Condition: ready for operation (used), chuck outer diameter: 1,200 mm, controller model: E.C.S CNC 1402, empty load weight: 17,000 kg, 5000 kg maximaal op tafel KM 50 gereedschappen Max turningdia -- passage: 1400 mm Power on the spindle: 60 kW Max longitudinal travel X-axis: 2700 mm Max hight of workpiece Z-axis: 750 mm Number of speeds: 2-430 rpm - max 450 Nm Power needed: 3 x 380 V Nedpfoxqh R Njx Agzelh TOOLING: yes Turret: yes Qty Tools: 24 Coolant pump: yes Light: yes

Condition: ready for operation (used), turning length 500 mm turning diameter over bed 297 mm Nljdpfxoxq Hh Ho Agzsh turning diameter over slide rest 160 mm spindle bore 36.0 mm tool adaptor DIN 55022 Gr. 5 quill: 3 MK quill travel 90.0 mm turning speeds 30 - 3550 U/min motor speeds: 1410 / 2830 U/min total power requirement 3.3 kW voltage 380 V weight of the machine ca. 620 kg. range L-W-H 1420 x 700 x 1200 mm from a vocational school - in very good condition (!!) particularly suitable for medium-precision turned parts Features: - Robust lead/feed screw lathe - RÖHM three-jaw chuck Ø 160 mm - Foldable lathe chuck guard - Chuck key - MULTIFIX steel holder A, with 3x new inserts - Movable tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - 1x empty tool cabinet - Emergency stop button - Operating instructions

Condition: new, The LabTurn 2028 CNC, part of the CNC Slant Bed Lathes category and 2-axis CNC Lathes group, is designed for both CNC training and the efficient production of small workpieces. This compact and mobile lathe combines the functionality of larger production machines with a robust cast-iron inclined bed design, ensuring excellent stability for precise machining. The machine features an 8-station tool turret with four tools each for inside and outside turning and a max spindle speed of 3000 rpm, enabling versatility in various applications. Additionally, the Siemens 808D Advance controller provides an intuitive interface for beginners. The LabTurn includes a 100 mm 3-jaw chuck, hydraulic tailstock, and a well-structured design with an enclosed workspace for safety. Enhance your machining capabilities with the LabTurn and experience the potential for high precision and performance. Request a quote today to explore this superior CNC Slant Bed Lathe. Nlsdpfx Agouy Iclezsh

Condition: used, Year of construction: 2015, turning diameter 210 mm turning length 1000 mm control Fanuc 31i max. turning speeds 5.000 min/-1 drive capacity - main spindle 15 kW max. torque 476 Nm Nlodpfx Asxq R Evsgzoh bar passage 65 mm x-axis 250 mm z-axis 1050 mm x2-axis 150 mm z2-axis 1030 mm spindle hours ca. 700 h accessories: Lünette, Späneförderer In our opinion, the machine is in very good used condition and can be inspected under power by appointment. Technical details: - approx. 500 spindle hours Accessories: - Steady rest - Chip conveyor Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and information as well as prior sale!

