Used Eht Tss 6-31 for sale (54)

Condition: used, Year of construction: 1985, machine/vehicle number: 101018, Lg.no. 24242 Technical data: Podpfx Ajtqmzcodyerc - max. cutting width 3050 mm - max. cutting capacity at 45 Kp/mm² 6 mm - Cutting angle adjustment 1 - 2.20 ° - Cutting gap - adjustment via lateral adjustment lever - Number of hold-down devices 16 pcs - Stroke rate up to 22 /min - Front angle stop 1100 mm - 2 front support arms 600 mm - mot. Back gauge with ELGO positioning control - 5 - 1000 mm - cutting line lighting - E - foot switch - Drive 400 V / 12 kW - Space requirement approx. W 4100 x H 1500 x D 2200 mm - Weight approx. 5.0 t

Condition: used, Year of construction: 1985, sheet width 3100 mm plate thickness 4.0 mm thickness at "Niro-steel" 2.5 mm cutting angle adjustment 1.0 ° back stop - adjustable 10 - 1000 mm Psdpexab Tvjfx Adyorc adjustment speed 180 mm/s down holder 21 Stück strokes per minute 18 - 31 oil volume 160 L Control ELGO P8511 column arm 200 mm distance between columns 3050 mm 0 max. 300 bar voltage 400 V main drive 9.0 kW weight of the machine ca. 4800 kg. dimensions of the machine ca. 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear "swing cut" - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left * for positioning the electro-motoric rear stop * target/actual position value input possible * adjustment by three-phase motor via toothed belt - support table with ball rollers * there are recessed grips between the table plates - front finger guard - hydraulically acting sheet metal hold-down device - 1x freely movable foot switch - emergency stop button at the front - movable scrap switch - original operating instructions + circuit diagram Special accessories included: - EHT pneumatic sheet metal holding device for thin sheet metal cuts - 1x EHT extra long side stop 3.000 mm with mm scale & support foot - 1x EHT extra long support arm with 3.000 mm with scale & Support foot - EHT additional support arms with mm scale

Year of construction: 1987, condition: ready for operation (used), An EHT hydraulic guillotine shear refurbished in 2023 is available. Cutting length: 3000mm, max. sheet thickness steel/VA: 4mm/2mm, backgauge: 10mm-1000mm, adjustment speed: 180mm/s, stroke rate: 18-31 strokes/min, oil volume: 160l. Machine dimensions X/Y/Z: approx. 3700mm/2100mm/2150mm, weight: approx. 4800kg, operating hours: 44024h. The cylinders, blades and hoses were overhauled in 2023. On-site inspection is possible. Podpfx Aewrhwujdyorc

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1997, operating hours: 4,125 h, working width: 3,050 mm, sheet thickness (max.): 13 mm, back gauge: 1,000 mm, TECHNICAL DETAILS Sheet width: 3,050 mm Sheet thickness: 13 mm Back gauge – electric: 10–1,000 mm Strokes: 16 strokes/min Control: Elgo MACHINE DETAILS Total power requirement: 22 kW Operating hours: approx. 4,124 h EQUIPMENT - Automatic cutting gap adjustment - Sheet lifting device Podpfx Ajww E Nxodyorc - Foot switch - Digital back gauge 1,000 Elgo - Scrap chute - Rear safety guards - Angle stop - Material support arms

Condition: excellent (used), Year of construction: 2001, sheet thickness steel (max.): 6 mm, cutting length (max.): 3,050 mm, Equipment: finger protection, Hydraulic guillotine shear Manufacturer EHT Type. TSS 6-30 Year of manufacture 2001 Technical data Make: EHT Type: TSS 6 - 30 Year of manufacture: 2001 Usable length: 3050 mm Sheet thickness: 6 mm Motor: 11 kW Oil quantity 250 L Dimensions: L 3.70 x W 2.15 (plus stop arms 1m, plus grid 0.6m) x H 2.15 m Weight: approx. 8 t Psdpfxevkd Eto Adyorc Equipment • Angle stop • 3 support arms • Controlled rear stop 10-1000mm • Control Elgo P8721 • Pneumatic holding device with scrap chute • Cutting edge lighting • Rear area protection via light barrier • Cutting length adjustment All information without guarantee. A demonstration is possible at any time in our exhibition hall.

