Used Raypath Germany for sale (8,545)

Condition: used, Year of construction: 2002, Screw compressor, single-stage, oil-free. Djdpjvcqt Iefx Anweut Max. flow rate approx.: 1080 m³/h Power: 75 kW Length: 1605 mm Width: 1250 mm Height: 2000 mm

Condition: used, Additional title: Brewing vessels with copper hoods and hop dispenser, whirlpool and wort cooling Dsdpfx Aevcqufjnweut Capacity: 150 hl/brew Operation / Control: ProLeit / Siemens S7 Material: brew house vessels copper-covered Features: mash/wort kettle, mash/lauter tun, hop addition, vapor condenser system, whirlpool, wort cooler, various pumps and fittings

Condition: used, Centrifugal pumps for pumping liquids. The liquid enters the housing through the suction flange. The impeller creates a negative pressure in the centre of the suction pipe, as the medium is pressed to the edge of the casing by centrifugal force. Here, the liquid rises due to the higher pressure and leaves the casing via the pressure flange. Used centrifugal pumps from various manufacturers, with different key figures and equipment. Both mobile and stationary centrifugal pumps are available. Capacity: 15 - 1080 hl/h Delivery head: 5 - 140 m Power factor: cos ϕ Speed: 1435 rpm - 2930 rpm Power: kW Voltage: 22 V Current: 3 - 43 A Frequency: 5 Hz Capacity: 1080 hl/h Pumping head: 140 m Drive: 3520 rpm Performance factor: 0 cos ϕ Power: 0, - kW Current: 1,1 - 117 A Voltage: 22 V Frequency: 5 Hz Dusdpfx Anjvcqyuewst

Year of construction: 1991, condition: used, The Filtrox Cross Flow microfilter works with a permissible transmembrane pressure of 6 bar (0 °C - 95 °C) and a filtrate volume of 4.5 - 7 hl/h with a filter surface area of 26.4 m². Two pumps (20 kW) in the unfiltrate circuit transport the medium to be filtered. With 16 hl agitator tank as cleaning tank. Additional title: yeast-beer recovery Capacity: 7 hl/h Tol. operating pressure: 10 bar Tol. operating temperature: 85 °C Max. filter area: 26 m^2 Dujdpfxovcq Das Anwet Current: 4,85/2,8 A Voltage: 220/380 V Frequency: 50 Hz Operation / Control: Simatic S5 Features: 8 ceramic membrane modules (total filtration area 26.4 m2); high-pressure pump; 16 hl cleaning tank with agitator; various pipes, valves, measurement and control technology

Condition: used, Year of construction: 1993, Capacity: 12242 l Length: 2300 mm Width: 2300 mm Height: 3550 mm Material: stainless steel 1.4301 Position: standing on feet Dedpfx Aevcq Dyonweut Features: Flat conical bottom, frame and cone cooling zone, manhole, sampling tap, central spout.

Condition: used, The servo controller allows precise control of torque, speed and position. Ideal for complex, high-precision tasks. Here you will find a selection of used servo motors with various key figures and equipment. rotation speeds: rpm Torques: Nm Torque constants: Currents: 1.2 - .5 A Voltages: 0 - V Frequency: 5 Hz Equipped with brake motors of the following key figures and capacities: Voltage: 24 V Currents: A Torques: 1 - 5 Nm Servo motors with different manufacturers and years of manufacture. Drive: rpm Torque: Nm Torque constant: 2 Current: 1,2 - ,5 A Dsdpfx Asvcqgujnweut Voltage: 0 - V

Condition: used, Year of construction: 2003, Crushes bottles by pressing them. - high crushing capacity - high volume reduction - accident-proof (splinter-proof) - low noise [85/87 dB(Ai)] - low wear rate - compact design (minimum space requirement) Crushing capacity: 6000 b/h Dusdjvcqhxopfx Anwjt Current: 6,5 A Voltage: 380 V Frequency: 50 Hz Length: 15220 mm Width: 1300 mm Height: 22600 mm Weight: 700 kg Base construction: On dome feet Features: Fragment tub, noise protection box, slot for manual disposal of single bottles

Condition: used, Year of construction: 2006, The fully-automated carbonisation plant produces the CO2-amount of beer, beer mixing beverages, soft drinks, mineral water and wine in a continuous and high-precision way by precise controlled dosing of CO2. Capacity beer feed: 200 hl/h Capacity degassed water: 100 hl/h Capacity blended beer: 300 hl/h CO2-supply: 8 barg Power: 23 kW Current: 50 A Voltage: 400 V Frequency: 50 Hz Compressed air: 6 bar Length: 2790 mm Width: 1250 mm Height: 2440 mm Weight: 500 kg Operation / Control: fully automatic, electrical cabinet with control panel Djdpfx Anevcqlqjwsut Material: stainless steel Features: Flange connection: Beer: DN80, degassed water: DN40, CO2: DN25, blended beer: DN65 Beer pump; carbonisation section; flow measurement; Anton Paar original wort, alcohol and CO2 measurement; pressure gauge; sampling taps; various other valves