Condition: used, Year of construction: 2005, operating hours: 23,000 h, total length: 5,000 mm, Price: On request - Drive system: CNC - Control system brand: Fanuc - Control system type: 16i-T - Power [kW]: 15.0 - Swing over bed [mm]: 450 - Distance between centres [mm]: 500 - Spindle bore [mm]: 70 - Max. spindle speed [rpm]: 3500 - Year: 2005 - Documentation available: Yes - CE marking present: Yes - Operating hours: 23000 Nlsdpjxqnq Njfx Agzsh Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: new, Year of construction: 2019, machine/vehicle number: G3171-0100, This machine is only available to customers in the United Kingdom & Republic of Ireland HEAVY DUTY 3-AXIS SLANT BED, EXTRA LENGTH CNC TURNING CENTRE WITH C-AXIS & DRIVEN TOOLS, HARDENED & GROUND BOX GUIDEWAYS, BMT65 TURRET & 10" STANDARD CHUCK SIZE MACHINE CAPACITIES Swing Over the Bed - Ø 750 MM Swing Over the Carriage - Ø 480 MM Maximum Turning Diameter - Ø 410 MM Maximum Turning Length - 1,280 MM Bar Capacity - Ø 76 MM SPINDLE Chuck Size - Ø (10”) 254 MM Spindle Bore - Ø 95 MM Spindle Speed (Rpm) - 3,500 RPM Motor (Max / Cont.) - 22.0 / 18.5 KW Torque (Max / Cont.) - 493.2 / 414.7 NM Spindle Type - BELT Spindle Nose - A2-8 C-Axis Indexing - 360° (0.001°) FEED Travel X - 290 MM Travel Z - 1,350 MM Rapid Speed (X) - 20 M / MIN Rapid Speed (Z) - 24 M / MIN Slide Type - HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools - 12 Tool Size (OD) - Ø 25 MM² Tool Size (ID) - Ø 50 MM² Indexing Time - 0.3 SEC / STEP LIVE TOOL Motor (Max / Cont.) - 5.5 / 3.7 KW Milling Tool Speed - 4,000 RPM Torque (Max / Cont.) - 35.0 / 23.5 NM Collet Size - Ø 20 – ER 32 Type - BMT65P TAILSTOCK Taper - MT 5 Quill Diameter - Ø 100 MM Quill Travel - 120 MM Travel - 750 MM TANK CAPACITY Coolant Tank - 270 L Nlsdpfx Ashtq Absgzsh Lubricating Tank - 1.8 L POWER SUPPLY Electric Power Supply - 27 KVA Thickness of Power Cable - OVER 35 MM² Voltage 415 V / 50 HZ / 3PH MACHINE Floor Space (L x W) 4,171 X 2,002 MM Height 1,997 MM Weight 7,700 KGS FANUC 0IT CNC

Condition: ready for operation (used), chuck outer diameter: 1,600 mm, controller model: E.C.S CNC 2600, Mario Carnaghi TG10/1600 - Ø 1700 mm CNC Max turningdia -- passage: 1700 mm Power on the spindle: 36.7 kW Max longitudinal travel X-axis: 1965 mm Max hight of workpiece Z-axis: 750 mm Number of speeds: 3.5 - 300 rpm TOOLING: yes Turret: yes Qty Tools: 24 Nledpfexqh R Ajx Agzeh Coolant pump: yes Light: yes

Condition: ready for operation (used), turning length 500 mm turning diameter over bed 297 mm turning diameter over slide rest 160 mm spindle bore 36.0 mm tool adaptor DIN 55022 Gr. 5 quill: 3 MK quill travel 90.0 mm turning speeds 30 - 3550 U/min motor speeds: 1410 / 2830 U/min total power requirement 3.3 kW voltage 380 V weight of the machine ca. 620 kg. range L-W-H 1420 x 700 x 1200 mm from a vocational school - in very good condition (!!) particularly suitable for medium-precision turned parts Features: - Robust lead/feed screw lathe - RÖHM three-jaw chuck Ø 160 mm - Foldable lathe chuck guard - Chuck key - MULTIFIX steel holder A, with 3x new inserts - Movable tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - 1x empty tool cabinet Nedpoxq Hhyjfx Agzslh - Emergency stop button - Operating instructions

Condition: like new (used), Year of construction: 2023, functionality: fully functional, turning diameter over cross slide: 230 mm, turning length: 1,000 mm, SPECIAL OFFER MACHINE – INVENTORY SALE Nedpfxexqw D So Agzslh Chevalier FCL-1840H with Siemens 828D control system incl. ShopTurn Used machine, year of manufacture 2023 Machine equipment: • 3-stage automatic gearbox • Movable control arm / swiveling operating panel with 10.4'' screen • Automatic central lubrication • Coolant system with reinforced coolant pump • Thread repair cycle (thread recutting function) • Tool system: Parat RD2 with internal coolant supply • Clamping device: SMW 3-jaw wedge bar chuck, diameter 210mm Features: • Siemens 828D control incl. "ShopTurn" conversational programming system and 3D simulation • Fixed steady rest 20 - 160mm / travelling steady rest 10 - 90mm • Movable control arm (along the entire centre distance) • Manual tailstock with MK5 quill • Stable, double prism guideways • Max. torque 2,750 Nm PRICE NON-NEGOTIABLE! SALE EX WORKS BOCHUM! SALE WITHOUT WARRANTY! PRICE INCL. TRANSPORT TO CURBSIDE AND COMMISSIONING (within Germany): €49,000 NET

Condition: used, Year of construction: 2015, swing diameter 420 mm chucking diameter 400 mm x-travel 900 mm z-travel 495 mm Nledswqr S Topfx Agzsh spindle tunring speed 3.100 U/min number of tool places 12 Pos. In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and information as well as prior sale!