Year of construction: 1998, condition: good (used), functionality: fully functional, machine/vehicle number: 107856, new seals on hydraulic cylinders TECHNICAL DETAILS material length: 6050 mm sheet thickness: 6 mm (450 N/qmm) passage: 6050 mm upright projection: 100 mm Control system: ELGO P8721 number of support arms: 4 Podpfel N Ufyox Adysrc stop range (from cutting line): 10 - 1000 mm Adjustment speed: 70 mm/s MACHINE DETAILS machine length: 7000 mm machine width (without support arms): 2350 mm machine width with supporting arms: 3440 mm machine height: 2550 mm Machine weight: 21000 kg Oil tank. 300 l Connected load: 18 kW Material: aluminum 1,2 mm EQUIPMENT motorized backgauge 1 side stop sheet holding-up system

Condition: used, Year of construction: 2003, Max. cutting length: 6075 mm Max. sheet thickness: 4 mm steel Controlled back stop up to 1000 mm Light barrier Sheet metal holding Few operating hours Pjdpfstuna Esx Adysrc Machine is loaded free

Condition: used, Year of construction: 1998, sheet width 3050 mm plate thickness 10.0 mm thickness at "Niro-steel" 6.0 - 8.0 mm down holder 13 Stück distance between columns 3070 mm cutting angle 1.0 - 4.0 ° no. of strokes ~ 22 Hub/min Control ELGO P8721 oil volume 240 l voltage 400 V total power requirement 17.0 kW weight 8000 kg range L-W-H 3550 x 2350 x 1900 mm Good / well-maintained condition With special accessories (!!) Equipment: - NC electro-hydraulic guillotine shear "Sliding Guided" - Heavy-duty / stable welded construction (machine body) - NC ELGO digital control unit "P8721" - NC electro-motorized backgauge on recirculating ball screws - Electro-hydraulic cutting angle adjustment * Front analog cutting angle display - 1x stable side stop, with T-slot and mm scale - 3x stable support arms, with T-slot and mm scale - Ball transfer units in the work table including recessed grips - Front finger guard - foldable at the front Pedpfx Adexacixeyjrc - 1x freely movable foot switch - 2x emergency stop buttons at the front - Operating instructions (PDF) Special accessories included: - Pneumatic sheet holding device for thin sheet metal blanks * Movable - on casters - 1x used Set of scissor blades

Condition: excellent (used), functionality: fully functional, Year of construction: 1994, EHT hydraulic guillotine shear type TSS 3-40, working width 4100 mm, max. sheet thickness 3.0 mm, pneumatic sheet support device, NC controlled backgauge, support arms, extra set of blades. Prjdpfx Aew Uf Nrjdyjc

Condition: used, Year of construction: 1971, sheet width 2000 mm Podpfx Ajww Nccjdysrc plate thickness 16 bei St 42 mm passage width 2250 mm impact length 1000 mm blade length 2005 mm throat 600 mm cutting gap adjustment 0,05 - 0,95 mm cutting angle 1° 40' ° down holder 10 Stück back stop - adjustable 10 - 1000 mm table: 2500 x 700 table height over floor 800 mm quantity of oil 900 l weight of the machine ca. 10 t dimensions of the machine ca. 3 x 2,3 x 2,3 m voltage 380 V Food switch, material support beams, spare knifes.

Condition: used, Year of construction: 1994, sheet width / mm plate thickness / mm distance between columns / mm Manufacturer: EHT Type: TSS 20-25 Year of construction: 1994 Max. Cutting length: 2250 mm Max. Sheet thickness: 20 mm Strip width min / max: 10/1000 mm Distance between the consoles: 2530 Height above the ground: 900 mm Table length without extension arms: 3030 mm Oil volume: 800 l Max. Pressure: 280 bar Operating voltage: 400V Control voltage: 230 V. Nominal current: 87 A. Weight: 15.8 to Dimensions L x W x H: 3500 x 2500 x 2400 mm Prodeuddh Ajpfx Adysc Accessories / special equipment Pneumatic cutting gap adjustment Cutting length limitation Roller conveyor elevation bracket Hand protection 1 bay Multitron control Multitron PS 80; ELCO 85 P Lower knife height adjustment

Condition: good (used), Year of construction: 1999, cutting width: 6.050 mm cutting thickness: max. 4 mm length stop range: 10 - 1.000 mm Prodpfswzvntex Adyoc

Condition: not inspected (used), Year of construction: 1992, Plate shears make: EHT, type: TSS 4 - 40, SN: 105129, year of manufacture: 1992, working range: 4,000 x 4 mm, digital display, Note: Machine already professionally dismantled and ready for transport Predsv Duicspfx Adysc

