical Specifications: - Max. pressing force: 100 t - Max. ram stroke approx.: 500 mm - Stroke speed: 200 mm/sec - Return stroke: 200 mm/sec - Installation height approx.: 800 mm - Throat depth to ram center: 380 mm - Ram clamping area: 530 x 400 mm - Ram clamping pin: 40 mm - Table size: 750 x 560 mm Rsdpjxrpkaofx Abtsch - Table bore / through hole in table: 200 mm - Table height above floor: 720 mm - Oil capacity approx.: 200 ltr - Drive: 400 V / 11 kW - Required floor space approx.: W 1150 x H 3300 x D 1850 mm - Weight approx.: 5000 kg

Condition: good (used), functionality: fully functional, machine/vehicle number: 151/6, Hydraulic Straightening Press Manufacturer: WALTER Type: WP Machine No.: 151/6 The press has a table size of Length Width Thickness 1000 390 60 mm Cylinder stroke: 400 mm The current distance between cylinder and table is 450 mm. When the table adjustment is set to the lowest notch, the gap between table and cylinder is 850 mm. (See the attached sketch for details) The machine is also equipped with an appropriate control system. Max. Pressing force: 60 tons Redpjxl Tmfsfx Abtech 180 bar Table height adjustment approx.: 1000 mm (installation dimension) Motor power: 4 kW Two-hand control Emergency stop Foot pedal Stroke limitation via limit switch