Condition: good (used), Year of construction: 2008, Control: FANUC Series 18i-TB Max bar diameter: 65 mm Max length: 250 mm Max turning diameter main spindle: 520 mm Max speed main and sub spindle: 4,000 rpm C-axis 2 turrets, each with 12 stations All stations are driven Nsdpoxq D Hmsfx Agzelh Driven tool speed: 4,000 rpm Chip conveyor Bar loader TOP-Automazione XF365

Condition: excellent (used), Year of construction: 2010, Used Hankook model 7NB x 4000 2 axis CNC lathe Year 2010, serial number 41L09117 Manufacturer Hankook Country of Origin South Korea Model Protec 7NB x 4000 mm Machine Type Description 2 Axis CNC flat bed turning Centre CNC Control Fanuc 21- iT with MG-i MACHINE CONSTRUCTION & FEATURES  Heavy Cast iron Construction  Heavy Duty Hardened & Ground Solid Slideways  Large Spindle Bore  Full Length Rear Chip Guard  Automatic Lubrication to All Critical Areas MACHINE CAPACITIES Swing Over Bed Ø 750 mm Swing Over Carriage Ø 480 mm Max. Turning Dia. Ø 750 mm Distance Between Centres 4,000 mm Load Capacity 3,000 Kg SPINDLE Spindle Bore Ø 176 mm Nose A2-11 Spindle Centre Taper MT #6 Spindle Speed 3 – 1,000 RPM Spindle Speed Range Manual 2 Step AUTOMATIC V8 TURRET Number of Tools 8 Holder Diameter Ø 60 mm Mechanism Electric FEEDS Rapid Traverse X 3 m/min Z 6 m/min Travel X 425 mm Z 2070 mm TAILSTOCK Taper/Diameter MT #6 Quill Diameter Ø 112 mm Max. Quill Travel 200 mm MOTORS Spindle 15/18 Kw X - Axis 1.2 Kw Z - Axis 3 Kw WEIGHT Weight 5,520 Kgs STANDARD MACHINE FEATURES • CNC System • Single Front Door • Coolant System • Foundation Bolts and Liners • Work Light • Work Light • Centre Sleeve MT #6 x Taper 1/10 • Tool Box • Centre MT #6 • Full Length Rear Guard • Live Centre MT #6 STANDARD FITTED MACHINE OPTIONS • Fanuc 21-iT • Transformer for 415V, 3Ph, 50Hz HANKOOK 7NB x 4000mm with Fanuc 21-iTB Modified guarding for long boring bars 20” Chuck Steady rest 50 - 250mm Steady rest 250 - 450mm Algra Automatic 8 station Turret Boring Bar attachment 100mm diameter Nljdjv Rqftspfx Agzeh 60mm diameter boring bar toolholder (1 off) Inch Metric conversion Custom Macro B Additional Block Skip G Code System B/C Programmable Data Input Actual Spindle Speed Output tool offsets 32 Pairs Extended Part Program Edit Manual Guide i External i/o device control External data Input High Skip ADDITIONAL ACCESSORIES INCLUDED • Special Revolving Centre (TBC) • Marposs TT30 Removable Tool setting Arm • Short LNS swarf conveyor and coolant / swarf trays • Sandvik damped/tuned boring bar of size 100mm dia x 1500mm length supplied with the boring attachment. • Filtermist filtration • Additional door guarding.