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1993, bending force (max.): 150 t, stroke length: 700 mm, throat depth: 350 mm, distance between stands: 3,050 mm, working length: 3,550 mm, The control system was retrofitted in 2011! TECHNICAL DETAILS Press force: 150 t Bending length: 3,550 mm Distance between uprights: 3,050 mm Stroke: 700 mm Throat depth: 350 mm MACHINE DETAILS Control: Cybelec DNC 880S Dimensions & Weight Dimensions (L x W x H): 4,400 × 2,200 × 3,940 mm Machine weight: approx. 15,000 kg EQUIPMENT Bending aid in front of the machine Parking space for bending aid 3 backgauge fingers Prsdpfx Asxn Srxodysc

Year of construction: 1987, condition: used, fabric-no. 202 395 working length 2550 mm Pedpfxjq Awh Re Adyjrc output 2000 KN tracking travel 13 mm safety distance 176 mm

Condition: good (used), Year of construction: 2000, Punching press Manufacturer: EHT Model: Strippit 1500/30 Year of manufacture: 2000 CNC control: Fanuc Working area without repositioning: 2500 x 1500 mm Max. material thickness: 8 mm Punching force: 30 t Turret with 46 tool stations, including 4 index stations size D 3 programmable clamps Metal table Used exclusively in single-shift operation Prsdpfjul S Eajx Adyjc Including WILSON TOOL tooling

Condition: ready for operation (used), Year of construction: 1999, pressure 175 t chamfer lenght 3550 mm distance between columns 3050 mm column arm 300 mm ajustment speed 140 mm/sec work speed 9.0 mm/sec return speed 130 mm/sec work stroke 360 mm dayligth 320 - 680 mm table height 1000 mm table width 200 mm oil volume 300 ltr. operating pressure max. 293 bar air pressure 4.5 - 6.0 bar Number of working hours ca. 37.000 h voltage 400 Volt total power requirement 23.0 kW weight 15400 kg range L-W-H 6350 x 2400 x 3250 mm Equipment: - Electro-hydraulic CNC press brake/bending machine - CNC-controlled axes: * Y1 + Y2 + X + R + I + crowning + AK 1 - CYBELEC CNC control "ModEva 10S", pivoting at the front right Pedpfxoxnqwys Adyjrc * High-resolution graphic color screen * Product display as line, area, or volume drawing * Clear, user-friendly menus in the operator's language * Extensive tool and product library - CNC-controlled backgauge adjustment (X-axis) * Stop range X-axis from bending line .. 5.0 - 1,000 mm * Adjustment speed .. max. 250 mm/sec. * With 4 manually adjustable stop fingers - CNC-controlled vertical adjustment of the stop fingers (R axis) * Table surface adjustment range: 105 - 255 mm * Adjustment speed: max. 100 mm/sec. * Adjustment via servo motors - CNC electro-motorized table crowning - CNC pneumatic die adjustment (I axis) * Adjustment of 7 die positions - Pneumatic EHT upper tool clamping - Pneumatic EHT lower tool clamping - 2x freely movable 2-hand/foot controls - 1x CNC front bending aid (disassembled - AK1 axis) - 1x CNC front bending aid (disassembled and defective) - Front guard (SICK "V4000") * Including adjustment templates - Rear guard (swinging door) - Side guard (swinging doors) - Original operating manual (machine + control) Special accessories included: - 1x EHT bending tool set * 1x EHT split + offset upper tool * 1x EHT split 2V die (V32 + V40)

Condition: ready for operation (used), Year of construction: 1964, working width: 3,050 mm, sheet thickness (max.): 10 mm, total length: 4,250 mm, total width: 2,800 mm, total height: 1,800 mm, Working width: 3050 mm Sheet thickness: 10 mm Equipped with infeed table 2500x2000 mm Prjdpexrculefx Adyoc

Condition: good (used), Year of construction: 2008, Machine no.: B0623A0001, cutting length 6,050 mm, cutting thickness 4 mm, back gauge 1,000 mm, net weight 20,900 kg, 15 kW, control system, manufacturer Elgo Electric, model P8721, 7 supports Predpsxl Du Tefx Adyjc

Condition: good (used), Year of construction: 1990, Pressure 320 t folding length 8050 mm column width 7550 mm Control Cybelec ModEva 12S Prjdpshwib Tefx Adyec Equipment/accessories: - CNC-controlled backgauge x-direction and R-direction - motorized die shift M1 and M2 - 2 x pneumatic bending aids in front - pneumatic sheet holding unit - automatic die clamping at the top - motorized crowning rebuild 2009: - motorized die shift 111-112 mechanical and electrical NEW - backgauge X-R mechanical and electrical NEW - Punch clamping automatic mechanical and electrical NEW - CNC control mechanical and electrical NEW - Safety valves NEW - Measuring rulers NEW - Control valves Y1 - Y2 NEW - Main pump hydraulics NEW