Condition: used, Effluent plant for waste water treatment. Includes: - Mixing and equalisation tanks 1, 140 m3 - Mixing and equalisation tanks 2, 40 m3 - Mixing and equalisation tanks 3, 80 m3 - Bioreactor 1, 240 m3 - Bioreactor 2, 240 m3 - 2 air compressors for aeration in the reactors - Secondary sedimentation tank 1, 100 m3 - Secondary sedimentation tank 2, 100 m3 - Thin sludge tank, 70 m3 - Thick sludge tank, 90 m3 - Sludge dewatering 1 and 2 - Precipitant tank, 25 m3 - Various process water pumps Dujdpfevcql Rex Anwet Bioreactor capacity 2 x: 240 m3 Operation / Control: Siemens Simatic S7 Features: Mixing and equalisation tank 1, 2 & 3; Pumping station 1 - inlet bioreactor; pumping station 2 - inlet bioreactor; bioreactor 1; bioreactor 2; pumping station - outlet bioreactors; 2 x air compressor; Precipitant tank; filling unit; 2 x flocculent mixing station; secondary sedimentation tank 1 & 2; mixing tank; thin sludge tank; 2 x sludge dewatering; thick sludge tank

Condition: used, Free-standing pavilion constructed by upcycling the copper hood from a brewing vessel. Diameter is determined by the existing copper hood, so various different sizes are possible. A variety of options regarding feet or anchoring. Dujdpfx Ajvcqmnenwst Diameter: 5 m (depending on copper hood availability) Material: Copper / stainless steel Base construction: Pipe feet with base plates; optional: height-adjustable feet Features: Flue pipe cover; illumination system; copper side-wall

Condition: used, Additional title: in various designs Duedpfxsw Dy E Ue Anwot

Condition: used, Year of construction: 1990, Joha crate unpacker Additional title: Unpacking machine for bottle crates Capacity approx.: 400 crates/h Power: 2 kW Current: 5 A Voltage: 380 V Dsdpfx Aew S T I Denweut Position: free standing

Condition: used, vertical CIP tanks Additional title: vertical stainless steel tanks on base frame Content approx.: 600 l per tank Duedpfew Tal Sjx Anwet Length: 3000 mm Width: 750 mm Height: 2200 mm Material: stainless steel Base construction: standing tanks with square pipe feet on base frame Features: Manhole at the top, spray ball, ladder bracket, outlet side piped, pump, control cabinet

Condition: used, Year of construction: 2002, Packer Manufacturer: SZA Federspiel Model: Portropack-E Year of construction: 2002 Additional title: Packing machine for bottle crates Dsdpfew Tawzsx Anwout Capacity: 30000 Bottles/h Air consumption: 7 m³/h Current: 25 A Voltage: 230 / 400 V AC Compressed air: 5 bar Length: 2300 mm Width: 2800 mm Height: 2400 mm Formats: 0.33 l Vichy, 0,33 l Euro, 0.35 l lemonade, 0.5 l NRW bottles, modular crate, 8 packing heads (4x20 and 4x24) Running direction: Module box in longitudinal run, from right to left Operation / Control: Simatic S7-300 / OP17 Position: free standing Base construction: Square frame construction painted on spherical feet Features: Gripper head carrier with pneumatic equipment, operating area covered with windows, container transport, pack transport, 2 gripper head sets, safety device, electrical and pneumatic equipment

Condition: used, Compressed air system with compressed air compressor and compressed air tank - KAESER SK26 screw compressor (built in 2005) - Gebre GmbH compressed air tank with a capacity of 750 litres (built in 1996), standing on 3 feet with pressure gauge. Additional title: air compressor with compressed air tank Delivery appr.: 2,2 m3/h Dusdpfx Ajw Tbtksnwst Max. working overpressure compressor: 10 bar Gross volume compressed air tank: 750 l Max. working overpressure compressed air tank: 11 bar Power: 15 kW Current: 400 V Voltage: 35 A Frequency: 50 Hz Length: 0,8 m Width: 0,8 m Height: 1,03 m Weight: 290 kg Operation / Control: control panel on compressor Base construction: tank vertical on 3 feet Features: air compressor, compressed air tank