Condition: ready for operation (used), Type: TVM 450/5 Uitzonderlijke frees- en draaibank voor verticale bewerking die zeer grote werkstukken kan bewerken. Zowel de binnen- als de buitendiameter van de werkstukken kunnen worden bewerkt! De machine bestaat uit een vaste buitenkolom en een beweegbare binnenkolom. Draaitafel: buitendiameter: 6300 mm binnendiameter: 3000 mm grootste diameter van het werkstuk: 9800 mm kleinste diameter van het werkstuk: 2220 mm maximaal gewicht op tafel: 300 ton rotatiesnelheid: 0,08 27 tpm rotatiesnelheid bij draaien/frezen: ,4 tpm Vaste externe kolom: ramafmetingen: 550 x 550 mm diameter van de spindel: 304,8 mm ISO 60 - 37 kW op spindel maximale hoogte van uitwendig draaien/frezen: 8700 mm min. hoogte van uitwendig draaien/frezen: 700 mm verticale slag: 8000 mm horizontale slag: 2030 mm Beweegbare binnenkolom: RAM-formaat: 280 x 280 mm max. diameter van inwendig draaien/frezen: 5180 mm min. diameter van inwendig draaien/frezen: 3048 mm max. hoogte van inwendig draaien/frezen: 5800 mm min. hoogte van inwendig draaien/frezen: 615 mm verticale slag: 5800 mm Nsdpfx Asxqh Stogzjlh horizontale slag: 1120 mm Spiltoerentallen: 1,2 601 tpm Totaal vermogen: 250 kW 5-assige CNC-besturing

Condition: used, turning diameter 210 mm turning length 1000 mm swing diameter over bed slide 435 mm centre height 210 mm greates pass round over bed 435 mm spindle head DIN 55027 / DIN ISO 702-3 spindle bore 52 mm turning speeds 44 - 2.000 U/min transmission ratio 12 feed per revolution 0,036 - 2 U/mm Nledpfx Aexqrdyogzjh diameter of quill 65 mm quill stroke 120 mm taper bore DIN 228 MK4 total power requirement 5,5 kW -Lead screw and feed screw cover -Brake for main spindle -Toolmaker precision according to DIN 8605 -High drive power and high torque on the main spindle -Large thread cutting range -Convenient operation -Digital position display (HEIDENHAIN ND 7013) 3-axis display for bed, cross slide, and top slide Tool memory for 16 tools Tool memory with one reference point per axis Sum button for Z and Zo Inch/metric switchable Plane path X as radius or diameter display Display resolution up to 1 µ Taper calculator -LED machine light -Coolant device

Condition: like new (used), Year of construction: 2022, functionality: fully functional, turning diameter over cross slide: 230 mm, turning length: 1,000 mm, PROMOTIONAL MACHINE - INVENTORY SALE Chevalier FCL-1840H with Siemens 828D CNC including ShopTurn Used machine, year of manufacture: 2022 Machine Specifications: Nodpfx Aoxqw Aujgzolh • 3-stage automatic gearbox • Movable control arm / Swiveling control panel with 10.4'' screen • Automatic central lubrication • Coolant system with reinforced coolant pump • Thread repair cycle (thread re-cutting function) • Tool system: Parat RD2 with internal coolant supply • Workholding equipment: 3-jaw wedge bar chuck SMW, diameter 210 mm Performance Features: • Siemens 828D control system incl. dialog programming system "ShopTurn" and 3D simulation • Fixed steady rest 20 - 160 mm / follow rest 10 - 90 mm • Movable control arm (across the entire center distance) • Manual tailstock with MT5 quill • Robust, double prismatic guideways • Max. torque 2,750 Nm PRICE NOT NEGOTIABLE! EX WORKS BOCHUM! SALE WITHOUT WARRANTY! PRICE INCLUDING TRANSPORT (CURBSIDE DELIVERY) AND COMMISSIONING (within Germany): €49,000 NET

Condition: used, Year of construction: 2012, turning diameter 320 mm turning height 750 mm Control Siemens max. turning speeds 4500 min/-1 drive capacity - main spindle 26,8 / 20,9 kW max. torque 256 / 200 Nm spindle bore 52 mm spindle head KK A6 (DIN 55026) chucking diameter max. 315 mm number of tool places 8 Pos. tool taper Capto C5 max. workpiece diameter 50 mm max. workpiece weight 0,5 kg x-axis 450 mm z-axis 300 mm rapid traverse x 45 / z 40 m/min total power requirement 68,3 kW weight of the machine ca. 11,0 t dimensions of the machine ca. L 3,7/4,2 x B 1,6 x H 3,0 m In our opinion, the machine is in very good condition condition and can be inspected under power by appointment. Nsdjxq Hkzspfx Agzjlh Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: used, Control: Fagor Faceplate: 5420 mm Turning diameter: 6540 mm Nledpsvzqm Eofx Agzeh Max. turning height: 3500 mm Support (ram) stroke vertical: 1680 mm Support (ram) stroke horizontal: 3250 mm Workpiece weight: 60 tons Machine weight: 190 tons approx. Hydrostatic faceplate