Condition: good (used), Year of construction: 2006, machine/vehicle number: B0617A0014, Offer 25376 Technical Data: - Max. cutting width: 3050 mm - Max. cutting capacity at 45 Kp/mm²: 13 mm - Hydraulic cutting angle adjustment - Number of hold-downs: 13 pcs - Front angle gauge - 4 front support arms Prsdjxp Hp Uepfx Adyec - Motor-driven, position-controlled backgauge: 10 - 1000 mm - Cutting line illumination - Rear area safety with side grids and light barrier - Electric foot switch - Drive: 400 V / 20 kW - Required floor space approx.: W 4350 x H 2100 x D 2200 mm - Weight approx.: 8.5 t

Condition: used, Year of construction: 1998, pressure 175 t chamfer lenght 4050 mm distance between columns 3050 mm throat 300 mm stroke 240 mm stroke speed - idle stroke downwards max. 140 mm/sec working feed max. 9 mm/sec stroke speed -return max. 130 mm/sec distance between table / ram min. 370 - max. 610 mm control CYBELEC DNC 880S total power requirement 15 kW weight of the machine ca. 15 t dimensions of the machine ca. 5,89 x 3,6 x 3,16 m - controlled axes: Y1, Y2, X, R - crowning - Bending aid - Control CYBELEC DNC 880S - swiveling operation, front right - 4x stop fingers manually adjustable - foot switch - 1 set of upper tools Prsdpfjtv Rh Ajx Adysc - 1 set of lower tool - 2x material support arms in front - side + rear protection - Operation manual

Condition: used, functionality: fully functional, Year of construction: 2002, Press force: 135 t Bending length: 3050 mm Distance between uprights: 2550 mm Stroke: 400 mm Oil volume: 300 l Control: CYBELEC DNC 1200 PS Eco Prsdpsxfh R Ejfx Adyoc Total power requirement: 15 kW Machine weight approx.: 10,700 kg Dimensions (LxWxH): 4200x2200x3200 mm Accessories/Equipment: – 2 bending aids in front of the machine – Parking right/left for bending aids – 3 backgauge fingers – CYBELEC DNC 1200 PS Eco control

Condition: new, functionality: fully functional, Year of construction: 2004, Pressing force: 225 t Bending length: 3050 mm Distance between uprights: 2550 mm Control type: DNC 1200PS Eco/Col Podpfx Ajxb Tftedyorc Ram stroke: 700 mm Throat depth: 405 mm Distance table/ram: min. 320 / max. 1020 mm Total power requirement: 29.5 kW Machine weight approx.: 15,500 kg Accessories/Equipment: Rear gauge Backgauge traverse adjustment: - X-axis gauging range (from bending line): 5–1000 mm - X-axis adjustment speed: max. 500 mm/sec Height adjustment: - R-axis adjustment range (from table surface): 85–235 mm - R-axis adjustment speed: max. 150 mm/sec Backgauge finger adjustment: - Z1-axis adjustment range (from left table front): 520–2365 mm - Z1-axis adjustment speed: max. 1000 mm/sec - Z2-axis adjustment range (from left table front): 690–2535 mm - Z2-axis adjustment speed: max. 1000 mm/sec - X1-axis adjustment range (from center line): ± 125 mm - X1-axis adjustment speed: max. 250 mm/sec Die shifting – adjustment via rear gauge (MVX): - Adjustment range: max. 100 mm - Adjustment speed as per X-axis: 500 mm/sec Front support/press brake aides: - Swivel angle BV1/BV2-axis: 55° - Swivel speed BV1/BV2-axis: max. 45°/sec - Lifting force per swivel arm BV1/BV2-axis: max. 1,500 N

Condition: good (used), functionality: fully functional, Year of construction: 1999, Press force: 175 t Bending length: 3050 mm Frame gap: 2550 mm Oil capacity: 300 l Control: Cybelec Total power requirement: 15 kW Accessories/Equipment: - 2 support arms in front of the machine - 2 support arms - pneumatic tool clamping - crowning - controlled axes: y1, y2, x, R - 2 manually adjustable backgauge fingers - two-hand foot operation Predoxb Sgvjpfx Adyec - Cybelec DNC 800 control - side safety doors