Condition: used, Cold area with an annual capacity of 1,000 to 3,000 hl, consisting of 1 fermentation vat: Kaspar Schulz, 13.43 hl, year of construction: 2000 2 fermentation tanks: 1 x Kaspar Schulz, 24.22 hl, year of construction: 2000 1 x Kaspar Schulz, 42.19 hl, year of construction: 2000 4 storage tanks: 4 x Kaspar Schulz, 21.5 hl, year of construction: 2000 6 bright beer tanks: 6 x Kaspar Schulz, 11.22 hl, 3 bar, year of construction: 2000/2001 2 centrifugal pumps: 1 x Hilge, mobile, 15 m3/h, 2.7 bar, year of construction: 2000 1 x Hilge, mobile, 15 m3/h, 2.5 bar, year of construction: 2013 1 desi tank, 1 x cylindrical stainless steel tank on feet with side outlet, year of construction: 2000 with pipework and switch cabinet for automatic cooling system. Additional title: with centrifugal pumps and disinfection tub Features: Fermentation vat, 2 x fermentation tank, 4 x storage tank, 6 x pressure tank, 2 x centrifugal pump, 1 x desi tank, pipework and control cabinet for refrigeration control Dedpfx Anew Td Dlsweut

Year of construction: 2000, condition: used, Flat conical stainless steel fermentation tank for approx. 40 hl net content. Additional title: coolable tank Gross content: 4219 l Perm. working temperature: 20 °C Length: 2000 mm Width: 2000 mm Height: 1800 mm Dodjw Td D Eopfx Anweut Material: stainless steel Features: Manhole in the frame, spray head with spray head line and dummy cap DN 25, outlet flap, Pt 100 for automatic temperature control. height-adjustable tube feet; Magent valve for temperature control

Condition: used, Year of construction: 1999, 6 vertical storage tanks with jacket cooling Additional title: vertical, coolable stainless steel tanks Content: 2200 l Max. pressure: 0,99 bar Length: 1000 mm Width: 1000 mm Height: 1965 mm Operation / Control: manual Material: stainless steel 1.4301 Position: free-standing Base construction: cylindrical tank with curved bottoms and square tube feet on domes Duodpsw Tlppjfx Anwet Features: sprayball, bunging apparatus, pressure gauge, 1 shell cooling zone, standhose for content display, manhole, thermometer and sampler in the shell, manual valve for cooling control, central bottom outlet

Condition: used, Bottling line with a capacity of 30,000 bph. 0.33 litre Vichy, 0.33 litre Euro and 0.5 litre NRW non-returnable bottles can be used. The line consists of the following machines/components: - New glass unscrambler Manufacturer: Steinle Fördertechnik - Beer preheater Manufacturer: Fischer - Bottle filler Manufacturer: Krones - Crown cork filling hopper with transport Manufacturer: Gassner - Bottle level control Manufacturer: Metec - Labeller Manufacturer: Krones/Renner - Labelling control Manufacturer: Miho - Bottle carrier labeller Manufacturer: DOKU-Consult Capacity: 30000 bottles/h Formats: 0,33l Vichy, 0,33l Euro and 0,5l NRW Operation / Control: mainly Siemens S7 Position: free standing Features: New glass clearer; beer preheater; bottle filler; crown cap filling bunker with magnetic transport; bottle level control; labeler; label control; packer; full crate control; palletizing system Duodpfxsw Tmhaj Anwot Layer patterns: 4x8 boxes, 5 layers, on Euro pallet

Condition: used, Year of construction: 2001, Full crate inspection Manufacturer: Metec Model: Prom 1000 VKK Programs: 18, 20, or 24 bottles Year of construction: 2001 Capacity: 1500 Crates/h Dodpfx Answ Tmiwjwsut Length: 2100 mm Width: 2000 mm Height: 1600 mm Formats: 20 bottles, 24 bottles, 18 bottles Position: mounted on the roller conveyors Base construction: Square tubes screwed together Features: Electronics box, measuring devices, fault container rejection system with accumulation roller conveyor

Condition: used, Crown cap filling bunker with magnetic transport Manufacturer: Gassner Filling capacity: 30,000 bottles/h Additional title: Crown cork hopper with magnetic transport Performance of the filler: 30000 bottles/h Formats: Crown caps and twist off crown caps Duodpfx Anew Tmikswst Material: Housing in stainless steel Position: Free-standing receiving hopper, belt conveyor attached to the wall or ceiling Base construction: Receiving hopper in square tube/smooth sheet construction Features: Receiving hopper, 1 magnetic vertical conveyor, 2 horizontal belt conveyor, 1 electrical control/control cabinet