Condition: excellent (used), Year of construction: 2014, USED HANKOOK VTC140E – YOM 2014 – Serial Number 44L09842 - TWW Cat 7962 MACHINE CONSTRUCTION & FEATURES • Ram Type Vertical Boring & Turning Machine with C-Axis & Driven Tools. • Heavy-Duty Cast-Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Hardened & Ground Slideways to Provide Increased Stability & Rigidity. • 2 Step Automatic Gear Change. • 24 Position Tool Magazine. INCLUDED FACTORY FITTED MACHINE OPTIONS • Chip Conveyor & Chip Bucket • 30 Bar Through Spindle Coolant System • Measurement System C-Axis Scale • Transformer • Hydraulic 3-Jaw & Manual 4-Jaw Combination Chuck With4 Manual Adjustable Jaw Bodies • Automatic Tool Setting Device TOOLING INCLUDED • DINE Tool-changeable Angular Milling Head with 40 ISO Output • 2 Off Sandvik Capto C6 Turning Toolholders with Two Outputs (V & H) • 1 Off Sandvik Capto C6 Axial Turning Head • 7 OFF BT50 Driven Toolholders • 1 Off Hankook TA12B4121015043 • 1 OFF Hankook TA12B412015142 • 1 Off Hankook TA12410000161 • 2 OFF Hankook TA12417010160 CAPACITY Maximum Turning Diameter - Ø 1,600 mm Maximum Turning Height - 1,400 mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,400 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step TABLE C-AXIS Minimum Index Angle - 0.001° C-Axis Cutting Feedrate - 0 ~ 1,200 Deg / Min Max. C-Axis Speed - 3.333 RPM RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220 x 220 mm MILLING SPINDLE Milling Spindle Speed - 30 ~ 3,000 RPM Max. Milling Spindle Torque - 235 Nm TRAVEL & FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,600 mm Z-Axis Travel (Ram Vertical) - 900 mm Maximum X / Z-Axis Cutting Feedrate - 7,500 mm / Min X / Z-Axis Rapid Feedrate - 7,500 mm / Min ATC Type of Tool Holder - MAS BT 50 Tool Magazine Capacity - 24 (12T & 12M) Max. Tool Weight - 50.0 KGS MOTOR Table Motor (Cont. / 30 Min) - AC 37.0 / 45.0 kW Milling Spindle Motor Power - 15.0 / 18.5 kW X / Z-Axis Servo Motor - AC 7.0 kW C-Axis Motor - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50HZ / 3PH Power Capacity - 80 KVA DIMENSIONS & WEIGHT Height - 5,535 mm External Width (With Chip Conveyor) - 6,760 mm External Depth - 4,565 mm Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES • Fanuc 32iA Control System • Through Tool Coolant • Table, Servo Drives & Motors • Through Spindle Coolant Nodpjrur Nmofx Agzelh • 4 Jaw Independent Manual Chuck • Splash Guard & Safety Guard Rail • Automatic Tool Change System • X-Axis Slideway Protect Steel Cover • Lubrication Oil Cooler • Work Light • Hydraulic Power Unit • Levelling Blocks • Patrol Lamp (Red, Yellow & Green) • Automatic Guideway Lubrication System • NC Power Off • Coolant System & Wash Gun • Chip Pan • Electrical & Mechanical Manuals

Condition: ready for operation (used), chuck outer diameter: 1,120 mm, total height: 4,100 mm, empty load weight: 16,500 kg, Type: Stanko 1512 Maximale werkstukhoogte: 1000 mm Verticale schuifmaat maximale horizontale verplaatsing: 775 mm maximale verticale verplaatsing: 700 mm Nlsdpfjxp Slbex Agzeh Horizontale schuifmaat maximale horizontale verplaatsing: 630 mm maximale verticale verplaatsing: 1000 mm Dwarsbalk maximale slag: 660 mm Max turningdia -- passage: 1250 mm Power on the spindle: 30 kW Number of speeds: 5 > 250 rpm Long: 2750 mm Wide: 2975 mm

