max. wheel diameter 565 mm
gear width 100 mm
max. module 8,5
min. module 1
total power requirement 25 kW
weight of the machine ca. 7,8 t
dimensions of the machine ca. 1420 x 410 x1,8 m
Bevel gear generator GLEASON No 14
Manufacturer: Gleason Works
Made in: USA
-Max.: 805 mm
Pitch angle (max.) shafts at 90°: 84°18'
Pitch angle (min.): 5°42'
Extreme ratio: 10:1
Diametral pitch (coarsest): 8.5 Mod.
Index range: 5 to 100 inclusive and most ... more
MODUL - ZFTK 250/1 - 1987- change gears- 10-11 set of knives- knives grinder- knife height measuring - max gear diameter 315 mm- max gear width 45 mm- max modul 10- number of cutters 2x22- change gears- chip conveyor- was in use till end of November 2019- nice machine, cleaned- was manufacturing small gears
Milling machine for conical straight wheels ZFTKK 500x10.
- maximum diameter of the machined wheel: 500 mm
- maximum module: up to 10 mm
- maximum rim width: 71 mm
- number of teeth: 6-100
- maximum gear ratio: 1: 6
- radial adjustment: 30-220 mm
- adjustment of the cone angle: 0-90 degrees
- cutting speed: 40-80 m / min
- weight: 10ton, more
MODUL - ZFTK 250/1 - 1986- max gear diameter 315 mm- max gear width 45 mm- max modul 10- number of cutters 2x22- change gears- 3 set of knives - different items- chip conveyor- was in use till end of May 2019- nice machine, cleaned- was manufacturing small gears
Tooth width max 38 mm.
Advance seconds x tooth 2 - 3,1
Cutting speed 33 a 50 m/min
Radial displacement 14,8 mm.
Roll cradle feeds in minutes of angle per cutter head revolution 32,6 - 49,7 m/min.
Spindle nose with short taper, outside 99,06 mm.
Spindle speeds in standardised steps 400 rpm.
Ø max gear 102 mm.
Engine Cooling Power 2 Cv.
Main motor power 10 Cv.
Motor power chip conveyor 0,25 Cv.
Power hydraulic motor 7,5 Cv.
Voltage 220/380 V.
ZSTTK 280 x 8 milling machine for shaping gears.
Produced by WMW - MODUL. 1961.
Min. Wheel diameter:
at a gear ratio of 1: 1 - 25mm
at a gear ratio of 1: 7.5 - 20mm
Max. Diameter of a circle:
at a gear ratio of 1: 1 - 200mm
at a gear ratio of 1: 7.5 - 280mm
Max. workpiece cone length: 143mm
Max. gear ratio: 1: 7.5
Max. module: 8
Max. tooth length: 70mm
Max. slider stroke: 80mm
Number of strokes per 1 minute: 60 - 300
in steps 8
The number of revolutions of the propeller shaft per minute: ... more