Condition: used, Brewing plant with a wort output of 20 hl, consisting of the following components: 1. grist plant (Joh. Albrecht, 2000, 500 kg/h) with mill, malt hull, floor scales, grist conveyor and control cabinet 2. 3-device compact brewhouse with insulated stainless steel vessels with copper bonnets, spindle station and control cabinet 3. fermentation and storage cellar with 4 x fermentation vats (Joh. Albrecht, 1999, 25 hl), 1 x fermentation tank (Nerb, 2002, 50 hl, 0.99 bar), 5 x storage tank (Joh. Albrecht, 1999, 44 hl, 0.99 bar) and 6 x storage tank (Joh. Albrecht, 1999, 22 hl, 0.99 bar). All tanks with jacket cooling. 4th pressurised tank cellar with 2 x pressurised tank (Speidel, 2021, 86 hl, 3 bar), 1 x pressurised tank (INOX, 2018, 67 hl, 3 bar) and 4 x pressurised tank (Joh. Albrecht, 1999, 12 hl, 2.5 bar). All tanks with jacket cooling. 5. keg cleaning and filling system (BTB. Multimat MT/2, 1997, 17-20 kegs/h) 6. refrigeration system as ice water generator (Joh. Albrecht, 1999, cooling capacity 14.5 kW) 7. steam generator with soft water system (Jumag, 2000, 224 kg/h steam, oil-heated) 8. 40 hl hot water tank (Joh. Albrecht, 1999), heatable, with switch cabinet Interested in only part of the system? The system is offered as a consignment sale. A partial sale might be possible – feel free to contact us and submit your offer. Additional title: cast wort volume 20 hl, years of manufacture 1997-2001 Cast wort capacity: 20 hl Features: Grist system; 3-device compact brewhouse; fermentation vats; fermentation, storage and pressurised tanks; keg system; refrigeration system; steam generator, warm water tank, CO2 liquid gas tank Djdpfx Answgc Udeweut

Condition: used, Year of construction: 2017, Filling line for 0.33 L disposable Euro bottles The bottles are placed by hand on a bottle loading table. From there they run on a conveyor belt to the labeling machine, where an all-round adhesive label is applied. Then they go to the combined rinser/filler/sealer, and downstream bottle collection table, from which the bottles are manually packed into crates or other containers. Additional title: Glass bottle filling Dodpjwgi Dxsfx Anwout Nominal capacity approx.: 3750 bottles/h Formats: 0.33 L disposable Euro- and Vichy-bottles Running direction: left -> right Operation / Control: Filler: Siemens ET 200 SP, Touch Panel Position: free standing Features: Bottle loading table, labeling machine from Intrex (model: Intrex Set with all-round adhesive labeling), bottle rinser/filler from Leibinger GmbH (rinser model: 12 BG, filler model: Multima L (=long-tube filler) control: Siemens S7, built in 2019), Bottle collection table, bottle transport

Condition: used, Year of construction: 2015, Pentair BMF-Skid (with 18 modules) for beer filtration. Ideal for expanding existing systems or setting up a new filtration system. Additional title: Beer Membrane Filtration (BMF) Duedpfew Ea Ekex Anwot Max. capacity: 100 hl/h filtrate, depending on beer quality Flow rate: 330 m3/h un-filtrate pump Flow pressure: 1 bar un-filtrate pump Number of modules: 18 pcs. Length: approx. 5500 mm Width: approx. 1500 mm Operation / Control: ProfiBus connection to a central PLC Base construction: Module frame-mounted Features: 1 x BMF Skid, with 18 membrane modules; filtrate pump

Condition: used, Year of construction: 2000, Conveyor belts for glass bottles, with 2 unpressurised converging conveyors Transport with 1, 3 or 4 conveyor belts Capacity: 30,000 bottles/h Manufacturer: Krones Year of construction: 2000 Additional title: free container conveyors Capacity approx.: 33000 Bottles/h Free bottle transport approx.: 115 m 90° Bottle transport curves: 10 pc. Conveyor belt widths: 4 conveyor belts Formats: 0,33 l Vichy, 0,33 l Euro, 0,35 l Lemonade, and 0,5 l NRW Operation / Control: Simatic S7-400 / S7-300 Material: Mainly stainless steel Position: free standing Duedpfx Anew Ta Hcewst Features: Conveyor frames, deflection stations, drives, frequency controls, electrical switching devices, 2 pressureless bottle mergers (17/9/7/5/3/1 and 12/7/3/1 conveyor belts), automatic belt lubrication