Condition: good (used), Year of construction: 2001, movable headstock 10 axes Spindle speed 8,000 rpm C-axis TOOL CARRIER (X1-Y1 / X2-Y2) - 2 independent cross slides with 2x5 tools - Drive unit 8,000 rpm for up to 4 driven tools on X2-Y2 FRONT UNIT (X3-Z3) - Cross slide with 4 positions SUB-SPINDLE (X4-Y4-Z4) Nlsdpfx Agew Exk Sozeh - Speed 6,000 rpm - Slide with 3 independent axes SUB OPERATIONS - Holder with 7 positions (4 end and 3 cross) Workpiece feeder Coolant pump 20 bar KNOLL chip conveyor Bar feeder ROBOBAR 532, 3m bars

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm Nledpfx Aexnpp Ijgzsh SPINDLE MOTOR AC11kw (15HP) SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS SUB SPINDLE DRIVEN TOOLS (3 NO.S) PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER

Condition: good (used), Year of construction: 2018, functionality: fully functional, Technical details faceplate diameter 3500 mm swing diameter 3800 mm turning height 750 mm Control Siemens 840 D sl Additional information CNC vertical lathe with one turning spindle and two tool carriers on two cross slides The machine has been regularly serviced by the manufacturer and is in mint condition. Technical specifications: Max. swing diameter 3800 mm Max. working height 750 mm Slide travel X1 axis approx. 2800 mm Slide travel X2 axis approx. 3200 mm Slide travel Z axis 1000 mm Rapid traverse X/Z axis 32/20 m/min. Faceplate (turning spindle unit with motor spindle): Speed 100 rpm Torque 67,000 Nm at 40% duty cycle Drive power 200 kW at 100% duty cycle Load capacity (chuck, clamping jaws, and workpiece) 35,000 kg Tool carrier: Double tool holder, Capto C8 For internal and external machining Speed range up to 6000 rpm. Torque approx. 120 Nm at 100% duty cycle Direct coolant supply to the tool holders Double tool holder with swivel axis For turning and drilling (MFU) in conjunction with a tool magazine Equipment: CNC control Siemens 840 D sl Chuck Röhm lever chuck KFG 3500/3/6/12 25-station tool magazine, left of the work area 41-station tool magazine, right of the work area Max. tool diameter 150 mm Max. tool weight 20 kg Tool length 400 mm Tool cleaning with air Chip conveyor Nedpfx Agjxqn Nrezelh Coolant system 6 bar, 80 l/min. Knoll paper belt filter High-pressure coolant pump 70 bar

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Nsdpjxddvnefx Agzolh Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Faceplate diameter (removable): 1650 mm Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Special equipment Copying device for first support Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. 125 kg auxiliary crane on spindle box.

Condition: used, Year of construction: 2012, turning diameter 140 mm turning length 630 mm Nodpoxqrgzjfx Agzslh control Siemens 840 SL max. swing diameter over bed 250 mm turning speed range - main spindle 0 - 5000 min/-1 max. torque 256 Nm spindle bearing diameter 110 mm spindle bore 52 mm spindle head Gr. 6 DIN 55026 chucking diameter max. 250 mm number of tool places 3 x 12 Pos. tool taper VDI 40 max. tool weight 20 kg max. tool diameter 40 mm max. tool length 95 mm max. workpiece weight 20 kg max. workpiece diameter 140 mm x-travel 300 mm z-travel 740 mm rapid traverse x 45 / z 30 m/min total power requirement 70 kW weight of the machine ca. 25,0 t dimensions of the machine ca. 6,5 x 3,5 x 4,4 m In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical features: - Siemens S120 drive systems - 3x turret, all places AGW, 2x of them with y - axis - 2x main spindle, 1x with tailstock - Spindles total 5 pcs. - Tool monitoring, Artis - Total electronic axes: 21 pcs. Accesories: - chip conveyor - Radio probe, Renishaw - Cooling unit - Infeed and outfeed conveyor - suction There are 2 identical machines available. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: good (used), Year of construction: 2002, functionality: fully functional, spindle bore: 50 mm, turning diameter over bed slide: 340 mm, turning diameter over top slide: 170 mm, center height: 170 mm, turning length: 700 mm, spindle speed (max.): 2,350 rpm, Emcomat 17 S Spindle bore: 50 mm Turning diameter over bed: 340 mm Turning diameter over support: 170 mm Center distance: 700 mm Maximum 2350 rpm. Lathe features longitudinal and cross feeds. Digital two-axis position readout. Equipped with emergency stop and chuck guard. Year of manufacture: 2002 5.3 kW 400 V Nlodpfx Ajxp Hudjgzsh
